Summary of Contents for Samsung HT-KX715
- Page 1 HT-KX715 HT-TKX715 DVD Karaoke Home Cinema System user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive a more complete service, please register your product at www.samsung.com/global/register...
- Page 2 Anynet+(HDMI-CEC) Function Anynet+ is a function that can be used to operate the main unit using a Samsung TV remote control, by connecting the Home Cinema to a SAMSUNG TV using an HDMI Cable. (This is only available with SAMSUNG TVs that support Anynet+.)
-
Page 3: What's Included
WHAT’S INCLUDED Check for the supplied accessories below. Video Cable FM Antenna HDMI Cable User's Manual Remote Control DVD Karaoke Disc Song List Book ASC microphone... -
Page 4: Safety Information
safety information SAFETY WArNINGS This symbol indicates “dangerous voltage” inside the product that presents a risk of CAUTION electric shock or personal injury. rISK OF ELECTrIC SHOCK DO NOT OPEN This symbol indicates important instructions accompanying the product. CLASS 1 LASER PRODUCT CLASS 1 LASER PRODUCT This Compact Disc player is classified as a CLASS 1 KLASSE 1 LASER PRODUKT... -
Page 5: Precautions
PrECAUTIONS Ensure that the AC power supply in your house complies with the identifi cation sticker located on the back of your player. Install your player horizontally, on a suitable base (furniture), with enough space around it for ventilation (7.5~10 cm). Make sure the ventilation slots are not covered. -
Page 6: Table Of Contents
contents fEATURES What’s included SAfETy INfORmATION Safety Warnings Precautions gETTINg STARTED Before Reading the User’s Manual 10 Playable Discs 10 Do not use the following types of disc! 10 Copy Protection 11 Disc Type and Characteristics DESCRIPTION 12 Front Panel 13 Rear Panel REmOTE CONTROL 14 Tour of the Remote Control 16 Setting the Remote Control CONNECTIONS 18 Connecting the Speakers 22 Connecting the Optional Wireless Receiving Amplifier 24 Connecting the Video Out to your TV 26 HDMI Function 27 Connecting Audio from External Components 29 Connecting the FM Antenna 29 Connecting Microphone bEfORE USINg yOUR hOmE CINEmA... - Page 7 SySTEm SETUP 47 Setting the Language 48 Setting TV Screen Type 49 Setting Parental Controls (Rating Level) 49 Setting the Password 50 DVD Playback Mode 51 Setting the SPEAKER MODE 51 Setting the Delay Time 53 Setting the Test Tone 53 Setting the DRC (Dynamic Range Compression) 54 Setting the AV SYNC 54 Setting the HDMI Audio 55 Sound Field (DSP)/EQ Function 56 Dolby Pro Logic II Mode 56 Dolby Pro Logic II Effect 57 ASC (Auto Sound Calibration) SETUP KARAOKE 59 Playing DVD-OK Discs 59 Reserving a Song 59 Reserving a Song During Accompaniment 60 Priority Playing Accompaniment Music 60 DVD-OK Repeat Play 61 Karaoke Seting Function...
- Page 8 contents TROUbLEShOOTINg 73 Troubleshooting LANgUAgE CODE LIST 75 Language Code List USb hOST fEATURE SUPPORTED 76 Digital Camera PRODUCTS 76 USB Flash Disc 76 MP3 Player APPENDIx 77 Cautions on Handling and Storing Discs 78 Specifications...
