Pioneer DEH-P9100R Manual

Pioneer DEH-P9100R Manual

Multi-cd/md/dab control dsp high power cd player with rds tuner
Hide thumbs Also See for DEH-P9100R:
Table of Contents

Advertisement

Quick Links

See also: Service Manual , Operating Manual
Multi-CD/MD/DAB control DSP High power
CD player with RDS tuner
Manual
DEH-P9100R

Advertisement

Table of Contents
loading

Related Manuals for Pioneer DEH-P9100R

Summary of Contents for Pioneer DEH-P9100R

  • Page 1 Multi-CD/MD/DAB control DSP High power CD player with RDS tuner Manual DEH-P9100R...

  • Page 2: Table Of Contents

    Installation ..........4 Basic Operation of Multi-CD Player ....28 • Switching the Display Installation with the Rubber Bush ...... 4 • Track Search and Fast Forward/Reverse Removing the Unit ..........5 • Disc Search • Switching the Display Installing the Steering Remote (When playing a CD TEXTdisc on a CD Control Unit ...........

  • Page 3: High Pass Filter (High Pass

    Using Multi-CD Players .......48 Initial Setting ........73 • Repeat Play (Play Mode) Entering the Initial Setting Menu ..... 73 • Random Play (RandomPlay) Initial Setting Menu Functions ......74 • Scan Play (Scan Play) • Changing the FM Tuning Step •...

  • Page 4: Installation

    • Before finally installing the unit, connect the wiring temporarily, making sure it is all connected up properly, and the unit and the system work properly. • Use only the parts included with the unit to ensure proper installation. The use of unauthorized parts can cause malfunctions.

  • Page 5: Removing The Unit

    Removing the Unit Frame Pull out to remove the frame. (When reattaching the frame, point the side with a groove downwards and attach it.) Insert the supplied extraction keys into the unit, as shown in the figure, until they click into place.
  • Page 6 WARNING • Avoid installing this unit in such a location where the operation of safety devices such as airbags is prevented by this unit. Otherwise, there is a danger of a fatal accident. • Avoid installing this unit in such a location where the operation of the steering wheel and the gearshift lever may be prevented.

  • Page 7: Control Unit

    Installing the Unit on a Left-Hand-Drive Car • When the unit is installed on a right-hand-drive car, the horizontal positions are inverted. Inner holder Belt • Fit the inner holder to the steering wheel so that the arrow-marked side faces the driver as shown below.

  • Page 8: Connecting The Units

    • This unit is for vehicles with a 12-volt battery and negative grounding. Before installing it in a recreational vehicle, truck, or bus, check the battery voltage. • To avoid shorts in the electrical system, be sure to disconnect the battery cable before beginning installation.
  • Page 9 • When this product’s source is switched ON, a control signal is output through the blue/white lead. Connect to an external power amp’s system remote control or the car’s Auto-antenna relay control terminal (max. 300 mA 12 V DC). If the car features a glass antenna, connect to the antenna booster power supply terminal.

  • Page 10: Connection Diagram

    Basic Connection Depending on the kind of vehicle, the function of 3* and 5* may be different. In this case, be sure to connect 2* to 5* and 4* to 3*. Multi-CD player (sold separately) Connect leads of the same color to each other.
  • Page 11 This product conforms to new cord colors. IP-Bus input (Blue) RCA output IP-BUS cable Refer to “Connecting to a Sold Separately Power Amp”. ASL unit Antenna jack This Product Blue/white To system control terminal of the power amp (max. 300 mA 12 V DC). Refer to “Connecting to a Sold Separately Power Amp”.
  • Page 12 Connecting to a Sold Separately Power Amp This product can be connected to a sold separately power amp using the RCA output jacks. Connecting cords with RCA pin plugs (sold separately) Front output Power amp (sold separately) Rear output Power amp (sold separately) This Product Power amp...

