Air-Conditioners

Indoor unit

PLA-RP·AA / PLH-P·AAH
PKA-RP·GAL / PKH-P·GALH
PKA-RP·FAL (2) / PKH-P·FALH
PCA-RP·GA (2) / PCH-P·GAH

OPERATION MANUAL

For safe and correct use, please read this operation manual thoroughly before operating the air-conditioner unit.
BEDIENUNGSHANDBUCH
Zum sicheren und einwandfreien Gebrauch der Klimaanlage dieses Bedienungshandbuch vor Inbetriebnahme
gründlich durchlesen.
MANUEL D'UTILISATION
Pour une utilisation correcte sans risques, veuillez lire le manuel d'utilisation en entier avant de vous servir du
climatiseur.
BEDIENINGSHANDLEIDING
Voor een veilig en juist gebruik moet u deze bedieningshandleiding grondig doorlezen voordat u de
airconditioner gebruikt.
MANUAL DE INSTRUCCIONES
Lea este manual de instrucciones hasta el final antes de poner en marcha la unidad de aire acondicionado
para garantizar un uso seguro y correcto.
ISTRUZIONI DI FUNZIONAMENTO
Leggere attentamente questi istruzioni di funzionamento prima di avviare l'unità, per un uso corretto e sicuro
della stessa.
E°XEIPI¢IO O¢H°IøN XPH™Eø™
°È· ·ÛÊ¿ÏÂÈ· Î·È ÛˆÛÙ‹ ¯Ú‹ÛË, ·Ú·Î·Ï›ÛÙ ‰È·‚¿ÛÂÙ ÚÔÛ¯ÙÈο ·˘Ùfi ÙÔ ÂÁ¯ÂÈÚ›‰ÈÔ ¯Ú‹Ûˆ˜ ÚÈÓ ı¤ÛÂÙ ÛÂ
ÏÂÈÙÔ˘ÚÁ›· ÙË ÌÔÓ¿‰· ÎÏÈÌ·ÙÈÛÌÔ‡.
MANUAL DE OPERAÇÃO
Para segurança e utilização correctas, leia atentamente o manual de operação antes de pôr a funcionar a
unidade de ar condicionado.
DRIFTSMANUAL
Læs venligst denne driftsmanual grundigt før airconditionanlægget betjenes af hensyn til sikker og korrekt brug.
DRIFTSMANUAL
Läs denna driftsmanual noga för säkert och korrekt bruk innan luftkonditioneringen används.
Iflletme Elkitab›
Emniyetli ve do¤ru biçimde nas›l kullan›laca¤›n› ö¤renmek için lütfen klima cihaz›n› iflletmeden önce bu
elkitab›n› dikkatle okuyunuz.
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
Для обеспечения правильного и безопасного использования следует ознакомиться с инструкциями,
указанными в данном руководстве по эксплуатации, тщательным образом до того, как приступать к
использованию кондиционера.
PCA-RP·HA
PSA-RP·GA / PSH-P·GAH
PMH-P·BA
FOR USER
FÜR BENUTZER
POUR L'UTILISATEUR
VOOR DE GEBRUIKER
PARA EL USUARIO
PER L'UTENTE
°π∞ ∆√¡ Ã∏™∆∏
PARA O UTILIZADOR
TIL BRUGER
FÖR ANVÄNDAREN
KULLANICI ‹Ç‹N
ДЛЯ ПОЛЬЗОВАТЕЛЯ
Back to Index
Nederlands
(
)
English
Deutsch
Français
Español
Italiano
∂ÏÏËÓÈο
Português
Dansk
Svenska
Türkçe
Русский

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi Electric PLA-RP·AA

Summary of Contents for Mitsubishi Electric PLA-RP·AA

  • Page 1: Indoor Unit

    Back to Index Air-Conditioners Indoor unit PLA-RP·AA / PLH-P·AAH PCA-RP·HA PKA-RP·GAL / PKH-P·GALH PSA-RP·GA / PSH-P·GAH PKA-RP·FAL (2) / PKH-P·FALH PMH-P·BA PCA-RP·GA (2) / PCH-P·GAH OPERATION MANUAL FOR USER English For safe and correct use, please read this operation manual thoroughly before operating the air-conditioner unit. BEDIENUNGSHANDBUCH FÜR BENUTZER Deutsch...

  • Page 2: Table Of Contents

    Contents 1. Safety Precautions .............. 2 7. Other Functions ..............11 2. Parts Names ............... 2 8. Function Selection ............12 3. Screen Configuration ............6 9. Emergency Operation for Wireless Remote-controller ..16 4. Setting the Day of the Week and Time ....... 6 10.
  • Page 3 2. Parts Names I PLA-RP·AA/PLH-P·AAH I PMH-P·BA 4-way Ceiling Cassette 1-way Ceiling Cassette Vane Louver Vane Air outlet Filter Air outlet Air intake Filter Air inlet I PKA-RP·GAL/PKH-P·GALH Wall Mounted I PKA-RP·FAL (2)/PKH-P·FALH Wall Mounted Filter Air intake Air intake Filter Vane Louver...

  • Page 4: Operation Section

    2. Parts Names I Wired Remote-Controller “Sensor” indication Display Section Displayed when the remote controller sensor is used. Day-of-Week For purposes of this explanation, Shows the current day of the week. all parts of the display are shown as lit. During actual operation, only Time/Timer Display the relevant items will be lit.
  • Page 5 2. Parts Names I Wireless Remote-Controller Transmission area Transmission indicator Remote controller display Timer indicator * For explanation purposes, all of the items that appear in the display are shown. * All items are displayed when the Reset button is pressed. Operation areas ON/OFF button Set Temperature buttons...

