The warning icon on a Hyundai Sonata indicates a potential issue with the vehicle. Warning lights may flash or blink red, signaling problems that need immediate attention. Common warning icons include:

- Parking brake and brake fluid warning light: Indicates the parking brake is applied or the brake fluid is low. If this light appears with the ABS warning, the brake system has malfunctioned, and the vehicle should not be driven.
- Master warning light: A triangle with an exclamation mark that serves as a catchall for multiple issues, such as low fuel level or an open door or trunk.
- Other warning lights: Include the airbag warning light, seatbelt warning light, ABS warning, electronic brake force distribution warning, engine oil pressure light, and charging system warning.

Each warning light represents a specific issue, and drivers should refer to the dashboard guide to determine the appropriate action.

This answer is automatically generated

Summary of Contents for Hyundai Sonata

Page 1 A000A01A-AAT This Owner's Manual should be considered a part of the car and remain with it when it is sold for the use of the next owner. OWNER'S I.D. ORIGINAL OWNER ADDRESS CITY STATE ZIP CODE DELIVERY DATE (Date Sold to Original Retail purchaser) DEALER NAME DEALER NO.
Page 2 A020A01A-AAT RESPONSIBILITY FOR MAINTENANCE The maintenance requirements for your new Hyundai are found in Section 5. As the owner, it is your responsibility to see that all maintenance operations specified by the manufacturer are carried out at the appropriate intervals.
Page 3 Specifications HEF-080A All information in this Owner's Manual is current at the time of publication. However, Hyundai reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all Hyundai Sonatas and includes descriptions and explanations of optional as well as standard equipment. As a result, you may find material in this manual that does not apply to your specific vehicle.
Page 4 Your Owner's Manual will introduce you to the features and operation of your new Hyundai. It is suggested that you read it carefully since the information it contains can contribute greatly to the satisfaction you receive from your new car.
Page 5 A090A01A-AAT SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as WARNING, CAUTION and NOTE. These titles indicate the following: WARNING: This indicates that a condition may result in harm, serious injury or death to you or other persons if the warning is not heeded.
Page 6 Your Hyundai should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your Hyundai and may, in addition, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of regulations established by the U.S.
Page 7 Hyundai Motor Company to manu- Hyundai Genuine Parts? facture vehicles. They are designed and tested for the optimum safety, performance, Look for the Hyundai Genuine Parts Logo on and reliability to our customers. the package (see below). 2. Why should you use genuine parts?
Page 8 YOUR VEHICLE AT A GLANCE B250A04Y-AAT INSTRUMENTS AND CONTROLS 7 8 9 10 13 14 15 18 19 20 21 HEF-042 efhma-0.p65 9/24/04, 11:22 AM...
Page 9 YOUR VEHICLE AT A GLANCE 1. Hood Release Lever 11.Passenger Air Bag (If installed) 2. Instrument Panel Junction box 12.Glove Box 3. Multi-Function Light/Front Fog Light Switch 13.Traction Control System (If installed) (If installed) 14.Panel Brightness Control Knob (Rheostat Switch) 4.
Page 10 YOUR VEHICLE AT A GLANCE B255A01Y-AAT INDICATOR SYMBOLS ON THE INSTRUMENT PANEL SRS (Airbag) Service Reminder Door Ajar Warning Light and Chime Indicator Low Fuel Level Warning Light Turn Signal Indicator Lights Malfunction Indicator Light Seat Belt Reminder Light ABS Service Reminder Indicator High Beam Indicator Light Oil Pressure Warning Light Traction Control Indicator Light...
Page 11 TABLE OF CONTENTS SECTION PAGE 1. FEATURES OF YOUR HYUNDAI ................1-1 2. DRIVING YOUR HYUNDAI ..................2-1 3. WHAT TO DO IN AN EMERGENCY ...............3-1 4. CORROSION PREVENTION & APPEARANCE CARE ........... 4-1 5. VEHICLE MAINTENANCE REQUIREMENTS ............5-1 6. DO-IT-YOURSELF MAINTENANCE ...............6-1 7.
Page 12: Table Of Contents
OUR HYUND 1.FEA 1.FEA TURES OF OUR HYUND Fuel Recommendations ................1-2 Breaking in Your New Hyundai ..............1-3 Key ......................1-3 Door locks (Theft-alarm system) ..............1-4 Power windows ................... 1-9 Seat ......................1-10 Seat Belt ....................1-16 Child restraint system ................1-22 Supplemental restraint (AIRBAG) system ..........
Page 13: Fuel Recommendations
Gasohol (a mixture of 90% unleaded gasoline Fuels containing methanol (wood alcohol) should and 10% ethanol or grain alcohol) may be used not be used in your Hyundai. This type of fuel in your Hyundai. However, if your engine devel- can reduce vehicle performance and damage ops driveability problems, the use of 100% components of the fuel system.
Page 14: Breaking In Your New Hyundai
Before leaving your sub key with a parking If you are going to drive your Hyundai in another o Don't let the engine idle longer than 3 minutes attendant, make sure that the lock levers of country, be sure to: at one time.
Page 15: Key
1- 4 FEATURES OF YOUR HYUNDAI B030C01Y-AAT B040A01A-AAT B040B01A-AAT ILLUMINATED IGNITION SWITCH DOOR LOCKS Locking and unlocking front doors with a (If installed) WARNING: o Unlocked doors can be dangerous. Be- UNLOCK fore you drive away (especially if there LOCK...
Page 16 1- 5 FEATURES OF YOUR HYUNDAI B040C02Y-AAT B040D01Y-AAT B040F01Y-AAT Locking From the Outside Locking From the Inside Illuminated Door Key Cylinder (If installed) LOCK UNLOCK B040D02Y B040C01Y The doors can be locked without a key. To lock To lock the doors from the inside, simply close...
Page 17 B040G02Y HEF-131 The central door locking switch is located on the Your Hyundai is equipped with left and right side driver's arm rest. It is operated by depressing "child-protector" rear door locks. When the lock the door lock switch. If any door is open when...
Page 18 1- 7 FEATURES OF YOUR HYUNDAI B070B03Y-AAT B070C03L-AAT Armed Stage Alarm Stage Park the car and stop the engine. Arm the CAUTION: system as described below. Avoid trying to start the engine while the system is armed. 1) Remove the ignition key from the ignition switch.
Page 19 1- 8 FEATURES OF YOUR HYUNDAI If any door, trunk lid or engine hood is not opened B070E02HP-GAT Keyless Entry System (If installed) Replacing the battery within 30 seconds, the system will be rearmed. Locking doors When the transmitter's battery begins to get 1.
Page 20: Power Windows
1- 9 FEATURES OF YOUR HYUNDAI B050A01A-AAT B060A02Y-AAT WINDOW GLASS POWER WINDOWS (If installed) Close Open Battery HEF-193 2. Remove the old battery from the case and B050A02Y B060A02Y note the polarity. Make sure the polarity of the new battery is the same(+side facing...
Page 21 1- 10 FEATURES OF YOUR HYUNDAI B080A01A-AAT ADJUSTABLE FRONT SEATS WARNING: (1) Be careful that someone's head, hands WARNING: and body are not trapped by a closing window. Never attempt to adjust the seat while the (2) Never try to operate the main switch on vehicle is moving.
Page 22 1- 11 FEATURES OF YOUR HYUNDAI B080C02A-AAT B080D02L-GAT Adjusting Seatback Angle Adjustable Headrests WARNING: To minimize risk of severe injury in the event of a collision or a sudden stop, both the driver and passenger seatbacks should always be in an upright position while the vehicle is in motion.
Page 23: Seat
1- 12 FEATURES OF YOUR HYUNDAI B080E01Y-AAT B080F01S-AAT Lumbar Support Control Seat Cushion Height Adjustment (Driver's seat only) (If installed) (If Installed) (Driver's Seat Only) WARNING: o For maximum effectiveness in case of an accident, the headrest should be adjust-...
Page 24 1- 13 FEATURES OF YOUR HYUNDAI B090A01Y-AAT B090B01Y-AAT B090C01Y-AAT POWER DRIVER'S SEAT (If installed) Adjusting Seat Forward and Rearward Seat Cushion Height Adjustment The driver's seat can be adjusted appropriately by using the control knob on the left side of the seat.
Page 25 1- 14 FEATURES OF YOUR HYUNDAI B090D01Y-AAT B140A01S-AAT Adjusting Seatback Angle SEAT WARMER (If installed) WARNING: The seat warmer is provided to warm the front To minimize the risk of personal injury in seats during cold weather. With the ignition key the event of a collision or a sudden stop, in the "ON"...
