If your SRS1500 needs service, please
follow these instructions:
1. Review the preceding troubleshooting
suggestions. Please.
2. Call Tech Support at 1-800-258-6883,
7am to 5pm PST, to explain the problem
in detail. They will ask you all sorts of
impertinent questions in the hope of
sorting out the problem. If it appears
that the SRS1500 needs repair, request
an RA (Return Authorization) number.
Have your subwoofer's serial number
ready. You must have an RA number
before you can obtain service at the
factory or an authorized service center.
3. Keep this user's manual. We don't need
it to repair the subwoofer.
4. Pack the subwoofer in its original
packaging, including protective wrap,
endcaps, and box. This is very impor-
tant. When you call for the RA number,
please let Tech Support know if you
need new packaging. Mackie is not
responsible for any damage that occurs
due to non-factory packaging.
5. Include a legible note stating your name,
shipping address (no P.O. boxes),
daytime phone number, RA number,
and a detailed description of the prob-
lem, including how we can duplicate it.
6. Write the RA number in BIG PRINT
on top of the box.
7. Ship the subwoofer to us. We recom-
mend United Parcel Service (UPS). We
suggest insurance for all forms of
cartage. Ship to this address:
Mackie Designs
SERVICE DEPARTMENT
16220 Wood-Red Rd. NE
Woodinville, WA 98072
8. We'll try to fix the subwoofer within
three business days. Ask Tech Support
for the latest turnaround times when
you call for your RA number. We
normally send everything back prepaid
using UPS BLUE (Second Day Air).
However, if you rush your subwoofer to
us by Next Day Air, we'll treat it in kind
by shipping it back to you UPS RED
(Next Day Air). This paragraph does
not necessarily apply to non-warranty
service.
8

SPECIFICATIONS

System Specifications
Frequency Range
Frequency Response (–3 dB)
Maximum SPL @ 1m 123 dB
Peak Output @ 1m
Crossover Frequency
Input Type
Input Impedance
Input Protection
Thermal Protection
Transducer Specifications
Low-Frequency Transducer
Diameter
Voice Coil Diameter
Power Handling
Power Amplifier
Low-Frequency Power Amplifier
Burst Capability
Rated THD
Cooling
Line Input Power
US
Europe
Physical Properties
Height 23.25˝ (590mm)
Width 17.0˝ (432mm)
Depth 23.5˝ (597mm)
Weight 100 lbs. (45.4kg)
Enclosure 18mm thick multi-layered baltic
birch wood
Enclosure Geometry
Rectangular
Mounting Methods
Floor mount only
Disclaimer
Since we are always striving to make our
products better by incorporating new and improved
materials, components, and manufacturing methods,
we reserve the right to change these specifications at
any time without notice.
"Mackie" and the "Running Man" figure are
trademarks or registered trademarks of Mackie
Designs Inc.
All other brand names mentioned are trade-
marks or registered trademarks of their respective
holders, and are hereby acknowledged.
©2000 Mackie Designs Inc.
All Rights Reserved.
Printed in the U.S.A.
40Hz–120Hz
45Hz–120Hz
126 dB
120Hz (12 dB/octave)
Balanced differential
50k ohms
Level protected
Input stage muting,
auto-reset
15˝ (381mm)
3.0˝ (75mm)
350 watts rms
600 watts
< 0.05%
Passive
120V, 60Hz
230V, 50Hz
