  • Page 1 ® Coinmaster GT White’s Electronics, Inc. Sweet Home, Oregon USA Building the World’s Finest metal detectors for over 60 years.

  • Page 2: Table Of Contents

    Coinmaster GT Owner’s Manual CONTENTS Introduction........3 Assembly .

  • Page 3: Panel Indicators

    Tone ID mode Numeric VDI indicator and depth The Coinmaster GT (or CoinGT) is an easy-to-use metal detector with features and performance that rival more expen- sive models. The CoinGT has automatic ground tracking (Auto- ® Trac ) which maximizes performance across many different ground conditions.

  • Page 4: Assembly

    Coinmaster GT Owner’s Manual Assembly 1. Remove all parts from the shipping carton and check assem- bly diagram to ensure all parts are present. 2. Install black rubber washers on fiber clevis/lower rod, insert clevis lower rod onto loop ears. Use only nonmetallic wash- ers, fiber bolt, and fiber thumb nut to secure loop/search coil to clevis/lower fiber rod.

  • Page 5: Batteries

    Coinmaster GT Owner’s Manual 5. Grip the instrument by the handle, with your arm in the elbow cup with strap and sweep the loop/search coil over the floor. If the instrument fit feels uncomfortable, readjust clevis/lower rod length with spring clip button and cam- lock so that search coil can be held near the floor without stooping over.

  • Page 6: Quickstart

    Coinmaster GT Owner’s Manual shelf life. It is a good idea to carry back up batteries. 7. A rechargeable NiMH battery pack may be purchased sepa- rately. Rechargeable batteries typically provide similar or slightly less run time than alkaline batteries.

  • Page 7: Controls

    Coinmaster GT Owner’s Manual Controls ON/OFF Besides the obvious, the button also controls the ON/OFF display backlight. Press and hold the button to toggle the back- light. SENS control increases or decreases the respon- Sensitivity siveness of the CoinGT. Normally, this determines how deep the detector will “see”...

  • Page 8: Tone Id

    Coinmaster GT Owner’s Manual Use the circular arrow button to cycle the disc cursor through the 9 ranges, and press the disc select button toggle the selection of a particular range. The range is disabled when the symbol is displayed.

  • Page 9: Display

    Coinmaster GT Owner’s Manual like Disc mode, the All Metal mode requires that the coil be in motion in order to respond to a target. If the coil is held steady over a target it will get tuned out after a few seconds.

  • Page 10: More Info

    Coinmaster GT Owner’s Manual zone. Rejecting a zone only affects the audio; the display will still show target information even if you can’t hear an audible response. The CoinGT display includes a backlight for extended hunt- ing. Press and hold the button to toggle the backlight.

  • Page 11: Depth & Discrimination

    Coinmaster GT Owner’s Manual same responses as foil, nickels, and pull tabs. Likewise, pull tabs often look like nickels and vice-versa. Target ID is by no means foolproof and should be consid- ered only a probability estimate. As we’ll see in the next sec- tion, the probability decreases with depth.

  • Page 12: Overload

    Coinmaster GT Owner’s Manual Overload If the received signal is too large to process the CoinGT will give an overload response. This is heard as an obnoxious alarm sound, plus the display will read “OL”. An overload can be the result of a large metal target near the surface, or from extreme ground mineralization.

  • Page 13: Sizing, Pinpointing, & Digging

    Coinmaster GT Owner’s Manual Wrong Right Finally, sweep speed affects target response and depth. Some detectors are designed for an exceptionally slow sweep speed, some need a fast sweep. The CoinGT works best at a moderate rate of about 3 feet per second. Somewhat slower or somewhat faster is fine, but whipping the coil at a fast rate is a good way to miss deeper targets.

  • Page 14: Specifications

    Coinmaster GT Owner’s Manual Specifications Operating mode ......VLF-IB Frequency....... . . 8.192kHz Search modes .

  • Page 15: Warranty

    Coinmaster GT Owner’s Manual Warranty If within two years (24 months) from the original date of purchase, your White’s detector fails due to defects in either material or workmanship, White’s will repair or replace at its option, all necessary parts without charge for parts or labor.

  • Page 16: Code Of Ethics

    Coinmaster GT Owner’s Manual Coinmaster GT Treasure Hunter’s Code of Ethics 1. Always check federal, state, county, and local laws before searching. 2. Always obtain the owner’s permission before access- ing private property. 3. Take care to refill all holes and leave no trace.