  • Page 13: Rfp Alert Installation

    CAUTION • Because of the complexity of today’s technically advanced vehicle wiring systems, we recommend that your RFP Alert be installed ONLY by a professional Pioneer installer. Affix the included deterrent stickers to the inside of the front door windows.

  • Page 14: Door Switch (White/Yellow)

    DOOR SWITCH (White/yellow) Grounding Type Switch: Most European, Japanese, GM and Chrysler vehicles. • Set RFP Alert to recognize ground trigger from RFP Alert Setting Menu. Set Door System to “Door System: Negative, Current mode: Close”. This Product White/yellow Fuse holder Dome light Factory Door Switches...

  • Page 15: Positive (Non-Grounding) Type Switch

    Positive (Non-grounding) Type Switch: Jaguar, Mercedes, Ford • Set RFP Alert to recognize positive trigger from RFP Alert Setting Menu. Set Door System to “Door System: Positive, Current mode: Close”. This Product White/yellow Dome light Factory Door Switch Fuse holder Installing New Pin Switches Separately sold pin switches are available that can be used to protect your vehicle’s trunk, hood, etc.

  • Page 16: Key Finder

    Head Unit DISPLAY button FUNCTION button RESET button EJECT button buttons %!# ENTERTAINMENT button EQ selector BAND button Buttons 1–6 +/– button PGM button PTY button AUDIO button SOURCE/OFF button TA button Steering Remote Controller A steering remote controller that enables remote operation of the head unit is supplied. Operation is the same as when using buttons on the head unit.

  • Page 17: Before Using This Product

    About This Product • This product complies with the EMC Directives (89/336/EEC, 92/31/EEC) and CE Marking Directive (93/68/EEC). The tuner frequencies on this product are allocated for use in Western Europe, Asia, the Middle East, Africa and Oceania. Use in other areas may result in improper reception. The RDS function operates only in areas with FM stations broadcasting RDS signals.

  • Page 18: About The Demo Mode

    About the Demo Mode This product features two demonstration modes. One is the Reverse Demo mode, the other is the Feature Demo mode. Reverse Demo If you do not perform an operation within about 30 seconds, screen indications start to reverse, and then continue reversing every 10 seconds.

  • Page 19: When Using The Dab (Digital Audio Broadcasting) Tuner

    When using the DAB (Digital Audio Broadcasting) Tuner You can use this product with a separately sold hide-away DAB tuner (GEX-P900DAB, GEX- P900DABII). For details concerning operation, refer to the DAB Tuner’s Operation Manuals. This section provides information on DAB operations with this product which differs from that described in the DAB Tuner’s Operation Manual.

  • Page 20: Operation

    Operation With this product, operation of the following four functions differs. (Reference pages are in the Hide-away DAB Tuner’s Operation Manual.) • Changing the Label (Refer to page 12.) • Changing Display Indications (Refer to page 13.) • Operating Announcements with Function Menu (Refer to page 19.) •...

  • Page 21: Precaution

    • Protect the product from moisture. • If the battery is disconnected, the preset memory will be erased and must be reprogrammed. In Case of Trouble Should this product fail to operate properly, contact your dealer or nearest authorized Pioneer Service Station.

  • Page 22: Remote Controller And Care

    Using the Steering Remote Controller • Do not operate this unit while manipulating the steering wheel as it might result in a traffic accident. • If you have to operate this unit unavoidably when driving, look ahead carefully to avoid the risk of being involved in a traffic accident.
  • Page 23 Replacing the Lithium Battery ² • Replace the battery with a CR2032 lithium battery. • Replace the battery in the unit using a non metallic tapered instrument. WARNING: • Keep the lithium battery out of reach of children. Should the battery be swallowed, immediately consult a doctor.

  • Page 24: Basic Operation

    3 Multi-MD player 3 Multi-CD player 3 External Unit 3 AUX • External Unit refers to a Pioneer product (such as one available in the future) that, although incompatible as a source, enables control of basic functions by this product. Only one External Unit can be controlled by this product.

