Lyman Turbo Sonic 2500 Operating Instructions
  1. Manuals
  2. Brands
  3. Lyman Manuals
  4. Ultrasonic Jewelry Cleaner
  5. Turbo Sonic 2500
  6. Operating instructions

Lyman Turbo Sonic 2500 Operating Instructions

Hide thumbs
1
2
3
4

Advertisement

Quick Links

Enlarged version
SPECIFICATIONS
Description
Item No.
Rating voltage
& Frequency
Consumption Power
Ultrasonic Frequency
Material of tank
Plastic Housing
Tank Size
Tank Capacity
5 Recycle digital timer
Net Weight
Gross Weight
Watch our Instructional Ultrasonic Cleaning Videos!
Visit our website at www.lymanproducts.com
Lyman
475 Smith Street
Middletown, CT 06457
1-860-632-2020
www.lymanproducts.com
Part # 7980508
Digital Ultrasonic Cleaner
(115V) 7631700
(230V) 7631702
AC 220~240V ~ 50-60 Hz
AC 100~120V ~ 50-60 Hz
160 Watts
170 Watts
42,000 Hz
Stainless Steel SUS304
ABS 757
9.84 x 5.90 x 3.15 in.
250 x 150 x 80 mm
2500ml (MAX-) 2100ml 4.44pt
(5.29 pt) (MIN-) 600ml 1.27pt
180s —280s—380s—480s—90s
5lbs, 8.18oz. (2.5 Kg)
6lbs, 9.82oz. (3.0 Kg)
®
Rev. 01/12
Lyman
Turbo
®
Sonic 2500
Ultrasonic Cleaner
Operating
Instructions
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the Turbo Sonic 2500 and is the answer not in the manual?

Questions and answers

Related Manuals for Lyman Turbo Sonic 2500

Summary of Contents for Lyman Turbo Sonic 2500

  • Page 1 Lyman ® SPECIFICATIONS Description Digital Ultrasonic Cleaner Turbo ® Sonic 2500 Item No. (115V) 7631700 (230V) 7631702 Ultrasonic Cleaner Rating voltage AC 220~240V ~ 50-60 Hz & Frequency AC 100~120V ~ 50-60 Hz Consumption Power 160 Watts 170 Watts Ultrasonic Frequency...

  • Page 2: Main Features

    Sonic for uses other than cases or steel parts that you use the correct cleaning www.lymanproducts.com solution or you risk damage to the item you are cleaning. Lyman offers a special jewelry cleaning solution. Other recommended uses for your Turbo Sonic are list- ed below.

  • Page 3: Cartridge Case Cleaning Solution

    Rinse the unit with clean water before recharging. • Do not mix with other cleaners or chemicals. If the item is out of warranty and is in need of repairs, the Lyman prod- uct should also be returned to the same address listed below.

  • Page 4: Features And Accessories

    OPERATING INSTRUCTIONS the minimum time needed. The part(s) can be allowed to soak (no sonics) to help in decreasing the time required for sonic cleaning. • Open lid by pulling straight up. Aluminum can be damaged by excessive sonic energy. •...
