HG658c Home Gateway

User Guide

HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading

Related Manuals for Huawei HG658c

Summary of Contents for Huawei HG658c

  • Page 1: User Guide

    HG658c Home Gateway User Guide HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 User Guide Issue Date 2012-10-19 Part Number 202537 Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service. Please feel free to contact our local office or company headquarters. Huawei Technologies Co., Ltd. Address: Huawei Industrial Base Bantian, Longgang...
  • Page 3 Thus the descriptions herein may not exactly match the product or its accessories you purchase. Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation.

  • Page 4: Table Of Contents

    3.2 Setting up a Wireless Connection Manually ......6 4 Voice Services ................7 5 Configuring the HG658c ............7 5.1 Accessing Mobile Storage Devices Using the FTP Client ..7 5.2 Changing the User Name and Password for the Web-based Configuration Utility ................
  • Page 5 7.2 Ports and Buttons ..............22 7.3 Default Settings ................ 24 7.4 Product Specifications .............. 24...

  • Page 6: Connecting Cables And Getting Started

    1 Connecting Cables and Getting Started Thank you for purchasing the HG658c (HG658c for short). You can go online using the Ethernet, USB and DSL modem services. However, you can only use one type of service at one time. 1.1 Connecting Cables Using the WAN Port...

  • Page 7: Connecting Cables Using The Usb Port

    4. USB modem 5. HG658c Getting Started After connecting the cables, press the On/Off button on the side of the HG658c to power on the HG658c. After you power on the HG658c, the Power indicator turns on, the USB indicator turns on. This indicates that the HG658c is working properly. When the USB indicator starts blinking, data is being transmitted between the HG658c and the connected device.

  • Page 8: Connecting Cables Using The Dsl Port

    After connecting the cables, press the On/Off button on the side panel to power on the HG658c. After you power on the HG658c, the Power indicator turns on. The WAN indicator lights up and starts blinking. This indicates that the DSL port activation is in progress.

  • Page 9: Setting Network Access Parameters

    5. Set WLAN parameters by choosing Basic > WLAN. You can configure the SSID and WPA pre-shared key. The default wireless network name (SSID) are printed on the label of the HG658c's rear panel are preset before delivery. And then click Next.

  • Page 10: Setting Up A Wireless Connection

    WPS function, do the following to connect your computer to the HG658c over a wireless connection: 1. Press and hold the WPS button (on the HG658c side panel) more than 1 second. 2. The WLAN indicator light on the HG658c starts blinking, indicating that the HG658c is in the WPS negotiation state.

  • Page 11: Setting Up A Wireless Connection Manually

    1. Find the wireless network name (SSID) and its password (WLAN Key) printed on the label of the HG658c's rear panel. 2. Start the wireless configuration service of the Windows XP operating system as follows: 1) Right-click My Computer to display a short-cut menu, and then choose Manage.

  • Page 12: Voice Services

    5 Configuring the HG658c 5.1 Accessing Mobile Storage Devices Using the FTP Client The HG658c supports a home storage function. Mobile storage devices, such as a USB flash drive, can be connected to the USB port on the HG658c. You...

  • Page 13: Changing The User Name And Password For The Web-Based Configuration Utility

    5) Enter a server port number (default is 21) in the Port text box. 6) Click Submit to save the settings. 3. Start the FTP client, and access the HG658c's LAN IP address through the FTP server. 1) On your computer, open a web browser.

  • Page 14: Changing The Login Ip Address

    IP address, enter the new IP address into the web browser's address box. Ensure that the IP address of the computer is in the same network segment as that of the HG658c to enable the computer to access the web-based configuration utility.

  • Page 15: Enabling Or Disabling The Wireless Network Function

    The default wireless network encryption mode is WPA-PSK/WPA2-PSK. You can find the default wireless network name (SSID) and password (WLAN Key) printed on the label of the HG658c's rear panel. To change the wireless network name and password: (This example uses WPA-PSK/WPA2-PSK encryption mode.) 1.

