Follett 7CI100A Installation, Operation And Service Manual

Countertop and freestanding ice and water dispenser with chewblet ice machine
Hide thumbs Also See for 7CI100A:
Table of Contents

Advertisement

Quick Links

See also: Installation, Operation and Service Manual
Countertop and Freestanding Ice and Water
Dispenser with Chewblet
®

Ice Machine

7CI100A, 7FS100A
Installation, Operation and Service Manual
Serial numbers E01087 and above
7CI100A
7FS100A
Following installation, please forward this manual
to the appropriate operations person.
801 Church Lane • Easton, PA 18040, USA
Order parts online:
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
www.follettice.com
00951640R07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7CI100A and is the answer not in the manual?

Questions and answers

Related Manuals for Follett 7CI100A

Summary of Contents for Follett 7CI100A

  • Page 1: Ice Machine

    Countertop and Freestanding Ice and Water Dispenser with Chewblet ® Ice Machine 7CI100A, 7FS100A Installation, Operation and Service Manual Serial numbers E01087 and above 7CI100A 7FS100A Following installation, please forward this manual to the appropriate operations person. 801 Church Lane • Easton, PA 18040, USA Order parts online: Toll free (877) 612-5086 •...

  • Page 2: Table Of Contents

    Base Stand ................38 Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 3: Welcome

    Before You Begin ––––––––––––––––––––––––––––––––––––––––––––––––––– After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. If damage is found, immediately notify the shipper and contact Follett Corporation so that we can help in the fi ling of a claim, ❶...

  • Page 4: Specifi Cations

    17.53" (450 mm) 41.93" (1065 mm) Unit Shipping Weight 90 lb (41 kg) 120 lb (54.4 kg) Ambient Information CAUTION! The 7CI100A and 7FS100A are for indoor use only. Maximum* Minimum* Air Temperature † 100 F (38 C) 50 F (10 C) Water Temperature 90 F (32.2 C)

  • Page 5: Specifi Cations

     Must be grounded - requires 3-prong outlet. Do not remove ground. Refrigeration WARNING! Do not damage the refrigerant circuit. Refrigerant can cause personal injury and/or damage dispenser.  Refrigerant R134a – 7.2 ounces (204 grams) Heat Rejection  1700 BTU/hr (498 W) Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 6: Detailed Drawing

    14.55" (370 mm) NEMA 5-15 right angle 17.54" 17.54" (446 mm) (446 mm) 6.72" 6.79" (171 mm) (172 mm) power cord 2.40" 2.98" (61 mm) (76 mm) 1/4" MPT water inlet 24.39" (620 mm) 22.05" (560 mm) Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 7: Installation

    * If your dispenser has the internal water fi lter option, the water fi lter must be installed for the dispenser to operate. Because internal components will need to Plug be accessed for both procedures, Follett recommends installing the water fi lter just prior to initial sanitizing. Valve 5.

  • Page 8: Freestanding Installation

    8 ft. (2.4 m) cord and plug.  Water: supply line (with shut-off valve) connects to the dispenser's 1/4" MPT inlet. NOTICE! If installing optional Leg Accessory, complete those steps before proceeding. See page 10 for Leg Accessory instructions. Dispenser and Ice machine 7CI100A/7FS100A...
  • Page 9 * If your dispenser has the internal water fi lter option, the water fi lter must be installed for the dispenser to operate. Because internal components will need to Plug be accessed for both procedures, Follett recommends installing the water fi lter just prior to initial sanitizing. Valve Connect power supply.
  • Page 10 If your dispenser has the internal water fi lter option, the water fi lter must be installed for the dispenser to operate. Because internal components will need to be accessed for both procedures, Follett recommends installing the water fi lter just prior to initial sanitizing.