  • Page 25: Basic Operation Of Tuner

    Basic Operation of Tuner This product’s AF function can be switched ON and OFF. AF should be switched OFF for normal tuning operations. (Refer to page 38.) Manual and Seek Tuning Manual Tuning (step by step) 0.5 seconds or less Seek Tuning 0.5 seconds or more •...

  • Page 26: Basic Operation Of Built-In Cd Player

    Basic Operation of Built-in CD Player Switching the Display Eject Each press of the DISPLAY button changes Press the EJECT button, and you can the display in the following order: open the front panel before ejection. Playback mode (Play Time) 3 Disc Title In case of opening the front panel, you can just eject a CD.

  • Page 27: Disc Loading Slot

    Track Search and Fast Forward/Reverse Track Search 0.5 seconds or less Fast forward/Reverse Continue pressing Disc Loading Slot If a CD is inserted, the front panel is closed automatically. The Built-in CD player plays one standard 12 cm or 8 cm (single) CD at a time.

  • Page 28: Basic Operation Of Multi-Cd Player

    Basic Operation of Multi-CD Player This product can control a Multi-CD player (sold separately). Switching the Display Track Search and Fast Forward/Reverse Each press of the DISPLAY button changes the display in the following order: Playback mode (Play Time) 3 Disc Title Track Search 0.5 seconds or less Fast forward/Reverse...

  • Page 29: Disc Number Search

    Disc Number Search (for 6-Disc, 12-Disc types) • When a 12-Disc Multi-CD Player is connected and you want to select disc 7 to 12, press the 1 to 6 buttons for 2 seconds. Disc Number Rough Search (for 50-Disc type only) This handy function lets you select discs loaded in a 50-Disc Multi-CD Player using the 1 to 5 buttons.

  • Page 30: Corresponding Display Indications And Buttons

    Corresponding Display Indications and Buttons This product’s display features Key Guidance Indicators. These light to indicate which of the buttons you can use. When you’re in the Function Menu (refer to next section), %!# Detailed Setting Menu (refer to page 34), Initial Setting Menu (refer to page 73) or Audio Menu 1, 2 (refer to pages 55 and 63), they also make it easy to see which buttons you can %!#...

  • Page 31: Entering The Function Menu

    Entering the Function Menu The Function Menu lets you operate simple functions for each source. • After entering the Function Menu, if you do not perform an operation within about 30 seconds, the Function Menu is automatically canceled. Each press changes the Mode ... The button used and the operation it performs are indicated by the key guidance indicator.

  • Page 32: Function Menu Functions

    Function Menu Functions The following chart shows functions for each source in the Function Menu. The chart also shows indications for each function, operations and buttons used to perform operations. For more details, or when you want to know about an operation, refer to the page number indicated in the chart.
  • Page 33 Multi-CD Player Repeat Play (Play Mode) : Select (Play Range) Selecting Discs by Disc Title List : Select (Disc Title) (Disc List) : Play Selecting Tracks by Track Title List : Select (Track Title) (Track List) : Play Random Play (RandomPlay) : ON : OFF Scan Play (Scan Play)

  • Page 34: Entering The Detailed Setting Menu

    Entering the Detailed Setting Menu In the Detailed Setting Menu, you can operate convenient, complex functions for each source. Hold for 2 seconds Each press changes the Mode ... • You can cancel the Detailed Setting Menu by pressing the FUNCTION button again for 2 seconds.

  • Page 35: Detailed Setting Menu Functions

    Detailed Setting Menu Functions The following chart shows functions for each source in the Detailed Setting Menu. The chart also shows indications for each function, operations and buttons used to perform operations. For more details, or when you want to know about an operation, refer to the page number indicated in the chart.