Page 26 1- 15 FEATURES OF YOUR HYUNDAI B140A01S-AAT B110A01Y-AAT REAR SEAT WARNING FOLDING REAR SEATBACKS (If installed) WARNING: The purpose of the folding rear seatbacks is to allow you to carry longer objects than could otherwise be accommodated. Do not allow passengers to sit on top of the folded...
Page 27: Seat Belt
1- 16 FEATURES OF YOUR HYUNDAI B120A01Y-AAT B150A02A-AAT B150B03Y-AAT REAR SEATBACK LOCK SEAT BELT PRECAUTIONS Infant or Small Child All 50 states have child restraint laws. You should be aware of the specific requirements in your state. Child and/or infant safety seats must...
Page 28 1- 17 FEATURES OF YOUR HYUNDAI B150C02A-AAT B150E01A-AAT Larger Children Injured Person WARNING: Children who are too large for child restraint A seat belt should be used when an injured Sitting in a reclined position or lying down systems should occupy the rear seat and use person is being transported.
Page 29 Hyundai Dealer. and not your neck. To adjust the height of the seat belt anchor,...
Page 30 B180A01L installed in the front passenger seat position, convert from the automatic locking feature Hyundai strongly recommends that children To fasten your seat belt, pull it out of the retractor to the emergency locking operation mode, always be seated in the rear seat. NEVER place and insert the metal tab into the buckle.
Page 31 1- 20 FEATURES OF YOUR HYUNDAI B200A01A-AAT B210A01A-AAT ADJUSTING YOUR SEAT BELT To Release the Seat Belt WARNING: o For maximum restraint system protec- tion, the seat belts must always be used whenever the car is moving. o Seat belts are most effective when seatbacks are in the upright position.
Page 32 1- 21 FEATURES OF YOUR HYUNDAI B220A02Y-AAT o Lock the metal tab (a) and the buckle (b) SEAT BELTS - Rear Seat Center's 3- immediately after folding rear seatbacks Point System With Combination Locking Retractor o To disconnect the metal tab (a) from the...
Page 33: Child Restraint System
1- 22 FEATURES OF YOUR HYUNDAI B220C01Y-AAT B230A03Y-AAT To Release the Seat Belt CHILD RESTRAINT SYSTEM WARNING: Children riding in the car should sit in the rear o A child restraint system must be placed seat and must always be properly restrained to in the rear seat.
Page 34 1- 23 FEATURES OF YOUR HYUNDAI B230B01Y-AAT For small children and babies, the use of a child shoulder belt fit. The lap belt portion of Using a Child Restraint System seat or infant seat is strongly recommended the lap/shoulder belt must always be and may be required in your state.
Page 35 1- 24 FEATURES OF YOUR HYUNDAI B230G03Y-AAT Tether anchor cover Tether strap Installation on Rear Seats hook holder WARNING: If the tether strap is clipped incorrectly, the child restraint seat may not be restrained properly in the event of a collision.
Page 36 If the seat belt does not operate as de- enough to secure the child restraint seat scribed, have the system checked imme- properly in the center of the rear seat and diately by your authorized Hyundai may break, causing serious injury or dealer. death.
Page 37 B180B01HP-AAT Pre-tensioner Seat Belt Your Hyundai vehicle is equipped with driver's HXG229 B230D03Y and front passenger's pre-tensioner seat belts. The ISOFIX anchors are located between the...
Page 38 6 seconds, or if it illumi- belts were activated. nates while the vehicle is being driven, 1. SRS airbag warning light please have an authorized Hyundai dealer 2. Seat belt pre-tensioner assembly inspect the pre-tensioner seat belt or 3. SRS control module SRS airbag system as soon as possible.
Page 39: Supplemental Restraint (Airbag) System
Do not attempt to inspect or replace the airbags deploy only in certain frontal pre-tensioner seat belts yourself. This impact conditions severe enough to likely must be done by an authorized Hyundai HEF-200 cause significant injury to the vehicle dealer.
Page 40 If the airbags deploy, they must be re- serious or fatal injuries. placed by an authorized Hyundai dealer. efhma-1a.p65 9/24/04, 11:24 AM...
Page 41 1- 30 FEATURES OF YOUR HYUNDAI The airbag modules are located both in the Passenger's Airbag center of the steering wheel and in the front passenger's panel above the glove box. When the SRSCM detects a considerable im- pact to the front of the vehicle, it will automatically deploy the airbags.
Page 42 B990B02Y ately inspected by your Hyundai dealer. is not intended to prevent airbag deploy- Your Hyundai is equipped with a side impact o Before you replace a fuse or disconnect ment while a child is in the front passen- airbag in each front seat. The purpose of the a battery terminal, turn the ignition key ger's seat.
Page 43 Such objects may become yourself. The entire SRS system must be dangerous projectiles and cause injury inspected by an authorized Hyundai dealer if the supplemental side impact air bag 10 years after the date that the vehicle was inflates.
Page 44 No objects should be placed over or near shouldn't try to start the engine; have the airbag modules on the steering the car towed to an authorized Hyundai wheel, instrument panel, and the front dealer. passenger’s panel above the glove box,...
Page 45 1- 34 FEATURES OF YOUR HYUNDAI B240D01JM-AAT o Keep occupants away from the airbag Additional Safety Precautions covers. All occupants should sit upright, fully o Never let passengers ride in the cargo back in their seats with their seat belts on and...
Page 46: Instrument Cluster And Indicator Lights
1- 35 FEATURES OF YOUR HYUNDAI B260A05Y-GAT INSTRUMENT CLUSTER AND INDICATOR LIGHTS B260A04Y-A1 10 11 12 13 14 16 17 18 19 20 21 22 1. Malfuction Indicator Light (If installed) 10.Trunk Lid Open Warning Light 17.Low Fuel Warning Light 2.
Page 47 If the arrow comes on but does not blink, engine should be checked by a Hyundai blinks more rapidly than normal, or does not dealer before the car is driven again.
Page 48 Parking Brake/Brake Fluid Level Trunk Lid Open Warning Light should be immediately and carefully driven to a Hyundai dealer for inspection. If further trouble Warning Light is experienced, the vehicle should not be driven This light remains on unless the trunk lid is at all but taken to a dealer by a professional completely closed and latched.
Page 49 If the TCS indicator stays on, take converter. ABS. your car to your authorized Hyundai dealer and If this occurs, have your vehicle checked by have the system checked. See section 2 for your Hyundai dealer as soon as possible. The more information about the TCS system.
Page 50 It may also be heard when the brake pedal is pushed down firmly. Excessive rotor damage will result if the worn pads are not replaced. See your Hyundai dealer immediately. B280A01A-AAT FUEL GAUGE...
Page 51 1- 40 FEATURES OF YOUR HYUNDAI B330A01Y-AAT B310B03Y-GAT Trip odometer TACHOMETER ODOMETER/TRIP ODOMETER Records the distance of 2 trips in miles or kilometers. TRIP A: first distance you have traveled from your origination point to a first destination. TRIP B: Second distance from the first destina- tion to the final destination.
Page 52: Trip Computer
1- 41 FEATURES OF YOUR HYUNDAI B315A02Y-GAT Selectable Function TRIP COMPUTER (If installed) Display window Mode Function o The trip computer is a microcomputer-con- This mode indicates first distance you have trolled driver information system that dis- plays information related to driving, such as...
Page 53 B340B01Y B340C01Y a malfunction in the system. Check for a burned- out fuse or bulb or see your Hyundai dealer. To indicate a lane change, move the lever up or To operate the headlights, turn the barrel on the down to a point where it begins flashing.
Page 54: Windshield Wiper/Washer Switch
1- 43 FEATURES OF YOUR HYUNDAI B340D01A-AAT B360B02Y-GAT B350A01A-AAT High-beam Switch Front Fog Light Switch (If installed) WINDSHIELD WIPER AND WASHER SWITCH To turn on the headlight high beams, push the lever forward (away from you). The High Beam Indicator Light will come on at the same time. For low beams, pull the lever back toward you.
