Snap-On ELECTRIC PRESSURE WASHER Instruction Manual

1650 psi / 113.8 bar electric pressure washer
Hide thumbs
Table of Contents

Advertisement

Quick Links

1650 PSI / 113.8 bar
ELECTRIC

PRESSURE WASHER

INSTRUCTION MANUAL

For consumer questions or comments,
please call 1-888-278-8092.
Days/Hours of operation:
9am-7pm EST Monday - Friday
10am-6pm EST Saturday - Sunday
English and Spanish Speaking
Customer Service Representatives are
Available.
THIS
MANUAL
CONTAINS
MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USE, READ CAREFULLY AND
UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS. FAILURE TO DO SO
COULD RESULT IN SERIOUS PERSONAL INJURY AND/OR PROPERTY DAMAGE.
IF YOU SHOULD HAVE ANY QUESTIONS OR EXPERIENCE A PROBLEM WITH YOUR SNAP-ON
PRODUCT, DO NOT RETURN THIS PRODUCT TO THE STORE. PLEASE CALL OUR CUSTOMER SERVICE
DEPARTMENT AT 1-888-278-8092. BEFORE YOU CALL, HAVE THE FOLLOWING INFORMATION
AVAILABLE:
MODEL
No.,
REPRESENTATIVE CAN RESOLVE YOUR PROBLEM OVER THE PHONE.
IMPORTANT
INFORMATION
DATE
PURCHASED
AND
ITM./ART. 642672
REGARDING
SAFETY, OPERATION,
STORE
LOCATION. AN
ALLTRADE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELECTRIC PRESSURE WASHER and is the answer not in the manual?

Questions and answers

Related Manuals for Snap-On ELECTRIC PRESSURE WASHER

Summary of Contents for Snap-On ELECTRIC PRESSURE WASHER

  • Page 1: Pressure Washer

    UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS. FAILURE TO DO SO COULD RESULT IN SERIOUS PERSONAL INJURY AND/OR PROPERTY DAMAGE. IF YOU SHOULD HAVE ANY QUESTIONS OR EXPERIENCE A PROBLEM WITH YOUR SNAP-ON PRODUCT, DO NOT RETURN THIS PRODUCT TO THE STORE. PLEASE CALL OUR CUSTOMER SERVICE DEPARTMENT AT 1-888-278-8092.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS CONGRATULATIONS! ......... 1 INTRODUCTION .

  • Page 3: Introduction

    INTRODUCTION This instruction manual is intended for your benefit. Please read and follow the safe- ty, installation, maintenance and troubleshooting steps described within to ensure your safety and satisfaction. The contents of this instruction manual are based upon the latest product information available at the time of publication. The manufactur- er reserves the right to make product changes at any time without notice.
  • Page 4 CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. CAUTION used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may result in property damage. NOTE provides additional information that is useful for proper use and maintenance of this tool.

  • Page 5: Important Information About This Manual

    IMPORTANT INFORMATION ABOUT THIS MANUAL Improper and unsafe use of this Pressure Washer can result in death, fire and/or bodily injury. This instruction manual contains important information about product safety. Keep the instruction manual available for others to read before they use the Pressure Washer. Improper maintenance and operation are responsible for the majority of accidents involving Pressure Washers.

  • Page 6: Safety Warnings

    SAFETY WARNINGS READ ALL SAFETY WARNINGS BEFORE USING PRESSURE WASHER. GENERAL SAFETY RULES People with electronic devices, such as pacemakers, should consult their physician(s) before using this product. Operation of electrical equipment in close proximity to a heart pacemaker could cause interference or failure of the pacemaker. WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

  • Page 7: Safety Rules For Pressure Washers

    Always make sure the tool is in the OFF position when making adjustments, changing parts, or performing any maintenance. Service must be performed only by qualified repair personnel. Service or maintenance by unqualified personnel may result in a risk of injury. Do not use the tool if the power switch does not turn it “ON”...
  • Page 8 NEVER place hands in front of nozzle. NEVER attempt to attach or remove spray wand or hose fittings while Pressure Washer system is pressurized. DO NOT treat fluid injection injuries as a simple cut. Seek immediate med- ical attention. HIGH VELOCITY fluid spray can cause objects to break, propelling particles at high speeds.
  • Page 9 NEVER cut or splice the power cord or extension cords. DO NOT spray electrical apparatus and wiring. WEAR rubber-soled tennis shoes or other footwear that provides some insula- tion when operating the Pressure Washer. COLD water use only. FOR EITHER INDOOR OR OUTDOOR USE. Store indoors. DO NOT direct spray toward electrical outlets, switches or products connected to electrical service.

  • Page 10: Ground-Fault Circuit - Interrupter Protection

    GROUND-FAULT CIRCUIT - INTERRUPTER PROTECTION This Pressure Washer is provided with a Ground-Fault Circuit- Interrupter (GFCI) built into the plug of the power supply cord. This device provides additional protection from the risk of electric shock. Should replacement of the plug or cord become necessary, use only identical replacement parts that include GFCI protection.

  • Page 11: Extension Cord Usage

    UNGROUNDED AC OUTLET GROUNDING ADAPTER GROUNDED AC OUTLET POWER CORD PLUG GROUNDING PIN GROUNDING PIN POWER CORD PLUG GROUNDING RIGID EAR COVERPLATE MOUNTING SCREW Figure 1 EXTENSION CORD USAGE Use only 3-wire extension cords that have 3-prong grounding-type plugs and 3-pole cord connectors that accept the plug from the product.

  • Page 12: Functional Description

    FUNCTIONAL DESCRIPTION 16 17 PRESSURE WASHER FEATURES: 12. Garden Hose Coupling/Water Inlet 2. Adjustable Nozzle 13. Detergent Tank Lid 3. Pressure Adjust Collar 14. Electric Cord Holder 4. Wand 15. Gun Holder (Top) 5. Trigger 16. GFCI Power Cord 6. Trigger Safety Lock 17.

