- Page 1 Professional Notebook / Workstation English EasyGuide CELSIUS H / LIFEBOOK E Series...
- Page 2 Are there ..any technical questions or problems? Please contact: • our Hotline/Help Desk (see the enclosed Help Desk List or the Internet: "www.fujitsu-siemens.com/support/") • Your sales partner • Your sales office Additional information is contained in the Help Desk list and the "Warranty" manual. The "Warranty"...
- Page 4 This manual was produced by Xerox Global Services Published by Fujitsu Siemens Computers GmbH AG 05/07 Edition 1 Order no.: A26391-K226-Z120-1-7619...
- Page 5 CELSIUS H /LIFEBOOK E Series EasyGuide Innovative technology… Notational conventions Important notes Ports and operating elements Removing and installing components during servicing Technical data Index...
- Page 6 All other trademarks referenced are trademarks or registered trademarks of their respective owners, whose protected rights are acknowledged. Copyright © Fujitsu Siemens Computers GmbH 2007 All rights reserved, including rights of translation, reproduction by printing, copying or similar methods, in part or in whole.
-
Page 7: Table Of Contents
Contents Contents Innovative technology… ............. . . Notational conventions . - Page 8 Contents A26391-K226-Z120-1-7619,edition1...
-
Page 9: Innovative Technology
"Safety" and "Warranty" manuals • in the "Wireless LAN" manual • in the documentation of the operating system • In the information files (e.g. *.TXT, *.DOC, *.WRI, *.HLP, *.PDF) You can find information on accessories for your notebook at "www.fujitsu-siemens.com/accessories". A26391-K226-Z120-1-7619, edition 1... -
Page 10: Notational Conventions
• Cross-references to an external source, e.g. a web address: For more information, go to" www.fujitsu-siemens.com" • indicates names of CDs and DVDs as well as names and titles of other materials, e.g.: "CD/DVD Drivers & Utilities" or "Safety" manual refers to a key on the keyboard, e.g.:... -
Page 11: Important Notes
Important notes Important notes Take note of the safety hints provided in the "Safety" manual, in the "Professional Notebook" operating manual and in this manual. A26391-K226-Z120-1-7619, edition 1... -
Page 12: Ports And Operating Elements
Ports and operating elements Ports and operating elements Ports This chapter presents the individual hardware components of your notebook. You can obtain an overview of the ports and operating elements of the notebook. Please familiarise yourself with these components before you start to work with your notebook. Opened Notebook Front View... -
Page 13: Left Side
Ports and operating elements Left side DCINjack Microphone port Modem port USBport FireWire port SmartCardreader PCcardslot ExpressCardslot Cardejectbutton Headphoneport/SPDIF 1 = DC IN jack 6 = FireWire port 2 = Microphone port 7 = SmartCard reader 3 = Headphone port / SPDIF (CELSIUS 8 = PC card slot H250 only) 9 = Card eject button... -
Page 14: Rear
Ports and operating elements Rear View Rear KensingtonLock USBport Parallelport Serialport Monitorport(VGA) S-Video OUTsocket LANport 1 = Kensington Lock 5 = Monitor port (VGA) 2 = USB ports 6 = LAN port 3 = Parallel port 7 = S-Video OUT socket 4 = Serial port A26391-K226-Z120-1-7619, edition 1... -
Page 15: Under Side
Ports and operating elements Under side Under side Batterylock Battery Portfor portreplicator Air filter Memorymodule 1 = Air filter 4 = Battery 2 = Port for port replicator 5 = Battery lock 3 = Cover for memory modules A26391-K226-Z120-1-7619, edition 1... -
Page 16: Switching On The Notebook
Ports and operating elements Switching on the notebook ► Press the release button (1) and open the LCD–display panel (2). ► Press the ON/OFF button (1) to switch the notebook on. The power-on indicator of the notebook appears in the status indicator panel (2). Windows XP: You can configure the ON/OFF switch under Start –... -
Page 17: Switching Off The Notebook
Ports and operating elements Switching off the Notebook ► Close all programs and shut down your operating system (please see operating system manual). If the notebook cannot be shut down properly, press and hold the ON/OFF button for approximately four seconds. The notebook will switch off. Any unsaved data may be lost. ►... -
Page 18: Status Indicator Panel
Ports and operating elements Status indicator panel Statusindicator panel The status indicator panel is a small LCD panel on which various symbols appear. These symbols provide information about the status of the power supply, the drives, and the keyboard functions. Power-on indicator CD/DVD indicator Power indicator... - Page 19 Ports and operating elements The meanings of the symbols are as follows: Power-on indicator Power-onindicator Indicator • Indicator lights up: The notebook is switched on. • The indicator flashes (1 second on / 1 second off): The notebook is in power saving mode.
-
Page 20: Key Combinations
Ports and operating elements Key combinations The following description of key combinations refers to functions when using Microsoft Windows. Some of the following key combinations may not function in other operating systems and with some device drivers. Key combinations are entered as follows: ►... - Page 21 Ports and operating elements Volume increase Fn+F9 Volume This key combination raises the volume of the integrated loudspeakers. Toggle output screen Fn+F10 Toggleoutputscreen If an external monitor is connected, the monitor on which the output is to be displayed can be selected with this key combination. You can opt to use: •...