-
Page 9: Getting Started
If a problem occurs, check the Troubleshooting. (See pages 73~74) Copyright © 2008 Samsung Electronics Co.,Ltd. All rights reserved; No part or whole of this user’s manual may be reproduced or copied without the prior written permission of Samsung Electronics Co.,Ltd. -
Page 10: Playable Discs
getting started DVD (Digital Versatile Disc) offers fantastic audio and video, thanks to Dolby Digital surround sound and MPEG-2 video compression technology. Now you can enjoy these realistic effects in the home, as if you were in a movie cinema or concert hall. DVD players and the discs are coded by region. -
Page 11: Disc Type And Characteristics
DISC TYPE AND CHArACTErISTICS This product does not support Secure (DRM) Media files. CD-r Discs ❖ Some CD-R discs may not be playable depending on the disc recording device (CD-Recorder or PC) and the condition of the disc. Use a 650MB/74 minute CD-R disc. Do not use CD-R discs over 700MB/80 minute as they may not be played back. -
Page 12: Description
description FrONT PANEL POWER ( ) BUTTON PLAY/PAUSE ( ) BUTTON MIC 1 JACK FUNCTION BUTTON TUNING UP & SKIP ( ) BUTTON MIC 2 JACK TUNING DOWN & SKIP ( ) VOLUME CONTROL AUX IN 1/ASC IN JACK BUTTON DISC TRAY USB PORT STOP... -
Page 13: Rear Panel
rEAr PANEL 5 5.1 CHANNEL SPEAKER OUTPUT CONNECTORS Connect the front, center, rear, subwoofer speakers. COMPONENT VIDEO OUTPUT JACKS Connect a TV with Component video inputs to these jacks. AUX IN 2 JACKS Connect to the 2CH analog output of an external device (such as a VCR) VIDEO OUTPUT JACK Connect the TV's Video Input jack (VIDEO IN) to the VIDEO OUT jack. -
Page 14: Remote Control
remote control TOUr OF THE rEMOTE CONTrOL INFO... - Page 15 DVD RECEIVER button INFO button TV button EJECT button POWER button CANCEL button NUMBER (0~9) buttons PAUSE button RESERVE button PLAY button STOP button REPEAT button SEARCH buttons Tuning Preset/CD Skip buttons TUNING/CH button VOLUME button MUTE button MENU button RETURN button FAVORITE SONG, AUDIO button CURSOR/ENTER button...
-
Page 16: Setting The Remote Control
If there is more than one code listed for your TV in the table, enter one at a time to determine which code works. Example : For a Samsung TV While holding down the POWEr button, use the number buttons to enter 00, 15, 16, 17 and 40. - Page 17 18, 59, 67, 76, 77, 78, 92, 93, 94 Craig 03, 05, 61, 82, 83, 84 Realistic 03, 19 Croslex Sampo Crown Samsung 00, 15, 16, 17, 40, 43, 46, 47, 48, 49, Curtis Mates 59, 61, 63 59, 60, 98 Sanyo 19, 61, 65 Daewoo...
-
Page 18: Connections
connections This section involves various methods of connecting the Digital Home Cinema to other external components. Before moving or installing the product, be sure to turn off the power and disconnect the power cord. CONNECTING THE SPEAKErS Position of Digital Home Cinema Place it on a stand or cabinet shelf, or under the TV stand. -
Page 19: Speaker Components
Front/rear Tallboy Stand (HT-TKX715 only) Speaker Components SCREW (Large) : SPEAKER STAND STAND BASE SCREW (Small) : 16EA How to Install the Speaker on the Stand Turn the STAND upside-down and connect it to the STAND BASE. STAND BASE STAND Turning the SCrEW (Small) clockwise, connect it to four holes marked with the arrow using a screwdriver as shown in the illustration. - Page 20 (+) terminal, and then release the tab. Connect the connecting plugs to the back of the Home Cinema. Make sure the colors of the speaker terminals match the colors of the connecting plugs. Black HT-KX715 Front Speaker (R) Front Speaker (L) Center Speaker Subwoofer...
- Page 21 HT-TKX715 Front Speaker (R) Front Speaker (L) Center Speaker Subwoofer Rear Speaker (R) Rear Speaker (L) Do not let children play with or near the speakers. They could get hurt if a speaker falls. When connecting the speaker wires to the speakers, make sure that the polarity (+/ –) is correct. Keep the subwoofer speaker out of reach of children so as to prevent children from inserting their hands or other objects into the duct (hole) of the subwoofer speaker.
-
Page 22: Connecting The Optional Wireless Receiving Amplifier
CONNECTING THE OPTIONAL WIrELESS rECEIVING AMPLIFIEr To connect the rear speakers by wireless, you have to purchase the wireless receiving module and TX card from your Samsung retailer. When you have Purchased the Wireless receiving Module (SWA-4000) HT-KX715 Front Speaker (R) - Page 23 This product (HT-KX715/HT-TKX715) is compatible with the wireless receiver module SWA-3000. Do not insert any other card except the TX card dedicated to the product. The product might be damaged or the card may not be removed easily.
