SERVICE MANUAL
Level &2
RM-230
CONFIDENTIAL
Copyright © 2007 NOKIA. All rights reserved.
RM-302
Transceiver characteristics:
Band:
EGSM: Quad-band 850/900/1800/1900MHz
WCDMA: 2100MHz
(RM-230 only!)
Display:
LCD: 5.588cm QVGA (2.2") (240x320 pixel); 16M colors
Camera:
Camera: 2.0 Megapixel SMIA95, 4x digital zoom
Operating System:
Series 60
Connections:
Wireless: Bluetooth, IRDA
Connector: Mini USB Connector; AV Connector
Memory:
MicroSD™ (max 4GB)
Transceiver with BP-5M Li-Ion battery pack
Talk time
up to 3.4h
up to 11days
N5700 RM-230 / RM-302
Service Manual Level &2
Standby
Note
Depends on network
parameters
ISSUE 2
