- Page 1 REFRIGERATOR RT28 OWNER’S INSTRUCTIONS Before operating the unit, please read this manual thoroughly, and retain for future reference. DA99-01149A REV(0.0)
-
Page 2: Table Of Contents
Dealer concerning this product. - Ice cube maker ........- Chiller Compartment ......This manual is made on the basis of - Twin-Vegetable Box ......RT25/ RT28 model. LEVELING THE APPLIANCE ....REMOVING ACCESSORIES ....12,13 Date of Purchase : BEFORE CALLING SERVICE .... -
Page 3: Getting Started
Getting Started Before plugging in for the first time, allow the refrigerator to stabilize for at least one hour. Allow the freezer compartment to cool for 2 to 3 hours before storing food. INSTALLATION The appliance must be positioned so that the electrical supply and plug is easily accessible. -
Page 4: Cautions While Using
CAUTIONS WHILE USING -Do not allow water to splash onto the refrigerator. -Water impairs the insulation of electric parts and may cause an electrical shock or a fire hazard. -Do not use flammable sprays such as lacquer and paint near the refrigerator. - Page 5 -For optimum operation, do not leave the door open for any longer than necessary. -Leaving the door open allows warmer air to enter the refrigerator and causes the refrigeration unit to use more energy to maintain the temperature. -Do not store volatile chemicals such as ether and benzene in the refrigerator.
- Page 6 PARTS(RT25/28) Twist Ice Cube Tray (Select model) Ice Storage Bin (Select model) Freezer Compartment T emperature Control Guard FRE upp (Select model) Super-Freeze Zone (Select model) Chiller Compartment (Select model) Refrigerator Compartment T emperature Control i-Cooling Tray Egg(3-Line) Refrigerator Shelf (Plastic or Steel or glass) Lamp Foldable Storage Guard Pocket Storage Guard...
-
Page 7: Replacing The Lamp
REPLACING THE LAMP Press upper tab of the lamp cover with some tool such as driver and pull it out. -Turn the existing lamp bulb and replace it with a new one. -Replace the lamp cover by aligning the cover at the top ( ) and carefully pressing it into place ( ) -
Page 8: Storing Food
STORING FOOD Store food in small portions (Optional) Seal food in containers with lids, in plastic wrap or in plastic bags to prevent drying and the mingling of odors. Allow hot food and drinks to cool to room temperature before placing them in the refrigerator or freezer. -
Page 9: How To Use
HOW TO USE Freezer T emperature control Temperature control COLDER Turn the T emperature Control to "COLDER" if you; -have a lot of food to store (refrigerator or freezer) -want to make ice (freezer) -require fast freezing (freezer) Freezer Refrigerator NORMAL Refrigerator T emperature control Turn the T emperature Control to the midway... -
Page 10: Ice Cube Maker
Ice Cube Maker (Premium T ype) Fill the ice cube tray with water taking care not to overfill. Slide the tray onto the ice cube shelf. When ice is formed, remove the ice cubes Knobs of ice tray from the ice cube tray by twisting the ice tray knobs. -
Page 11: Chiller Compartment
Chiller Compartment (Premium only) This compartment helps with preserving the taste of food and prolongs its freshness by freezing the surface of the food only . Use the chiller for storing cheese, meat, snacks, fish or any food to be used soon. Twin-Vegetable Box (Premium only) This compartment maintains the moisture and freshness of vegetables. -
Page 12: Leveling The Appliance
LEVELING THE APPLIANCE T o compensate for any floor unevenness, adjust the height of the appliance by turning the adjustable feet clockwise or counterclockwise. The adjustable feet are at the front along the lower edge of the refrigerator chassis. When the refrigerator leans to the left, turn the left front foot counterclockwise. -
Page 13: Removing Accessories
REMOVING ACCESSORIES Freezer Shelf (Premium model) -Pull the shelf forward and slide it out. Refrigerator Shelf -Pull the shelf forward until it meets the stopper. -Tilt the front of the shelf up and pull it out. T win-Vegetable Box and Cover -Pull the vegetable bin forward and take it out of the refrigerator. - Page 14 Chiller Compartment -Pull the chiller compartment towards you until it meets the stopper. -Tilt the front upward and pull the compartment out. Foldable Storage Guard -Rotate the Guard clockwise and push it upward. Bottle Storage Guards Lift the guard up and slide it out (This bottle storage guard is not adjustable;...
-
Page 15: Before Calling Service
BEFORE CALLING SERVICE Problem Problem Probable cause Probable cause Solution Solution 1. Refrigerator Power plug not connected properly Connect the power plug properly not working Input electricity supply voltage Use stabilizer for rated voltage Low/High Stabilizer not working Connect the power plug directly to wall socket. If refrigerator works, call an electrician to fix the stabilizer problem 2. - Page 16 Problem Problem Probable cause Probable cause Solution Solution 4. Noise Legs of Refrigerator not leveled Install refrigerator in a flat/ stable surface & adjust the properly front legs Refrigerator installed too close Maintain proper gap from the walls to wall Objects behind or under the Remove the objects from behind or under the refrigerator...
- Page 17 Note :...
- Page 19 ELECTRONICS Samsung Electronics Co., Ltd. Jan 2006. Printed in India.