-
Page 24: Connecting The Video Out To Your Tv
The resolution from the Component Output is 576i(480i). If you use an HDMI cable to connect a Samsung TV to the DVD Player, you can operate the Home Cinema using the TV's remote control. This is only available with SAMSUNG TVs that support Anynet+(HDMI-CEC). -
Page 25: Hdmi Auto Detection Function
(TV, projector. etc). Content is encrypted at the source device to prevent unauthorized copies from being made. What is Anynet+? Anynet+ is a convenient function that offers linked operation of this unit through Samsung TVs with the Anynet+ feature. - If your Samsung TV has an ' logo, then it supports the Anynet+ function. -
Page 26: Hdmi Function
Anynet + can be used by connecting this Home Cinema to a your TV, or watch a movie by pressing SAMSUNG TV using an HDMI Cable. This is only available with the Play button on your Samsung TV's SAMSUNG TVs that support Anynet+. -
Page 27: Connecting Audio From External Components
CONNECTING AUDIO FrOM EXTErNAL COMPONENTS AUX1 : Connecting an External Component/MP3 player Components such as an MP3 Player Audio Cable (not supplied) Audio OUT Connect AUX IN 1 (Audio) on the Home Cinema to the Audio Out of the external component/MP3 player. - Page 28 connections AUX2 : rear Panel OPTICAL : rear Panel Audio Cable (not supplied) Optical Cable If the external analog (not supplied) component has only one Audio Out, connect either left or right. External Analog External Digital Component Component AUX2 : Connecting an External Analog Component Analog signal components such as a VCR.
-
Page 29: Connecting The Fm Antenna
CONNECTING THE FM ANTENNA Connect the FM antenna supplied to the FM 75Ω COAXIAL Jack. Slowly move the antenna wire around until you fi nd a location where reception is good, then fasten it to a wall or other rigid surface. FM Antenna (supplied) This unit does not receive AM broadcasts. -
Page 30: Before Using Your Home Cinema
The DVD Home Cinema's remote can be used to control Samsung TVs. Plug the main unit's power cord into the AC power supply. Press the DVD rECEIVEr button to switch to DVD RECEIVER mode to operate the DVD Home Cinema. -
Page 31: Playback
playback DISC PLAYBACK Load a disc vertically into the Disc Insert Hole. Place a disc gently into the tray with the disc’s label facing Close the compartment by pressing the PLAY ( ) button. Playback starts automatically. To stop playback, press the STOP (@) button during playback. If pressed once, PrESS PLAY is displayed and the stop position will be stored in memory. -
Page 32: Mp3/Wma-Cd Playback
playback MP3/WMA-CD PLAYBACK Data CDs (CD-R, CD-RW) encoded in MP3/WMA format can be played. Load the MP3/WMA disc. The MP3/WMA menu screen will appear and playback will start. The appearance of the menu depends on the MP3/WMA disc. WMA-DRM fi les cannot be played. In Stop mode, use the Cursor $, %, _, + button to select the album, and then press the ENTEr button. -
Page 33: Jpeg File Playback
JPEG FILE PLAYBACK Images captured with a digital camera or camcorder, or JPEG fi les on a PC can be stored on a CD and then played back with this Home Cinema. rotate/Flip Function Press the Cursor $, %, _, + button during playback. button: Flip Vertically button: Rotate 90°... -
Page 34: Divx Playback
playback DIVX PLAYBACK The functions discussed on this page apply to DivX disc playback only. Skip Forward/Back During playback, press the [, ] button. Goes to the next fi le whenever you press the ] button, if there are over 2 fi les on the disc. Goes to the previous fi le whenever you press the [ button, if there are over 2 fi les on the disc. - Page 35 If the Disc has more than One Subtitle File If the disc has more than one subtitle fi le, the default subtitle may not match the movie and you will have to select your subtitle language as follows: In Stop mode, press the Cursor $, % button, select the desired subtitle ( ) from the TV screen, and then press the ENTEr button.
-
Page 36: Using The Playback Function
playback USING THE PLAYBACK FUNCTION BAGD Displaying Disc Information You can view disc playback information on the TV screen. Press the INFO button. Depending on the disc, the disc information display may appear different. Depending on the disc, you can also select DTS, DOLBY DIGITAL, or PRO LOGIC. - Page 37 Slow Playback Press the SLOW button. Each time the button is pressed during playback, the playback speed changes as follows: *1/2 ➞ *1/4 ➞ *1/8 ➞ &1/2 ➞ &1/4 ➞ &1/8 ➞ PLAY *1/2 ➞ *1/4 ➞ *1/8 ➞ PLAY No sound is heard during slow playback.
- Page 38 playback BAGD repeat Playback Repeat playback allows you to repeatedly play a chapter, title, track (song), or directory (MP3 fi le). Press the rEPEAT button. Each time the button is pressed during playback, the repeat playback mode changes as follows: rEPEAT : CHAPTEr ➞...
