Specifications; System Requirements; Weight And Dimensions; Ordering Information - Iomega StorCenter ix4-200d Product Release Information

Specifications

•
Desktop, compact, form factor
•
Marvell 6281 CPU at 1.2GHz with 512MB RAM
•
4 x 3.5" Easy-Swap SATA-II Hard Disk Drives
•
RAID Levels: RAID 0, RAID 5, RAID 10, JBOD
•
2 x RJ45 10/100/1000Mbps (GbE) Ethernet ports
LAN standards: IEEE 802.3, IEEE 802.3u
•
3 x USB 2.0 ports (to connect external HDD, printers,
Bluetooth)
•
Client computers for file system access
•
Windows PC, Mac OS, Linux
•
AC Voltage 100-240 VAC
•
Power consumption – 45 Watts maximum
•
Acoustic noise – 30 dBA maximum
Documentation localized for English, German, Spanish,
French, Italian, Brazilian Portuguese, Chinese Simplified, and
Russian
Contents
•
Iomega® StorCenter™ ix4-200d NAS Server
•
Ethernet cable
•
Power supply
•
Printed Quick Start Guide
•
Solutions CD with:
•
System administration software
•
Iomega QuikProtect Software
•
EMC Retrospect Express Backup Software
•
User Manual

Weight and Dimensions

Unit Information
7.9" x 7.7" x 6.6"
200 x 196 x 168 mm
2TB – 10.6 lbs (4.8 kg)
4TB – 12.2 lbs (5.5 kg)
8TB – 12.8 lbs (5.8 kg)
All dimensions LxWxH and are approximations.

Ordering Information

Capacity Configuration
2TB 4 x 500GB HDD
4TB 4 x 1TB HDD
8TB 4 x 2TB HDD
Accessories
Enhanced Service Plan
Spare HDD
Spare HDD
Spare HDD
Product Release Information
Iomega® StorCenter™ ix4-200d NAS Server

System Requirements

•
Available 10/100 Mbps network Ethernet port (required) 1000
Mbps recommended for maximum performance
•
DHCP configured network (recommended)
•
Network hub, switch or router (recommended)
•
PC Users:
•
Pentium® 300Mhz processor or higher; must meet minimum
RAM requirements for your operating system
•
Microsoft® Windows® XP Home/XP Professional/XP
Professional x64; Windows Vista™ Home Basic/Home
Premium/Business/Ultimate
•
Microsoft Internet Explorer 6.0, Netscape
later web browser
•
256MB RAM or higher
•
CD or DVD drive to install software
Mac® Users:
•
Requires Mac OS X 10.3 or later version
•
Apple Safari 2.0 browser or later
•
Must meet minimum RAM requirements for your operating
system CD or DVD drive to install software
Linux® Users
•
Supported Linux distributions: Ubuntu 7.10, Fedora 8, Fedora 7,
Fedora Core 6/5, Red Hat Enterprise Linux 5
Desktop/Workstation, Red Hat Enterprise Linux 4
Desktop/Workstation, OpenSUSE 10.3, Debian 4
Scheduled Availability – September 2009
Single Package Information
12.3" x 10.4" x 8.5"
312 x 264 x 216 mm
2TB – 11.9 lbs (5.4 kg)
4TB – 13.5 lbs (6.1 kg)
8TB – 14.1 lbs (6.4 kg)
Model Name
StorCenter ix4-200d NAS Server, 2TB
StorCenter ix4-200d NAS Server, 4TB
StorCenter ix4-200d NAS Server, 8TB
StorCenter Pro NAS Gold+ Service Support Contract
500GB SATA HDD – NAS ix4-200d/2TB
1TB SATA HDD – NAS ix4-200d/4TB
2TB SATA HDD – NAS ix4-200d/8TB
Master Carton Information
12.5" x 10.8" x 9.3"
318 x 273 x 235 mm
2TB – 12.7 lbs (5.8 kg)
4TB – 14.3 lbs (6.5 kg)
8TB – 14.9 lbs (6.8 kg)
1 unit per master carton
SKU
34547
34550
34564
32903
34717
34718
34719
8.0, Firefox 1.5, or
® ®
Pallet Information
84 units per pallet
7 layers, 12 units per layer
Pallet size 48" x 40" x 70"
1292 lbs (586 kg) max
UPC Code
742709345470
742709345500
742709345647
742709329036
742709347177
742709347184
742709347191