  • Page 11: Maintenance/Cleaning Mode

    5. Remove and set aside the front panel (Fig. 11.4) - do not disengage the plug on the back of the User Interface or the tubing at the water dispenser chute (if so equipped). Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 12: Filter Display Indicator Activation

    Filter Display Indicator Activation ––––––––––––––––––––––––––––––––––––– If you purchased your dispenser with a Follett fi lter, the fi lter display indicator Fig. 12 activation has been preset at the factory. If you are using an “after market fi lter,” an adjustment may be made to activate the “Fresh Filtered Ice &...

  • Page 13: Cleaning And Sanitizing

    8. Place a bucket under the dispense chute and remove cap. Note: Some sanitizing solution will remain and drain out when cap is removed. Reposition cap on bin lid spout. 9. Reinstall front panel, ice dispense chute, and drip tray. 10. Press and hold maintenance/clean switch to exit Maintenance Mode. Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 14: Service

    Auger gearmotor has exceeded 0.55A. The HI amps and Time delay LEDs will illuminate, the machine will shut down for one hour, the LEDs will turn off, and the machine will resume normal operation. Service 8000 hour bushing check (call Follett technical service group at (877) 612-5086 or +1 (610) 252-7301). Maintenance Yellow Enter Maintenance Mode by pressing and holding maintenance/clean switch for 5 seconds.

  • Page 15: Evaporator Disassembly

    User Interface. Lift and remove the top panel, set aside (Fig. 16.5). 8. Remove two screws (Fig. 16.6) and remove left side panel. 9. Remove two screws (Fig. 16.7) and remove right side panel. Dispenser and Ice machine 7CI100A/7FS100A...
  • Page 16  Pull gear motor from auger (Fig. 18.3).  Remove main housing insulation (Fig. 18.4). 13. Remove all traces of petro-gel from auger shaft. 14. Remove compression nozzle: Fig. 19  Loosen hose clamp (Fig. 19.1).  Remove transport tube (Fig. 19.2). Dispenser and Ice machine 7CI100A/7FS100A...
  • Page 17 15. Remove M6 socket head allen screw (Fig. 20.1). Fig. 20 16. Remove compression nozzle retainer (Fig. 20.2). 17. Remove compression nozzle (Fig. 20.3). 18. Remove main housing: Fig. 21  Disconnect vent line from T fi tting (Fig. 21.1). Dispenser and Ice machine 7CI100A/7FS100A...
  • Page 18 19. Remove three M6x25 socket head allen screws Fig. 22 (Fig. 22.1). 20. Remove main housing (Fig. 22.2). Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 19: Evaporator Assembly

    5. Install auger (Fig. 24.4). 6. Install main housing: Fig. 25  Slide main housing onto auger shaft (Fig. 25.1).  Install three M6x25 allen screws (Fig. 25.1).  Connect vent line to T fi tting (Fig. 25.1). Dispenser and Ice machine 7CI100A/7FS100A...
  • Page 20 Fig. 27 9. Tighten hose clamp (Fig. 27.2). 10. Install gear motor: Fig. 28  Install main housing insulation (Fig. 28.1).  Slide gear motor onto auger shaft (Fig. 28.2).  Install two M6x90 allen screws (Fig. 28.3). Dispenser and Ice machine 7CI100A/7FS100A...
  • Page 21 13. Install spacer, ensure that key is captured in slot Fig. 30 (Fig. 30.1) 14. Insert screwdriver into groove of auger shaft and pry shaft Fig. 31 outwards (Fig. 31.1). 15. Insert retainer into groove (Fig. 31.2), ensure that retainer is aligned with hole in spacer. Dispenser and Ice machine 7CI100A/7FS100A...
  • Page 22 16. Install screw and tighten (Fig. 32.1). Fig. 32 17. Plug in gear motor (Fig. 33). Fig. 33  BLUE to BLUE  BLACK to BLACK  WHITE to WHITE  Connect ground wire with ground screw. Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 23: Water Feed Schematic

    Service –––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Water Feed Schematic Evaporator Float Water Chute (optional) Water Solenoid Valve Filter (optional) (optional) Water Solenoid Valve Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 24: Bin Melt Water/Evaporator Feed/Clean Out System Schematic

