HeatMat Programmable Thermostat User Manual

U S E R M A N U A L

Programmable Thermostat

57479B 11/06 - (BJ)
Introduction
The thermostat is capable of switching on your heating system at pre determined times on different days of the week. It is possible to set 4 periods
called events each day with different temperatures. From the factory, a default schedule is programmed suitable for most installations. Unless you change these
settings the thermostat will operate to this default program.
Working with lower temperatures during times that the room is unoccupied could lower your energy costs without reducing the comfort. The thermostat has an
adaptive function that automatically changes the start time of a heating period so that the desired temperature is reached at the time that you set. After 5
days the adaptive function has learned when the heating must be switched on.
The thermostat has a pin button marked R, allowing you to reset the thermostat to factory settings. These are listed at the end of this manual with space for
you to record your own weekly schedule.
The display is backlit when operating the buttons. The heating element is switched off when the light is on in the display.
The heating system can be switched off on the built-in interrupter. The Microprocessor taking care of the time will still be supplied with power whereby time
and day will be maintained. When the heating is required and the thermostat is switched on, it will continue the 4-event programme based on present time
and day.
1. Getting started
Buttons
G
A
B
C
R
A: B: C:
Pin button Reset to
On/off
adjust of factory
clock setting
E: F: G:
OK - Adjustment Display
accept up
Setting the thermostat into operation
First time power is connected the clock and day will be flashing and must be set. If you need to adjust
the time of the thermostat at a later date, insert a pin into the hole
press for 3 seconds. Adjustment must be made for summer and winter time.
☞
Press the UP (
the correct time and press OK button (
☞
Then press the UP (
select the correct day and press OK (
Then press the UP (
☞
select the requested temperature in manual mode
and press OK (
• To activate the 4 event clock mode press the OK
• The temperature set in room temp - This can be changed to floor sensor only
if the programmer is outside the room, in a cupboard or in a warm room.
See: 4. Advanced Optional Settings, APP
F
E
D
D:
Adjustment
down
for setting of time and day and
) or DOWN ( ) buttons to select
).
) or DOWN ( ) button to
) button.
) or DOWN ( ) button to
) button.
( ) button once.
Display symbols
H
I
J
K
H: I: J:
Clock Manual Time and
function mode temperature
L: M: N:
Heating on %
Monitoring
of switch-on
time
1-7
°C
N
M
L
K:
Day number
4-event symbol
Wake Out
Night
Home
1
