Features
80 PLUS® GOLD
Up to 92 percent efficiency at 230V and 20 to 100 percent load. 80 PLUS® Gold certified.
ErP Lot 6 2013 ready!
Help systems to meet the latest EU eco-design directive ErP Lot 6 2013 (< 0.5W in standby mode*) due to a high-efficient 5V standby
(+5Vsb) circuitry.
*only in combination with an ErP Lot 6 2013 ready mainboard
DC-to-DC Design
The secondary voltages (+5V and +3.3V) are generated by the primary voltage rail (+12V). Positive effect: Higher efficiency, clean
output voltages (low ripple & noise) and a perfect voltage regulation at all loads.
Full GPU & CPU Power
Massive 12V rail to power high-performance and overclocked processors and graphics cards. More than 97 percent of the total power
of the PSU can be delivered by the 12V rail only.
Full Gaming Power
Min. two 6+2P (8P) PCI-E connectors to power the latest high-end graphics cards and multi-GPU systems (CrossfireX™ & SLI™).
Modular & Flat Cables
Simplify the cable routing and enhance the airflow inside the case.
Intel® Haswell™ Ready!
Supports the C6/C7 energy-saving functions of the latest Intel® CPUs incl. the forthcoming Intel® Haswell™ generation.
Intel ATX 12V v2.4
Compliant with the latest desktop power supply design guide. Full support of most current Intel® and AMD® CPU.
Worldwide Compatibility
100-240V AC input with automatic adjustment and up to 99% active Power Factor Correction (PFC) for global usage.
Air Cooling by Enermax
Integrated 13.9cm fan with patented Twister Bearing Technology ensures efficient and ultra silent cooling and long lifetime
(100,000 hours MTBF).
SpeedGuard
Ultra silent and powerful cooling performance due to an advanced and intelligent fan speed control.
HeatGuard
Keeping PSU fan running for 30-60 seconds after shut down to dissipate the remaining system heat and prolonging the system's lifetime.
w w w . e n e r m a x . c o . u k
Advertisement
Related Manuals for ENERMAX Revolution X't
Summary of Contents for ENERMAX Revolution X't
- Page 1 Worldwide Compatibility 100-240V AC input with automatic adjustment and up to 99% active Power Factor Correction (PFC) for global usage. Air Cooling by Enermax Integrated 13.9cm fan with patented Twister Bearing Technology ensures efficient and ultra silent cooling and long lifetime (100,000 hours MTBF).
-
Page 2: Cables And Connectors
Features High-quality Japanese Main Capacitors Highest component standards for maximum stability and durability. Non-Stop 24/7 @ 40°C Non-stop industrial class performance at 40°C/104°F ambient. SafeGuard Multiple protection circuitry of OVP, OTP, OPP, SCP and SIP. CordGuard Fixing the AC cord tightly to avoid accidental shutdowns of your PC. Compact, Scratch-resistant Housing Dimensions: 150 mm x 86 mm x 140 mm (W x H x D) 5 years vendor warranty... -
Page 3: Specifications
Cables and Connectors ERX430 ERX530 ERX630 ERX730 Modular Cables EMC014-F 2x PCI-E 2.0 6+2 Pin 50cm 50cm 50cm 50cm EMC019-F 4x SATA 45 / 60 / 75 / 90cm 45 / 60 / 75 / 90cm 45 / 60 / 75 / 90cm 45 / 60 / 75 / 90cm EMC020-F 4x 4 Pin Molex +... - Page 4 0.5W. The decisive components to fulfil the ErP Lot 6 targets are the mainboard and the PSU. Enermax relies on a circuit design, which improves the efficiency of the 5V standby rail (+5Vsb) about 20 per cent.
