M707Z M808Z M1010Z
Digital Photo Frame
Owner's Manual
Thank you for purchasing a Micca product. Should you need any
assistance, please contact our technical support before returning the
product to the retailer. Email
support@miccastore.com
Product information, firmware updates, and common questions and
answers can be found at:
http://content.miccastore.com/
Copyright © 2009-2012 Micca, Ltd. All rights reserved.
This manual may not be reproduced in whole or in part
without permission for any purpose other than personal use.
Advertisement
Table of Contents
Related Manuals for Micca M707Z
Summary of Contents for Micca M707Z
- Page 1 M707Z M808Z M1010Z Digital Photo Frame Owner’s Manual Thank you for purchasing a Micca product. Should you need any assistance, please contact our technical support before returning the product to the retailer. Email support@miccastore.com Product information, firmware updates, and common questions and answers can be found at: http://content.miccastore.com/...
- Page 3 Thank you very much for purchasing this digital photo frame. We hope you will enjoy using it to view your treasured photos. This photo frame has the following features: 1.1.1 Highlights M707Z: 7-Inch 800x480 high resolution wide-screen LCD screen M808Z: 8-Inch 800x600 high resolution LCD screen M1010Z: 10-Inch 1024x600 high resolution wide-screen LCD screen...
-
Page 4: Precautions And Maintenance
2 Precautions 2.1 Precautions and Maintenance This product is intended for residential indoor use only. It is not intended for outdoors use, or use in harsh environments, or demanding commercial use. To avoid risk of fire or electric shock, do not expose the unit to moisture or condensation. -
Page 5: Connections And Buttons
3 Connections and Buttons 3.1 Buttons 1. Power 2. Previous or Up 3. Play/Pause or Enter 4. Right (Short Press) or Volume+ (Long Press) 5. Left (Short Press) or Volume- (Long Press) 6. Next or Down 7. Menu (Long Press) or Return (Short Press) Note: The left and right buttons are named in accordance of their function when the user is looking at the photo frame. -
Page 6: Remote Control
3.3 Remote Control Function Power Turn the photo frame on or off Start a slideshow with background music Mute Mutes the sound output. Press again to unmute. Menu Behavior is different depending on context, either brings up an operations menu or displays the main menu. Move cursor up Return Go back to the previous step... -
Page 7: Getting Started
Previous Go to previous photo, music, or video file Next Go to next photo, music, or video file To replace the battery in the remote, place the remote control face down, press down on the ridged area of the battery cover and pull towards you to remove the tray. Place one CR2025 lithium button-cell battery on the tray with the positive “+”... -
Page 8: Viewing Photos
5 Operating Instructions After turning on the photo frame, the main menu will display after a few seconds. If there is a flash memory card or USB flash drive inserted into the photo frame, a slideshow will automatically begin plain. To get back to the main menu, press the “Menu/Return”... -
Page 9: Copying Photos
When viewing photos, the following operations are available using the buttons on the back of the photo frame: Button Description Play/Pause Play or pause the photo slide show. Left Go to the previous photo. Right Go to the next photo. Rotate photo counter-clock wise. -
Page 10: Playing Music
5.6 Playing Music To begin playing music, select the “Music” icon from the main menu. All music files found on the storage device will be displayed in one list. Scroll to the desired music file and press the “Play/Pause/Enter” button to begin playing the music. While playing music, the following operations are available using the buttons on the back of the photo frame: Button... -
Page 11: File Browsing
5.8 File Browsing The “File” icon from the main menu lets users browse the contents of the selected storage device by navigating its folder directory structure. All compatible file types will be displayed while incompatible file types are not displayed. It is possible to copy or delete files using the same methods as described in previous sections. -
Page 12: Detailed Settings
6 Detailed Settings To access the setup menu of the photo frame, turn it on and wait for the main menu to display. Highlight the Setup icon and press “Enter”. The Setup menu has the following settings: Language Changes the operating language of the photo frame. Available Values: English, French, Italian, German, Spanish Photo Sequence Changes the photo playback sequence when displaying slideshows. - Page 13 Available Values: 3/5/15/30 Seconds, 1/5/15/30 Minutes, 1 Hour Photo Effect Applies a special effect to photos when they are displayed. Setting Description Color Photos will be displayed as they are without any special effects. Mono Photos will be displayed as black and white. Sepia Photos will be displayed in sepia tone.
- Page 14 Video Mode Changes the way videos are displayed when they do not perfectly fit the screen of the photo frame. Setting Description Videos are displayed in their native resolution. If they are too Original small, they will appear only in the center portion of the screen. Videos are enlarged to fit the screen but the original aspect ratio Screen of the screen is retained.
- Page 15 Setting Description Status Turn the alarm on or off Number Switch to alarm slot #1 or #2 Hour Set the hour of the alarm Minute Set the minute of the alarm Configure how often the alarm is active: Once: Alarm is active only once. Mode Each Day: Alarm is active every day.
-
Page 16: Troubleshooting Guide
Card Reader: SD/SDHC Up to 32GB USB: USB flash drives up to 32GB Photo Format: JPG Music Format: MP3 up to 320kbps Video Format: AVI MP4 Files, MPEG1/2/4 for video and MP3 for audio LCD Screen: M707Z M808Z M1010Z Size 7-Inch TFT 8-Inch TFT 10.1-Inch TFT... - Page 18 Information in this manual is believed to be accurate and reliable but Micca Ltd assumes no responsibility for its use nor for any infringement of patents or other rights of third parties which may result from the use of this manual or the product.