Page 55 1- 44 FEATURES OF YOUR HYUNDAI B350B01Y-GAT B350C02Y-AAT Mist Wiper Operation Windshield Washer Operation Adjustable Intermittent Wiper Operation B350B04Y B350B03Y B350C02Y To use the windshield washer, pull the wiper/ If a single wipe is desired in mist, push the MIST To use the intermittent wiper feature, place the washer lever toward the steering wheel.
Page 56 1- 45 FEATURES OF YOUR HYUNDAI B370A01A-AAT B380A01Y-AAT The rear window defroster is actuated in con- HAZARD WARNING SYSTEM REAR WINDOW DEFROSTER nection with the outside rear view mirror heater. The rear window defroster is turned on by SWITCH pushing in on the switch. To turn the defroster Automatic type off, push in on the switch a second time.
Page 57 When this is done: If it is necessary to replace the cigarette lighter, use only a genuine Hyundai replacement or its Pressing "R" between 10 : 30 and 11 : 29 approved equivalent. changes the readout to 11 : 00.
Page 58 1- 47 FEATURES OF YOUR HYUNDAI B430A03Y-AAT B440A01Y-AAT B450A03Y-GAT FRONT ASHTRAY REAR ASHTRAY DRINK HOLDER (If installed) 1MS104029 HEF-155 B440A01Y The front ashtray may be opened by pushing The rear ashtray may be opened by pulling it out The drink holder is located on the main console.
Page 59: Sunroof
The sunroof can be electrically opened or closed B460A01Y with the ignition key in the "ON" position. To open Your HYUNDAI is equipped with a sliding sun- or to close, press and hold the button located shade which you can manually adjust to let in in the front of the roof panel.
Page 60 1- 49 FEATURES OF YOUR HYUNDAI NOTE: After washing the car or after there is rain, be sure to wipe off any water that is on the sunroof before operating it. B460D03Y-AAT Manual Operation of Sunroof If the sunroof does not electrically operate:...
Page 61 1- 50 FEATURES OF YOUR HYUNDAI B480A01Y-AAT B480B02Y-AAT B490A02Y-AAT MAP LIGHT (with sunroof) MAP LIGHT (without sunroof) INTERIOR LIGHT (If installed) Map Light Switch lnterior Light Switch With Sunroof Without sunroof B490A02Y HEF-198 The two map light switches are located on both The interior courtesy light has three buttons.
Page 62 1- 51 FEATURES OF YOUR HYUNDAI B500A02A-AAT B510A01A-AAT GLOVE BOX OUTSIDE REARVIEW MIRROR Manual Type CAUTION: If the mirror control is jammed with ice, do not attempt to break it free using the control handle or by manipulating the face of the mirror.
Page 63 1- 52 FEATURES OF YOUR HYUNDAI To adjust the position of either mirror: Rotary and push button type 1. Move the selecting switch to the right or left WARNING: to activate the adjustable mechanism for the corresponding door mirror. Be careful when judging the size or dis- 2.
Page 64: Mirror
HEF-206 HEF-207 To fold the outside rearview mirrors, push them Your Hyundai is equipped with a day/night inside The electric type day/night inside rearview mir- toward the rear. To unfold the ouside rear view rear view mirror. The "night" position is selected ror controls automatically the glare of headlights mirrors, push them toward the front.
Page 65: Homelink Mirror
1- 54 FEATURES OF YOUR HYUNDAI B520C01L-GAT Automatic-Dimming Function HOMELINK PROGRAMMING HOMELINK MIRROR (If installed) CAUTION: o Make sure people and/or objects are out of the way of any garage doors or gates you may be operating during the pro- gramming procedures.
Page 66 1- 55 FEATURES OF YOUR HYUNDAI Programming Additional Programming for Rolling Code Devices Flashing Your vehicle may require that the ignition switch to be turned to the "ACC" position to program For any rolling-code-equipped device; follow and/or operate HomeLink system. It is also the steps below after completing the "Program-...
Page 67 1- 56 FEATURES OF YOUR HYUNDAI Operating HomeLink Reprogramming a Single HomeLink Gate Operator Programming & Cana- Button dian Programming Simply press the appropriate HomeLink button to activate the trained product (garage door, To program a device to HomeLink using a...
Page 68 1- 57 FEATURES OF YOUR HYUNDAI B530A01A-AAT B540A01S-GAT B540B04Y-AAT PARKING BRAKE TRUNK LID Trunk Lid Knob Lock (If installed) Remote Trunk Lid Release HEF-154 B540B04Y Always engage the parking brake before leav- If the trunk lid lock knob (located near the latch) HEF-132 ing the car.
Page 69 1- 58 FEATURES OF YOUR HYUNDAI B540C02Y-AAT B540B02Y-AAT o HYUNDAI recommends that cars be kept To unlock using the key Trunk Lid Emergency Latch Release locked and keys be kept out of the reach of children, and that parents teach their children about the dangers of playing in trunks.
Page 70 NOTE: the filler area. If you need to replace the If the fuel-filler lid will not open because ice filler cap, use a genuine Hyundai re- has formed around it, tap lightly or push on placement part. the lid to break the ice and release the lid. Do o If you open the fuel filler cap during high not pry on the lid.
Page 71 1- 60 FEATURES OF YOUR HYUNDAI B560B01L-GAT o Do not "TOP-OFF" after the first nozzle Manual Fuel Filler Lid Release shut off when refueling. WARNING: o The fuel cap must be tightened at least o When using a portable fuel container be 3 clicks, otherwise "...
Page 72: Hood Release
HEF-134A 1MS104008 HEF-116A 1. Pull the release knob to unlatch the hood. Your Hyundai is equipped with sun visors to give WARNING: 2. Press the safety catch lever up and lift the the driver and front passenger either frontal or o Always double check to be sure that the hood.
Page 73 1- 62 FEATURES OF YOUR HYUNDAI A red light comes on when the front door is B611A02Y-AAT REAR SEAT ARM REST (If installed) opened. The purpose of this light is to assist when you get in or out and also to warn passing WARNING: vehicles.
Page 74 WARNING: Do not use electric accessories or equip- o Make sure the floor mat is properly placed ment other than the Hyundai genuine parts on the floor carpet. If the floor mat slips in the socket. and interferes with the movement of the...
Page 75: Cruise Control
1- 64 FEATURES OF YOUR HYUNDAI B660A01S-AAT B660B01L-AAT B660C01Y-AAT CRUISE CONTROL (If installed) To Set the Cruise Speed To Cancel the Cruise Speed B660C01L B660A04Y B660B01L The cruise control system provides automatic 1. Push in the cruise control main switch. This...
Page 76 1- 65 FEATURES OF YOUR HYUNDAI B660D01L-AAT B660F01L-AAT To Resume the Preset Speed To Reset at a Slower Speed WARNING: o Keep the main switch off when not using the cruise control. Use the cruise control system only when traveling on open highways in good weather.
Page 77: Heating And Cooling Control
1- 66 FEATURES OF YOUR HYUNDAI B710A01Y-GAT B710A01Y-AAT HEATING AND COOLING CONTROL VENTILATION To operate the ventilation system: o Set the air intake control at the fresh air ) position. o To direct all intake air to the dashboard vents, set the airflow control to the face ( position.
Page 78 1- 67 FEATURES OF YOUR HYUNDAI B670A02Y-GAT B670B02Y-AAT B670E01A-AAT Rotary and Push Button Type Fan Speed Control Temperature Control (Blower Control) 2 3 4 Cool Warm B670A01Y HEF-032 1. Fan speed control This is used to turn the heating system on and HEF-031 2.
Page 79 1- 68 FEATURES OF YOUR HYUNDAI B670C01O-AAT NOTE: B675C01Y-AAT Air Intake Control MAX A/C switch o It should be noted that prolonged opera- tion of the heating system in " " mode will give rise to fogging of the wind-...
Page 80 1- 69 FEATURES OF YOUR HYUNDAI B670D04A-AAT Air Intake Air Flow Control Control Switch ON or OFF * ON or OFF * * The A/C or the air intake control switch HEF-043 returns to its former setting. HEF-030 Face-Level This is used to direct the flow of air. Air can be Selecting the "Face"...
Page 81 1- 70 FEATURES OF YOUR HYUNDAI Bi-Level Air is discharged through the face vents and the floor vents. This makes it possible to have cooler air from the dashboard vents and warmer air from the floor outlets at the same time.
Page 82 1- 71 FEATURES OF YOUR HYUNDAI B690A04Y-AAT B740C01A-AAT B740A01S-AAT HEATING CONTROLS De-Humidified Heating AIR CONDITIONING SYSTEM Air Conditioning Switch For normal heating operation, set the air intake For dehumidified heating: control to the fresh air ( ) position and the air flow control to the floor ( ) position.
Page 83 1- 72 FEATURES OF YOUR HYUNDAI B740B01A-AAT o Adjust the fan control to the desired speed. Air Conditioning Operation For greater cooling, turn the fan control to one of the higher speeds or temporarily (If installed) select the recirculate (...
