MB86R11 Evaluation Board
MB86R11EVB
Hardware Manual
January, 2011
The 1.1 edition
FUJITSU SEMICONDUCTOR LIMITED

Advertisement

Table of Contents
loading

Related Manuals for Fujitsu MB86R11

Summary of Contents for Fujitsu MB86R11

  • Page 1 MB86R11 Evaluation Board MB86R11EVB Hardware Manual January, 2011 The 1.1 edition FUJITSU SEMICONDUCTOR LIMITED...
  • Page 2 The company names and brand names herein are the trademarks or registered trademarks of their respective owners. Notation Term Description Generic term of MB86R11 evaluation board which is a set of MB86R11EVB-CPU01 (CPU MB86R11EVB board), MB86R11EVB-BASE01 (Base board), and MB86R11EVB-OPT01 (Option board).
  • Page 3 When you develop equipment incorporating the device based on such information, you must assume any responsibility arising out of such use of the information. FUJITSU SEMICONDUCTOR assumes no liability for any damages whatsoever arising out of the use of the information.

  • Page 4: Revision History

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual Revision History Date Ver. Contents 2011/1/13 Newly issued 2011/1/25 Table 9-1 Revised description Added FPGA specifications...

  • Page 5: Table Of Contents

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual Contents 1. Outline of MB86R11EVB..................1 1.1. Composition ............................1 1.2. General specifications ..........................2 1.3. External view ............................3 1.4. Connection configuration........................5 2. Outline of Hardware.................... 6 2.1. Hardware specifications of CPU board ....................6 2.2.
  • Page 6 MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.3.6. SDIO ............................. 46 3.3.7. PWM ............................. 47 3.3.8. IrDA .............................. 48 3.3.9. IDE ..............................49 3.3.10. SPI-FLASH (Quad)........................50 3.3.11. SPI-FLASH (Single) ........................50 3.3.12. I2C..............................50 3.3.13. General-purpose ADC ........................51 3.3.14.

  • Page 7: Outline Of Mb86R11Evb

    This board mounts only the external peripheral functions. The pin of MB86R11 is multifunctional, and is switched by the external pin setting or the register setting. In MB86R11EVB, to realize the switching of each resource according to the setting mode by an enable control, the buffer is inserted between MB86R11 and each resource.

  • Page 8: General Specifications

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 1.2. General specifications The table below shows the general specifications. Table 1-1 General specifications Item Contents Remarks  CPU board  Board name Base board  Option board  DDR2  Flash ROM ...

  • Page 9: External View

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 1.3. External view The external view of MB86R11EVB is shown as follows. Figure 1-1 External view of MB86R11EVB External view of CPU board Figure 1-2 External view of CPU board 1. Outline of MB86R11EVB...
  • Page 10 MB86R11 Evaluation Board MB86R11EVB Hardware Manual External view of Base board Figure 1-3 External view of Base board External view of Option board Figure 1-4 External view of Option board 1. Outline of MB86R11EVB...

  • Page 11: Connection Configuration

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 1.4. Connection configuration The connection configuration is shown as follows. CPU Board Option Board Base Board MB86R1 Option Board Base Board CPU Board Option board side connector CPUboard side connector CN8 Base board side connector...

  • Page 12: Outline Of Hardware

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual Outline of Hardware This chapter describes the outline of hardware of MB86R11EVB. 2.1. Hardware specifications of CPU board Table 2-1 shows the hardware specifications of CPU board. Table 2-1 Hardware specifications of CPU board...

  • Page 13: Hardware Specifications Of Base Board

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 2.2. Hardware specifications of Base board Table 2-2 shows the hardware specifications of Base board. Table 2-2 Hardware specifications of Base board (1/2) Used FPGA Spartan6 XC6SLX100-2FGG676C (Xilinx) FBGA-676pin Item Contents Remarks The connector is DVI-I.
  • Page 14 Option board connection 160pin stack Customer board connection 87BFN100R-3F (KEL) 100pin right angle connector 8bit slide switch 4 MB86R11 mode selection switch CHS-08B (NIDEC COPAL ELECTRONICS) 8bit slide switch Capture input selection switch CHS-08B (NIDEC COPAL ELECTRONICS) 2. Outline of Hardware...

