NI 5782R User Manual and
Specifications
The NI 5782 is an analog dual-input, dual-ouput, intermediate-frequency (IF) transceiver
adapter module designed to work with your NI FlexRIO™ FPGA module. The NI 5782 features
two analog input (AI) channels with 14-bit sample rates of up to 250 MS/s. The NI 5782 also
has two analog output (AO) channels with 16-bit sample rates of up to 500 MS/s when using
both AO channels, or up to 1 GS/s when using only one AO channel.
This document contains signal information and specifications for the NI 5782R, which is
composed of an NI FlexRIO FPGA module and the NI 5782 adapter module. This document
also contains tutorial sections that demonstrate how to acquire data using a LabVIEW FPGA
example VI and how to create and run your own LabVIEW project with the NI 5782R.
NI 5782R refers to the combination of your NI 5782 adapter module and your
Note
NI FlexRIO FPGA module. NI 5782 refers to your NI 5782 adapter module only.
Caution
a manner not described in this document.
Contents
Electromagnetic Compatibility Guidelines .............................................................................. 2
How to Use Your NI FlexRIO Documentation Set .................................................................. 3
Front Panel and Connector Pinouts .......................................................................................... 4
Block Diagram.......................................................................................................................... 7
NI 5782 Component-Level Intellectual Property (CLIP)......................................................... 8
Connecting Cables .................................................................................................................... 10
Clocking.................................................................................................................................... 10
Using Your NI 5782R with a LabVIEW FPGA Example VI .................................................. 11
Creating a LabVIEW Project and Running a VI on an FPGA Target...................................... 13
Appendix A: Specifications...................................................................................................... 16
Appendix B: Installing EMI Controls ...................................................................................... 34
Where to Go for Support .......................................................................................................... 36
The protection provided by the NI 5782R can be impaired if it is used in
Advertisement
Table of Contents
Related Manuals for National Instruments NI 5782R
Summary of Contents for National Instruments NI 5782R
-
Page 1: Table Of Contents
LabVIEW FPGA example VI and how to create and run your own LabVIEW project with the NI 5782R. NI 5782R refers to the combination of your NI 5782 adapter module and your Note NI FlexRIO FPGA module. -
Page 2: Electromagnetic Compatibility Guidelines
NI FlexRIO Device Adapter Module FPGA Module Before configuring your NI 5782R, you must install the appropriate software Note and hardware. Refer to the NI FlexRIO FPGA Module Installation Guide and Specifications for installation instructions. Figure 1 shows an example of a properly connected NI FlexRIO device. -
Page 3: How To Use Your Ni Flexrio Documentation Set
PROGRAM Your LEARN About NI FlexRIO System You New to LabVIEW FPGA in LabVIEW FPGA LabVIEW FPGA Module Module Module? LabVIEW FPGA NI FlexRIO LabVIEW Module Help Help Examples NI 5782R User Manual and Specifications | © National Instruments | 3... -
Page 4: Front Panel And Connector Pinouts
Connections that exceed any of the maximum ratings of any connector on Caution the NI 5782R can damage the device and the chassis. NI is not liable for any damage resulting from such signal connections. For the maximum input and output ratings for... - Page 5 50 Ω SE analog output (AO) channel 0. AO 0 AI 0 50 Ω SE AO channel 1. AO 1 AI 1 AO 0 AO 1 14-Bit AI 16-Bit AO Analog I/O NI 5782R User Manual and Specifications | © National Instruments | 5...
- Page 6 AUX I/O port is not an HDMI interface. Do not connect the AUX I/O port on the NI 5782 into the HDMI port of another device. NI is not liable for any damage resulting from such signal connections. 6 | ni.com | NI 5782R User Manual and Specifications...
-
Page 7: Block Diagram
AO 0 Data N–3 Interface AO 1 Data N Data AO 1 Data N–1 Clock AO 1 Data N–2 AO 1 Data N–3 Analog AO 1 Front End IOModSyncClock NI 5782R User Manual and Specifications | © National Instruments | 7... -
Page 8: Ni 5782 Component-Level Intellectual Property (Clip)
CLIP Adapter Module CLIP Socket User-Defined LabVIEW Adapter Socketed CLIP FPGA VI Fixed I/O Module CLIP DRAM 0 DRAM 1 CLIP Socket CLIP Socket Socketed Socketed CLIP CLIP DRAM0 DRAM1 8 | ni.com | NI 5782R User Manual and Specifications... - Page 9 – Internal Sample Clock – Internal Sample Clock locked to an external Reference Clock through the CLK IN connector – External Sample Clock through the CLK IN connector NI 5782R User Manual and Specifications | © National Instruments | 9...
