2. Mini DisplayPort Connector
Top Row
Pin Number
Signal Type
1
GND
3
5
7
GND
9
11
13
GND
15
17
19
GND
CONNECTION DIAGRAM
DVI
cable
Mac
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Pin Name
GND
Out
ML Lane 0 (p)
Out
ML Lane 0 (n)
GND
Out
ML Lane 1 (p)
Out
ML Lane 1 (n)
GND
Out
ML Lane 2 (p)
Out
ML Lane 2 (n)
GND
AT-DP200
USB
cable
Mac
Notebook
Mac Mini
PC
Bottom Row
Pin Number
Signal Type
2
In
4
CONFIG
6
CONFIG
8
GND
10
Out
12
Out
14
GND
16
I/O
18
I/O
20
PWR Out
Mini DisplayPort cable
5
Pin Name
Hot Plug Detect
CONFIG 1
CONFIG 2
GND
ML Lane 3 (p)
ML Lane 3 (n)
GND
AUX CH (p)
AUX CH (n)
DP_PWR
Apple LED Cinema display
www.atlona.com