  • Page 15: Hardware Specifications Of Option Board

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 2.3. Hardware specifications of Option board Table 2-3 shows the hardware specifications of Option board. Table 2-3 Hardware specifications of Option board Item Contents Remarks The connector is DVI-I. Diplay0 DVI-D SiI164BCT64(Silicon Image) The connector is DVI-I.

  • Page 16: Block Diagram

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 2.4. Block diagram Figure 2-1 shows the block diagram of MB86R11EVB. MB86R11 FPGA DISP0 DISP0 DDR2 DISP1 DISP1 Nor Flash DISP2 USB- Host CAP0 Enable signal of each buffer USB- Host CAP1 USB- Function...

  • Page 17: Details Of Hardware

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual Details of hardware This chapter describes details of the hardware of MB86R11EVB. 3.1. CPU board Single-chip system LSI MB86R11 with built-in CoreTex-A9 is used for CPU. Table 3-1 CPU Item Model number Manufacturer Quantity...

  • Page 18: Usb-Function

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.1.4. USB-Function The CPU board has the USB2.0-Function by 1 port (CN4). VBUS is connected to INT_A[1]. Table 3-5 USB-Function Item Model number Manufacturer Quantity Remarks USB connector UX60SC-MB-5ST miniB Schmitt buffer SN74LVC1G17DCK VBUS detection...

  • Page 19: Selection Of Boot Flash Memory

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.1.6. Selection of boot flash memory The CPU board has the switch that selects the boot memory. It can select either of NOR-FLASH or NAND-FLASH of the external memory. Table 3-7 Slide switch Item...

  • Page 20: Pin Multiplex Switch

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.1.7. Pin Multiplex Switch The setting of each switch on CPU board is as follows. Table 3-9 DIP SW Item Model number Manufacturer Quantity Remarks DIP SW CHS-08B NIDEC COPAL ELECTRONICS SW2 (PLLMODE) Default...
  • Page 21 MB86R11 Evaluation Board MB86R11EVB Hardware Manual SW3 (MPXMODE) Default Table 3-11 SW3 setting Signal Description Default MPXMODE[1:0] SW[2:1]=[OFF, OFF]=Mode0 SW[2, 1]= SW[2:1]=[OFF, ON]=Mode1 [OFF, OFF] SW[2:1]=[ON, ON]=Mode1 SW[2:1]=[ON, OFF]=Mode2 MPXMODE[2] OFF=Mode0 ON=Mode2 NOR_EAEN NOR-FLASH bus select ON=32bit OFF=16bit JTAGSEL JTAG select...

  • Page 22: Jumper Setting

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.1.8. Jumper setting The CPU board has the header pin that has the following functions. Table 3-12 General-purpose pin header Item Model number Manufacturer Quantity Remarks General-purpose pin FFC-2ASM1 HONDA TSUSHIN 1 row, 2 poles...

  • Page 23: Base Board

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.2. Base board The AC adaptor is connected to this board, and it supplies power to each board. The signal of the Display, Capture, and External Bus are connected to FPGA, and an enable control is performed for the buffer of each resource according to the mode that the user set.