-
Page 39: Angle Function
A-B repeat Playback You can repeatedly play back a designated section of a DVD. Press the INFO button twice. Press the Cursor + button to move to REPEAT PLAYBACK ) display. Press the Cursor $, % button to select A- and then press the ENTEr button. -
Page 40: Bonus Group
playback Bonus Group DVD-AUDIO Some DVD-Audio discs have an extra ‘bonus’ group that requires a 4-digit key number to access. See the disc packaging for details and the key number. When you play a DVD-Audio disc that has a bonus group, the key number input screen appears automatically. -
Page 41: Subtitle Language Selection Function
Subtitle Language Selection Function Press the INFO button twice. Press the Cursor + button to move to SUBTITLE ( display. Press the Cursor % button or numeric buttons to select the desired subtitle. EN 01/03 SP 02/03 Fr 03/03 OFF/03 EN 01/03 To operate this function, you can also press the SUBTITLE buttons on the remote control. -
Page 42: Using The Disc Menu
playback Using the Disc Menu You can use the menus for the audio language, subtitle language, profi le, etc. DVD menu contents differ from disc to disc. In Stop mode, press the MENU button. Press the Cursor $, % button or numeric buttons to move to Disc Menu and then press the ENTEr button. -
Page 43: Using Bluetooth
(refer to Bluetooth device's user manual) Select the Stereo headset menu on the Bluetooth device. You will see a list of scanned devices. Select "Samsung Home Theater" from the searched Bluetooth devide list. When the Home Cinema System is connected to the Bluetooth device, the Home Cinema System will display "Connect"... - Page 44 playback To disconnect the Bluetooth device from the Home Cinema System You can disconnect the Home Cinema System from the Bluetooth device. (refer to Bluetooth deivice's user's manual) The Home Cinema System will be disconnected. When the Home Cinema System is disconnected from the Bluetooth device, the Home Cinema System will display "Disconnect"...
-
Page 45: Playing Media Files Using The Usb Host Feature
PLAYING MEDIA FILES USING THE USB HOST FEATUrE You can enjoy media fi les such as pictures, movies and music saved on an MP3 player, USB memory stick or digital camera in high quality video with 5.1 channel Home Cinema sound by connecting the storage device to the USB port of the Home Cinema. -
Page 46: Fast Playback
playback Fast playback During playback, press the (, ) button. Each time you press either button, the playback speed will change as follows: 2x 4x 8x 32x Normal. Compatible Devices USB devices that support USB Mass Storage v1.0. (USB devices that operate as a removable disc in Windows (2000 or later) without additional driver installation.) MP3 Player: HDD and fl ash type MP3 players. -
Page 47: System Setup
system setup For your convenience, you can set this Home Cinema System's features for the best use in your home environment. SETTING THE LANGUAGE OSD(On-Screen Display) language is set to English by default. In Stop mode, press the MENU button. Press the Cursor % button to move to Setup and then press the ENTEr or + button. -
Page 48: Setting Tv Screen Type
system setup SETTING TV SCrEEN TYPE Depending on your TV type (Wide Screen or conventional 4:3), you can select the TV's aspect ratio. In Stop mode, press the MENU button. Press the Cursor % button to move to Setup and then press the ENTEr or + button. -
Page 49: Setting Parental Controls (Rating Level)
SETTING PArENTAL CONTrOLS (rATING LEVEL) Use this to restrict playback of adult or violent DVDs you do not want children to view. In Stop mode, press the MENU button. Press the Cursor % button to move to Setup and then press the ENTEr or + button. -
Page 50: Dvd Playback Mode
system setup N button to return to the previous level. d Press the EXIT button to exit the setup screen. DVD PLAYBACK MODE Some DVD-Audio discs contain DVD-Video as well as DVD-Audio. To play back the DVD-Video portion of the DVD-Audio disc, set the unit to DVD-Video mode. -
Page 51: Setting The Speaker Mode
SETTING THE SPEAKEr MODE Signal outputs and frequency responses from the speakers will automatically be adjusted according to your speaker configuration and whether certain speakers are used or not. In Stop mode, press the MENU button. Press the Cursor % button to move to Audio and then press the ENTEr or + button. - Page 52 system setup SETTING THE DELAY TIME Setting up the Speaker Delay Time When 5.1CH Surround Sound is played, you can enjoy the best sound if the distance between you and each speaker is the same. Since the sounds arrive at the listening position at different times depending on the placement of speakers, you can adjust this difference by adding a delay effect to the sound of the Center and Surround Speakers.