Page 84 FEATURES OF YOUR HYUNDAI B970A01Y-AAT TYPE A (Without Air Quality System) AUTOMATIC HEATING AND COOLING CONTROL SYSTEM (If installed) Your Hyundai is equipped with an automatic heating and cooling control system controlled by simply setting the desired temperature. B970B03Y-GAT Heating and Cooling Controls 1.
Page 85 1- 74 FEATURES OF YOUR HYUNDAI B970C03L-AAT NOTE: Automatic Operation If the battery has been discharged or dis- connected, the temperature mode will reset to Centigrade degrees. This is a normal condition and you can change the temperature mode from Centi- grade to Fahrenheit as follows;...
Page 86 1- 75 FEATURES OF YOUR HYUNDAI B995A02Y-GAT B980B02Y-AAT B670C01Y-AAT AMBIENT SWITCH Fan Speed Control Switch Air Intake Control Switch (Without A.Q.S) HEF-034 Pressing the button displays the ambient tem- The fan speed can be set to the desired speed HEF-027 perature on the LCD.
Page 87 1- 76 FEATURES OF YOUR HYUNDAI With the "Recirculation" mode selected, and air B980D01Y-AAT Heating and Cooling System Off from within the passenger compartment will be drawn through the heating system and heated Press the "OFF" button to stop the operation of or cooled according to the function selected.
Page 88 1- 77 FEATURES OF YOUR HYUNDAI B980F02Y-AAT Bi-Level Defrost Switch When selecting the "Bi-Level" mode, the indica- tor light will come on and the air will be dis- charged through the face vents and the floor vents. This makes it possible to have cooler air from the dashboard vents and warmer air from the floor outlets at the same time.
Page 89 1- 78 FEATURES OF YOUR HYUNDAI B760A06Y-AAT B740D01Y-AAT AIR CONDITIONER FILTER (FOR Operation Tips CAUTION: EVAPORATOR AND BLOWER UNIT) o If the interior of the car is hot when you first o Replace the filter every 12,000 miles (If installed) get in, open the windows for a few minutes (20,000 km) or once a year.
Page 90 1- 79 FEATURES OF YOUR HYUNDAI B720A08Y-AAT DEFROSTING/DEFOGGING B720A03Y B720A04Y To remove interior fog on the windshield. To remove frost or exterior fog on the windshield; o Set the air flow control to the defrost ( ) position. o Set the air flow control to the defrost ( ) position.
Page 91: Stereo Sound System
1- 80 FEATURES OF YOUR HYUNDAI B750A02A-AAT AM reception FM radio station STEREO SOUND SYSTEM Ionosphere How Car Audio Works Mountains Unobstructed FM reception area Ionosphere Buildings Iron bridges Obstructed area B750A02L B750A03L AM broadcasts can be received at greater FM broadcasts are transmitted at high fre- distances than FM broadcasts.
Page 92 1- 81 FEATURES OF YOUR HYUNDAI B750B02Y-AAT Using a cellular phone or a two-way radio When a cellular phone is used inside the vehicle, noise may be produced from the audio equip- ment. This does not mean that something is wrong with the audio equipment.
Page 93 1- 82 FEATURES OF YOUR HYUNDAI H240A01O-GAT STEREO RADIO OPERATION (H240) (If Installed) 5. BAND Selector 3. TREBLE/FADER Control Knob (TREB/FAD) 6. PRESET Buttons 2. BASS/BALANCE Control Knob (BASS/BAL) 4. TUNE/SEEK Select Button 7. SCAN Button 1. POWER ON/OFF, VOLUME Control Knob K240A01TB efhma-1b.p65...
Page 94 1- 83 FEATURES OF YOUR HYUNDAI H240B04O-GAT 3. TREB (Treble Control) Knob 5. BAND Selector 1. POWER ON-OFF Control Knob Press to pop the knob out and turn to the left or Pressing the button changes the AM, FM1 FM/AM The radio unit may be operated when the ignition right for the desired treble tone.
Page 95: Audio System
1- 84 FEATURES OF YOUR HYUNDAI o Press the station select button for more than two seconds. A select button indicator will show in the display indicating which select button you have depressed. The frequency display will flash after it has been stored into the memory with a beep sound.
Page 96 1- 85 FEATURES OF YOUR HYUNDAI H240C01O-GAT CASSETTE TAPE PLAYER OPERATION (H240) (If Installed) 3. TAPE PROGRAM Button 6. TAPE SLOT 2. AUTO MUSIC SELECT Button 4. EJECT Button 1. FF/REW Button 5. DOLBY SELECT Button K240A01TB efhma-1b.p65 9/24/04, 11:28 AM...
Page 97 1- 86 FEATURES OF YOUR HYUNDAI H240A04O-GAT NOTE: 1. FF/REW Button When tape operation is abnormal or ER8 fault code is displayed, press the eject o The FF (fast forward tape winding) starts button more than 5 seconds to reset the...
Page 98 1- 87 FEATURES OF YOUR HYUNDAI H260A01O-AAT STEREO RADIO OPERATION (H260) (If Installed) 3. BASS/TREBLE Control Knob 4. SCAN Button 6. BAND Selector 7. PRESET Button 5. TUNE/SEEK Select Button 1. POWER ON-OFF/VOLUME/BALANCE Control Knob 2. FADER Control Knob H260A01O efhma-1b.p65...
Page 99 1- 88 FEATURES OF YOUR HYUNDAI H260B04E-AAT 3. BASS Control Knob SEEK Operation 1. POWER ON-OFF Control Knob (Automatic Channel Selection) Press to pop the knob out and turn to the left or The radio unit may be operated when the ignition right for the desired bass tone.
Page 100 1- 89 FEATURES OF YOUR HYUNDAI o Press band selector to set the band for AM, FM1 or FM2. o Select the desired station to be stored by seek, scan or manual tuning. o Determine the preset station select button you wish to use to access that station.
Page 101 1- 90 FEATURES OF YOUR HYUNDAI H260B01O-AAT COMPACT DISC PLAYER OPERATION (H260) (If Installed) 4. SCAN Button 1.Playing CD 3. TRACK UP/DOWN 6. EJECT Button 2. FF/REW Button 5. REPEAT Button H260A01O efhma-1b.p65 9/24/04, 11:28 AM...
Page 102 1- 91 FEATURES OF YOUR HYUNDAI B260D02O-AAT NOTE: 4. SCAN Button 1. Playing CD o To assure proper operation of the unit, o Press the SCAN button to playback the first keep the vehicle interior temperature 10 seconds of each track.
Page 103 1- 92 FEATURES OF YOUR HYUNDAI CAUTION: o Do not insert warped or poor quality discs into the CD player as damage to the unit may occur. o Do not insert anything like coins into the player slot as damage to the unit may occur.
Page 104 1- 93 FEATURES OF YOUR HYUNDAI H290A01O-AAT STEREO RADIO OPERATION (H290) (If Installed) 1. POWER ON/OFF VOLUME Control Knob 8. BSM, SCAN Button (If installed) 7. EQUALIZER Button 3. TREBLE/FAD Konb 2. BASS/BALANCE Control Knob 5. PRESET Buttons 4. TUNE/SEEK Select Button 6.
Page 105 1- 94 FEATURES OF YOUR HYUNDAI H290B04E-GAT 3. TREBLE/FAD Knob 5. PRESET STATION Select Buttons 1. POWER ON-OFF Control Knob Six (6) stations for AM, FM1 and FM2 respec- TREBLE Control Knob The radio unit may be operated when the ignition...
Page 106 1- 95 FEATURES OF YOUR HYUNDAI 6. BAND Selector Pressing the button changes the AM, FM1 FM/AM CAUTION: and FM2 bands. The mode selected is shown o Do not place beverages close to the on the display. audio system. The playback mechanism may be damaged if you spill them.
Page 107 1- 96 FEATURES OF YOUR HYUNDAI H290C01O-AAT CASSETTE TAPE PLAYER OPERATION (H290) (If Installed) 5. EQUALIZER Button 4. TAPE EJECT Button 2. AUTO MUSIC Select Button 1. FF/REW Button H290A01O 6. DOLBY Button 3. TAPE PROGRAM Button efhma-1b.p65 9/24/04, 11:28 AM...
Page 108 1- 97 FEATURES OF YOUR HYUNDAI H290D02O-GAT 4. TAPE EJECT button 1. FF/REW Button o When the button is pressed with the CAUTION: o Fast forward tape winding starts when the cassette loaded, the cassette is ejected. o Do not insert anything like coins into the...
Page 109 1- 98 FEATURES OF YOUR HYUNDAI H290E01O-AAT COMPACT DISC PLAYER OPERATION (H290) (If Installed) 6. CD EJECT Button 7. SCAN Button 5. EQUALIZER Button 3. TRACK UP/DOWN 2. FF/REW Button H290A01O 4. REPEAT 1. CD Select Button efhma-1b.p65 9/24/04, 11:28 AM...
Page 110 1- 99 FEATURES OF YOUR HYUNDAI H290F02O-GAT NOTE: 4. REPEAT 1. CD Select Button o To assure proper operation of the unit, o To repeat the music you are listening to, keep the vehicle interior temperature o Insert the CD with the label facing upward.
Page 111 1- 100 FEATURES OF YOUR HYUNDAI CAUTION: o Do not insert warped or poor quality discs into the CD player as damage to the unit may occur. o Do not insert anything like coins into the player slot as damage to the unit may occur.
Page 112 SOLUTION CDP DECK MECHANICAL ERROR AFTER RESETTING THE AUDIO, PUSH THE EJECT BUTTON. (EJECT ERROR, LOADING ERROR) IF DISC IS NOT EJECTED, CONSULT YOUR HYUNDAI DEALER. FOCUS ERROR MAKE SURE THE DISC IS NOT SCRATCHED OR DAMAGED. DATA READ ERROR PRESS THE EJECT BUTTON AND PULL OUT THE DISC.