  • Page 24: Display

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.2.3. Display The Base board has 2 ports (Display0 and Display1) as an image output interface, and is output with the DVI connector. In addition, only the Diplay0 port has CVBS and the analog RGB connector for the analog output.
  • Page 25 MB86R11 Evaluation Board MB86R11EVB Hardware Manual Table 3-17 Capture (CH0) pin assignment Signal name Description No. Signal name I/O Description Ground Ground Ground Ground Ground Ground 10 B7 11 GND Ground 12 GND Ground 13 G0 14 G1 15 G2...
  • Page 26 MB86R11 Evaluation Board MB86R11EVB Hardware Manual SW1 (DISP0_DAC_CTRL) Default Set SW1[2:1]=[OFF, OFF] when I2C0 is used. Default SW1 Signal Description (I2C mode) DSEL Dual edge clock select / I2C Data This pin is an open collector input/output. If I2C bus is enabled (ISEL=OFF), then this pin is the I2C data line.
  • Page 27 MB86R11 Evaluation Board MB86R11EVB Hardware Manual Default SW1 Signal Description (I2C mode) DKEN De-skewing enable. I2C mode (ISEL=OFF) DKEN pin must be set to OFF. DK[3:1] pins are ignored and the De-skewing increments are selected through the I2C interface. Non I2C mode (ISEL=ON) DKEN=ON: then default De-skewing setting is used.
  • Page 28 MB86R11 Evaluation Board MB86R11EVB Hardware Manual SW2 (DISP_DAC_CTRL1) Default Set SW2[2:1]=[OFF, OFF] when I2C0 is used. Default SW2 Signal Description (I2C mode) DSEL Dual edge clock select / I2C Data This pin is an open collector input/output. If I2C bus is enabled (ISEL=OFF), then this pin is the I2C data line.
  • Page 29 MB86R11 Evaluation Board MB86R11EVB Hardware Manual Default SW2 Signal Description (I2C mode) DKEN De-skewing enable. I2C mode (ISEL=OFF) DKEN pin must be set to OFF. DK[3:1] pins are ignored and the De-skewing increments are selected through the I2C interface. Non I2C mode (ISEL=ON) DKEN=ON: then default De-skewing setting is used.

  • Page 30: Capture

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.2.4. Capture The Base board has 4 ports as an image output interface. Capture0 can be input from DVI, NTSC, and the pin header, and Capture1 can be input from HD, NTSC, and the pin header.
  • Page 31 MB86R11 Evaluation Board MB86R11EVB Hardware Manual Table 3-20 Capture (CH0) pin assignment Signal name Description No. Signal name I/O Description Ground Ground Ground Ground Ground Ground 10 B7 11 GND Ground 12 GND Ground 13 G0 14 G1 15 G2...

  • Page 32: Ethernet

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.2.5. Ethernet The Base board has 1 port (CN11) as the Ethernet interface for GbE. Table 3-22 GbE Item Model number Manufacturer Quantity Remarks GbE-PHY 88E1111-B2-BAB-C000 Marvell LAN connector TM21R-5C88(50) Transformer H5007NL Pulse Xtal...

  • Page 33: Can

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.2.8. As for the Base board, CAN0 1ch is connected to the Dsub9 connector (CN14) as the CAN interface. Table 3-25 CAN Item Model number Manufacturer Quantity Remarks Transceiver SN65HVD234 Dsub9 connector RDED-9P-LNA(4-40)(55) Switch...

  • Page 34: Usart (Uart)

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.2.9. USART (UART) As for the Base board, 2ch of USART0/1 is connected to the Dsub9 connector (CN15, CN17) and the general-purpose pin header as the UART interface. Table 3-26 UART Item Model number...

  • Page 35: Gpio

    3.2.10. GPIO MB86R11 has 126 channels as the GPIO interface. The GPIO interface of 10 channels is used in the Base board. They are connected to a tact switch, LED, and a general-purpose connector. The 6 channels are used for the tact switch, and the 4 channels are used for LED and the pin header.

  • Page 36: Sdio

    SDIO The Base board mounts SD0 1ch as the SDIO interface, and is connected to the SD card slot (CN21). The power supply to the SD card is controlled with the pin of MB86R11 (see Figure 3-). Table 3-30 SDIO...
  • Page 37 MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.2.12. The Base board has the TS interface. This interface is connected to pin header (CN23). Table 3-31 TS Item Model number Manufacturer Quantity Remarks General-purpose pin OQW-11-4.2-07PW Mac8 2 rows, 14 poles header...

  • Page 38: Medialb

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.2.13. MediaLB This Base board has one connector (CN24) as the MediaLB interface. Table 3-33 MediaLB Item Model number Manufacturer Quantity Remarks Connector for MOST A3A-10PA-2SV(71) 2 rows, 10 poles controller connection Table 3-34 MOST debug connector pin assignment...