  • Page 36: Tuner Operation

    Local Seek Tuning (LOCAL) When Local mode is ON (“LOC” indicator lights), you can only select broadcast stations providing strong reception. : LEVEL 1 4 LEVEL 2 4 LEVEL 3 4 LEVEL 4 MW/LW : LEVEL 1 4 LEVEL 2 •...

  • Page 37: Using Rds Functions

    What is RDS? RDS (Radio Data System) is a system for transmitting data along with FM programs. This data, which is inaudible, provides a variety of features such as: program service name, program type display, traffic announcement standby, automatic tuning and program type tuning, intended to aid radio listeners in tuning to a desired station.

  • Page 38: Af Function (Alternativefrequency)

    AF Function (AlternativeFrequency) The AF (Alternative Frequencies search) function is used to search for other frequencies in the same network as the currently tuned station. It automatically retunes the receiver to another frequency in the network which is broadcasting a stronger signal when there are problems with reception of the currently tuned station or better reception is possible on a different frequency.

  • Page 39: Pi Seek Function

    PI Seek Function The tuner searches for another frequency broadcasting the same programming. “PI Seek” appears on the display and the radio volume is muted during a PI Seek. The muting is discontinued after completion of the PI Seek, whether or not the PI seek has succeeded. If the PI Seek is unsuccessful, the tuner returns to the previous frequency.

  • Page 40: Traffic Announcement Standby Function

    Traffic Announcement Standby Function (Traffic Announcement) The TA (Traffic Announcement standby) function lets you receive traffic announcements automatically, no matter what source you are listening to. The TA function can be activated for either a TP station (a station that broadcasts traffic information) or an EON TP station (a station carrying information which cross-references TP stations).

  • Page 41: Canceling Traffic Announcements

    Canceling Traffic Announcements The announcement is canceled but the tuner remains in the TA mode until the TA button is pressed again. Adjusting the TA Volume When a traffic announcement begins, the volume adjusts automatically to a preset level to enable you to hear the announcement clearly.

  • Page 42: Pty Function

    PTY Function With Wide and Narrow classification of program type, the PTY function provides two ways to select stations by the type of program being broadcast (PTY Search). It also provides automatic tuning to emergency broadcasts (PTY Alarm). • There’s no need to perform PTY Search settings again if they have previously been set. After switching to the PTY Search Setting mode in Step 1, just perform PTY Search in Step 4.

  • Page 43: News Program Interruption Setting (News)

    News Program Interruption Setting (News) You can switch automatic reception of PTY code news programs ON/OFF. When a received news program ends, reception of the previous program resumes. “NEWS” Hold for 2 seconds • You can also switch the News Program Interruption Setting ON/OFF in the Function Menu. PTY Alarm PTY Alarm is a special PTY code for announcements regarding emergencies such as natural disasters.

  • Page 44: Pty List

    PTY List News&Inf News News. Affairs Current affairs. Info General information and advice. Sport Sports programs. Weather Weather reports/Meteorological information. Finance Stock market reports, commerce, trading etc. Popular Pop Mus Popular music. Rock Mus Contemporary modern music. Easy Mus Easy listening music. Oth Mus Other types of music, which can’t be categorized.

  • Page 45: Using The Built-In Cd Player

    Repeat Play (Play Mode) Repeat Play plays the same track repeatedly. • If you perform Track Search or Fast Forward/Reverse, Repeat Play is automatically canceled. Random Play (RandomPlay) Random Play plays the tracks on a CD in random order for variety.

  • Page 46: Scan Play (Scan Play)

    Scan Play (Scan Play) Scan Play plays the first 10 seconds or so of each track on an CD in succession. If the Function Menu has been canceled automatically, select the Scan mode in the Function Menu again. • Scan Play is canceled automatically after all the tracks on a disc have been scanned. Pause (Pause) Pause pauses the currently playing track.

