Page 1: User Manual
SCZ-3250PD(ND) SCZ-2250PD(ND) SCZ-2250P(N) SCZ-3250P(N) Power Zoom Camera User Manual imagine the possibilities Thanks you for purchasing this Samsung product. To receive a more complete service, please visit our website www.samsungsecurity.com... - Page 2 overview CAUTION RISK OF ELECTRIC SHOCK.DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSISTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.
- Page 3 IF THIS PRODUCT FAILS TO OPERATE NORMALLY, CONTACT THE NEAREST SERVICE CENTER. NEVER DISASSEMBLE OR MODIFY THIS PRODUCT IN ANY WAY. (SAMSUNG IS NOT LIABLE FOR PROBLEMS CAUSED BY UNAUTHORIZED MODIFICATIONS OR ATTEMPTED REPAIR.) WHEN CLEANING, DO NOT SPRAY WATER DIRECTLY ONTO PARTS OF THE PRODUCT. DOING SO MAY CAUSE FIRE OR ELECTRIC SHOCK.
- Page 4 overview FCC STATEMENT THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS : 1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND 2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
-
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including amplifi... -
Page 6: Table Of Contents
overview CONTENTS Important Safety Instructions OVERVIEW Contents Features What’s Included At a Glance Preparing Installation INSTALLATION & Connecting the Cables CONNECTION Main Menu SETUP Profi le Camera Set Intelligent Video Privacy Zone Preset Other Set Communication System Info Shortcut Keys APPENDIX Specifi... -
Page 7: Features
This is appropriate to high quality recording and fi le only ) transfer via the Internet. ( SCZ-3250PD(ND) SCZ-3250P(N) High performance surveillance camera, equipped with x25 zoom lens and digital zoom IC, enabling monitoring up to 400 times... -
Page 8: What's Included
overview WHAT’S INCLUDED Please check if your camera and accessories are all included in the product package. Camera Holder Camera (Mount Adaptor) User's Manual 2 Screws AT A GLANCE SIDE VIEW Mount Adapter Fixing Grooves Camera Lens Wipe out a dirty surface of the lens softly with a lens tissue or cloth to which you have applied ethanol. - Page 9 Rear Panel SCZ-3250P(N) SCZ-2250P(N) SCZ-3250PD(ND) SCZ-2250PD(ND) Input/Output Connector This connector has input and output ports for RS-485 control signals, DAY/NIGHT switching, and alarm output signals. SCZ-2250PD(ND) SCZ-2250P(N) SCZ-3250PD(ND) SCZ-3250P(N) English _9...
- Page 10 Alarm out jack for motion detection. (Open Collector, On Gnd) 2. GND Grounding jack. 3. TRIGGER IN ( SCZ-3250PD(ND) SCZ-3250P(N) Displays the current still image when it receives the Trigger signal. (Normal Open Type) 4.5.6 FOCUS, COM, ZOOM This port is used for ZOOM/FOCUS, MENU CONTROL, HOME RETURN, and ONEAF by using an external controller.
- Page 11 * 2 : For short voltage supply during MENU OFF, executes ONEAF and for more than 2 second * 3 : For more than 2 second long voltage supply, moves to the PRESET 0(HOME) position. 7. 5V OUT Power supply jack for RS-485 JIG. Use within typical DC +5V 100mA. 8.
-
Page 12: Installation & Connection
To install and use the camera, fi rst prepare the following cables. Power Adapter Cable (sold separately) The requirements for the power adapter, which connects to the camera’s POWER IN terminal, are as follows: SCZ-3250PD(ND) : DC 12V 600mA SCZ-2250PD(ND) AC 24V 300mA... - Page 13 R IG 5 . C 4 . F G E R O C U 6 . Z O O M 7 . 5 8 . D A Y /N IG H T IN +12V SCZ-2250PD(ND) SCZ-3250PD(ND) SCZ-3250P(N) SCZ-2250P(N) English _13...
- Page 14 Next, plug the power adapter into a wall outlet. 5. If the camera operates normally, the following screen will be displayed for 5 seconds and then disappears. SYSTEM INFO TYPE TYPE 4_25ZOM_WDR_N 4_25ZOM_WDR_N PROTOCOL PROTOCOL SAMSUNG SAMSUNG-E ADDRESS ADDRESS COMM.TYPE COMM.TYPE RS485,HALF RS485,HALF BAUD RATE BAUD RATE...