  • Page 39: Pin Multiplex Switch

    MB86R11EVB Hardware Manual 3.2.14. Pin Multiplex Switch The pin of MB86R11 can be switched by MPXMODE[2:0] or the register setting. In the Base board, the same setting as the register setting is set with an external switch. Table 3-35 DIP SW...
  • Page 40 MB86R11 Evaluation Board MB86R11EVB Hardware Manual SW11 (SW_ED) SW11 switches the PIN mode of "PIN Group E and D" of MB86R11. Default Table 3-31 SW11 setting SW11 Group Description Default SW[1]=[OFF]: Mode5 SW[1]=[ON]: Mode0 SW[3, 2]=[ON, ON] SW[6, 5, 4]=[ON, ON, ON]: Mode0...
  • Page 41 MB86R11 Evaluation Board MB86R11EVB Hardware Manual SW14 (SW_IH) SW14 switches the PIN mode of "PIN Group I and H" of MB86R11. Default Table 3-39 SW14 setting SW14 Group Description Default SW[3, 2, 1]=[ON, ON, ON]: Mode0 SW[3, 2, 1]=[ON, ON, ON]...
  • Page 42 MB86R11 Evaluation Board MB86R11EVB Hardware Manual SW19 (DEVICE_SEL) The Caputure0-3 and the color space can be selected by the SW19[5:1] bits. In addition, FPGA internal memory can be checked by the SW19[8:6]. Default Table 3-40 SW19 setting SW19 Function Color Space...

  • Page 43: Option Board

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.3. Option board All functions of MB86R11 can be used by using the CPU board, the Base board, and the Option board. The Option board has the Dual monitor function and the HDMI connector. 3.3.1. Display The Option board mounts three DVI connectors as an image output interface.
  • Page 44 MB86R11 Evaluation Board MB86R11EVB Hardware Manual Default SW1 Signal Description (I2C mode) EDGE Edge select / Hot Plug input. If the I2C bus is enabled (ISEL=OFF), then this pin is used to monitor the "Hot HTPLG Plug" detect signal (Please refer to the DVI or VESA P&D and DFP standards).
  • Page 45 MB86R11 Evaluation Board MB86R11EVB Hardware Manual SW2 (DISP1_DAC_CTRL) Default Set SW1[2:1]=[OFF, OFF] when I2C1 is used. Default SW2 Signal Description (I2C mode) DSEL Dual edge clock select / I2C Data This pin is an open collector input/output. If I2C bus is enabled (ISEL=OFF), then this pin is the I2C data line.
  • Page 46 MB86R11 Evaluation Board MB86R11EVB Hardware Manual Default SW2 Signal Description (I2C mode) DKEN De-skewing enable. I2C mode (ISEL=OFF) DKEN pin must be set to OFF. DK[3:1] pins are ignored and the De-skewing increments are selected through the I2C interface. Non I2C mode (ISEL=ON) DKEN=ON: then default De-skewing setting is used.
  • Page 47 MB86R11 Evaluation Board MB86R11EVB Hardware Manual SW3 (DISP2_DAC_CTRL) Default Set SW3[2:1]=[OFF, OFF] when I2C1 is used. Default SW3 Signal Description (I2C mode) DSEL Dual edge clock select / I2C Data This pin is an open collector input/output. If I2C bus is enabled (ISEL=OFF), then this pin is the I2C data line.
  • Page 48 MB86R11 Evaluation Board MB86R11EVB Hardware Manual Default SW3 Signal Description (I2C mode) DKEN De-skewing enable. I2C mode (ISEL=OFF) DKEN pin must be set to OFF. DK[3:1] pins are ignored and the De-skewing increments are selected through the I2C interface. Non I2C mode (ISEL=ON) DKEN=ON: then default De-skewing setting is used.

  • Page 49: I2S (Audio)

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.3.2. I2S (AUDIO) The Option board has 3 channels as an audio interface. This interface is connected to audio mini-jack and the general-purpose pin header for the connection of the microphone and the speaker.

  • Page 50: Can

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.3.3. The Option board has 1 channel as the CAN interface. This interface is connected to Dsub9 connector (CN6). Table 3-45 CAN Item Model number Manufacturer Quantity Remarks Transceiver SN65HVD234 Dsub9 connector RDED-9P-LNA(4-40)(55) Switch...