-
Page 22: Easy Launch Keys
Ports and operating elements Easy Launch keys Easy Launchkeys Your notebook is equipped with four Easy Launch keys. Lock Workstation key This key allows you to lock your workstation. However, you can also configure this key as desired. Mobility Center key This button starts the Mobility Center. -
Page 23: Camera (Optional)
Removing and installing the battery Notes Battery Only use batteries approved by Fujitsu Siemens Computers for your notebook. Never use force when inserting or removing a battery. Make sure that no foreign bodies get into the battery connections. A26391-K226-Z120-1-7619, edition 1... -
Page 24: Removing The Battery
Ports and operating elements Removing the battery ► Switch the notebook off and pull the power plug out of the mains socket. ► Close the LCD screen so that it locks into place. ► Disconnect all cables connected to the notebook. ►... -
Page 25: Removing And Installing The Air Filter
Ports and operating elements Removing and installing the air filter Clean the existing air filter regularly. Dirty air filters will lead to an increased temperature inside the device. Operating temperatures which are too high can lead to loss of data and unreliable operation. Air filter removal ►... -
Page 26: Install Air Filter
Ports and operating elements Install air filter Make sure that the arrow (a) on the air filter points in the correct direction and that you insert the air filter again in the same orientation as it was before the cleaning operation. ►... -
Page 27: Sim Card
Ports and operating elements SIM card Follow the instructions supplied by the provider of the SIM card. Inserting the SIM card ► Switch the notebook off and pull the power plug out of the mains socket. ► Close the LCD screen so that it locks into place. ►... -
Page 28: Removing A Sim Card
Ports and operating elements Removing a SIM card ► Switch the notebook off and pull the power plug out of the mains socket. ► Close the LCD screen so that it locks into place. ► Disconnect all cables connected to the notebook. ►... -
Page 29: Radio Components: Umts (Optional)/Wireless Lan/Bluetooth
Wireless LAN Bluetooth UMTS The installation of a wireless LAN, Bluetooth or UMTS module not approved by Fujitsu Siemens Computers GmbH voids the permits (CE!, FCC) issued for this device. The modules for radio components are switched off during shipping. -
Page 30: Removing And Installing Components During Servicing
Removing and installing components during servicing Removing and installing components during servicing Only qualified technicians should repair your notebook. Unauthorised opening or incorrect repair may greatly endanger the user (electric shock, fire risk) and will invalidate your warranty. Servicing Components You may remove and install the components described in this chapter yourself after consulting the Hotline/Help Desk. -
Page 31: Removing And Installing Memory Modules
Removing and installing components during servicing Removing and installing memory modules Mainmemory Memoryexpansion Memoryupgrade System expansion The notebook will not start without memory modules, as no fixed main memory is installed. Your notebook supports dual-channel DDR2 technology. The dual-channel DDR2 technology can only be used with two identical memory modules. -
Page 32: Cover Removal
Removing and installing components during servicing Cover removal ► Remove the screw (1). ► Pull the cover off the notebook (2). Removing memory modules ► Carefully push the two mounting clips outwards (1). Memory expansion Memory module The memory module snaps upwards (2). ►... -
Page 33: Attaching The Cover
Removing and installing components during servicing Attaching the cover ► Place the cover in the correct mounting position (1). ► Fasten the cover with the screw (2). ► Reinstall the battery (see "Installing battery", Page 16). ► Turn the notebook the right way up and place it on a flat surface. ►... -
Page 34: Technical Data
Technical data Technical data CELSIUS H250/LIFEBOOK E8410 Technicaldata LIFEBOOK E8410 LIFEBOOK E8410 Device Celsius H250 (external graphics) (internal graphics) Processor Intel Core2™ Duo (Merom) Main memory Maximum 4 Gbyte DDR2 SDRAM 2 slots for 256, 512 Mbyte modules, 1 Gbyte or 2 Gbyte modules Possible modules •... -
Page 35: Battery
Technical data Slots ExpressCard slot 1 x ExpressCard/34 or ExpressCard/54 PC card slot PCMCIA 1 x type I or II Memory card slot 1 x Secure Digital, 1 x MemoryStick or 1 x MemoryStickPro SIM card slot Ports S-Video out socket 7-pin mini DIN female connector Monitor port (VGA) 15-pin socket... -
Page 36: Mains Adapter 80W
Technical data Mains adapter 80W Technicaldata Use ONLY the 80W mains adapter for a LIFEBOOK E8410 (internal graphics) ! Rated voltage 100 V to 240 V (automatic) Max. rated current 4.22 A An additional mains adapter or power cable can be ordered at any time. 100W mains adapter Technicaldata Use ONLY the 100W mains adapter for a LIFEBOOK E8410 with external... -
Page 37: Index
Index Index Front 4 Air filter 7 Alt+Tab 13 Hard disk indicator 11 Headphone port / SPDIF 5 Back tab 13 Battery 7 important notes 15 Indicator indicator 11 Battery charging indicator 11 Battery charging indicator 11 Bluetooth 11 Battery lock 7 Caps Lock 11 Bluetooth 21 CD/DVD 11... - Page 38 Index SmartCard reader 5 Notes Status indicator panel 4, 10 battery 15 System expansion boards 22 memory expansion 23 Num Lock indicator 11 Technical data battery 27 On/Off switch 4 Mains adapter 28 notebook 26 Toggle output screen 13 Touchpad 4 Parallel port 6 disable 12 PC Card...
