- Page 1 Hardware Reference Guide HP Compaq t5135/t5530 Thin Clients...
- Page 2 Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. This document contains proprietary information that is protected by copyright.
-
Page 3: About This Book
About This Book WARNING! bodily harm or loss of life. CAUTION Text set off in this manner indicates that failure to follow directions could result in damage to equipment or loss of information. NOTE Text set off in this manner provides important supplemental information. ENWW Text set off in this manner indicates that failure to follow directions could result in... - Page 4 About This Book ENWW...
-
Page 5: Table Of Contents
3 Specifications 4 Security provisions Securing the thin client ... 17 5 Mounting the thin client HP Quick Release ... 18 Supported mounting options ... 20 Non-supported mounting option ... 22 6 Thin client operation Routine thin client care ... 23 Supported orientations ... - Page 6 Non-supported orientation ... 24 7 Electrostatic discharge Preventing electrostatic damage ... 26 Grounding methods ... 27 8 Shipping information Shipping preparation ... 28 Important service repair information ... 28 ENWW...
-
Page 7: Product Features
Standard features Thank you for purchasing an HP Compaq thin client. We hope you have years of use from our t5135 or t5530 thin clients. Our goal is to provide you with award-winning clients that are easy to deploy and manage with the power and reliability you expect. -
Page 8: Front Panel Components
Figure 1-2 Secure USB compartment ports The secure USB compartment allows you to use two USB devices in a secured location. Chapter 1 Product features Line-out (headphone) audio connector Line-in (microphone) connector Universal serial bus (USB) connectors (2) http://h18004.www1.hp.com/products/quickspecs/ ENWW... -
Page 9: Rear Panel Components
Rear panel components Cable lock slot Ethernet RJ-45 connector Parallel connector Universal serial bus (USB) connectors (4) For more information, see the model-specific QuickSpecs at QuickSpecs_Archives/QuickSpecs_Archives.html ENWW PS/2 connectors (2) Monitor connector Serial connector Power connector http://h18004.www1.hp.com/products/quickspecs/ Rear panel components... -
Page 10: Installing The Stand
Installing the stand To install the stand: Turn unit upside down. Locate the slots on the bottom of the unit into which the tabs on the stand fit. Insert the tabs into the slots (1), and then slide the stand about 1/2–inch toward the back of the unit until it locks into place (2). -
Page 11: Using The Keyboard
Using the keyboard Figure 1-6 Keyboard features Caps Lock Scroll Lock Num Lock Ctrl Windows Logo Key Application key Editing keys Available in select geographic regions. ENWW Activates/deactivates the Caps Lock feature. Activates/deactivates the Scroll Lock feature. Activates/deactivates the Num Lock feature. Use in combination with another key;... -
Page 12: Windows Logo Key
Break Windows Logo Key + Additional function keys The following key combinations also work on HP Compaq t5135/t5530 thin clients: Shift Special mouse functions Most software applications support the use of a mouse. The functions assigned to each mouse button depend on the software applications you are using. -
Page 13: Serial Number Location
Serial number location Every thin client includes a unique serial number located as shown in the following illustration. Have this number available when contacting HP customer service for assistance. Figure 1-7 Serial number location ENWW Serial number location... -
Page 14: Hardware Changes
Hardware changes General hardware installation sequence To ensure the proper installation thin client hardware components: Back up any data, if necessary. If the thin client is powered on: Turn the unit and any other attached devices off. Disconnect the power cord from the wall outlet. Disconnect any external devices or cables. - Page 15 NOTE You can download select hardware drivers from HP at http://www.hp.com/country/ us/eng/support.html. Reconfigure the thin client, if necessary. ENWW General hardware installation sequence...
