LEFT SIDE PANEL
SILVERSTONETEK
CP05
5.25" DRIVE BAY x 5
SCREW A
SCREW B
SCREW C
SCREW D
RADIAOR-BKT
BUNCH WIRE TIES
PSU BKT
2.5" HDD BKT
BUNCH WIRE TIES
FAN CABLE
3
PS2 PSU(OPTION)
12025 FAN
FRONT I/O
SECURE 5.25" DRIVE
SECURE HARD DRIVE
SECURE POWER SUPPLY OR
PSU BKT AND MOTHERBOARD
SECURE MOTHERBOARD
SECURE RADIATOR
SECURE TIE WIRE
SECURE POWER SUPPLY
SECURE 2.5" HARD DRIVE
SECURE POWER SUPPLY
SECURE FAN
18032 FAN SWICTH x 3
3.5" HDD Tray
3.5" DRIVE BAY x 5
RIGHT SIDE PANEL-W
USB2.0 CONNECTOR
USB+5V USB+5V
LP- LP-
LP+ LP+
GND GND
NC
PIN
AC'97 CONNECTOR
AUD GND MIC
NC MIC~BIAS
RET-R FPOUT~R
PIN NC
RET-L FPOUT~L
HD CONNECTOR
AUD GND PORT1L
PRESENCE PORT1R
SENSE1_RETURN PORT2R
PIN SENSE_SEND
SENSE2_RETURN PORT2L

TOP COVER

PSU FILTER
ATX MB(OPTION)
18032 FAN GUARD x 2
18032 FAN x 3
18032 FAN BRACKET x 2
PIN
PIN
PIN
