Page 1 Backup Sensors User’s Information...
Page 2: Table Of Contents
Contents Introduction ... 3 Important Information ... 4 How the Backup Sensors Work ... 5 Limitations ... 8 Operation ... 10 Daily Inspection... 12 Caring for the Backup Sensors... 13 Troubleshooting... 14 © 2006 American Honda Motor Co., Inc. - All Rights Reserved.
Page 3: Introduction
Introduction Thank you for purchasing this Honda accessory. Please read this User’s Information carefully before using the backup sensors, and keep this manual in the glove box for future reference. This product is designed to be used exclusively on an Honda CR-V. Honda is not responsible if the unit is used for any other intended purpose.
Page 4: Important Information
However, the system may not detect all objects depending on their size, shape, and location. • Even with the backup sensors, the driver is still responsible for making sure the path is clear when driving in reverse.
Page 5: How The Backup Sensors Work
The sensors operate by emitting ultrasonic waves. They calculate the distance between the rear bumper and an obstacle by measuring the time the ultrasonic waves take to reach the sensor after being reflected by an obstacle. © 2006 American Honda Motor Co., Inc. - All Rights Reserved. How the Backup Sensors Work CORNER SENSOR CENTER...
Page 6: How The Backup Sensors Work
How the Backup Sensors Work The sensors are designed to give you an audible signal when the rear bumper is approaching an obstacle. • The audible signal has three sounds: Corner Sensors Center Sensors Sound Slow intermittent Within 2.0 feet Within 4.9 feet...
Page 7 The sensors may not detect the rear bumper of tall vehicles. © 2006 American Honda Motor Co., Inc. - All Rights Reserved. How the Backup Sensors Work The system can be turned on/off by operating the switch of the buzzer.
Page 8: Limitations
Limitations The sensors may not work if the obstacle is an odd shape or made of material that does not reflect ultrasonic waves. Examples: POLE CARDBOARD CARTON SMALL TREE SOFT SNOW AND OTHER ABSORBENT OBJECTS CURBSTONE WIRE, ROPE, AND NET FENCE The sensors may not work if the ambient air temperature is below -4°F (-20°C) or above 122°F (50°C).
Page 9 The audible signal may sound warning even if there is no obstacle behind the vehicle: • Sensors clogged with snow, dirt or mud 4202050Y The sensors may sound continuously under the following conditions: • When driving on rough surfaces or gravel roads or in grass, or when stopped on a hill ©...
Page 10: Operation
Operation Before using the backup sensors, become familiar with the types of sounds in relation to the distances between the sensors and the obstacle by actually backing your vehicle into a garage or parking space. Also confirm the obstacle detecting range of each backup sensor.
Page 11 Check that the intermittent warning beeps become quicker as you bring the palm of your hand closer to the sensor. For the corner sensors: About 1.5 feet (45 cm) For the center sensors: About 3.3 feet (100 cm) Check that the intermittent warning beeps change to a continuous beep as you bring the palm of your hand closer to the sensor.
Page 12: Daily Inspection
Daily Inspection Turn the ignition switch to ON (II), and apply the parking brake. Depress the brake pedal, and move the shift lever to the reverse position. Check that the audible signal sounds for about one second. • The sensors are normal if the audible signal sounds for about one second.
Page 13: Low-Pressure Water
LOW-PRESSURE WATER 4202090Y © 2006 American Honda Motor Co., Inc. - All Rights Reserved. Caring for the Backup Sensors Do not spray high-pressure water against the sensors. HIGH- PRESSURE WATER (Do not use.)
Page 14: Troubleshooting
• Frozen sensor • Melt with lukewarm water • Extended parking in • The backup sensors may not cold weather or work if the outside air under blazing sun temperature is below -4°F (-20°C) or above 122°F (50°C).
Page 15: Troubleshooting With Beeps
Troubleshooting Troubleshooting With Beeps When you turn the ignition switch to ON (II), and the backup sensor signal sounds more than once, there may be a problem with one of the sensors. Corner Sensors Two fast beeps: right sensor is faulty. Three fast beeps: left sensor is faulty.