-
Page 15: Setup
setup Using OSD icons ◄► : If these icons appear in the left and right corner of a menu item, you can use them move to the previous or next menu. (EXIT): Exits the menu setup screen. Before exiting the setup screen, select <SAVE> to save your settings to the whole menus, or <QUIT>... -
Page 16: Profi Le
setup COMMUNICATION Confi gures the settings pertaining to RS-485 communication. SYSTEM INFO Shows the system information such as the camera version or communication settings. PROFILE You can select one from the pre-determined configurations as appropriate to your specific camera installation environment. Your selection on each item in PROFILE will affect all other settings of the camera. - Page 17 CAMERA SETUP MENU STANDARD BACKLIGHT DAY/NIGHT GAMING Parent Menu Sub-menus LEVEL BACKLIGHT IRIS WEIGHT Custom Setting Custom Setting MEDIUM Custom Setting Custom Setting WDR LEVEL Custom Setting Custom Setting Custom Setting Custom Setting WHITE BAL Custom Setting Custom Setting Custom Setting Custom Setting Custom Setting (F.FAST) (F.FAST) (F.FAST)
-
Page 18: Camera Set
When done, press [ENTER]. The camera ID will be displayed in the specifi ed position. If you set it to <ON>, the camera images will be displayed in progressive mode. VPS is only available for SCZ-3250P(N) SCZ-3250PD(ND) 18_ setup... - Page 19 As long as you use the VPS function, the WDR will not be available as the CCD read method differs accordingly. If you set VPS to ON, WDR will be set to <OFF> accordingly. WDR is only available for SCZ-3250PD(ND) MANUAL SCZ-3250P(N) [ 00 ] ----I---- LEVEL MANUAL : Adjust the iris level manually.
- Page 20 setup With this, you can adjust the AGC level of a CAMERA SET camera. CAMERA ID CAMERA ID With AGC active, if the signal strength falls below the standard level, AGC will amplify the IRIS IRIS video signal to automatically improve the (VERY HIGH) --- sensitivity.
- Page 21 SHUTTER CAMERA SET CAMERA SET CAMERA ID CAMERA ID You can select a fixed fast electronic shutter speed in 7 options ranging from 1/100 to 1/10k, IRIS IRIS which is mostly used to take a picture of a fast (VERY HIGH) (VERY HIGH) -- --- moving object.
- Page 22 setup DAY/NIGHT You can specify a recording mode according to the scene. DAY/NIGHT AUTO WHITE BAL WHITE BAL Select <CAMERA SET> - <DAY/NIGHT>. FOCUS MODE FOCUS MODE ONEAF ONEAF ZOOM SPEED ZOOM SPEED [ 2 2 ] ] Select a screen transition mode according DISPLAY ZOOM DISPLAY ZOOM to the illumination, and set options as...
-
Page 23: White Bal
EXT : The interface to an external alarm enables an automatic switch between DAY and NIGHT mode. If you use an infrared light source while in AUTO mode, this may cause a failure in AUTO SWITCH or AUTO FOCUS. WHITE BAL If you need to adjust the color according to the ambient illumination, you can use the <WHITE BAL>... -
Page 24: Focus Mode
setup You can set the R-GAIN, and B-GAIN value only in <AWC> mode. WHITE BAL WHITE BAL DAY/NIGHT DAY/NIGHT MODE [ [ 00 00 ] ] ---- ---- I I ---- ---- NIGHT : You can set the <WHITE BAL> [ [ 00 00 ] ] ---- ---- I I ---- ----... -
Page 25: Zoom Speed
the focus manually, that will operate the same as in <MF>. This will also restore focus after the operation of zoom. - ONEAF : Restores focus after the operation of zoom, and operates the same as in <MF> DAY/NIGHT DAY/NIGHT AUTO AUTO WHITE BAL... - Page 26 It’s a must to use AC 24V power supply when you select line lock for SCZ-2250P(N) SCZ-3250P(N) Line lock is not available for SCZ-2250PD(ND) SCZ-3250PD(ND) AGC COLOR SUP You can adjust the color reproduction range according to AGC. REVERSE You can reverse the video signal from left DAY/NIGHT...