-
Page 16: Installing Usb Devices In The Secure Usb Compartment
Installing USB devices in the secure USB compartment The secure USB compartment allows you to install two USB devices in a secure location inside of the thin client. Along with providing a hidden location, the secure USB compartment can be locked by the optional security cable lock. -
Page 17: Installing The Usb Device
Installing the USB device Insert the USB device into the USB port in the secure USB compartment. See the following ▲ illustration for the location of the ports in the secure USB compartment. Figure 2-2 Secure USB compartment port location Replacing the secure USB compartment cover To replace the secure compartment cover: Place the cover on top of the unit so it is offset about 1/2–inch toward the rear of the unit, allowing... -
Page 18: Replacing The Battery
Replacing the battery Before beginning the replacement process, review procedures you should follow before and after installing or replacing hardware. To replace the battery: Remove the side access panel and metal side cover Remove and replace the battery Replace the metal side cover and side access panel Removing the side access panel and metal side cover WARNING! the power cord is disconnected from the electrical outlet. -
Page 19: Removing And Replacing The Battery
Lift the metal side cover up and off the unit (2). Figure 2-5 Removing the metal side cover Removing and replacing the battery To remove and replace the battery: Locate the battery on the system board. Pull back on the clip (1) that is holding the battery in place, and then remove the battery (2). Figure 2-6 Removing and replacing the internal battery Insert the new battery and position the clip back into place. -
Page 20: External Drives
Figure 2-8 Replacing the side access panel External drives Various external USB drives are available as options for the t5135/t5530. For more information about these drives, visit http://www.hp.com/products/thinclientsoftware, or refer to the instructions that accompany the option. For more information about available options, visit the HP Web site at configure2.cfm... -
Page 21: Specifications
10° to 40° C -22° to 140° F -30° to 60° C ** The operating temperature range when the thin client is attached to a flat panel using the HP Quick Release is 50° to 95°F (10° to 35°C). 10–90% 10–90% 5–95%... - Page 22 Table 3-1 HP Compaq t5135/t5530 Thin Client (continued) Power Output (maximum) Rated Output Current (maximum) Chapter 3 Specifications 40 W 40 W 3.3 A 3.3 A ENWW...
-
Page 23: Security Provisions
Security provisions Securing the thin client The HP Compaq t5135/t5530 thin client is designed to accept a security cable lock. This cable lock prevents unauthorized removal of the thin client, as well as locking the secure compartment. To order this option, visit the HP Web site at http://h30143.www3.hp.com/configure2.cfm. -
Page 24: Mounting The Thin Client
Mounting the thin client HP Quick Release The HP Compaq t5135/t5530 thin client incorporates four mounting points on each side of the unit. These mounting points follow the VESA (Video Electronics Standards Association) standard, which provides industry-standard mounting interfaces for Flat Displays (FDs), such as flat panel monitors, flat displays, and flat TVs. - Page 25 To use the HP Quick Release with a VESA-configured thin client: Using four 10 mm screws included in the mounting device kit, attach one side of the HP Quick Release to the thin client as shown in the following illustration.
-
Page 26: Supported Mounting Options
CAUTION To ensure proper function of the HP Quick Release and a secure connection of all components, make sure both the release lever on one side of the mounting device and the rounded opening on the other side face upward. - Page 27 Figure 5-6 Thin client mounted on back of monitor stand ● You can mount the thin client on a wall. Figure 5-7 Thin client mounted on wall ● You can mount the thin client under a desk. ENWW HP Quick Release...
-
Page 28: Non-Supported Mounting Option
Non-supported mounting option CAUTION Mounting a thin client in an non-supported manner could result in failure of the HP Quick Release and damage to the thin client and/or other equipment. Do not mount the thin client on a flat panel monitor stand, between the panel and the stand. -
Page 29: Thin Client Operation
Supported orientations HP supports the following orientations for the thin client. CAUTION You must adhere to HP-supported orientations to ensure your thin clients function properly. ● You can place the thin client vertically using the supplied stand. -
Page 30: Non-Supported Orientation
You can lay the thin client under a monitor stand with at least one inch of clearance. Figure 6-3 Under monitor stand Non-supported orientation HP does not support the following orientation for the thin client. CAUTION Non-supported placement of thin clients could result in operation failure and/or damage to the devices. - Page 31 Figure 6-4 Do not put thin clients in drawers or other sealed enclosures ENWW Non-supported orientation...
-
Page 32: Electrostatic Discharge
Electrostatic discharge A discharge of static electricity from a finger or other conductor may damage system boards or other static-sensitive devices. This type of damage may reduce the life expectancy of the device. Preventing electrostatic damage To prevent electrostatic damage, observe the following precautions: ●... -
Page 33: Grounding Methods
Use conductive field service tools. ● Use a portable field service kit with a folding static-dissipating work mat. If you do not have any of the suggested equipment for proper grounding, contact an HP authorized dealer, reseller, or service provider. NOTE For more information about static electricity, contact an HP authorized dealer, reseller, or service provider. -
Page 34: Shipping Information
For environmental nonoperating ranges, see Specifications. Important service repair information In all cases, remove and safeguard all external options before returning the thin client to HP for repair or exchange. In countries that support customer mail-in repair by returning the same unit to the customer, HP makes every effort to return the repaired unit with the same internal memory and flash modules that were sent.
