SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
SPLIT-TYPE, AIR CONDITIONERS

SERVICE MANUAL

Indoor unit
[Model names]
[Service Ref.]
PKA-RP35HAL
PKA-RP35HAL
PKA-RP50HAL
PKA-RP50HAL
INDOOR UNIT
CONTENTS
1. REFERENCE MANUAL ................................... 2
2. SAFETY PRECAUTION ................................... 3
3. PART NAMES AND FUNCTIONS ................... 4
4. SPECIFICATIONS ............................................ 6
5. NOISE CRITERION CURVES .......................... 7
6. OUTLINES AND DIMENSIONS ....................... 8
7. WIRING DIAGRAM .......................................... 9
9. TROUBLESHOOTING .................................... 11
10. SPECIAL FUNCTION ..................................... 26
11. DISASSEMBLY PROCEDURE ....................... 29
PARTS CATALOG (OCB453)
March 2009
No. OCH453
NOTE:
• This manual describes
only service data of the
indoor units.
• RoHS compliant products
have <G> mark on the
spec name plate.
