INSTRUCTIONS FOR INSTALLATION & USE for the AQUARIUS+ RANGE
Hotpoint recommends, for your own safety and to ensure you get the best possible results from your
Washing Machine, you read through this booklet and follow these steps thoroughly.
STEP 1
Electrical Guide
Choose a location for your washing
machine, where possible on a solid floor,
with the electrical sockets and water
supply taps easily accessible.
Allow sufficient space: 600mm width,
600m depth and 900mm height.
DO NOT install in a bath or shower room.
STEP 3
Dispenser Drawer
Read through this section to familiarise
yourself with the different
compartments within the dispenser
NOTE: Always follow manufacturer's dosage
How to start your selected programme
and how to stop or change the
NOTE: Progress indicator lights show what stage in
the programme cycle has been reached.
A picture guide provides a clear
explanation how to set a wash
DO NOT overload the washing machine.
NOTE: Hotpoint recommend, on completion of
your programme, that you switch off both the
electricity and water supply to the appliance.
Read the rest of these instructions to get the best from your appliance, remember to fill in your guarantee registration.
WF645,WF640,WF630 and WF620
drawer.
recommendations.
programme.
Keep this Book in a safe place for quick reference.
STEP 2
Installation Guide
Dispose of packaging material in a safe
place and remove any labels.
Please read instructions thoroughly to
ensure you understand each stage
before you begin.
Remember you may be charged for a service call if a
problem with your washing machine is caused by
incorrect installation or misuse.
STEP 4
Programme Selection
A wash chart is provided to help you to
select your required programme.
Examples are given for the maximum
washing load weights for different fabric
types.
STEP 6
Options Guide
All available optional wash features are
explained within this section - These
allow you to adjust your selected wash
programme to suit your needs.
NOTE: In addition to the temperature of the
incoming water, the selection of optional wash
features will affect the programme times.
Please refer to the Troubleshooting
section if you have any problems when
using your washing machine.
READ BEFORE
There may be nothing wrong!
CONTACTING
SERVICE!
Advertisement
Table of Contents
Related Manuals for Hotpoint AQUARIUS+ WF620
Summary of Contents for Hotpoint AQUARIUS+ WF620
-
Page 1: Table Of Contents
INSTRUCTIONS FOR INSTALLATION & USE for the AQUARIUS+ RANGE Hotpoint recommends, for your own safety and to ensure you get the best possible results from your Washing Machine, you read through this booklet and follow these steps thoroughly. STEP 1... -
Page 2: Step 1
Changing the Mains Lead If you have damaged the existing lead and need a new one, contact Hotpoint Service UK on: 08709 066 066 or www.theservicecentre.co.uk (or in the Republic of Ireland on: 1850 302 200). A charge will be made. We strongly advised that fitting a new lead is carried out by a qualified electrician. -
Page 3: Installation
Spin Speed up to 1400rpm - WF645 & WF640 NOTE: ALTHOUGH YOU MAY NEED TO up to 1300rpm - WF630 MOVE THE HOOKED END SUPPORT up to 1200rpm - WF620 ALONG THE GREY DRAINAGE HOSE, DO NOT REMOVE IT. Control programmes... -
Page 4: The Dispenser Drawer
STEP 3 The Dispenser Drawer Index: 1. Drawer release latch 2. Pre-wash detergent compartment Maximum 200ml powder or 100ml liquid 3. Main detergent compartment Maximum 400ml powder or 200ml liquid 4. Grate 5. Fabric conditioner compartment 120ml maximum Dispensing Powder Detergent To achieve the best wash results the manufacturer’s recommended amount of detergent should be measured and added to the main detergent compartment (II symbol) -
Page 5: Programme Selector Dial
= 3kg Slow Gentle Handwash Wool Approved ‘The wool wash cycle on the Slow WF series of Hotpoint washing Gentle machines has been tested and approved by the Woolmark Slow Company for washing gar- ments labelled as “hand wash” ,... -
Page 6: Step 5 Using Your Machine
STEP 5 Programme listing WARNINGS: ● In the unlikely event of something not working, see ‘Troubleshooting’ STEP 8. Variable Temperature button On-Off / Selecting a programme... The machine is switched on by pressing the ‘On/Off’ button for 2 seconds. All the indicator lights will light up for a few seconds and the ‘Door Locked’... -
Page 7: Time Saver
● This is not available with programmes A, J, L M, Rinse & Spin or Spin Only. Extra Rinse... (Model WF620 only) For large wash loads and items for young children or people with sensitive skin. This option adds a rinse. -
Page 8: Automatic Features
STEP 7 Sort laundry into Add detergent (and fabric conditioner if groups by washcare labels. required) to the Load the machine, dispenser drawer (see STEP 3). making sure that the laundry is not Refer to the detergent manufacturer’s trapped in the door. Close the door by dosage instructions. -
Page 9: Step
Is the drawer clogged with ✗ Are the fill hoses on correctly? detergent? If not tighten them. ✓ Does the washer need Clean the dispenser drawer, see replacing? STEP 3:‘The Dispenser Drawer’ Check the drawer is properly Is your water pressure too ✗... -
Page 10: Getting To Know Your Appliance
Model shows the maximum features available on an Aquarius+ washing machine. Dispenser Drawer Interlocking door and release lever Hooked End Support Mains Cable Rating Plate Hot Water inlet point and supplied Hose (Red or Grey end) Cold Water inlet point and supplied Hose (Blue end) Plumbing Indicator Line label Transit Bolts (both MUST be removed... -
Page 11: After Sales Service
Republic of Ireland: 1850 502 200 Whether you have just one or a number of Hotpoint appliances in your kitchen, we offer two service cover plans to give you total peace of mind. ● Repair Protection Plan - FREE service repairs for a single Hotpoint appliance during the period of cover.