-
Page 53: Setting The Test Tone
SETTING THE TEST TONE Use the Test Tone feature to check the speaker connections. In Stop mode, press the MENU button. Press the Cursor % button to move to Audio and then press the ENTEr or + button. Press the Cursor % button to move to TEST TONE and then press the ENTEr or + button. -
Page 54: Setting The Av Sync
system setup Setting the AV SYnC Video may look slower than the audio if it is connected to a digital TV. If this occurs, adjust the audio delay time to to match the video. In Stop mode, press the MenU button. Press the Cursor % button to move to Audio and then press the enteR or + button. -
Page 55: Sound Field (Dsp)/Eq Function
SOUND FIELD (DSP)/EQ FUNCTION DSP(Digital Signal Processor) : DSP modes have been designed to simulate different acoustic environments. EQ : You can select ROCK, POP, or CLASSIC to optimize the sound for the genre of music you are playing Press the DSP/EQ button. DSP appears on the display panel. -
Page 56: Dolby Pro Logic Ii Mode
system setup DOLBY PrO LOGIC II MODE You can select the desired Dolby Pro Logic II AUDIO mode. Press the PL II MODE button. Each time the button is pressed, the mode changes as follows. MUSIC ➞ CINEMA ➞ PrO LOGIC ➞ MATrIX ➞ STErEO ➞... -
Page 57: Asc (Auto Sound Calibration) Setup
ASC (Auto Sound Calibration) SETUP By setting the ASC function just once when you relocate or install the unit, you can have the unit automatically recognize the distance between speakers, levels between channels, and frequency characteristics to create a 5.1-channel sound fi eld optimized for your environment. Microphone L: F SL: R... - Page 58 system setup ASC (Auto Sound Calibration) SETUP Plug the ASC microphone into the ASC input jack. Place the ASC microphone at the listening position. Press ASC button. To create the optimal 5.1 channel sound fi eld, the selections are in the following sequence: L ➞...
-
Page 59: Karaoke
karaoke PLAYING DVD-OK DISCS You can enjoy the feeling of a karaoke bar in the comfort of your home. Watch the video and sing along the lyrics displayed on the TV screen with company. Use the number (0~9) buttons to select the song you want to play back. -
Page 60: Priority Playing Accompaniment Music
karaoke PrIOrITY PLAYING ACCOMPANIMENT MUSIC Even if there is a song already reserved, you can have the song you want to sing to be played fi rst. In Stop mode, press the number (0~9) buttons to select the song you want to play back. Press the PLAY ( ) button. -
Page 61: Setting The Fanfare
KArAOKE SETTING FUNCTION It consists of two modes: Karaoke and Setup. In Karaoke mode, you can select from Search song/ Favorite List/ Bowling game. In Setup mode, you can select from Back-vocal/ Fanfare/ Assessment level/ Shadow/ Language. Press the MENU button in Stop mode. Use the ,... -
Page 62: Setting The Shadow
karaoke Setting the Assessment Level You can set the grade of scores displayed in the screen in advance. Load a DVD-OK disc. Press MENU button. Use the ,,, button to select SETUP Assessment Level. Use the , button to select the desired item and press the ENTEr button. -
Page 63: Searching Song Function
SEArCHING SONG FUNCTION You can easily search songs on screen without viewing the song list book. Pressing the (,) button in Song list mode will move one page at a time. , moves one song at a time. Structure of Song Search Items Detailed Items Alphabet(and Number) -
Page 64: Searching By Genre
karaoke Searching a DUET SONG During the stop mode, press the SEArCH SONG button. or in MENU mode, use the ,,, button to select Karaoke SEArCH SONG Press the rED (b) button, press the , button to select the Dutes. At this time, press rETUrN button to move to the song list on the bottom. -
Page 65: Favorite Song Function
SEArCHING SONG FUNCTION Searching by HIT SONGS During the stop mode, press the SEArCH SONG button. or in MENU mode, use the ,,, button to select Karaoke SEArCH SONG Press the rED (b) button press the , button to select the Hits. - Page 66 karaoke Saving FAVOrITE SONG Case 3> During the playback, press PAUSE ( ) button. Press FAVOrITE SONG button. Press , button to select the favorite list you want to save the song. Press ENTEr button to save the song. Deleting FAVOrITE SONG Press the FAVOrITE SONG button in Stop mode, or use ,,,...