  • Page 47: Selecting Tracks By Track Title List

    Selecting Tracks by Track Title List (Track List) Every 6 track titles on a CD TEXT disc are displayed. You can scroll the display. “No T.Title” is displayed for track whose titles have not been input. • You can also select and play the desired track title directly with the 1 to 6 buttons. •...

  • Page 48: Using Multi-Cd Players

    Repeat Play (Play Mode) There are three repeat play ranges: One-track Repeat, Disc Repeat and Multi-CD player Repeat. Default repeat play range is Multi-CD player Repeat. Multi-CD player Repeat (“Magazine Repeat” is displayed) 3 One-track Repeat (“Track Repeat” is displayed) 3 Disc Repeat (“Disc Repeat”...

  • Page 49: Scan Play (Scan Play)

    Scan Play (Scan Play) In the Disc Repeat, the beginning of each track on the selected disc is scanned for about 10 seconds. In the Multi-CD player Repeat, the beginning of the first track on each disc is scanned for about 10 seconds. After selecting the desired repeat play range from those referred to in “Repeat Play”...

  • Page 50: Compression And Dbe (Compression)

    Compression and DBE (Compression) Using the Comp. (Compression) and DBE (Dynamic Bass Emphasis) functions enables Multi- CD player sound quality adjustment. Each of the functions enables two-step adjustment. Comp. DBE The Comp. (Compression) function DBE (Dynamic Bass Emphasis) boosts adjusts imbalances between loud and bass levels to give a fuller sound.

  • Page 51: Its (Instant Track Selection)

    ITS (Instant Track Selection) The ITS function allows you to search for the track you wish to play when a Multi-CD player is installed. You can use ITS to program automatic playback of up to 24 tracks per disc from up to 100 discs.

  • Page 52: Erase A Track Program

    Erase a Track Program ITS is canceled and playback of the next ITS-programmed track begins. If there are no more programmed tracks in the current range, “ITS EMPTY” is displayed and normal play resumes. Erase a Disc Program Disc Title Disc Title Input (Title Input ABC) You can input Titles up to 10 letters long for up to 100 discs.
  • Page 53 Each press of button 1 changes the Character type in the following order: Alphabet (Upper case), Numbers and Symbols 3 Alphabet (Lower case) 3 European letters, such as those with accents (e.g. á, à, ä, ç) • You can select to input Numbers and Symbols by pressing button 2. To insert a space, select the flashing cursor “_”.

  • Page 54: Selecting Discs By Disc Title List (Disc List)

    Selecting Discs by Disc Title List (Disc List) Every 6 discs are displayed. You can scroll the display. Follow the procedures below to play a disc for which you have input the title in a Multi-CD player or a CD TEXT disc on a CD TEXT compatible Multi-CD player. “No D.Title”...

  • Page 55: Audio Adjustment

    Selecting the Equalizer Curve You can switch between Equalizer curves. SUPER BASS 4 POWERFUL 4 NATURAL 4 VOCAL 4 CUSTOM 4 FLAT • “CUSTOM” stores an equalizer curve you have made adjustments to. (Refer to “Adjusting Equalizer Curves” on page 59.) •...

  • Page 56: Audio Menu 1 Functions

    Audio Menu 1 Functions The Audio Menu 1 features the following functions. Balance Adjustment (FAD/BAL) This function allows you to select a Fader/Balance setting that provides ideal listening conditions in all occupied seats. “Fader Front:15” – “Fader Rear:15” is displayed as it moves from front to rear. “Balance Left:9”...

  • Page 57: Graphic Equalizer

    Graphic Equalizer Compared to compensation for car interior acoustic characteristics provided by the Auto- equalizing function, this lets you create your own equalization curves as desired. There are two types of equalizer curves: Default equalizer curves (Factory curves) and a user- defined equalizer curve (Custom).

