Controls
OSD (On-Screen Display) control buttons on the front of the monitor function
as follows:
1. Basic Key function
RESET
Button
(LCD22WV Only)
OSD Off
Message displayed
"Reset Yes/No"
OSD ON
Message displayed
(Icon selection stage)
"Reset Yes/No"
OSD ON
Message displayed
(Adjustment stage) "Reset Yes/No"
OSD Lock
Message displayed
"Reset Yes/No"
2. OSD Lock function
To lock the OSD, press and hold the MENU button while the monitor is off and then press power button to turn the monitor on.
To un-lock the OSD press and hold the MENU button while the monitor is off and then press power button to turn the monitor
on.
3. OSD structure
Press
"MENU"
key
Press
"AUTO" key
Press
"MENU" key
AUTO
Active Auto
Adjustment function
(press over 2 seconds)
Act Exit-key.
Act Exit-key.
Active Auto
Adjustment function
(press over 2 seconds)
Main Menu
(Icon Select, Analog Input)
Press
"AUTO" key
Sub Menu (Icon Select)
– / <
Shortcut to Luminance
(Brightness) window.
Cursor moves left.
Adjust value decrease
or Cursor for adjust
moves left.
Shortcut to Luminance
(Brightness) window.
Main Menu (Exit)
Press
"- / <" or "+ / >"
Press "AUTO" key
Press
"- / <" or "+ / >"
Press
"MENU" key
Sub Menu (Adjust)
English-6
+ / >
Shortcut to Luminance OSD displayed.
(Contrast) window.
Cursor moves right. Go to Adjustment
stage.
Adjust value increase Go to Icon selection
or Cursor for adjust stage.
moves right.
Shortcut to Luminance Message displayed
(Contrast) window. "OSD Loked".
Press "AUTO" or
"MENU" key
Adjust by using
"- / <" or "+ / >"
MENU