-
Page 67: Key Control
KEY CONTrOL During the playback, press the KEY CONTrOL buttons. Each time GrEEN (#) button is pressed, the key is increased, and each time rED (b) button is pressed, the key is decreased. TEMPO CONTrOL During the playback, press the TEMPO buttons. Each time BLUE (+) button is pressed, the tempo gets faster, and each time YELLOW (–) button is pressed the tempo gets slower. -
Page 68: Male-Female Key Control
karaoke MALE-FEMALE KEY CONTrOL During the playback, press the MALE/FEMALE button. Each time the MALE/FEMALE button is pressed, this selection alternates between Male and Female. Select Male when singing in male voice and select Female when singing in female voice. BOWLING GAME FUNCTION You can make a team to participate in a singing contest. - Page 69 BOWLING GAME FUNCTION reserving a song in the Bowling Game In Bowling Game mode, use the number (0~9) button to select a song. or In Bowling Game mode, press the SEArCH SONG button. Select a song in the Search song list. To return to the Bowling Game mode, press the EXIT button.
-
Page 70: Radio
radio LISTENING TO rADIO remote Control Press the TUNEr button to select the FM band. Tune in to the desired station. Automatic Tuning 1 : When the [, ] button is pressed, a preset broadcast station is selected. Automatic Tuning 2 : Press and hold the ,, . button to automatically search for active broadcasting stations. -
Page 71: Convenient Function
convenient function SLEEP TIMEr FUNCTION You can set the time that the Home Cinema will shut itself off. Press the SLEEP button. SLEEP will be displayed. Each time the button is pressed, the preset time changes as follows : ➞ ➞... -
Page 72: Audio Upscaling
convenient function P.BASS P.BASS function stresses low tones providing thudding sound effects. Press the P.BASS button to select P.BASS mode. P BAS ON P BAS OFF The P.BASS function is only available with 2 channel LPCM sources such as mp3,Divx,cd and wma. Press P.BASS button and "POWER BASS ON"... -
Page 73: Troubleshooting
Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, turn off the unit, disconnect the power cord, and contact the nearest authorized dealer or Samsung Electronics Service Center. SYMPTOM Check/Remedy I cannot eject the disc. - Page 74 troubleshooting SYMPTOM Check/Remedy • Disc is rotating but no picture is • Is the TV power on? produced. • Are the video cables connected properly? • Picture quality is poor and picture is • Is the disc dirty or damaged? shaking.
-
Page 75: Language Code List
language code list Enter the appropriate code number for the initial settings “Disc Audio”, “Disc Subtitle” and/or “Disc Menu” (See page 47). Code Language Code Language Code Language Code Language 1027 Afar 1181 Frisian 1334 Latvian, Lettish 1506 Slovenian 1028 Abkhazian 1183 Irish... -
Page 76: Usb Host Feature Supported Products
Optio 33LF Pentax Digital Camera Dimage X21 Minolta Digital Camera Optio MX Pentax Digital Camera Coolpix4200 Nikon Digital Camera Digimax-420 Samsung Digital Camera Coolpix4300 Nikon Digital Camera Digimax-400 Samsung Digital Camera Coolpix 2200 Nikon Digital Camera Sora PDR-T30 Toshiba Digital Camera... -
Page 77: Appendix
appendix CAUTIONS ON HANDLING AND STOrING DISCS Small scratches on the disc may reduce sound and picture quality or cause skipping. Be especially careful not to scratch discs when handling them. Handling discs Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints will not get on the surface. -
Page 78: Specifications
appendix SPECIFICATIONS Power Consumption 90 W Weight 4.2 kg General Dimensions 449.6 (W) x 251.5 (H) x 99.1 (D) mm Operating Temperature Range +5°C~+35°C Operating Humidity Range 10 % to 75 % Reading Speed : 3.49 ~ 4.06 m/sec. DVD (Digital Versatile Disc) Approx. - Page 79 Subwoofer : 217 x 362 x 412 mm Front/Rear : 6.5 kg Weights Center : 1.2 kg, Subwoofer : 6.7 kg *: Nominal specification - Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. - Weight and dimensions are approximate.
- Page 80 Contact SAMSUNG WOrLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. region Country Customer Care Center Web Site CANADA 1-800-SAMSUNG(726-7864) www.samsung.com/ca North America MEXICO 01-800-SAMSUNG(726-7864) www.samsung.com U.S.A 1-800-SAMSUNG(726-7864) www.samsung.com...
- Page 81 AH68-02090P...