  • Page 58: Recalling The Equalizer Curves (Equaliz E R)

    Recalling the Equalizer Curves (Equaliz You can easily recall equalizer curves. There are two ways to do it. Direct Recall • When you have performed Auto-equalizing (refer to page 68), you can turn AUTO EQ ON and OFF by pressing the button for the equalizer curve that was called. Sequential Recall Super Bass 4 Powerful 4 Natural 4 Vocal 4 Custom 4 Flat...

  • Page 59: Adjusting The Equalizer Curves (Equaliz E R)

    Adjusting the Equalizer Curves (Equaliz All curves but Flat can be adjusted (fine adjustment). Adjustment can be made by either using Graphic Equalizer or 13-Band Graphic Equalizer Adjustment. Graphic Equalizer The factory curves can be adjusted at fine levels (nuance control). Display shows “+6”...
  • Page 60 13-Band Graphic Equalizer Adjustment You can select this mode only when you select Custom. 50 4 80 4 125 4 200 4 315 4 500 4 800 4 1.3k 4 2k 4 3.2k 4 5k 4 8k 4 12.5k (Hz) Display shows “+6”...

  • Page 61: Sound Field Control And Octaver

    Sound Field Control and Octaver The sound field control function (SFC) incorporates 3 programs for reproducing typical sound fields of a studio etc. This function makes it possible to reproduce a realistic sound field of a studio etc. in your car. Octaver makes the bass sound loud effectively.

  • Page 62: Position Selector

    Position Selector One way to assure a more natural sound is to clearly position the stereo sound image (putting you in the center of the sound field). The Position Selector function adjusts volume level of sound from each speaker to match seat positions and the number of people in the car, and lets you recall settings at the touch of a button.

  • Page 63: Entering The Audio Menu 2

    Entering the Audio Menu 2 In the Audio Menu 2, you can operate convenient, complex functions for each source. • After entering the Audio Menu 2, if you do not perform an operation within about 30 seconds, the Audio Menu 2 is automatically canceled. •...

  • Page 64: Audio Menu 2 Functions

    Audio Menu 2 Functions The Audio Menu 2 features the following functions. Subwoofer Output (Sub W-1) When a Subwoofer is connected, switch Subwoofer output ON. Initially, Subwoofer output is OFF. The Subwoofer output phase can be switched between normal, or 0° (“Phase:NOR”), and reverse, or 180°(“Phase:REV”).

  • Page 65: Non-Fading Output (Non Fad E -1)

    Non-Fading Output (Non Fad When the Non-Fading Output setting is ON, the audio signal does not pass through this unit’s low pass filter (for the Subwoofer), but is output through the RCA output. • When the Subwoofer Controller setting is only “Sub woofer control External”, you can switch the Non-Fading Output ON/OFF mode.

  • Page 66: High Pass Filter (High Pass)

    High Pass Filter (High Pass) When you do not want sound in the Subwoofer output frequency range output from the front or rear speakers, switch the High Pass Filter ON. Only higher frequencies than those in the selected range are output from the front and rear speakers. 50 4 80 4 125 (Hz) Loudness Adjustment (Loudn The Loudness function compensates for deficiencies in the low and high sound ranges at low...

  • Page 67: Automatic Sound Levelizer (Asl) Function

    Automatic Sound Levelizer (ASL) Function During driving, noise in the car changes according to the driving speed and road conditions. The automatic sound levelizer (ASL) monitors such varying noise and automatically increases the volume level, if this noise becomes greater. The sensitivity (variation of volume level to noise level) of ASL can be set to one of five levels.

  • Page 68: Auto-Equalizing Function

    Auto-equalizing Function This product’s Auto-equalizer automatically measures car interior acoustic characteristics, and then creates the Auto-equalizer curve based on that information. Before Operating the Auto-equalization WARNING: • To prevent accidents, never perform Auto-equalizing when driving. When this function measures car interior acoustic characteristics to create an Auto-equalizer curve, a loud measurement tone (noise) may be output from the speakers.