-
Page 27: Intelligent Video
taken under a fl uorescent lamp / Regular-patterned image. INTELLIGENT VIDEO You can enable the motion detection and tracking functions. Select <MAIN MENU>-<INTELLIGENCE>. Select each item and set appropriately. MOTION INTELLIGENCE You can enable the motion detection and tracking functions. MOTION MOTION ADVANCED... - Page 28 setup MASK AREA MASK AREA MASK AREA Select the number of the area to be <SIZE> masked that will be excluded from <LOCATION> <LOCATION> motion detection. Select the mask number and set the mask size and its coverage. DISPLAY When selected <ON>, it displays the motion detected and detection of configured advanced function.
-
Page 29: Privacy Zone
PRIVACY ZONE You can set up to 12 privacy zones that will be hided for privacy of the subject when recording. Zone Setup Select <MAIN MENU>-<PRIVACY PRIVACY ZONE ZONE>. Select the number of the zone and press [ENTER]. PRIVACY SET PRIVACY SET The Zone setup screen appears. -
Page 30: Preset
setup PRESET This function provides preset camera settings such as zoom and focus so to enable quicker and easier accessing and monitoring, which supports up to 512 presets. Select <MAIN MENU>-<PRESET>. MAIN MENU MAIN MENU Select the preset number. PROFILE PROFILE CAMERA SET CAMERA SET... -
Page 31: Other Set
OTHER SET You can reset the system by running FACTORY DEFAULTS, or set the font color etc. lANGUAGe OTHER SET Select <LANGUAGE> and use the left/right button to select a preferred display language. LANGUAGE ENGLISH EXTERNAL TRG EXTERNAL TRG (OFF)--- (OFF)--- Select <MAIN MENU>-<OTHER SET>. -
Page 32: Communication
By inputting the wire remote port, you may set up the A, B, C or D mode. Tele Wide Near Code COMMUNICATION COMMUNICATION Select <MAIN MENU>- PROTOCOL PROTOCOL SAMSUNG SAMSUNG-E <COMMUNICATION>. BAUD RATE BAUD RATE 9600 9600 ADDRESS ADDRESS Select each item and set appropriately. -
Page 33: System Info
SYSTEM INFO You can check the system information. SYSTEM INFO TYPE TYPE 4_25ZOM_WDR_N 4_25ZOM_WDR_N Select <MAIN MENU>-<SYSTEM INFO>. PROTOCOL PROTOCOL SAMSUNG SAMSUNG-E The current system information is ADDRESS ADDRESS COMM. TYPE COMM. TYPE RS485, HALF RS485, HALF displayed. BAUD RATE... -
Page 34: Shortcut Keys
appendix SHORTCUT KEYS You may control this camera by using Controller (SSC-5000). Function DAY/NIGHT - DAY [PRESET] + [5] + [1] + [2] + [ENTER] DAY/NIGHT - NIGHT [PRESET] + [5] + [1] + [3] + [ENTER] DAY/NIGHT - AUTO [PRESET] + [5] + [1] + [4] + [ENTER] DAY/NIGHT - EXT [PRESET] + [5] + [1] + [5] + [ENTER]... -
Page 35: Specifi Cations
Vertical : 59.94 Hz (INT) / 60 Hz (L/L) Vertcal: 50 Hz (INT) / 50 Hz (L/L) Synchronization INT/LINE LOCK (LINE LOCK is not available for SCZ-2250PD(ND) / SCZ-3250PD(ND) Horizontal : 600 TV LINES (color) Resolution Vertical : 350 TV LINES... - Page 36 Item Description N:SCZ-3250ND/SCZ-3250N:X128 PAL: SCZ-3250PD/SCZ-3250P:X160 WDR is not available for SCZ-2250PD(ND) /SCZ-2250P(N) Signal Output COMPOSITE VIDEO OUT : 1.0 Vp-p 75 ohms/BNC x25 Zoom Lens Integrated Focal length : 3.66 ~ 91.36mm Lens Aperture : F1.65(Wide) F3.0(Tale) - MOD(Minimum Object Distance) : 1000mm...
