  • Page 1 XLS200 MKII Subwoofer System OWNERS MANUAL...

  • Page 2: Table Of Contents

    CONTENTS Page No. Safety instructions. Connecting up your XLS200. Connecting up using the high level input. Connecting up using the low level input. Setting up your XLS200. Controls and their functions. Specifications.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS Caution: To avoid the risk of electric shock do not remove the panel from the cabinet. If this unit fails or has a serious deterioration in performance then refer repair to the dealer where you purchased the unit. 1)Please read these instructions carefully and keep them for future reference.

  • Page 4: Connecting Up Your Xls200

    CONNECTING UP YOUR XLS200 Always switch off your system before disconnecting or connecting any wires. To make connecting up of the XLS200 as versatile as possible we have included two separate inputs. One Neutrik Speakon socket and one pairs of gold plated RCA sockets. This is to facilitate use with both Hi-Fi and AV surround systems.

  • Page 5: Connecting Up Using The High Level Input

    If you do have a class d amplifier and are unable to use the high level input, then BK have developed a sonicaly transparent isolator that overcomes this problem. Please contact us for further details.

  • Page 6: Connecting Up Using The Low Level Input

    CONNECTING UP USING THE LOW LEVEL INPUT Figure 2. Shows a diagram on how to connect the low level input. Using the supplied RCA to RCA interconnect, plug one end into the XLS200 low level input and the other end into the dedicated sub output on your amplifier or processor.

  • Page 7: Setting Up Your Xls200

    SETTING UP YOUR XLS200 Connect your XLS200 as shown in Figure 1 or Figure 2. Then attach your subwoofer to the power supply using the power cable supplied, at this point have the power switch in the off position. Now turn both the high level and low level gains to the minimum position, and the frequency control to 120Hz.

  • Page 8: Controls And Their Functions

    GAIN FILTER FREQUENCY PHASE HIGH LEVEL LOW LEVEL 230V 50-60Hz T2AL XLS200 MKII 275 W S ub Bass System Designed and manufactured by :- B.K. Electronics www.bkelec.com Southend-On-Sea +44 (0)1702 527572 Essex. England TO AVOID RISK OF ELECTRIC SHOCK DO NOT REMOVE PANEL NO USER SERVICEABLE PARTS INSIDE.
  • Page 9 SPECIFICATION System Type: Infinite Baffle Sub-bass system with on-board amplification and active filtering. Fully optimised enclosure manufactured from critically damped 18mm and 25mm MDF Drive Units: 250mm 10“ high-efficiency unit. Extreme long stroke composite fiber cone driven by a 2 ” 50mm voice coil. Heavy-duty non-resonant cast aluminium chassis and fully optimised stacked magnet system.