  • Page 69: Auto-Equalizing

    Auto-equalizing (Refer to “Position Selector” on page 62.) • When not setting for the “Front Seat Left” or “Front Seat Right”, if you start Auto-equalizing, “Front Seat Left” is automatically selected. If the engine is left running, engine noise may prevent correct Auto-equalizing. The Auto-equalizer curve may differ depending on where you place the microphone.

  • Page 70: Auto-Equalizing

    The measurement tone (noise) is output from the speakers, and Auto-equalizing (acoustic characteristics measurement and compensation) begins. • When all speaker units are connected, Auto-equalizing is completed in about 7 or 8 minutes. • To cancel Auto-equalizing part way through, press any button. When correct measurement of car interior acoustic characteristics is not possible, an error message is displayed.

  • Page 71: Error Codes Of Auto-Equalizing Function

    Error Codes of Auto-equalizing Function When correct measurement of car interior acoustic characteristics is not possible with the Auto- equalizer, the following error messages are displayed. After checking, try again. Error Check Mic Microphone is not connected. Plug in the supplied microphone securely into the jack.

  • Page 72: Front Panel

    Theft Protection The front panel of the head unit is detachable to discourage theft. • Never use force or grip the display tightly when removing or replacing the front panel. • Avoid subjecting the front panel to excessive shocks. • Keep the front panel out of direct sunlight and high temperatures. Detaching the Front Panel •...

  • Page 73: Initial Setting

    Entering the Initial Setting Menu With this menu, you can perform initial settings for the product. Hold for 2 seconds Each press changes the Mode ... • Holding down the FUNCTION button for 2 seconds also cancels the Initial Setting Menu.

  • Page 74: Initial Setting Menu Functions

    Initial Setting Menu Functions The Initial Setting Menu features the following functions. Changing the FM Tuning Step (FM tuning step) Normally set at 50 kHz during Seek tuning in the FM mode, the tuning step changes to 100 kHz when the AF or TA mode is activated. It may be preferable to set tuning step to 50 kHz in the AF mode.

  • Page 75: Switching The Auto Pi Seek (Auto Pi Seek)

    Switching the Auto PI Seek (Auto PI Seek) During Preset Station PI Seek operation, you can switch the Auto PI Seek function ON/OFF. (Refer to “PI Seek Function” on page 39.) Setting the Warning Tone (Warning Tone) You can switch the Warning Tone function ON/OFF. (Refer to “Warning Tone” on page 72.) Switching the AUX Mode (AUX) It is possible to use auxiliary (AUX) equipment with this product.

  • Page 76: Switching The Rear Speaker Output

    Switching the Rear Speaker Output (Rear Speaker Out) This product's rear speaker leads can be used for full-range speaker (“Full Range output”) or Subwoofer (“Sub woofer output”) connection. If you switch Rear Speaker Lead setting to the “Sub woofer output”, you can connect a rear speaker lead directly to a Subwoofer without using an auxiliary amp.

  • Page 77: Setting The Dimmer (Dimmer)

    Setting the Dimmer (Dimmer) To enable this product’s display from being too bright at night, when the vehicle’s head lights are turned ON the display is dimmed. You can switch this function ON/OFF. Selecting the Illumination Color (Illumination Color) This product is equipped with two illumination colors, green and red. You can select the desired illumination color.

  • Page 78: Selecting The Wall Paper (Wall Paper)

    Selecting the Wall Paper (Wall Paper) This product is equipped with three types of wall paper. Selecting the Brightness (Brightness) You can select the display brightness. The display shows “0” – “31”.

  • Page 79: Rfp Alert Function

    Activating the RFP Alert Feature Pioneer has developed a menu display that allows you to set-up your RFP Alert to meet your personal needs. By scrolling through this menu it is possible to select your own “Entry Delay Time”, “Speaker Output Volume”...