Page 113 1- 102 FEATURES OF YOUR HYUNDAI B850A01F-AAT Fingerprints, dust, or soil on the surface of a disc Storage Care of DISC could cause the pickup to skip signal tracks. When not in use, place your discs in their Wipe the surface clean with a clean soft cloth.
Page 114 1- 103 FEATURES OF YOUR HYUNDAI o Never leave a cassette inserted in the player o Store cassettes in a cool, dry place with the available from audio specialty shops. Follow when not being played. This could damage open side facing down to prevent dust from the supplier's directions carefully and never the tape player unit and the cassette tape.
Page 115: Antenna
1- 104 FEATURES OF YOUR HYUNDAI B870A01A-AAT B870B01Y-AAT ANTENNA Power Antenna (If installed) Fixed Rod Antenna (If installed) B870B02Y The antenna will automatically be extended B870A01Y when the radio power switch is turned "ON" Your car uses a fixed rod antenna to receive while the ignition key is in either the "ON"...
Page 116: Driving Your Hyundai
2. DRIVING YOUR HYUNDAI Before starting the engine ..............2-3 Key position ..................2-3 Starting .....................2-4 Operating the manual transaxle ............2-5 Automatic transaxle .................2-7 Anti-Lock Brake System (ABS) ............. 2-10 Traction Control System (TCS) ............. 2-11 Good braking practices ..............2-12 Driving for economy ...............2-13 Winter Driving.................
Page 117 Hyundai dealer. o Do not run the engine in an enclosed area.
Page 118: Before Starting The Engine
1. Look around the vehicle to be sure there are LOCK no flat tires, puddles of oil, water or other o If your Hyundai is equipped with a manual indications of possible trouble. transaxle, place the shift lever in neutral and 2.
Page 119: Starting
2- 4 DRIVING YOUR HYUNDAI C070C02A-AAT C050A01A-AAT o "ON" To Remove the Ignition Key STARTING When the key is in the "ON" position, the ignition is on and all accessories may be turned on. If the engine is not running, the key should not be...
Page 120: Operating The Manual Transaxle
HEF-238 mature wear of the transaxle shift forks. Be sure that the clutch is fully depressed Your Hyundai's manual transaxle has a con- when starting a manual transaxle vehicle. ventional shift pattern. This shift pattern is im- Your manual transaxle equipped vehicle printed on the shift knob.
Page 121 2- 6 DRIVING YOUR HYUNDAI C070B02A-AAT shift into reverse, depress the clutch, move C070E02A-AAT Using the Clutch Recommended Shift Points the shift lever to neutral, wait three seconds, then shift to the reverse position. The clutch should be pressed all the way to the o Exercise extreme caution when driving on a floor before shifting, then released slowly.
Page 122: Automatic Transaxle
T.C.M (Transaxle Control Module). The indicator lights in the instrument cluster C090A01Y indicate the selector lever position when the The highly efficient Hyundai automatic transaxle ignition is switched "ON". During the sports has four forward speed and one reverse speed. CAUTION:...
Page 123 2- 8 DRIVING YOUR HYUNDAI C090B01A-AAT C090C01A-AAT C090F02O-GAT The function of each position is as fol- o R(Reverse): Sports Mode lows: Use for backing up the vehicle. Bring the car to a complete stop before shifting the selector o P (Park): lever to "R"...
Page 124 2- 9 DRIVING YOUR HYUNDAI o Before driving away from a stop on a C090I02L-GAT slippery road, push the selector lever forward into the +(UP) position. This CAUTION: causes the transaxle to shift into 2nd CAUTION: o In sports mode, the driver must execute...
Page 125: Anti-Lock Brake System (Abs)
2- 10 DRIVING YOUR HYUNDAI C090N03O-AAT C120A02A-AAT Good Driving Practices ANTI-LOCK BRAKE SYSTEM (If installed) WARNING: o Never move the gear selector lever from "P" o Avoid high cornering speeds. or "N" to any other position with the accelera- The Anti-Lock Brake System (ABS) is designed o Do not make quick steering wheel move- tor pedal depressed.
Page 126: Traction Control System (Tcs)
2- 11 DRIVING YOUR HYUNDAI On slippery road surfaces, the traction control o Driving on rough, gravel or snow-cov- system (TCS) limits the drive wheels from ered roads. spinning excessively, thus helping the car to WARNING: o Driving with tire chains installed.
Page 127: Good Braking Practices
Nothing should be carried on top of the o If a tire goes flat while you are driving, apply by an authorized Hyundai dealer. cargo area cover behind the rear seat. If the brakes gently and keep the car pointed there were an accident or a sudden stop, straight ahead while you slow down.
Page 128: Driving For Economy
Keep your car clean. For maximum service, Avoid braking or gear changing in corners, essarily. Avoid heavy traffic whenever pos- your Hyundai should be kept clean and free especially when roads are wet. Ideally, corners sible. Always maintain a safe distance from of corrosive materials.
Page 129 Section 6. The level of charge To Keep Locks from Freezing in your battery can be checked by your Hyundai Tire chains are not legal in all states. Check To keep the locks from freezing, squirt an dealer or a service station.
Page 130 Window washer anti- tions where this may happen, you should peri- overheating and possible failure of the tires. freeze is available from Hyundai dealers and odically check underneath the car to be sure the Avoid using worn or damaged tires which may most auto parts outlets.
Page 131: Trailer Or Vehicle Towing
C190C01Y-AAT ments for towing trailers, cars, or other types of Trailer Brakes vehicles or apparatus may differ. Ask your Hyundai dealer for further details before towing. If your trailer is equipped with a braking system, C190D01S-AAT Safety Chains make sure it conforms to federal and/or local...
Page 132 2- 17 DRIVING YOUR HYUNDAI C190E03Y-AAT combined weight of the vehicle, driver, Trailer Weight Limit all passengers and their luggage, cargo, hitch, trailer tongue load and other op- CAUTION: tional equipment. The following specifications are recom- 3. The front or rear axle weight must not mended when towing a trailer.
Page 133 2- 18 DRIVING YOUR HYUNDAI C190F01S-AAT 9. If the trailer has electric brakes, start your Trailer or Vehicle Towing Tips vehicle and trailer moving, and then apply the trailer brake controller by hand to be sure the CAUTION: 1. Before towing, check hitch and safety chain brakes are working.
Page 134: Vehicle Load Limit
2- 19 DRIVING YOUR HYUNDAI C190F01JM-AAT Steps for Determining Correct Load (5)Determine the combined weight of VEHICLE LOAD LIMIT Limit luggage and cargo being loaded on Tire and Loading Information Label (1)Locate the statement "The combined the vehicle. That weight may not...
Page 135 2- 20 DRIVING YOUR HYUNDAI Example 1 Example 2 Example 3 C190F02JM C190F01JM C190F03JM Item Description Total Item Description Total Item Description Total 1400 lbs 1400 lbs 1400 lbs Vehicle Capacity Weight Vehicle Capacity Weight Vehicle Capacity Weight (640 kg)
Page 136 2- 21 DRIVING YOUR HYUNDAI C190G01JM-AAT Refer to your vehicle's tire and loading This label also tells you the maximum Compliance Label information label for specific informa- weights that can be supported by the tion about your vehicle's capacity weight front and rear axles, called Gross Axle and seating positions.
Page 137 2- 22 DRIVING YOUR HYUNDAI NOTE: o Overloading your vehicle may WARNING: cause damage. Repairs would not Items you carry inside your vehicle be covered by your warranty. Do can strike and injure people in a not overload your vehicle.
Page 138: What To Do In An Emergency
3. WHAT TO DO IN AN EMERGENCY If the engine will not start ..............3-2 Jump starting..................3-2 If the engine overheats ..............3-3 Spare tire ..................3-4 If you have a flat tire .................3-5 If your car must be towed ............... 3-11 Emergency towing .................
Page 139: If The Engine Will Not Start
The gas produced by the battery during the ment. jump-start operation is highly explosive. If 4. If the engine still does not start, call a Hyundai these instructions are not followed exactly, dealer or seek other qualified assistance. serious personal injury and damage to the...
