Bosch LTC 2662/90 Series Technical Specifications

CCTV | LTC 2662/90 Series Color Universal Video Multiplexer
LTC 2662/90 Series Color Universal Video
Multiplexer
The Universal Multiplexer uses state-of-the-art technology
to produce high quality, true-to- life color video images.
Enhanced circuitry allows increased image accuracy and
faster display rates without annoying on-screen-flickering
(aliasing) common with multiscreen displays. These units
can display any camera to either monitor A or B and include
camera sequencing and alarm or action call-up. With an
additional unique camera display lockout feature, the
selected camera will not display on both monitors.
However, selected video camera(s) will record in the
background. These units can simultaneously record and
view on multiscreens and can playback previously recorded
tapes from 6 different manufacturers.
Functions
Furnished with a switching power supply, the Universal
Multiplexer intelligently detects the input signal and input
voltage and automatically sets the unit for PAL/NTSC or EIA/
CCIR. User-friendly controls make these units fast and easy
to program and operate. An on-screen programming menu
in English, French, German, Spanish, Dutch, or Italian is
included. A Quick Setup feature or customized system
configuration is available through the advanced setup
program. Help screens guide the operator through the
setup process.
▶ User-friendly
▶ AutoSet startup
▶ High quality video image
▶ Digital motion detection
▶ Timed events feature
▶ Camera display lockout
▶ Compatible with all VCR types
▶ Decodes multiple recording formats
When the AutoSet feature is enabled, the system
automatically configures itself for recording, sequencing,
and video loss listing based on the number of connected
cameras. These multiplexers also include a Timed Events
feature, which allows preprogrammed set up parameters,
including the record functions, to be activated based on the
time of day. Up to six separate operational settings can be
programmed and stored in memory. To enhance the
recording of cameras, the Digital motion Detection feature
intelligently analyzes the motion content of all camera
inputs and ensures that the camera(s) with motion are
recorded as a priority. There are two modes of the activity
detection, "exclusive" and "interleave" which are also
operational under alarm conditions.
In addition, the Digital Motion Detection feature provides
four levels of sensitivity, including direction sensing and a
special walk-through setup to eliminate false alarms. A
selectable audible buzzer is available in this mode.
Additionally, these units include a wide selection of features
such as front panel controls, synchronization with VCR head
switching, freeze, 4X zoom, video loss indicators, alarm
capture, password security protection, multirelay function
outputs, and full function time and date with 16 character
titling record capability. All units are compatible with
standard VHS and Super VHS format Normal or High Density