  • Page 6: Screen Configuration

    3. Screen Configuration <Screen Types> For details on setting the language for the remote controller display, refer Set Day/Time Function Selection of remote controller to section 8. Function Selection. TIME SUN The initial language setting is English. G Function Selection of remote controller: Set the functions and ranges available to the re- mote controller (timer functions, operating restric- tions, etc.)
  • Page 7 5. Operation 5.3. Temperature setting <To Stop Operation> I Press the ON/OFF button 1 again. s s s s s To decrease the room temperature: • The ON lamp 1 and the display area go dark. button 3 to set the desired temperature. Press The selected temperature is displayed 3.

  • Page 8: Timer

    5. Operation G To run the ventilator independently: <To Change the Right/Left Air Direction> I Press the louver button 7 as necessary. I Press the Mode button 2 until appears on the display. This will • The louver image 7 appears. cause the ventilator to start.
  • Page 9 6. Timer 6.1.2. Simple Timer 7. Press the appropriate Set Temperature button 3 to set the desired I You can set the simple timer in any of three ways. temperature (at 7). • Start time only: * Each press changes the setting, in the following sequence: No display (no setting) ⇔...
  • Page 10 6. Timer 7. After completing steps 3 to 6 above, press the Filter button 4 to lock Example 2: in the value. Start the timer, with OFF time is sooner than ON time Note: ON Setting: 5 hours Your new settings will be cancelled if you press the Mode (Return) button 2 OFF Setting: 2 hours button 4.

  • Page 11: Other Functions

    6. Timer 6.2. For wireless remote controller <Checking the Current Auto Off Timer Setting> Timer Setting TIMER AFTER AUTO OFF 1. Be sure that the “Auto Off” is visible on the screen (at 1). 2. Hold down the Timer Menu button B for 3 seconds, so that “Monitor” is indicated on the screen (at 4).

  • Page 12: Function Selection

    7. Other Functions 7.2. Error Codes indication ERROR CODE ON lamp ON/OFF (Flashing) Error Code Indoor Unit No. Indoor Unit’s Refrig- erant Address Alternating Display If you have entered contact number to be called in the event of a problem, the screen displays this number. (You can set this up under Function Selection of remote controller.
  • Page 13 8. Function Selection [Function selection flowchart] Normal display (Display when the air condition is not running) Setting language (English) Hold down the E button and press the D button for 2 seconds. E Press the operation mode button. Hold down the E button and press the D button for 2 seconds. G Press the TIMER MENU button.
  • Page 14 8. Function Selection [Detailed setting] [4]–3. Mode selection setting (1) Remote controller main/sub setting [4]–1. CHANGE LANGUAGE setting ON/OFF] button D. • To switch the setting, press the [ The language that appears on the dot display can be selected. 1 Main: The controller will be the main controller.
  • Page 15 8. Function Selection [Dot display table] Selecting language English Germany Spanish Russian Italy Chinese French Japanese Waiting for start-up Operation mode Cool Heat Auto Auto(Cool) Auto(Heat) Ventilation Stand by (Hot adjust) Defrost Set temperature Fan speed Not use button Check (Error) Test run Self check Unit function selection...

  • Page 16: Emergency Operation For Wireless Remote-Controller

    9. Emergency Operation for Wireless Remote-controller When the remote controller cannot be used When the batteries of the remote controller run out or the remote controller malfunctions, the emergency operation can be done using the emergency buttons on the grille. COOL HEAT STAND ADEFROST/STAND BY lamp...
  • Page 17 10. Care and cleaning I PKA-RP·GAL I PSA-RP·GA • Remove the screw from the suction grille handle. • The suction grille is open if you pull the handle in arrow direction 1. 1 Pull both the bottom corners of the intake grille to open the grille, •...

  • Page 18: Trouble Shooting

    11. Trouble Shooting Having trouble? Here is the solution. (Unit is operating normally.) I Clean the filter. (Airflow is reduced when the filter is dirty or clogged.) Air conditioner does not heat or cool well. I Check the temperature adjustment and adjust the set temperature. I Make sure that there is plenty of space around the outdoor unit.

  • Page 19: Specifications

    11. Trouble Shooting Having trouble? Here is the solution. (Unit is operating normally.) I The indoor operation sound level is affected by the acoustics of the par- Noise is louder than specifications. ticular room as shown in the following table and will be higher than the noise specification, which was measured in an echo-free room.
  • Page 20 12. Specifications Model PKH-P35GALH PKH-P50GALH PKH-P60FALH PKH-P71FALH PKH-P100FALH Power source (voltage <V>/Frequency <Hz>) ~/N 230/50 Rated Input (Indoor only) <kW> 0.07/0.07 0.07/0.07 0.09/0.09 0.09/0.09 0.11/0.11 Rated Current (Indoor only) <A> 0.33/0.33 0.33/0.33 0.43/0.43 0.43/0.43 0.52/0.52 HEATER <kW> 0.73 0.73 1.93 1.93 2.20 Dimension (Height)
  • Page 21 12. Specifications Model PSH-P71GAH PSH-P100GAH PSH-P125GAH PSH-P140GAH Power source (voltage <V>/Frequency <Hz>) ~/N 230/50 Rated Input (Indoor only) <kW> 0.15/0.15 0.24/0.24 0.28/0.28 0.36/0.36 Rated Current (Indoor only) <A> 0.66/0.66 1.06/1.06 1.23/1.23 1.59/1.59 HEATER <kW> 1.93 2.48 2.76 2.76 Dimension (Height) <mm>...
  • Page 22 This product is designed and intended for use in the residential, commercial and light-industrial environment. • Low Voltage Directive 73/23/ EEC The product at hand is • Electromagnetic Compatibility Directive 89/ based on the following 336/ EEC EU regulations: Please be sure to put the contact address/telephone number on this manual before handing it to the customer.
