Page 1: Air Conditioner
4 Way Cassette Type Air Conditioner user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register DB98-32786A(2) -
Page 2: Table Of Contents
Features of your new air conditioner Contents Safety precautions ................. 3 Cool Summer Offer Checking before use ..............7 On those hot sweltering summer days and long restless Viewing the parts ................ 10 nights, there is no better escape from the heat than the Cleaning and maintaining the air conditioner .... -
Page 3: Safety Precautions
Because the following operating instructions cover various models, the characteristics of your air conditioner may differ slightly from those described in this manual. If you have any questions, call your nearest contact center or find help and information online at www.samsung.com. Important safety symbols and precautions: WARNING Hazards or unsafe practices that may result in severe personal injury or death. - Page 4 Safety precautions FOR INSTALLATION CAUTION Install your appliance on a level and hard floor that can support its weight. Failing to do so may result in abnormal vibrations, noise, or problems with the product. Install the draining hose properly so that water is drained correctly. Failing to do so may result in water overflowing and property damage. When installing the outdoor unit, make sure to connect the draining hose so that draining is performed correctly. The water generated during the heating operation by the outdoor unit may overflow and result in property damage.
- Page 5 FOR USING WARNING Do not touch the circuit breaker with wet hands. This may result in electric shock. Do not strike or pull the air conditioner with excessive force. This may result in fire, injury, or problems with the product. Do not place an object near the outdoor unit that allows children to climb onto the machine. This may result in children seriously injuring themselves.
- Page 6 Safety precautions FOR USING CAUTION Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. This may result in electric shock, fire, problems with the product, or injury. Do not operate the appliance with wet hands. This may result in electric shock.
-
Page 7: Checking Before Use
Checking before use Operation ranges The table below indicates the temperature and humidity ranges the air conditioner can be operated within. Refer to the table for efficient use. MODE OUTDOOR TEMPERATURE INDOOR TEMPERATURE INDOOR HUMIDITY COOLING -15°C/5°F to 50°C/122°F 18°C/64°F to 32°C/90°F HEATING -20°C/-4°F to 24°C/75°F 27°C/81°F or less... -
Page 8: Maintaining Your Air Conditioner
Checking before use Maintaining your air conditioner Internal protections via the unit control system This internal protection operates if an internal fault occurs in the air conditioner. Type Description Against cold air The internal fan will be off to against cold air when the heat pump is heating. De-ice cycle The internal fan will be off to against cold air when the heat pump is heating. - Page 9 Tips on using air conditioner Here are some tips that you would follow when using your air conditioner. TOPIC RECOMMENDATION Cooling • If current outside temperatures are much higher than the selected indoor temperature, it may take time to bring the inner temperature to the desired coolness. •...
-
Page 10: Viewing The Parts
Viewing the parts Main parts Air flow blade Air intake Air filter (under the grille) Display Indicator Remote control sensor Filter reset indicator Timer indicator Removing frost indicator On/Off operation indicator • Your air conditioner and display may look slightly different from the illustration shown above depending on your model. -
Page 11: Cleaning And Maintaining The Air Conditioner
Cleaning and maintaining the air conditioner Cleaning the exterior Wipe the surface of the unit with a slightly wet or dry cloth when needed. Wipe off dirt of odd-shaped area by using a soft brush. • Do not use Benzene or Thinner. They may damage the surface of the air conditioner and can CAUTION create a risk of fire. - Page 12 Remove the safety clip first and then remove the Samsung logo. Press both of the levers and pull the hinge. Pull the green switch on the hinge part down grille downward. Two safety clips are mounted to the and then press and pull the hinge part to remove the grille.
-
Page 13: Periodical Checks
If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in best condition. Dry the air conditioner thoroughly by operating in Fan mode for 3 to 4 hours and disconnect the power plug. ... -
Page 14: Troubleshooting
Troubleshooting Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary expenses. PROBLEM SOLUTION The air conditioner does not • Because of the protective mechanism, the appliance does not start operating immediately operate immediately after it to keep the unit from overloading. - Page 15 Memo...
- Page 16 021 206 01 10 for landline and mobile, normal tariff SERBIA 0700 Samsung (0700 726 7864) www.samsung.com SLOVAKIA 0800-SAMSUNG(726-7864) www.samsung.com SPAIN 902 - 1 - SAMSUNG (902 172 678) www.samsung.com SWEDEN 0771 726 7864 (SAMSUNG) www.samsung.com www.samsung.com/ch SWITZERLAND 0848 - SAMSUNG(7267864, CHF 0.08/min) www.samsung.com/ch_fr/(French)
