Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR
FUTURE USE. Record the following information for quick reference.
and not actual. Attach copy of sales receipt.
Date Purchased:______________________ Model Number: 9400-_______ Color: ______________________________________
Parts List
Make sure you have all the parts listed below before using your Play Yard. If any parts are
missing, call Consumer Affairs at 1-800-99-COMBI.
Main Body
Storage
Attachment
Bassinet Frame
Short Top
Rails
Brake
Wheels
Combi USA, Inc. • 1962 HWY 160 W, Suite 100 • Fort Mill, SC
Bassinet
Mattress
Bassinet
Stabilizers (x2)
Changing Table
with pockets
Consumer Affairs 1-800-99-COMBI
Travel
Solutions Play Yard
Instruction Manual
Canopy
with Soft Toys
Pedestal
Arms (x2)
Play Yard
Mattress
Long Top
Rails
Wheel
Brake
9400 Series
Note: Illustrations are only representative
Instruction
Pedestal Stay Bars
Manual
Pedestal Basket
Pedestal
Legs (x2)
Travel
Bag
Bassinet Toys
Canopy
Canopy
Attachments
Attachment for
Play Yard
Wheels
29708 • www.combi-intl.com
(x2)
Accessories Bag
Advertisement
Related Manuals for Combi Travel Solutions Play Yard
Summary of Contents for Combi Travel Solutions Play Yard
-
Page 1: Parts List
Short Top Long Top Bassinet Toys Rails Rails Canopy Canopy Attachments Attachment for Play Yard Wheel Brake Wheels Brake Wheels Combi USA, Inc. • 1962 HWY 160 W, Suite 100 • Fort Mill, SC 29708 • www.combi-intl.com Consumer Affairs 1-800-99-COMBI... - Page 2 Combi® reserves the right to modify the products in its line during the and may not represent the actual product. course of the year. Non contractual media. Colors are as accurate as the media in which they appear allows.
- Page 3 Note: Illustrations are only representative and not actual. Setting Up Your Play Yard 1. Remove Play Yard from Travel Bag. 2. Remove mattress from around the Play Yard. 3. While holding the plastic handle to keep the center of Play Yard floor upright (3a), use your other hand to, lift short top rails (3b) until locked into position.
-
Page 4: Folding Play Yard
Folding Play Yard 1. Remove mattress from Play Yard. 2. Rotate center grip 90°, to upright position. Pull center of floor upwards (a), followed by both sides of floor (b). 3. Slightly lift top rail while pressing center button to release. Once rails release, push down. - Page 5 Storing Play Yard 1. With Play Yard in upright position, locate plastic loop attached to outside of Play Yard leg. Route top white Velcro strap through loop on Play Yard and through plastic loop on opposite side of mattress. Plastic Loop 2.
- Page 6 Using Accessories with Play Yard BASSINET 1 Attach both plastic hooks to both long top rails of Play Yard as shown. 2. Press down on center of bassinet to ensure both ends are secure. CHANGING TABLE 1 Attach both plastic hooks to Play Yard (end without wheels) with changing table fac- ing down and storage pockets facing up, as shown.
- Page 7 Stay Bar Diagram B pin locations Pedestal Legs...
- Page 8 Attaching Bassinet Stabilizers 1. Insert both sides of stabilizer bar into each end of pedestal. 2. Pull up on each stabalizer to be sure they are secure. Using the Swivel Wheels 1. While pressing the tab in with finger, rotate tab until wheel drops down and “clicks”...
- Page 9 Attaching Bassinet to Pedestal Plastic Hooks (x4) 1. Push metal bars toward ends of bassinet until they are hooked underneath plastic hooks on bassinet base. Metal Bars 2. Attach snaps on bassinet cover to snaps on bassinet base. 3. Add bassinet mattress. DO NOT use bassinet without mattress.
- Page 10 Attaching Canopy to Bassinet 1. Confirm the canopy is facing the proper direction 2. Attach plastic hooks on canopy to canopy holders on bassinet. 3. Attach Velcro on canopy to the Velcro on bassinet cover. Changing Table Assembly 1. Remove changing table from storage bag. Pull back fabric cover on each side to locate metal bars.
-
Page 11: Routine Maintenance
Routine Maintenance STORE IN A COOL AND DRY AREA, especially in the summer. Do not store the Play Yard in the trunk of a vehicle. MAIN BODY AND BASSINET Briskly wipe off any mud and dirt. To clean the body, wipe with a damp cloth then wipe out any traces of moisture on the body with a dry cloth. - Page 12 Shipping and Handling Fees: Add $8.00 for orders $34.99 and under. Add Shipping & Handling $13.00 for orders $35.00 and over. Note: Additional shipping charges will apply outside of the Continental U.S. Combi USA reserves the right to change pricing at Sales Tax (6%) any time.
