You have purchased a product which uses the open source (http://opensource.org/) programs mtd, msdosfs, netfilter/iptables and initrd in
object code and other open source programs licensed under the GNU General Public License and Apache License.
We will provide you with a complete copy of the corresponding source codes upon request within a period of three years from the
distribution of the product by TCT.
You may download the source codes from http://sourceforge.net/projects/alcatel/files/. The provision of the source code is free of charge
from internet.
1
Advertisement
Table of Contents
Related Manuals for Alcatel One Touch Evo 7
Summary of Contents for Alcatel One Touch Evo 7
- Page 1 We will provide you with a complete copy of the corresponding source codes upon request within a period of three years from the distribution of the product by TCT. You may download the source codes from http://sourceforge.net/projects/alcatel/files/. The provision of the source code is free of charge from internet.
-
Page 2: Table Of Contents
Table of contents 1 Your device..........................................3 1.1 appearance illustration......................................3 1.2 home screen..........................................6 1.3 apps and widgets........................................8 1.4 basic operation........................................9 2 Settings.............................................13 2.1 Device.............................................13 2.2 Personal..........................................13 2.3 System.............................................14 This device meets applicable national SAR limits of 2.0 W/kg. The specific maximum SAR values can be found on page 19 of this user guide. -
Page 3: Your Device
Your device ..............Appearance illustration Camera Volume Up/Down Power Key Microphone Micro-USB Connector/ Battery charge Earphone Interface... - Page 4 (Optional) Removable Frame Slot for 3G Module (Alcatel onetouch EVO7 3G Module) SD Card Reset Alcatel onetouch EVO7 3G Module (Optional)
- Page 5 Inserting the SIM card Installing the 3G Module...
-
Page 6: Home Screen
Note Please charge before first use. Normally, long press the Power key will power the pad on and the Home Screen will show up, but a battery icon will show instead of the Home Screen when the pad is lack of power, that indicates you should charge before use. Use only charger recommended by TCT Mobile Limited and its affiliates. - Page 7 ● Icons on your screen Icon Name Description Google search Touch it to access the Google search engine. Voice actions Use Voice Actions to watch a video, send email, set alarm, get directions, etc. All apps Touch to show all apps list interface. Back Go back to the previous menu or screen.
-
Page 8: Apps And Widgets
On the right of the screen bottom, there is a notification bar . A hidden menu will popup when you press the bar, which includes time, date, network connection and battery information, etc. For further operation, you can press setting. Apps and widgets ●... -
Page 9: Basic Operation
● Remove apps icon from desktop Touch and hold the icon you want to delete from the desktop, drag it right over the " ", which appears right in the middle of the screen top. ● Uninstall apps Press to enter all Apps, then touch and hold the Apps icon you want to uninstall, drag it over the , which appeas top-left in the desktop. - Page 10 ● Reset your device When your device is out of function, 1. you can shut down it by pressing the reset key. (Referring to Page 4). 2. Long press the Power key about 10 seconds to shut down your device. Then press the Power key to restart.
- Page 11 ● Change your wallpaper You can change your wallpaper in two different ways: touch & hold any space on home screen, select a wallpaper source from Gallery, Live Wallpapers or Wallpapers, touch a picture, select OK at the top of the screen (for Gallery images) or Set wallpaper;...
- Page 12 ● Zoom in/out Draw your fingers together/apart to zoom in/out (Web broswer, Gallery ect...)
-
Page 13: Settings
Settings................Device 3.1.1 Sound You can set Volumes, Touch sounds and Screen lock sound to your preference with the Volume up/down key, or touch Settings\DEVICE\Sound. 3.1.2 Display Touch settings> DEVICE >Display, you can see the items: Brightness: adjust your screen in a comfortable brightness Wallpaper: set your wallpaper Auto-rotate screen: mark the checkbox, to enable or disable auto-rotation Sleep: set Screensavers time... -
Page 14: System
Touch Settings>PERSONAL>Language & input to view or set system language and input methods. Language: set the system language Keyboard & input methods: check and select all the input methods installed in the pad System 3.3.1 Date & time Touch Settings>SYSTEM>Date & time, to set date, time and format 3.3.2 About tablet Touch Settings>SYSTEM>About tablet to check legal information, tablet status and software version, etc. - Page 15 SATEFY INFORMATION............ We recommend that you read this chapter carefully before using your device. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein. ● TRAFFIC SAFETY Given that studies show that using a device while driving a vehicle constitutes a real risk, even when the hands-free kit is used (car kit, headset...), drivers are requested to refrain from using their device when the vehicle is not parked.
- Page 16 When the device is switched on, it should be kept at least 15 cm from any medical device such as a pacemaker, a hearing aid or insulin pump, etc. In particular when using the device, you should hold it against the ear on the opposite side to the device, if any. To avoid hearing impairment, move the handset away from your ear while using the “hands-free”...
- Page 17 Parents should monitor their children’s use of video games or other features that incorporate flashing lights on the device. All persons should discontinue use and consult a doctor if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation.
- Page 18 - This battery must be disposed of in accordance with locally applicable environment regulations. This symbol on your device, the battery and the accessories means that these products must be taken to collection points at the end of their life: - Municipal waste disposal centers with specific bins for these items of equipment.
- Page 19 THIS DEVICE MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO RADIO WAVES Your device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves (radio frequency electromagnetic fields) recommended by international guidelines. The guidelines were developed by an independent scientific organization (ICNIRP) and include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.
- Page 20 microSD Logo is a trademark. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such m arks by TCT Mobile Limited and its affiliates is under license. Other trademarks and trade names are those of their respective owners. ONETOUCH EVO7 Bluetooth QD ID B020132 TouchPal™...
- Page 21 General information • Internet address: www.alcatelonetouch.com • Hot Line Number: see “TCT Mobile Services” leaflet or go to our website. On our website, you will find our FAQ (Frequently Asked Questions) section. You can also contact us by e-mail to ask any questions you may have.
- Page 22 All third party materials in this handset are provided “ as is”, without warranty of any kind, whether express or implied, including the implied warranties of merchantability, fitness for a particular purpose or use/third party application, interoperability with other materials or applications of the purchaser and non-infringement of copyright.
- Page 23 Accessory Charger, 5.0V/2.0A Charger Plug USB cable, 5pins micro USB...