  • Page 13: Assembly & Setup

    ASSEMBLY & SETUP This Pressure Washer requires some assembly. If you have any problems with the assembly of your Pressure Washer, please call the Pressure Washer helpline at 1-888-278-8092. If calling for assistance, please have the model, revision, and seri- al number from the data tag available.

  • Page 14: Operating The Pressure Washer

    1. Before connecting the garden hose to the Pressure Washer, connect the gar- den hose to the water source and run water through the hose to flush out any debris. Shut off the water at the source. 2. Attach garden hose to the Pressure Washer coupling inlet at the lower front of the unit.
  • Page 15 OPERATING THE PRESSURE WASHER ALWAYS wear approved safety glasses when operating Pressure Washers. Spray can splash back or propel objects, including incorrectly attached accessories. The high pressure stream of water that this equipment produces can cut through skin and its underlying tissues, leading to possible amputation. Spray gun traps high water pressure, even when the motor is stopped and water is disconnected, which can cause injury.

  • Page 16: Water Flow Adjustment

    WATER FLOW ADJUSTMENT ADJUSTING FOR FAN PATTERN The angle of spray coming out of the nozzle may be adjusted by rotating the front of the nozzle (cone). This will vary the spray pattern from approximately a 0° narrow high impact stream (by turning the nozzle fully to the left) to a 60° wide fan spray (by turning the nozzle fully to the right).

  • Page 17: Shutting Down Pressure Washer

    • If you get spray nozzle too close, especially using high pressure mode, you may damage surface being cleaned. • DO NOT get closer than 6 inches when cleaning tires. SHUTTING DOWN THE PRESSURE WASHER The Pressure Washer motor runs only when the trigger is engaged. To shut off the Pressure Washer: 1.

  • Page 18: Maintenance

    Wetting the surface first is not recommended, as it dilutes the detergent and reduces its cleaning ability. 7. Allow detergent to "soak in" for 3-5 minutes before washing and rinsing. Reapply as needed to prevent surface from drying. Do Not allow detergent to dry on surface (prevents streaking).
  • Page 19 Some adjustments will need to be made periodically to properly maintain the Pressure Washer. All service and adjustments should be made at least one time each season. It is important that the maintenance chart below be followed. MOVING AND STORAGE After each application or winter storage follow these instructions: 1.

  • Page 20: Troubleshooting Guide

    2. Set the nozzle to high pressure setting to make the nozzle hole accessible. 3. Clear blockage in nozzle by inserting the nozzle cleaning needle (provided) through center hole. 4. After cleaning, remove the needle from nozzle and store for future use. LUBRICATION This Pressure Washer does not require any maintenance on the pump or motor.
  • Page 21 TROUBLESHOOTING GUIDE Problem Probable Cause Solution 5. No AC power at the 5. Main circuit breaker is outlet. tripped or outlet is faulty. 6. Main voltage supply is 6. Make sure main supply too low. voltage is adequate (See specifications). 7.
  • Page 22 TROUBLESHOOTING GUIDE Problem Probable Cause Solution 1. Extension cord is too 1. Remove extension long or wire size too cord or use proper small. extension cord (See instructions). Motor stops suddenly 2. Thermal safety switch 2. Make sure main supply has tripped due to voltage corresponds to overheating and over-...
  • Page 23 TROUBLESHOOTING GUIDE Problem Probable Cause Solution 1. Clogged Nozzle. 1. Clean Nozzle (See instructions). 2. Wand is attached 2. See instructions. incorrectly. 3. Clogged filter. 3. Clean filter (see instructions) 4. Kink in the Garden 4. Unwrap the Garden Hose or Hose is Hose and lay it out flat wrapped on a storage to ensure that there...
  • Page 24 TROUBLESHOOTING GUIDE Problem Probable Cause Solution 5. Water supply is over 5. Provide cooler water I00°F / 37.7˚ C supply. 6. Water inlet filter is 6. Clean the Screen filter clogged. (see instructions). 7. Water leaking from 7. Stop water from either Hose or Unit.

  • Page 25: Specifications

    TROUBLESHOOTING GUIDE Problem Probable Cause Solution 1. Disconnected or 1. Call Customer Kinked Detergent Pick Service: Detergent Leak from inside up Tube. 1-888-278-8092. the unit or won’t hold 2. Chemical Tank Nipple 2. Call Customer detergent Broken. Service: 1-888-278-8092. 1. A small amount of 1.

  • Page 26: Year Limited Warranty

    SPECIAL WARRANTY NOTE FOR COMMERCIAL OR RENTAL USE: The above warranty for this SNAP-ON™ Pressure Washer shall be effective for only 90 days from the original date of purchase if this tool is used for any COMMERCIAL OR RENTAL PURPOSE.
  • Page 27 The use of other than genuine Snap-On™ Repair Parts will VOID the warranty. WARRANTY DISCLAIMERS EXCLUSION AND DISCLAIMER OF ALL OTHER EXPRESS WARRANTIES, GUAR-...
  • Page 28 BUYER, ARE HEREBY EXPRESSLY EXCLUDED AND DISCLAIMED BY ALLTRADE AND/OR ITS REPRESENTATIVES. PURCHASER KNOWINGLY AND WILLINGLY WAIVES ANY AND ALL SUCH WARRANTIES AND RIGHTS, CLAIMS AND/OR CAUSE OF ACTION ARISING THEREFROM OR BASED THEREON. PURCHASER'S SOLE AND EXCLUSIVE REMEDY IS AS STATED ABOVE. EXCLUSION AND DISCLAIMER OF ALL IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
