Panasonic WV-CW314L Speci?Cations

Weather Resistant Day/Night Fixed Camera with IR LED and advanced features

Key Features

• High resolution: 650 TV lines
• High sensitivity with Day/Night function: 0.08 lx (Color), 0 lx, (B/W,
LED on) at F1.3. IR cut filter switches on/off to enhance the
sensitivity in B/W mode.
• IR LED equipped: The equipped infrared LED makes it possible to
take pictures at 0 (zero) lx.
IR LED irradiation distance 50 m
• LED AUTO mode : Control to the best brightness level
automatically when the IR LED is ON.
• ABS (Adaptive Black Stretch) enhances visibility of dark area
without degrading image quality in bright area.
• ABF (Auto Back Focus) ensures easy installation.
• Various adjustment features including BLC (Back-Light
Compensation), ATW (Auto Tracing White Balance) and ALC
(Automatic Light Control)
• 2.8 ~ 10 mm 3.6x Varifocal Auto Iris lens
• 16 axis matrix color compensation function enables wider range of
natural color adjustment.
• Adaptive Digital Noise Reduction: Integration of 2D-DNR and
3D-DNR ensures noise reduction in various conditions.
• Electronic sensitivity enhancement: Auto (Up to 32x) / Fix (Up to 512x)
• Electronic shutter from 1/100 to 1/120,000 sec.
• Digital zoom: Up to 2x
• Auto Image Stabilizer for applications where vibration or wind is a concern
• Internal synchronization
• Over the coaxial cable data communication
• 16 alphanumerics camera title display
• Multi language: English, French, Italian, Spanish, German, Russian,
Chinese, Japanese
• Lens Distortion Correction
Weather Resistant IR LED Day/Night
WV-CW314L
• On screen display menu
• ELC mode for easier lens adjustment upon installation
• IP66 rated water and dust resistant. Compatible with IEC60529
measurement standard.

Standard Accessories

Installation Guide.......................................................................................................1 pc.
Desiccant instruction for use....................................................................................1 pc.
CD-ROM*...................................................................................................................1 pc.
The following is used during installation procedures:
Waterproof tape ........................................................................................................1 pc.
Desiccant ...............................................................................................................1 pc.
Installation template label..........................................................................................1 pc.
Spring washer............................................................................................................1 pc.
*The CD-ROM contains the operating instructions (PDF).
Fixed Camera
WV-CW314L
NTSC
(24 V AC or 12 V DC)