  • Page 51: Lin

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.3.5. The Option board has 1 channel (USART ch5) as the LIN interface. This interface is connected to 2pin connector (CN28). The interface of LIN Host and Function can be switched by setting CN27.

  • Page 52: Sdio

    The Option board has 2 channels of Ch1 (CN31) and Ch2 (CN32) as the SDIO interface. This interface is connected to the SD card slot. The power supply to the SD card is controlled with the pin of MB86R11 (see Figure 3-). Table 3-51 SDIO...

  • Page 53: Pwm

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.3.7. The Option board has 12 channels as the PWM interface. This interface is connected to the pin header (CN29 and CN30). CN29 is connected with CR integrating circuit, and CN30 is not connected with it.

  • Page 54: Irda

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.3.8. IrDA The Option board has general-purpose connector (CN24) as the IrDA. Table 3-54 IrDA Item Model number Manufacturer Quantity Remarks General-purpose OQW-11-4.2-06PW Mac8 2 rows, 12 poles connector Table 3-55 IrDA connector pin assignment...

  • Page 55: Ide

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.3.9. The Option board has ATA2.5inch connector (CN33) as the IDE interface. The connection specification is Host. Table 3-56 IDE Item Model number Manufacturer Quantity Remarks ATA connector WCAW-20-2-22PW MAC8 Table 3-57 IDE connector pin assignment...

  • Page 56: Spi-Flash (Quad)

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.3.10. SPI-FLASH (Quad) The Option board has the SPI-FLASH (Quad) interface. This interface is connected to the SPI-FLASH of 32Mbit and the general-purpose pin header. Table 3-58 SPI-FLASH (Quad) Item Model number Manufacturer Quantity...

  • Page 57: General-Purpose Adc

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.3.13. General-purpose ADC The Option board has general-purpose connector (CN1) as the general-purpose ADC interface. This interface is connected to the operational amplifier. The operational amplifier power supply connects +3.3V with the plus side, and connects GND with the minus side.

  • Page 58: Tcon

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 3.3.14. TCON The Option board has general-purpose pin header (CN34) as the TCON interface. Table 3-65 TCON Item Model number Manufacturer Quantity Remarks TCON OQW-11-4.2-07PW Mac8 2 rows, 14 poles Table 3-66 TCON connector pin assignment...

  • Page 59: Board Interface

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual Board interface 4.1. CPU – Base board I/F The CPU board and the Base board are connected by two 160pin stack connectors. Table 4-1 CPU – Base board I/F Item Model number Manufacturer Quantity...
  • Page 60 MB86R11 Evaluation Board MB86R11EVB Hardware Manual The connector pin assignment is shown as follows. Table 4-2 Stack connector pin assignment [CPU (CN8), Base (CN31)] (1/2) Name Name +3.3V +3.3V +3.3V +3.3V DISP0G0 DISP0G4 DISP0G1 DISP0G5 DISP0G2 DISP0G6 DISP0G3 DISP0G7 DISP0R0...
  • Page 61 MB86R11 Evaluation Board MB86R11EVB Hardware Manual Table 4-2 Stack connector pin assignment [CPU (CN8), Base (CN31)] (2/2) Name Name MEM_EA19 MEM_EA6 MEM_EA18 MEM_EA5 MEM_EA17 MEM_EA4 MEM_EA16 MEM_EA3 MEM_EA15 MEM_EA2 MEM_EA14 MEM_EA1 A47 GND B47 GND MEM_ED15 MEM_ED7 MEM_ED14 MEM_ED6 MEM_ED13...
  • Page 62 MB86R11 Evaluation Board MB86R11EVB Hardware Manual Table 4-3 Stack connector pin assignment [CPU (CN9), Base (CN32)] (1/2) Name Name +3.3V +3.3V +3.3V +3.3V DISP0B0 DISP0B4 DISP0B1 DISP0B5 DISP0B2 DISP0B6 DISP0B3 DISP0B7 DISP0HSYNC DISP0VSYNC DISP0CSYNC USART0_SCK USART1_SCK USART0_SOUT USART1_SOUT USART0_SIN USART1_SIN...
  • Page 63 MB86R11 Evaluation Board MB86R11EVB Hardware Manual Table 4-3 Stack connector pin assignment [CPU (CN9), Base (CN32)] (2/2) Name Name AD_VRL0 AD_VRL1 SELFL AD_VR0 AD_VR1 CAP3VI_0 CAP3VI_4 CAP3VI_1 CAP3VI_5 CAP3VI_2 CAP3VI_6 CAP3VI_3 CAP3VI_7 A48 GND B48 GND CAP3CLK CAP2CLK A50 GND...