Page 140: If The Engine Overheats
Hyundai dealer. engine cooling fan is operating. If the fan is touching. not running, turn the engine off.
Page 141: Spare Tire
Hyundai replaced. injury. dealer.
Page 142: If You Have A Flat Tire
3- 5 WHAT TO DO IN AN EMERGENCY D050A01A-AAT D060A01A-AAT IF YOU HAVE A FLAT TIRE CHANGING A FLAT TIRE CAUTION: If a tire goes flat while you are driving: o Do not use snow chains with your 1. Take your foot off the accelerator temporary spare tire.
Page 143 3- 6 WHAT TO DO IN AN EMERGENCY D060K02Y-AAT D060C01A-AAT 2. Insert the wrench bar into the notch Wheel Cover (If installed) 2. Block the Wheel of the wheel cover and pry gently to Aluminum Wheel remove the wheel cover. 3.
Page 144 3- 7 WHAT TO DO IN AN EMERGENCY D060D02A-AAT D060E01A-AAT D060F02E-AAT 3. Loosen Wheel Nuts 4. Put the Jack in Place 5. Raising the Car Wrench bar Wheel nut wrench D060D01Y HEF-111A HFC4022 The wheel nuts should be loosened The base of the jack should be placed After inserting a bar into the wheel nut slightly before raising the car.
Page 145 3- 8 WHAT TO DO IN AN EMERGENCY D060G02Y-AAT Raise the car high enough so that the 6. Changing Wheels fully inflated spare tire can be installed. To do this, you will need more ground clearance than is required to remove the flat tire.
Page 146 3- 9 WHAT TO DO IN AN EMERGENCY D060H02A-AAT D060I01Y-AAT wheel nuts could come loose and 7. Reinstall Wheel Nuts 8. Lower Vehicle and Tighten Nuts cause the loss of a wheel. Loss of a wheel may result in loss of control of the vehicle.
Page 147 3- 10 WHAT TO DO IN AN EMERGENCY D060J01A-AAT Go around the wheel tightening every After you have changed wheels, al- After Changing Wheels other nut until they are all tight. Then ways secure the flat tire in its place in double-check each nut for tightness the trunk and return the jack, jack handle, and reinstall the wheel cover.
Page 148 If your vehicle has to be towed, it should be done truck (1), (2) or flatbed equipment (3). by your Hyundai dealer or a commercial tow truck service. This will help assure that your vehicle is not damaged in towing. Also, profes- sionals are generally aware of local laws gov- erning towing.
Page 149: Emergency Towing
3- 12 WHAT TO DO IN AN EMERGENCY NOTE: o Automatic Transaxle: D080D02A-AAT Emergency Towing Be sure to use a towing dolly under the front Before towing, check the level of the auto- wheels. matic transaxle fluid. If it is below the "HOT" Front range on the dipstick, add fluid.
Page 150: If You Lose Your Keys
"ACC" position. D120A01A-AAT IF YOU LOSE YOUR KEYS If you lose your keys, many Hyundai dealers can make you a new key if you have your key number. If you lock the keys inside your car and you cannot obtain a new key, many Hyundai dealers can use special tools to open the door for you.
Page 151: Corrosion Prevention
4. CORROSION PREVENTION & APPEARANCE CARE Corrosion protection .................4-2 To help prevent corrosion ..............4-2 Washing and waxing ................4-3 Cleaning the interior .................4-4 efhma-4.p65 9/24/04, 11:29 AM...
Page 152: Corrosion Prevention & Appearance Care
In such conditions, the corrosive material is Hyundai produces cars of the highest quality. kept in contact with the car surfaces by mois- o If you live in a high-corrosion area — where However, this is only part of the job.
Page 153: Washing And Waxing
Don't rub, this can These are available at your Hyundai dealer or damage the finish. auto parts outlet. Don't use strong household...
Page 154: Cleaning The Interior
E030B01A-AAT serve the appearance of the bumpers on your line, solvent, paint thinner or other strong clean- Spot Cleaning Hyundai. They are: ers. Don't use gasoline, strong solvents or corro- o Be careful not to spill battery electrolyte or sive cleaning agents. These can damage the hydraulic brake fluid on the bumpers.
Page 155 Apply If you have any questions about the care of your the foam following the manufacturer's direc- car, consult your Hyundai dealer. tions, then rub in overlapping circles. Do not add water. These cleaners work best when the carpet is kept as dry as possible.
Page 156 5. VEHICLE MAINTENANCE REQUIREMENTS Maintenance intervals ..............5-2 Scheduled maintenance ..............5-4 Maintenance under severe usage conditions ........5-6 Explanation of scheduled maintenance items ........5-7 efhma-5.p65 9/24/04, 11:29 AM...
Page 157: Vehicle Maintenance Requirements
These are the regular checks you should per- Service Requirements adjustments and replacements that are listed in form when you drive your Hyundai or you fill the To ensure that you receive the greatest number the maintenance charts starting on page 5-4.
Page 158: Scheduled Maintenance
5- 3 VEHICLE MAINTENANCE REQUIREMENTS F020A02Y-AAT SCHEDULED MAINTENANCE REQUIREMENTS o Inspection should be performed any time a malfunction is experienced or suspected. o Receipts for all emission control system services should be retained to demonstrate compliance with conditions of the emissions system warranty.
Page 159 5- 4 VEHICLE MAINTENANCE REQUIREMENTS F030A01A-AAT SCHEDULED MAINTENANCE The following maintenance services must be performed to ensure good emission control and performance. Keep receipts for all vehicle emission services to protect your warranty. Where both mileage and time are shown, the frequency of service is determined by whichever occurs first. F030B02Y-AAT R :Replace I : Inspect and, after Inspection, clean, adjust, repair or replace if necessary.
Page 160 5- 5 VEHICLE MAINTENANCE REQUIREMENTS F030C10Y-AAT R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MILES X 1000 22.5 37.5 52.5 67.5 82.5 97.5 112.5 127.5 142.5 DESCRIPTION KILOMETERS X 1000 MONTHS GENERAL ITEMS DRIVE BELT 2.4DOHC (ALT, W/PUMP) 2.7V6 ( ALT, P/STR'G, A/CON)
Page 161: Maintenance Under Severe Usage Conditions
5- 6 VEHICLE MAINTENANCE REQUIREMENTS F040A06Y-AAT MAINTENANCE UNDER SEVERE USAGE CONDITIONS The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MAINTENANCE MAINTENANCE...
Page 162: Explanation Of Scheduled Maintenance Items
Air cleaner filter o Vacuum, Crankcase required. Ventilation Hoses A Genuine Hyundai air cleaner filter is recom- mended when filter is replaced. F060C01A-AAT Inspect the surface of hoses for evidence of o Fuel Filter heat and/or mechanical damage.
Page 163 Steering Gear Box, Linkage & Boots/ GENUINE ATF SP III, DIAMOND ATF SP III, SK Lower Arm Ball Joint, Upper Arm Ball ATF SP III or other brands approved by Hyundai Joint Motor Co., when adding or changing fluid. Using...
Page 164 5- 9 VEHICLE MAINTENANCE REQUIREMENTS F070N01A-AAT o Power Steering Pump, Belt and Hoses Check the power steering pump and hoses for leakage and damage. Replace any damaged or leaking parts immediately. Inspect the power steering belt for evidence of cuts, cracks, ex- cessive wear, oiliness and proper tension.
Page 165 6. Do-It-Yourself Maintenance Engine compartment ................6-2 General checks ................6-4 Checking the engine oil ..............6-5 Changing the oil and filter ..............6-6 Checking and changing the engine coolant........6-7 Spark plugs ..................6-9 Changing the air cleaner filter ............6-11 Checking the transaxle oil (Manual) ..........6-12 Checking the transaxle fluid (Automatic) ........
Page 166: Do-It-Yourself Maintenance
6- 2 DO-IT-YOURSELF MAINTENANCE G010A02Y-GAT ENGINE COMPARTMENT (2.4 DOHC) HEF-064 1. Engine oil filler cap 6. Windshield washer fluid reservoir 10.Automatic transaxle fluid level dipstick 2. Brake Booster 7. Power steering fluid reservoir (If installed) 3. Brake fluid reservoir 8. Engine oil level dipstick 11.Radiator cap 4.
Page 167 6- 3 DO-IT-YOURSELF MAINTENANCE G010B03Y-AAT ENGINE COMPARTMENT (2.7 V6 Delta) G010B04Y 1. Air cleaner 6. Engine oil level dipstick 10.Radiator cap 2. Brake fluid reservoir 7. Engine cover 11.Battery 3. Brake booster 8. Engine oil filler cap 12.Coolant reservoir cap 4.
Page 168: Engine Compartment
Seat belt condition and operation o Sunvisor operation If you notice anything that does not operate correctly or appears to be functioning incor- rectly, inspect it carefully and seek assistance from your Hyundai dealer if service is needed. efhma-6.p65 9/24/04, 11:30 AM...