-
Page 10: Connecting Cables
(CLK IN) Clock through the CLK IN front panel connector. External Clock 250 MHz to Connect an external Sample Clock through the (CLK IN) 1 GHz CLK IN front panel connector. 10 | ni.com | NI 5782R User Manual and Specifications... -
Page 11: Using Your Ni 5782R With A Labview Fpga Example Vi
LabVIEW FPGA application. This section explains how to use an existing LabVIEW FPGA example project to generate and acquire samples with the NI 5782R. This example requires at least one SMA cable to connect signals to your NI 5782R. - Page 12 Click OK in the Configure Open FPGA VI Reference dialog box. Save the VI. On the front panel, in the RIO Resource pull-down menu, select an NI 5782R resource that corresponds with the target that you configured in step 6.
-
Page 13: Creating A Labview Project And Running A Vi On An Fpga Target
This section focuses on proper project configuration, proper CLIP configuration, and how to access 5782 AI IO nodes. For more detailed information about acquiring data on your NI 5782R, refer to the device-specific examples available in NI Example Finder. - Page 14 15. Right-click the input node of the Timed Loop to wire an FPGA Clock Constant to the node. Set this constant to IO Module\Data Clock. Your block diagram should resemble the block diagram in Figure 6. Figure 6. 5782SampleAcq (FPGA).vi Block Diagram 14 | ni.com | NI 5782R User Manual and Specifications...
- Page 15 FPGA VI Reference In terminal of the Close FPGA VI Reference function. 15. Wire the error out terminal of the Read/Write Control function to the error in terminal of the Close FPGA VI Reference function. NI 5782R User Manual and Specifications | © National Instruments | 15...
-
Page 16: Appendix A: Specifications
All numeric specifications are typical unless otherwise noted. All graphs Note illustrate the performance of a representative module. Specifications are subject to change without notice. For the most recent device specifications, visit ni.com/manuals. 16 | ni.com | NI 5782R User Manual and Specifications... - Page 17 1 MHz ............>90 dB 100.1 MHz ..........90 dB 501 MHz ........... 70 dB For additional information on the ADS62P49, refer to the Texas Instruments device data sheet at www.ti.com NI 5782R User Manual and Specifications | © National Instruments | 17...
- Page 18 120 160 200 240 280 320 360 400 440 480 520 560 Frequency (MHz) Figure 9. Terminated Input –10 –20 –30 –40 –50 –60 –70 –80 –90 –100 –110 Frequency (MHz) 18 | ni.com | NI 5782R User Manual and Specifications...
- Page 19 –100 –110 Frequency (MHz) Figure 11. Two-Tone Spectral Measurement (19.5 and 20.5 MHz, -10 dBFS) –10 –20 –30 –40 –50 –60 –70 –80 –90 –100 –110 Frequency (MHz) NI 5782R User Manual and Specifications | © National Instruments | 19...
- Page 20 Figure 12. Analog Input Bandwidth (Passband) –1 –2 –3 –4 –5 –6 –7 –8 –9 –10 120 160 200 240 280 320 360 400 440 480 520 560 Frequency (MHz) 20 | ni.com | NI 5782R User Manual and Specifications...
- Page 21 –100 –110 Frequency (MHz) Figure 14. Analog Input One-Tone Spectral Measurement (70 MHz, -1 dBFS) –10 –20 –30 –40 –50 –60 –70 –80 –90 –100 –110 Frequency (MHz) NI 5782R User Manual and Specifications | © National Instruments | 21...
- Page 22 DLL On.............250 MHz to 1 GHz DAC part number..........DAC5682Z ; 16-bit resolution, dual DAC For additional information on the DAC5682Z, refer to the Texas Instruments device data sheet at www.ti.com 22 | ni.com | NI 5782R User Manual and Specifications...
- Page 23 100.1 MHz ..........90 dB 251 MHz ........... 90 dB Figure 16. Bandwidth (Passband) –1 –2 –3 –4 –5 –6 –7 –8 –9 –10 Frequency (MHz) Includes DAC sinc response. NI 5782R User Manual and Specifications | © National Instruments | 23...