  • Page 64: Base - Option Board I/F

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 4.2. Base – Option board I/F The Base board and the Option board are connected by 160pin stack connector. Table 4-4 Base – Option board I/F Item Model number Manufacturer Quantity Remarks Connector receptacle...
  • Page 65 MB86R11 Evaluation Board MB86R11EVB Hardware Manual The connector pin assignment is shown as follows. Table 4-5 Stack connector pin assignment [Base (CN7), Option (CN33)] (1/2) Name Name QD0SCK QD0SDI0 QD0SDI1 QD0SEL0 QD0SDI2 QD0SEL1 QD0SDI3 QD0SEL2 QD0SEL3 A10 OSDCLK1 B10 SD1DATA0...
  • Page 66 MB86R11 Evaluation Board MB86R11EVB Hardware Manual Table 4-5 Stack connector pin assignment [Base (CN7), Option (CN33)] (2/2) Name Name A41 GND B41 GND A42 DISP0CKP B42 DISP0CKN A43 GND B43 GND A44 DISP2R7 B44 DISP0B7 A45 DISP2R6 B45 DISP0B6 A46 DISP2R5...
  • Page 67 MB86R11 Evaluation Board MB86R11EVB Hardware Manual Table 4-6 Stack connector pin assignment [Base (CN8), Option (CN34)] (1/2) Name Name PWM_O0 PWM_O2 PWM_O1 PWM_O3 I2S2_ECLK I2S2_SDI I2S2_SCK I2S2_SDO I2S2_WS GPIO86 BUF_EN_RSV SDIO_MMC2 A10 SD_PWR1 B10 SDIO_MMC1 A11 SD_PWR2 B11 GND USART0_SCK...
  • Page 68 MB86R11 Evaluation Board MB86R11EVB Hardware Manual Table 4-6 Stack connector pin assignment [Base (CN8), Option (CN34)] (2/2) Name Name SD0CMD OSDCLK0 A42 GND B42 GND I2S0_SDO I2S1_SDO I2S0_SDI I2S1_SDI I2S0_WS I2S1_WS A46 GND B46 GND I2S0_SCK I2S1_SCK A48 GND B48 GND...

  • Page 69: Customer I/F

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 4.3. Customer I/F The Base board and the Customer's board are connected by 100pin connector. Table 4-7 Connector for Customer's board connection (CN38) Item Model number Manufacturer Quantity Remarks Right angle connector 87BFN100R-3F Receptacle...
  • Page 70 MB86R11 Evaluation Board MB86R11EVB Hardware Manual Table 4-8 Customer's board connector (1/2) Name Name 100 3V MEM_MNREX MEM_XWR3 MEM_MNWEX MEM_XWR2 MEM_ALE MEM_XWR1 MEM_CLE MEM_XWR0 MEM_RDY MEM_XRD MEM_CLK MEM_ED31 MEM_ED23 MEM_ED30 MEM_ED22 MEM_ED29 MEM_ED21 MEM_ED28 MEM_ED20 MEM_ED27 MEM_ED19 MEM_ED26 MEM_ED18 MEM_ED25...
  • Page 71 MB86R11 Evaluation Board MB86R11EVB Hardware Manual Table 4-8 Customer's board connector (2/2) Name Name MEM_ED11 MEM_ED3 MEM_ED10 MEM_ED2 MEM_ED9 MEM_ED1 MEM_ED8 MEM_ED0 INT_A7 MEM_XCS0 XSRST1 MEM_XCS1 MEM_XCS2 6. Customer I/F...