Page 169: Checking The Engine Oil
6- 5 DO-IT-YOURSELF MAINTENANCE G030A01A-AAT G030B01O-AAT G030C02A-AAT CHECKING THE ENGINE OIL Recommended Oil To Check the Oil Level Engine oil is essential to the performance and service of the engine. It is suggested that you check the oil level at least once a week in normal use and more often if you are on a trip or driving in severe conditions.
Page 170: Changing The Oil And Filter
6- 6 DO-IT-YOURSELF MAINTENANCE G030D01A-AAT G040A03A-AAT 2. Open the hood and remove the engine oil Adding Oil CHANGING THE OIL AND FILTER filler cap. 3. Slide underneath the car and loosen the DOHC DOHC drain plug by turning it counterclockwise with a wrench of the proper size.
Page 171: Checking And Changing The Engine Coolant
6- 7 DO-IT-YOURSELF MAINTENANCE 5. Remove the oil filter by turning it counter- NOTE: G050A01A-AAT CHECKING AND CHANGING THE EN- clockwise with a oil filter wrench of the proper Always dispose of used engine oil in an size. A certain amount of oil will come out environmentally acceptable manner.
Page 172 If the level drops again, visit maintained with the correct concentration and cooling system in your car. Then, following your Hyundai dealer for an inspection and type of engine coolant to prevent freezing and the manufacturer's directions on the engine diagnosis of the reason.
Page 173: Spark Plugs
Hyundai. The use of 5. Start the engine, top off the radiator with other spark plugs can result in loss of perfor- water and then add coolant to the reservoir mance, radio interference or engine damage.
Page 174 2.7L Engines) should be changed by an Check to be sure it has snapped into place 5. When preparing to remove the old spark authorized Hyundai dealer. and can’t fall off. plug, guide the socket down over the spark plug, being careful not to damage the ce- 3.
Page 175: Changing The Air Cleaner Filter
If the wipers continue to streak or smear the whenever the washer system is in more fre- its place. glass, replace them with genuine Hyundai re- quent use. placement parts or their equivalent. The capacity of the washer reservoir is 3.2 U.S.
Page 176: Checking The Transaxle Oil (Manual)
Section G110B04A-AAT Recommended Fluid Your Hyundai automatic transaxle is specially Recommended Oil designed to operate with HYUNDAI GENUINE Use only HYUNDAI GENUINE PARTS MTF ATF SP III DIAMOND ATF SP-III SK ATF SP III 75W/85 (API GL-4) or equivalent in the manual or other brands approved by Hundai Motor Co,.
Page 177 CAUTION: Use of aftermarket ATF additives may cause damage to the automatic transaxle. Only use HYUNDAI GENUINE ATF SP III, DIA- MOND ATF SP III, SK ATF SP III or other brands approved by Hyundai Motor Co., If you are having your vehicle serviced at a facility other than a Hyundai dealer, verify ATF is used for your vehicle.
Page 178: Checking The Brakes
"MIN" mark, carefully add fluid to bring it up to they be checked and inspected by your "MAX". Do not overfill. Hyundai dealer. The brakes should be checked and inspected for wear at those intervals specified in the vehicle mainte- G120E02A-AAT nance schedule in Section 5.
Page 179: Air Conditioning Care
Fluid loss indicates a leak in the clutch system which should be inspected and repaired imme- The air conditioning condenser (and engine diately. Consult your Hyundai dealer. radiator) should be checked periodically for accumulation of dirt, dead insects, leaves, etc.
Page 180 10 minutes each week. This is particularly finger, you should not be able to deflect this belt specified, have it inspected by your Hyundai important during cool weather when the air anymore than 1/3 of an inch. If you have the dealer and adjusted or repaired if necessary.
Page 181 110 lbs (50 kg, 490 N). The brake pedal clear- Hyundai dealer and adjusted or repaired if resistance. This is the brake pedal free-play. ance is the distance from the top surface of the necessary.
Page 182: Checking Drive Belts
If this ever happens, other parts of the engine. After a belt is replaced, have a Hyundai dealer determine the cause, the new belt should be adjusted again after two repair the system and replace the fusible link.
Page 183 3. Be sure to check all other fuses even if you rinse your eyes by using a sponge or soft serious and should be referred to a Hyundai find one that appears to have burned out. cloth saturated with water.
Page 184 6- 20 DO-IT-YOURSELF MAINTENANCE While batteries are being charged (either by a G220A01A-AAT G230A03A-AAT CHECKING ELECTRIC COOLING POWER STEERING FLUID LEVEL battery charger or by the vehicle's generator), they produce explosive gases. Always ob- FANS serve these warnings to prevent injuries from occurring: o Charge batteries only in a well ventilated WARNING:...
Page 185 If you desire additional information about main- High Beam taining and servicing your Hyundai, you may purchase a factory Shop Manual at your Hyundai dealer's parts department. This is the same manual used by dealership technicians and while it is highly technical it can be useful in obtaining a better understanding of your car and how it works.
Page 186 6- 22 DO-IT-YOURSELF MAINTENANCE High Beam High Beam HEF-226 HEF-225 1FJB5036 Low Beam Low Beam WARNING: This halogen bulb contains gas under pres- sure and if impacted could shatter, result- ing in flying fragments. Always wear eye protection when servicing the bulb. Protect the bulb against abrasions or scratches and against liquids when lighted.
Page 187 6- 23 DO-IT-YOURSELF MAINTENANCE G270B01Y-AAT High Beam Front turn signal Light HEF-227 HEF-223 3. Replace to the new bulb. Low Beam HEF-221 1. Take off the headlight module to remove three bolts with a spanner. HEF-231 6. Replace to the new bulb. HEF-222 2.
Page 188 6- 24 DO-IT-YOURSELF MAINTENANCE G270D02Y-AAT (1) Trun signal light Rear Combination Light (2) Stop/Tail light (3) Back-up light G270E02Y-GAT Luggage Compartment Light 1. Open the trunk lid. Screwdriver G270E02L 3. Disconnect the power cord. HEF-242 1. Remove the cover with a Phillips screw driver.
Page 189 6- 25 DO-IT-YOURSELF MAINTENANCE G270G01TB-GAT G270H01Y-GAT G290A05Y-AAT Interior Light (If installed) License plate Light HEADLIGHT AIMING ADJUSTMENT Vertical aiming HEF-235 HEF-232 G290A04Y Before performing aiming adjustment, make 1. Reomove the cover with a flat blade screw 1. Reomove the cover with a philips screw sure of the following.
Page 190 Distance between each headlight center : WARNING: Low Beam: 51.97 in. (1,320mm) Horizontal aiming should be adjusted by an High Beam: 39.05 in. (992mm) authorized Hyundai Dealer. Cut-off line "L" Distance between the headlights and the wall Ground that the lights are tested against : 118 in. (3,000...
Page 191 6- 27 DO-IT-YOURSELF MAINTENANCE G280A04Y-AAT (High) (Low) G280A04Y Part Name Wattage Part Name Wattage Head Light (High/Low) 55(H1)/55(H7) High Mounted Rear stop Light 3.2 (LED type) With Sunroof Map Light Luggage Compartment Light Without Sunroof Rear Combination Light Interior Light Stop / Tail Light 27/8 Front Fog Light (If installed)
Page 192: Junction Box Description
6- 28 DO-IT-YOURSELF MAINTENANCE G200C03Y-GAT DESCRIPTION FUSE RATING PROTECTED COMPONENTS JUNCTION BOX DESCRIPTION COND FAN Condenser fan PWR WIND Power window Under hood junction box ABS 2 IGN SW-1 Ignition switch ABS 1 IGN SW-2 Ignition switch RAD FAN MTR Radiator fan motor FUEL PUMP Fuel pump...
Page 193: Instrument Panel Junction Box
6- 29 DO-IT-YOURSELF MAINTENANCE G200D02Y-GAT Instrument panel junction box DESCRIPTION FUSE RATING PROTECTED COMPONENTS RR HTD IND Rear window defroster, Outside rear view mirror heater HAZARD Hazard light, Turn signal lights RR FOG Rear fog light A/CON Air conditioning system ETACS ETACS, Keyless entry system, Door lock system DR LOCK...
Page 194: Emission Control System
7. EMISSION CONTROL SYSTEM Emission control system ..............7-2 EGR system ..................7-2 Catalytic converter ................7-3 efhma-7.p65 9/24/04, 11:31 AM...
Page 195 (Including ORVR: Onboard Refueling emissions while maintaining good vehicle tained by an authorized Hyundai dealer in ac- Vapor Recovery) System performace. cordance with the maintenance schedule in this manual.