    Service –––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Bin Melt Water/Evaporator Feed/Clean Out System Schematic Storage Bin Vent System Schematic Storage Bin Vent Tube Reservoir Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 25: Refrigeration Schematic

    Service –––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Refrigeration Schematic CONDENSER FILTER-DRIER CAP TUBE COMPRESSOR EVAPORATOR ACCUMULATOR LOW PRESSURE LIQUID HIGH PRESSURE VAPOR HIGH PRESSURE LIQUID LOW PRESSURE VAPOR Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 26: Condenser Fan Motor Removal

    Service –––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Condenser Fan Motor Removal Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 27: User Interface Display Identifi Cation

    Exit Maintenance Mode by pressing and holding maintenance/clean switch until no longer displays. Service - Call Follett Technical Service Group at 8000 hr (877) 612-5086 or +1 (610) 252-7301. bushing check The fl ashing wrench indicates that the 8000 hr bushing check is required.
  • Page 28 Internal leak in Locate leak and repair - Press reset dispenser on control board. Contact Follett if ice machine is leaking. Sleep mode Press either dispense button to return to normal operation. Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 29: Electrical Wiring Diagram

    Service –––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Electrical Wiring Diagram Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 30: Parts

    Parts ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Exterior Dispenser and Ice machine 7CI100A/7FS100A...
  • Page 31 Not Shown Fitting, Elbow - 1/4" FPT x 1/4" Tube 00974261 Not Shown Drip Tray Drain Kit 00956375 Not Shown Drip Tray Drain Kit with 4" legs 00981977 Not Shown Covers, Agion, User Interface 00969030 Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 32: Interior

    Parts –––––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Interior Dispenser and Ice machine 7CI100A/7FS100A...
  • Page 33 Valve, Failsafe Solenoid 00957738 Compressor with Mounting Hardware 00958009 Condenser 00958017 Condenser Fan and Cord 00958025 Control Board with Stand-offs 00958033 Capacitor, Gearmotor 00958041 Sensor, Retainer Hardware Kit 00958066 Relay and Overload 00958090 Refrigeration, Piping Assy 00958132 Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 34: Bin Assembly

    Parts –––––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Bin Assembly Dispenser and Ice machine 7CI100A/7FS100A...
  • Page 35 Lid, Bin Assy 00957779 Bin, Assy 00957787 Auger, Dispense 00957795 Motor, Dispense 00957803 Cap and Insulation, Bin 00957936 Not Shown For serial numbers D17619 and below: Bin Cap 00931519 Ice Chute 00927210 Chute Adapter 00926550 Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 36: Evaporator Assembly

    Parts –––––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Evaporator Assembly Dispenser and Ice machine 7CI100A/7FS100A...
  • Page 37 Part # Not Shown Water fi lter cartridge, 5 micron 00968107 Not Shown Cleaning and sanitizing kit, single use 00979856 Not Shown SafeClean, case of 24 00132001 Not Shown IMS II sanitizer concentrate, 16 oz 00979674 Dispenser and Ice machine 7CI100A/7FS100A...

  • Page 38: Base Stand

    Parts –––––––––––––––––––––––––––––––––––––––––––––––––––––– (continued) Base Stand Dispenser and Ice machine 7CI100A/7FS100A...
  • Page 39 Not Shown IMS II sanitizer concentrate, 16 oz 00979674 Not Shown 6" (15.24 cm) Legs for base stand, set of 4 00956318 Not Shown 4" (10.16 cm) Legs for countertop dispenser, set of 4 00956300 Dispenser and Ice machine 7CI100A/7FS100A...
  • Page 40 SafeCLEAN is a trademark of Follett Corporation. Follett is a registered trademark of Follett Corporation, registered in US. 801 Church Lane • Easton, PA 18040, USA 00951640R07 Toll free (877) 612-5086 • +1 (610) 252-7301 © Follet Corporation 8/13 www.follettice.com...