  • Page 72: Memory Map

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual Memory map 5.1. MB86R11EVB memory map MB86R11EVB memory map is shown as follows. Table 5-1 Memory map Class Attributes Device Physical Address Remarks SFI0 EEPROM (32KB) 0x06000000-0x06007FFF SFI1 SPI-FLASH (4MB) 0x16000000-0x163FFFFF SDRAM bus Bus width=32bit...

  • Page 73: Version Register

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 5.2.2. VERSION register VERSION(00h) Initial 0000_0000 Name Reserved Initial 0000_0000 Name Reserved Initial xxxx_xxxx Name Version Initial xxxx_xxxx Name Revision Revison(bit7-0) FPGA Revision Version(bit15-8) FPGA Version 9. Allocation of peripheral resource and I2C port...

  • Page 74: Pinmux Register

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 5.2.3. PINMUX register PINMUX(04h) Initial 0000 Name Reserved Initial Name Initial Name Reser Initial Name Reserved The read value of PINMUX is changed by the DIPSW setting. 000 : mode0 001 : mode1 010 : mode2...
  • Page 75 MB86R11 Evaluation Board MB86R11EVB Hardware Manual G_B(bit5-3) Set value of SW_CB[3:1](Base Board SW10) Read attribute : ON=”L” G_C(bit8-6) SW_CB[6:4](Base BoardのSW10) set value Read attribute : ON=”L” G_D(bit11-9) SW_ED[1](Base Board SW11) set value SW_ED[1]=ON(mode0) : ”000”, OFF(mode5) : ”101” G_E(bit14-12) SW_ED[6:4](Base Board SW11) set value Read attribute : ON=”L”...

  • Page 76: Device_Sel Register

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 5.2.4. DEVICE_SEL register DEVICE_SEL(08h) Initial 0000_0000 Name Reserved Initial 000_0000 Name Reserved MPXMODE[2] Initial xxxx_xxxx Name DEVICE_SEL Initial 0000 Name Reserved SELFL Reserved MPXMODE[1:0] MPXMODE[1:0](bit1-0) MPXMODE[1:0](CPU Board SW3) set value Read attribute : ON=”H”...

  • Page 77: Acc_Test Register

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 5.2.5. ACC_TEST register ACC_TEST(0C～FF) Initial 0000_0000 Name ACC_TEST Initial 0000_0000 Name ACC_TEST Initial 0000_0000 Name ACC_TEST Initial 0000_0000 Name ACC_TEST ACC_TEST(bit31-0) Access Test register. Setting of the SW19(DEVICE_SEL) bit[8:6]=[ON,ON,OFF]. The access except the above setting is “Hi-Z”.

  • Page 78: Fpga Signal Timing

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual 5.2.6. FPGA signal timing FPGA signal timing is shown as follows. MEM_CLK MEM_XCS[1] RIDLC WIDLC MEM_XRD MEM_XWRx MEM_EA[11:0] Read MEM_ED[ 3 1:0] Write Data Data Read Write MEMCS register min setting RACC : 1 (2cycle)

  • Page 79: Allocation Of Peripheral Resource And I2C Port

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual Allocation of peripheral resource and I2C port MB86R11EVB has the I2C port of 5 channels. Ch0 and Ch1 of I2C are allocated in the control of the peripheral resource. The slave address must not overlap if you use the port allocated in the peripheral resource for the interface with the outside.

  • Page 80: Power System Diagram

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual Power system diagram The power system diagram is shown as follows. Figure 7-1 Power system diagram of Base board 10. Power system diagram...
  • Page 81 MB86R11 Evaluation Board MB86R11EVB Hardware Manual The power supply of +5V and +3.3V is supplied from the Base board to CPU board through the stack connector. Figure 7-2 Power system diagram of CPU board 10. Power system diagram...
  • Page 82 MB86R11 Evaluation Board MB86R11EVB Hardware Manual The power supply of +5V and +3.3V is supplied from the Base board to Option board through the stack connector. Figure 7-3 Power system diagram of Option board 10. Power system diagram...

  • Page 83: Clock System Diagram

    MB86R11 Evaluation Board MB86R11EVB Hardware Manual Clock system diagram The clock system diagram of MB86R11EVB is shown as follows. Figure 8-1 Clock system diagram of MB86R11EVB 11. Clock system diagram...
