Summary of Contents for Nowada Technology N117
- Page 1 NOWADA Technology Inc. N117 GPS Navigator Operation Manual We are committed to exceeding customer expectations to provide solutions for automotive GPS...
-
Page 2: Table Of Contents
NOWADA Technology Inc. Content 1 General Description..................3 2 Feature ......................3 3 Specification....................4 4 Outline ......................6 5 Software Request.................... 6 6 Software Install ....................6 7 Operation ......................6 We are committed to exceeding customer expectations to provide solutions for... -
Page 3: General Description
NOWADA Technology Inc. 1 General Description This product is suitable setup to the single DIN, double DIN car's DVD product inner part, complete low cost and high performance DVD + Navigation function, may also make into outer Navigation box. 2 Feature... -
Page 4: Specification
NOWADA Technology Inc. 3 Specification System parameters 500MHz+250MHz DSP Main frequency Sirf Atlas IV Main chip model 64MB DDR(upper to 128M) Memory 64MB(upper to 8GB) Store space SD card（support SDHC） Navigation software store WINCE6.0 CORE Operation system MP3/PCM/WMA Support audio type mp4、mpeg、mpg、asf、wmv、mov、avi、3gp、3g2、k3g、m4v、... - Page 5 NOWADA Technology Inc. GPS parameters Chip set SiRF Star III Frequency 1.575GHZ C/A CODE 1.023 MHZ chip rate Channel number 64 channels Tracking sense degree -161dBm Position accuracy 10m, 2D RMS 5m, 2D RMS, WAAS enable Velocity 0.1m/s Data renewal rate Re-catching time Average 0.1s...
-
Page 6: Outline
NOWADA Technology Inc. 4 Outline 5 Software Request The using operation system is wince 6.0 CORE version. Navigation software's compilation type is ARMV4I, if need SDK, please contact us. Navigation board GPS use the COM2, Baud rate is 9600bps. If client need use the remote control operation, the client needs to provide the codes of remote control and the navigation software's the responding codes. - Page 7 NOWADA Technology Inc. click“ ”icon，enter system setting interface, as follows: Click“ ”icon，enter touch screen correct setting interface, -hint to often press the center cursor's position according to the picture, until correct the cursor to automatically move to left up-corner position, correct respectively left-down corner cursor position one by one in order, right-down corner cursor position, right-up corner cursor position.
- Page 8 NOWADA Technology Inc. click“ ”icon，system enter the system setting interface, as follow: Select navigation setting “ ”icon，enter as follow: We are committed to exceeding customer expectations to provide solutions for automotive GPS...
- Page 9 NOWADA Technology Inc. click“ ”icon，enter as follow: Accord to navigation software store path（here can multi-select “operate automatically navigation software when start”） ，select navigation software，click“ ”and exit，back to control interface，as follow: Select navigation “ ”icon，the system will enter navigation interface, navigation software operation please refer to navigation software operation elucidation.
- Page 10 NOWADA Technology Inc. C. Reading the E-book As the following control interface： click“ ” icon enter e-book reading main interface, as follow： Click icon“ ”, select e-book files’ store path, enter as follow： We are committed to exceeding customer expectations to provide solutions for...
- Page 11 NOWADA Technology Inc. Select the text file, single click icon“ ” or double click file name back to e-book reading interface, as follow: D．Play audio files As the following control interface： We are committed to exceeding customer expectations to provide solutions for...
- Page 12 NOWADA Technology Inc. click“ ”，icon enter music player main interface, as follow： Click icon“ ”, select audio files’ store path, enter as follow： Select the playing audio file, single click icon“ ” or double click file name back to music player...
- Page 13 NOWADA Technology Inc. Single click icon“ ”, can select all the files ,as follow： Single click icon“ ” back to music player interface。 Single click icon“ ”, continue add audio file， single click icon“ ” and back to music player interface.
- Page 14 NOWADA Technology Inc. Single click icon“ ” to delete all files; Single click icon“ ” to exit music player interface; The volume can be adjusted by click “volume bar” freely；The playing speed can be adjusted by click “play bar” freely;...
- Page 15 NOWADA Technology Inc. single click icon“ ” and the picture will be bigger as follow: F Video player interface operation： At the control interface，as follow： click“ ”icon，enter the video player main interface, as follow: We are committed to exceeding customer expectations to provide solutions for...
- Page 16 NOWADA Technology Inc. Click icon“ ”, select video file’s store path，enter the following interface： Select the video file, single click icon“ ” or double click file name and back to video interface, as follow： Or single click icon“ ” to select all the files, as follow:...
- Page 17 NOWADA Technology Inc. Single click icon” ” and back to imageviewer interface： Single click icon” ”, to change to full screen, as follow : Other icons’ function as follow： Single click icon“ ” to mute； We are committed to exceeding customer expectations to provide solutions for...
- Page 18 NOWADA Technology Inc. Single click icon“ ” to sound； Single click icon“ ” to select next video file； Single click icon“ ” to select previous video file； Single click icon“ ” to delete all the files； Single click icon“ ” to exit video player interface;...
- Page 19 NOWADA Technology Inc. ”enter brightness setting interface，accord personal habit to setup click “ the correlating parameters, click“ ” back to screen setting interface. as follow： click “ ”enter the screen size adjustable setting interface, as follow： Base on the image position to setup correlating parameters, click“...
- Page 20 NOWADA Technology Inc. setting interface. click “ ”enter the screen position adjustable setting interface, as follow： Accord the up, down, left, right keys to adjust the current image position, click“ ” back to the screen setting interface. System setting interface, click“...
- Page 21 NOWADA Technology Inc. Accord personal habit to setup the correlating parameters, click“ ” back to screen setting interface. We are committed to exceeding customer expectations to provide solutions for automotive GPS...