  • Page 16: Configuring The Firewall

    5.6 Configuring the Firewall The firewall can protect the terminal against malicious access on the WAN port and is used when the HG658c works in routing mode. To configure the firewall, do as follows: 1. Log in to the HG658c's web-based configuration utility.

  • Page 17: Restoring Default Settings

    Therefore, exercise caution when using this function. To restore the HG658c to default settings, power on the HG658c, press and hold the Reset button more than 6 seconds, and then release. You can also restore the HG658c to default settings from the web-based configuration utility: 1.

  • Page 18: Faqs

    HG658c's power adapter. If the voltage is unstable, for example, if the voltage is too high or too low, do not use the HG658c. Wait until the voltage recovers, and then use the HG658c.
  • Page 19 If the LAN indicator is off, perform further checks as follows: 1) Check that the network adapter on your computer is enabled. 2) Check that the network cable between the HG658c and the computer is securely connected. Remove and then insert the network cable or replace the network cable when necessary.
  • Page 20 Use a proxy server for your LAN (These settings will not apply to dial-up or VPN connections.) check box is cleared. 8. Try to access more websites to check whether the HG658c can access these websites. If the problem persists, contact your network service provider.
  • Page 21 HG658c's wireless network is displayed as Connected. 7. Try to access more websites to check whether the HG658c can access these websites. If you still cannot access the websites, restore the HG658c to its default settings. If the problem persists, contact your network service provider.
  • Page 22 SSID1. It is recommended that you set the security mode to WPA-PSK/WPA2-PSK. What can I do if I cannot set up a wireless connection between the HG658c and the computer by pressing the WPS button? 1. Check that only one computer tries to connect to the HG658c using the WPS function at a time.
  • Page 23 Note that the WPS function is forcibly disabled if the wireless network uses the Wired Equivalent Privacy (WEP) encryption. 4. Check the positions of the HG658c and the computer. Ensure that they are far from the electric appliances such as microwave ovens, refrigerators, or cordless telephones that generate strong magnetic or electric fields.

  • Page 24: Technical Specifications

    The DSL connection is established and activated. Or the GE connection is successfully established but no data is being transmitted. Green Blinking The DSL connection is being activated. The HG658c is powered off or no DSL or no GE connection is established.
  • Page 25 Green Blinking The Internet connection is successfully established and data is being transmitted. A physical connection is established, but the HG658c is not connected to the Internet. The HG658c is powered off.  The HG658c is working in bridge ...
  • Page 26 Green Blinking The LAN connection is successfully established and data is being transmitted. The HG658c is powered off.  No LAN connection is established.  Green The USB connection is successfully established in USB host mode but no data is being transmitted.

  • Page 27: Ports And Buttons

    Used to power on or off the HG658c. Power Connects a power adapter. Reset Restores the HG658c to default settings if you press and hold for 6 or more seconds. NOTE After you restore the HG658c to default settings, your customized data will be lost.
  • Page 28 Port or Button Function Phone1, Phone2 Connects to a telephone. Connect to computers, switches, or other Ethernet LAN1–LAN4 devices. Used to connect the HG658c to the network. Connects to a USB device.

  • Page 29: Default Settings

    Password for web-based HuaweiUser configuration utility login Wireless network name See the label printed on the HG658c's rear (WLAN Name) for wireless panel. connection Password (WLAN Key) See the label printed on the HG658c's rear for wireless connection panel.
  • Page 30 Item Specifications  G.993.1 Standards ADSL standards  G.993.2  G.992.1  G.992.3  G.992.5  T1.413 ADSL2 G.992.3 (G.dmt.bis) Annex L standard ADSL2+ G.992.5 (G.dmt.bitplus) standard VDSL G.993.2 standard 802.3、802.3u standards 802.3、802.3u standards Wireless 802.11b Up to 11 Mbit/s transmission rates mode 802.11g...
  • Page 31 HUAWEI TECHNOLOGIES CO., LTD. Huawei Industrial Base Bantian, Longgang Shenzhen 518129 People's Republic of China www.huawei.com...
