Replacing the pen battery

To replace the battery proceed as follows:
Remember to protect the environment. Used batteries should not be dis-
posed of in domestic waste. They must be taken to a collection point for old
batteries.

Replacing the pen nib

To replace the pen nib proceed as follows:
30
Silvercrest GTA2000 pen pad
1. Remove the cap.
2. Push the cover upwards slightly
and lift it off.
Do not push the cover too far
upwards, as the tabs at the front
could otherwise break off.
3. Replace the empty battery with a
new battery (1.5 V, type AAA).
The plus pole (+) must always
point towards the open end of the
pen!
Always ensure correct polar-
ity of the battery!
4. Place the tabs of the cover into
the front of the bottom section
and carefully push down until the
cover snaps into place on the
bottom section. Do not use any
force.
5. Replace the pen cap.
1. Grip the nib (O) with the nib ex-
tractor (Q) and pull the nib out of
the pen.
2. Push a new nib (O) as far as
possible into the pen.
