254
Note: Do not attempt to mix stud-piloted wheels or fasteners with
hub-piloted wheels or fasteners.
Note: Do not change from aluminum wheels to steel wheels or
vice-versa without changing the mounting hardware required or, with
flange nut mounting systems, changing the hub and stud assembly.
Consult your dealer or wheel or rim distributor before attempting any
wheel or fastener changes.
TECHNICAL SPECIFICATIONS
Wheel Lug Nut Torque Specifications
Note: Do not use lubrication on dry threads. Where excessive corrosion
exists, you can apply a light coat of lubricant on the first three threads
of the stud bolt. Keep lubricant away from the:
• Hex nut and rim clamp contact surfaces.
• Cap nut ball face and ball seat on the disc wheel.
• Flange nut washer surface and flat on the disc wheel.
Size
22 mm
2015 F-650/750 (f67)
Owners Guide gf, 2nd Printing, April 2014
USA (fus)
Wheels and Tires
Nut Mounting
Flange 450–500
Torque
ft-lb N•m
610–678