  • Page 80: Activating Internal Speaker On/Off

    Activating Internal Speaker ON/OFF This feature allows you to select whether or not the speaker output is sounded when the “RFP Alert” is triggered. Initially from the factory the speaker output is activated. Toggling between ,  buttons allows you to deactivate or activate the “Speaker Output”. If you switch the speaker output OFF, you cannot change the “Test Mode”.

  • Page 81: Selecting Door Switching Systems

    Selecting Door Switching Systems It is necessary to select the correct “Door System Type” (Negative or Positive switching) for that of your vehicle. Initially, the system is set for vehicles with the grounding type (Negative switching). Select the correct “Door System Type” of your vehicle from below. Vehicles to select “Door System: Vehicles to select “Door System: Negative, Current mode: Close”...

  • Page 82: Operation Of "Rfp Alert

    Upon entering your vehicle, and within the “Entry Delay Time” set within the “RFP Alert Menu”, attach your Pioneer Front Panel as described on page 72. If you have forgotten your removable front panel, simply insert the ignition key in the ignition...

  • Page 83: Entry Detection

    Entry Detection If the “RFP Alert” was not disarmed in accordance with “Disarming Alert”, the “RFP Alert” will be triggered. The “RFP Alert” will sound for 60 seconds and will repeat 5 times if any door is left open or reopened. After the fifth time the “RFP Alert” will reset to prevent continuous sounding and prevent your battery from discharging.

  • Page 84: Other Functions

    Switching the Entertainment Display You can change the display to the movie screens, etc. while listening to each source. (e.g. MOVIE SCREEN MODE 1) Each press changes the Display ... Each press of the ENTERTAINMENT button changes the display in the following order: SPECTRUM ANALYZER MODE 1 3 SPECTRUM ANALYZER MODE 2 3 SPECTRUM ANALYZER MODE 3 3 MOVIE SCREEN MODE 1 3 MOVIE SCREEN MODE 2 3 MOVIE SCREEN MODE 3...

  • Page 85: Using The Pgm Button

    Using the PGM Button The PGM button operates in a different way depending on the function programmed (memorized). Tuner Best Stations Memory (BSM) Regional Function (Regional) ON/OFF ––––– Local Seek Tuning (Local) ON/OFF Entering the Local Seek Sensitivity mode Built-in CD Player Pause (Pause) ON/OFF –––––...

  • Page 86: Using The Aux Source

    Using the AUX Source It is possible to use auxiliary (AUX) equipment with this product. To listen to auxiliary equipment, switch the AUX Mode in the Initial Setting Menu ON, and then select the desired source. Selecting the AUX Source Each press changes the Source ...

  • Page 87: Cd Player And Care

    Precaution • Play only CDs bearing the Compact Disc Digital Audio mark. (If a CD features the top right mark on its disc title side, that disc is a CD TEXT disc. There are also some CD TEXT discs that do not feature the top right mark.) •...

  • Page 88: Built-In Cd Player's Error Message

    When problems occur with CD playback, an error message appears on the display. Refer to the table below to identify the problem, then take the suggested corrective action. If the error persists, contact your dealer or your nearest PIONEER Service Center. ERROR- 11, 12, 17, 30 Dirty disc.

  • Page 89: Specifications

    General CD player Power source ....14.4 V DC (10.8 – 15.1 V allowable) System ........Compact disc audio system Grounding system ........... Negative type Usable discs ............ Compact disc Max. current consumption ......... 10.0 A Signal format ....... Sampling frequency: 44.1 kHz Dimensions Number of quantization bits: 20;...
  • Page 90 PIONEER ELECTRONICS OF CANADA, INC. 300 Allstate Parkway, Markham, Ontario L3R 0P2, Canada TEL: (905) 479-4411 PIONEER ELECTRONICS DE MEXICO, S.A. de C.V. Published by Pioneer Electronic San Lorenzo Num 1009 3er piso Desp. 302 Corporation. Copyright © 2000 by Pioneer Col.