- Page 24 1 kHz Resolution Bandwidth, 1 MHz Bandwidth) –10 –20 –30 –40 –50 –60 –70 –80 –90 –100 –110 69.5 69.6 69.7 69.8 69.9 70.0 70.1 70.2 70.3 70.4 70.5 Frequency (MHz) 24 | ni.com | NI 5782R User Manual and Specifications...
- Page 25 Figure 20. Analog Output One-Tone Spectral Measurement (70 MHz, 0.25 dBm, 1 kHz Resolution Bandwidth, 500 MHz Bandwidth) –10 –20 –30 –40 –50 –60 –70 –80 –90 –100 –110 Frequency (MHz) NI 5782R User Manual and Specifications | © National Instruments | 25...
- Page 26 100.1 MHz ..........100 dB 251.0 MHz ..........87 dB Figure 21. Analog Output Bandwidth (Passband) –1 –2 –3 –4 –5 –6 –7 –8 –9 –10 Frequency (MHz) Includes DAC sinc response. 26 | ni.com | NI 5782R User Manual and Specifications...
- Page 27 1 kHz Resolution Bandwidth, 1 MHz Bandwidth) –10 –20 –30 –40 –50 –60 –70 –80 –90 –100 –110 69.5 69.6 69.7 69.8 69.9 70.0 70.1 70.2 70.3 70.4 70.5 Frequency (MHz) NI 5782R User Manual and Specifications | © National Instruments | 27...
- Page 28 1 kHz Resolution Bandwidth, 500 MHz Bandwidth) –10 –20 –30 –40 –50 –60 –70 –80 –90 –100 –110 Frequency (MHz) Internal Sample Clock General Characteristics Oscillator type...........Fixed frequency synthesizer Frequency (default)...........1 GHz Reference spurs..........<60 dBc 28 | ni.com | NI 5782R User Manual and Specifications...
- Page 29 Input power (50 Ω ).......... 7.0 dBm to 16.8 dBm For additional information about the AD9512, refer to the Analog Devices device data sheet at www.analog.com IoModSyncClock is available only on NI PXIe-796xR FPGA modules. NI 5782R User Manual and Specifications | © National Instruments | 29...
- Page 30 Maximum V ..........3.6 V ............50 Ω ± 20% (DC).............±2 mA Pull-down resistor ..........150 k Ω Recommended operating voltage......-0.3 V to 3.6 V Overvoltage protection ........±10 V Maximum toggle frequency......6.6 MHz 30 | ni.com | NI 5782R User Manual and Specifications...
- Page 31 P33V ..............3.09 V to 3.47 V P12V ..............11.12 V to 12.60 V Physical Dimensions ............11.4 × 10.2 × 2.00 cm (4.5 × 4.0 × 0.8 in.) Weight............... 317.5 g (11.2 oz) NI 5782R User Manual and Specifications | © National Instruments | 31...
- Page 32 • UL 61010-1, CSA 61010-1 For PXI/PXI Express chassis configurations that group NI FlexRIO adapter modules in three or more contiguous slots, National Instruments recommends limiting the ambient operating temperature to less ° than 50 32 | ni.com | NI 5782R User Manual and Specifications...
- Page 33 NI customers. For additional environmental information, refer to the Minimize Our Environmental Impact web page at . This page contains the environmental regulations and directives ni.com/environment NI 5782R User Manual and Specifications | © National Instruments | 33...
-
Page 34: Appendix B: Installing Emi Controls
NI FlexRIO system. Your kit includes the HDMI cable ferrite, but the PXI EMC filler panels (National Instruments part number 778700-01) must be purchased separately. For more installation information, refer to the NI FlexRIO FPGA Module Installation Guide and Specifications. - Page 35 Do not over tighten screws (2.5 lb-inch maximum). For additional information about the use of PXI EMC filler panels in your PXI system, visit and enter ni.com/info emcpanels NI 5782R User Manual and Specifications | © National Instruments | 35...
-
Page 36: Where To Go For Support
LabVIEW, National Instruments, NI, ni.com, the National Instruments corporate logo, and the Eagle logo are trademarks of National Instruments Corporation. Refer to the Trademark Information at ni.com/trademarks for other National Instruments trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies.