Page 196 7- 3 EMISSION CONTROL SYSTEMS H020A01A-AAT o Do not stop your Hyundai over any com- CATALYTIC CONVERTER bustible material such as grass, paper, WARNING: leaves or rags. These materials might o Use unleaded fuel only. contact the hot catalytic converter and a o Maintain the engine in good operating fire might result.
Page 197: Consumer Information, Reporting Safety Defects
Tire traction ..................8-10 When to replace tires ..............8-10 Tire maintenance ................8-11 Spare tire and tools ................ 8-11 Warranties for Your Hyundai Vehicle ..........8-11 Consumer Information ..............8-11 Reporting Safety Defects ............... 8-13 Binding Arbitration of Warranty Claims .......... 8-14...
Page 198: Consumer Information, Reporting Safety Defects & Binding Arbitration Of Warranty Claims
TIRE INFORMATION the number of people that can be in your 1. On the bulkhead between the engine and The tires supplied on your new Hyundai passenger compartments. vehicle and vehicle capacity weight. 2. On the left top side of the instrument panel...
Page 199 8- 3 CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS o Check the pressure of your spare tire each time you check the pres- WARNING: sure of other tires. o Lower-than-recommended tire o Never overload your vehicle. Be pressures cause uneven tread especially careful about overload- wear, poor handling, poor fuel...
Page 200: Checking Tire Inflation Pressure
8- 4 CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS I035A01JM-AAT sary. If the pressure is low, add air until I030B01Y-AAT CHECKING TIRE INFLATION PRES- TIRE SIDEWALL LABELING you reach the recommended amount. SURE If you overfill the tire, release air by Check your tires once a month or more.
Page 201 8- 5 CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS 1. Manufacturer or Brand name o H: Speed Rating. The speed rating o Four numbers represent the week o Manufacturer or Brand name is denotes the speed at which a tire is and year the tire was built.
Page 202: Tire Terminology And Definitions
8- 6 CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS 6. Maximum load rating I030D01JM-AAT Cold Tire Pressure: The amount of air TIRE TERMINOLOGY AND DEFINI- This number indicates the maximum pressure in a tire, measured in pounds TIONS load in kilograms and pounds that per square inch (psi) or kilopascals...
Page 203 8- 7 CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS Intended Outboard Sidewall: The side Occupant Distribution: Designated Sidewall: The portion of a tire between of an asymmetrical tire, that must al- seating positions. the tread and the bead. ways face outward when mounted on a Outward Facing Sidewall: The side of Speed Rating: An alphanumeric code...
Page 204: Snow Tires
I040A01S-AAT ALL SEASON TIRES SNOW TIRES of designated seating positions multi- Hyundai specifies all season tires on If you equip your car with snow tires, plied by 150 lbs. (68 kg) plus the rated some models to provide good perfor-...
Page 205: Tire Chains
Use the SAE "S" class or wire & handling and tire wear. The tires on your Hyundai dealer so the cause may be plastic chains. Hyundai were balanced before the car corrected.
Page 206: Tire Traction
When replacing age. tires, never mix radial and bias ply o Wheels that do not meet Hyundai's tires on the same car. If you replace dimensional specifications may radial tires with bias-ply tires, they fit poorly and result in damage to must be installed in sets of four.
Page 207: Tire Maintenance
SHOP MANUAL of the U.S. Department of Transportation. It provides the purchasers and/or prospective A Hyundai Shop Manual is available from your purchasers of Hyundai automobiles with infor- authorized Hyundai dealer. It's written for pro- mation on uniform tire quality grading. Your...
Page 208 8- 12 CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS I130B02A-AAT Traction AA, A, B, C - The traction trolled conditions on a specified indoor Uniform tire quality grading grades, from highest to lowest, are AA, laboratory test wheel. Sustained high Department of Transportation quality A, B, and C.
Page 209: Reporting Safety Defects
CONSUMER INFORMATION, REPORTING SAFETY DEFECTS & BINDING ARBITRATION OF WARRANTY CLAIMS 270 Riverside Parkway, Suite A I130D01A-AAT I130C01A-AAT Hyundai motor vehicles are designed and manu- REPORTING SAFETY DEFECTS Austell, GA 30168 factured to meet or exceed all applicable safety (800) 633-5151 If you believe that your vehicle has a defect standards.
Page 210: Binding Arbitration Of Warranty Claims
Notice must be received within 90 days All other arbitration costs shall be borne after you purchase your vehicle. by Hyundai Motor America. You are not responsible to pay any of the costs Hyundai incurs. This Binding Arbitration Agreement shall not deprive you of any remedies avail- able to you under applicable law.
Page 211: Vehicle Specifications
9. VEHICLE SPECIFICATIONS Measurement ...................9-2 Engine ....................9-3 Lubrication chart ................9-4 efhma-9.p65 9/24/04, 11:31 AM...
Page 212 9- 2 VEHICLE SPECIFICATIONS J010A03Y-AAT J040A03Y-AAT MEASUREMENT ELECTRICAL Overall length 186.9 in. (4747 mm) Item 2.4L 2.7L (V6) Overall width 71.7 in. (1820 mm) Battery MF 60AH (12V) MF 68 AH (12V) Overall height (unladen) 55.9 in. (1422 mm) Generator 95A (13.5 V) Wheel base 106.3 in.
Page 213 9- 3 VEHICLE SPECIFICATIONS J070A03Y-AAT ENGINE SPECIFICATIONS ITEMS 2.4L (DOHC) 2.7L (V6) Engine Type 4-Cyl., In-line DOHC 6-Cyl., V-type DOHC Bore x Stroke. in. (mm) 3.41x 3.94 (86.5 x 100) 3.41 x 2.95 (86.7 x 75.0) Displacement. cc 2,351 2,656 Firing order 1 - 3 - 4 - 2 1 - 2 - 3 - 4 - 5 - 6...
Page 214 Manual HYUNDAI GENUINE PARTS MTF 75W/85 (API GL-4) 2.2 (1.8, 2.1) Auto HYUNDAI GENUINE ATF SP III, DIAMOND ATF SP III, SK ATF SP III or other brands 8.2 (6.9, 7.8) approved by Hyundai Motor Co., 7.7 (6.4, 7.3) 9.0 (7.6, 8.6)
Page 215 10.INDEX efhma-10.p65 9/24/04, 11:32 AM...
Page 216 Battery ..................2-14, 6-19 Corrosion protection Brake Cleaning the interior ............... 4-4 Anti-lock system ................2-10 Protecting your Hyundai from corrosion ........4-2 Checking the brakes ..............6-14 Washing and waxing ..............4-3 Fluid ....................6-14 Cruise Control ................... 1-64 Pedal clearance ................
Page 217 10- 3 INDEX Emission Control System ..............7-2 General Everyday Checks ..............6-4 Engine Glove Box ..................1-51 Before starting the engine .............. 2-3 Compartment (2.4 DOHC) ............6-2 Compartment (2.7 V6) ..............6-3 Hazard Warning System ..............1-45 Coolant ................... 6-7 Headlight ..................
Page 218 10- 4 INDEX Key ..................... 1-3 Radio (H240, H260, H290) ........... 1-82, 1-87, 1-92 If you lose your keys ..............3-13 Rear Seat Positions ..................2-3 Fold down ..................1-15 Rear View mirror ................1-53 Rear Window Defroster Switch ............1-45 Maintenance Intervals Reporting Safety Defects ..............
Page 219 10- 5 INDEX Tachometer ..................1-40 Vehicle Identification Number ............. 8-2 Theft-Alarm system ................1-6 Vehicle load limit ................2-19 Tires Balancing ..................8-9 Chains .................... 8-9 Warning Lights ..............1-36 ~ 1-39 Changing a flat tire ................. 3-5 Windows If you have a flat tire ...............
Page 220 2005 efhma-11.p65 9/24/04, 11:32 AM...
Page 221 “N” (Neutral) position. Then US.gal (Imp.gal., liter) 17.2 (14.3, 65) check the level of fluid on the dipstick. Use only HYUNDAI GENU- INE ATF SP III, DIAMOND ATF SP III, SK ATF SP III or other brands TIRE PRESSURE: approved by Hundai Motor Co.,...

Hyundai Sonata Owner's Manual

1.Fea

2. Driving Your Hyundai

3. What to Do in an Emergency

4. Corrosion Prevention & Appearance Care

5. Vehicle Maintenance Requirements

6. Do-It-Yourself Maintenance

8. Consumer Information, Reporting Safety Defects & Binding Arbitration of Warranty Claims

Quick Links

Chapters

Need help?

Questions and answers

Related Manuals for Hyundai Sonata

Summary of Contents for Hyundai Sonata

Table of Contents
