TSR Supaslim Combi
Combined Storage and Fan Heater
Assembly Instruction
Manual
Model Nos: 79358S
Cat. Nos:
TSR18CW
This product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC) EN55014, EN60555-2 and EN60555-3.
These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC
© GDC Group Ltd. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing.
A division of the GDC Group Ltd, Millbrook House, Grange Drive, Hedge End, Southampton SO30 2DF
79368S
TSR24CW
Automatic
75772002S 75772003S
TSR18ACW
TSR24ACW
Advertisement
Table of Contents
Related Manuals for Creda Newera TSR18CW
Summary of Contents for Creda Newera TSR18CW
- Page 1 Automatic Model Nos: 79358S 79368S 75772002S 75772003S Cat. Nos: TSR18CW TSR24CW TSR18ACW TSR24ACW This product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC) EN55014, EN60555-2 and EN60555-3. These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC ©...
- Page 2 IMPORTANT NOTES: It is important to read these instructions carefully and also note the information given on the heater itself. As these particular instructions refer to the assembly and installation of a new heater, they should be retained by the installer; not left behind for the user as this would invite the dismantling and servicing by unqualified persons.
- Page 3 PLEASE DON’T TAKE CHANCES Site conditions may vary considerably and Creda cannot recommend the correct wall fixings to be used. It is the responsibility of the installer to ensure that adequate permanent fixing has been achieved. Purely for guidance the suggested fixings are made for certain wall materials but this list is not comprehensive or authoritative.
- Page 4 First, turn carton upside down Open bottom flaps on cartonThe corner fitments contain the fixing kit. Stand the heater against the wall in its intended position. Mark the position of the two outside corners of the wall bracket. Carefully place the heater aside, and remove the wall bracket from the heater by removing the screw at each end.
- Page 5 WALL FIXINGS - VERY IMPORTANT When bracket is securely fixed, replace You must fit a the heater under the bracket angle and retaining screw at align screw holes on heaters ends. There each end of the are two fixing slots at each end of heater, heater.
- Page 6 ENSURE THAT THE CABLES ARE NOT TRAPPED UNDER THE HEATER LEGS MAINS TERMINALS IMPORTANT: For earthing, loosen the earth screws RESTRICTED SUPPLY sufficiently to wrap the mains’ earth wire around it between flat washer and cup washer, and retighten the earthing screw.
- Page 7 WARNING Remove the inner front panel; this carries on it’s inner face the front insulation slab. Handle this with care, the insulation must not be damaged. REMOVE ALL THE PACKING CARDBOARD FROM INSIDE THE STORAGE BRICK COMPARTMENT, IF LEFT INSIDE IT WILL BE SET ON FIRE WHEN THE HEATER IS SWITCHED ON.
- Page 8 Check that the front insulation slab is properly attached to the inner front panel and refit panel (insulation innermost) to the heater by locating its bottom edge behind the front lip of the chassis, and inserting retaining screws along the top and both sides. With the bricks pushed well back, as mentioned earlier, and the insulation properly aligned, there should be no bulging of this panel and no undue force necessary to fix it.
