Cavaliere 218 Series User Manual
Island mount range hood
Hide thumbs
Also See for 218 Series:
- Installation manual and user's manual (24 pages) ,
- Installation manual (4 pages)
Table of Contents
Related Manuals for Cavaliere 218 Series
Summary of Contents for Cavaliere 218 Series
- Page 1 Installation Guide and Users Manual 218 Series Island Hood IMPORTANT: Read and save these instructions. NOTICE: Installer: Leave this guide with the homeowner Homeowner: Keep this guide for future reference Island Mount Range Hood Rev. 2024u.1d...
-
Page 3: Important Safety Notice
Important Safety Notice Read all Instructions before Installing and operating this appliance • The installation in this manual is intended for qualified installers, service technicians or persons with similar qualified background. Installation and electrical wiring must be done by qualified profession- als and in accordance with all applicable codes and standards, including fire-rated construction. - Page 4 Important Safety Notice Read all Instructions before Installing and operating this appliance • Clean ventilating fan frequently. • Always use appropriate cookware and utensils size. • Always use cookware appropriate for the size of the surface element. To reduce the risk of injury to persons in the event of a stove top grease fire: •...
-
Page 5: Table Of Contents
Table of Contents INSTALLATION USE AND CARE Tools needed............3 Range hood operations......12-13 Parts supplied...........4 Troubleshooting...........14 Venting requirements........5 Use and care information.......15 Mount heights & clearance......5-6 Specifications..........15 Calculating vent system length.......6 Wiring diagram..........16 MAINTENANCE Venting methods & ductless conversion..7 Charcoal filters & electrical requirements..8 Cleaning, replacing filter &... -
Page 6: Parts Supplied
Parts supplied: Range Hood (vary with model) Upper Support Frame Lower Support Frame Lower Standard Chimney Upper Standard Chimney Qty: 32 PCS Qty: 4 PCS Air Diverter (Optional re-circulating kit, pre-installed when ordered together with range hood) Qty: 32 PCS Qty: 4 PCS Qty: 4 PCS Support frame extension... -
Page 7: Venting Requirements
Venting Requirements Height & Clearance • Vent system must terminate to the outside Support Maximum* ceiling clearance (roof or side wall). 101” at 31” hood mounting Structure • DO NOT terminate the vent system in an at- height above countertop/stove (may vary with different tic or other enclosed area. -
Page 8: Calculating Vent System Length
IMPORTANT: • A minimum of 6” round (standard for this range hood) or 3-1/4 x 10” rectangular duct (purchased separately) must be used to maintain maximum airflow efficiency. • Flexible 6” round duct provided for convenience, always use rigid type metal/aluminum ducts if available to maximize airflow when connecting to provided duct. -
Page 9: Venting Methods & Ductless Conversion
Venting Methods • This range hood is factory set for venting through the roof or wall. For non-vented (re-circulating) installa- tions, see Recirculating (Non-Vented) Kit on page 10. • Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. IMPORTANT: •... -
Page 10: Charcoal Filters & Electrical Requirements
Charcoal Filter Installation NOTE: The charcoal filters are preinstalled if you purchased the range hood with re-circulating kit from us. Remove aluminum filters on hood. Position the charcoal filters onto each side of the motor and turn until it locks. Re-install aluminum filters. Charcoal filters must be replaced after 120 hours of use (or approximately every 2 to 3 months based on the average of 1 to 2 hours of daily cooking time). -
Page 11: Preparation
Preparation WARNING Advanced Preparations: Be familiar with the controls of the range hood by reading through Range Hood Operations, Page 12. Place the range hood on a flat, stable surface. Connect the Excessive Weight range hood to a designated standard outlet (please refer the Require three or more person to move and product label for the suitable voltage of this unit) and turn on install this range hood. -
Page 12: Installation
Installation Align upper support frame with holes in ceiling. Mount the upper support frame to the ceiling using four “A” screws (for sheet rock only). Make sure that the upper support frame is securely fastened to the joist or support in the ceiling. -
Page 13: Installation Overview
Installation (Continued) Have a third person raise up and hold the island range hood in position, connect power plug to the 12” hanging electrical cord, and connect the duct work to the range hood. Mount the hood to the lower support frame using four “D” bolts and four “E” nuts: Securely fasten two “E” nuts to two “D”... -
Page 14: Range Hood Operations
Range Hood Operations Control Panel Layout and Buttons Configurations: Power Light Decrease Value Increase Value Blower Power Indicator Power-On Elapsed Digital Timer Blower Speed Indicator Power-Off Delay Digital Timer Light Power Indicator Power-Off Delay Timer Indicator This range hood is designed to remove smoke, cooking vapors and odors from the cook top area. For best results, start the range hood before cooking and allow it to operate several minutes after the cooking is completed to clear all smoke and odors from the kitchen. - Page 15 Range Hood Operations (Continued) Control Panel Layout and Buttons Configurations: Power Light Decrease Value Increase Value Blower Power Indicator Power-On Elapsed Digital Timer Blower Speed Indicator Power-Off Delay Digital Timer Light Power Indicator Power-Off Delay Timer Indicator • Controls: • Adjusting the timer function: •...
-
Page 16: Troubleshooting
Troubleshooting If the range hood or halogen light does not operate • Check if the range hood has been plugged in, make after installation: sure that all power has been turned back ON, fused not blown and all electrical wiring are properly con- nected. -
Page 17: Use And Care Information
Use and Care Information Operations: • Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. • Always leave safety grills and filters in place. Without these components, operating blowers could catch on to hair, fingers and loose clothing. -
Page 18: Wiring Diagram
Wiring Diagram Six Speed with Type GU10 Bulb Six Speed with Type MR16 Bulb Page 16... -
Page 19: Cleaning, Replacing Filter & Light Bulb
Maintenance SAFETY WARNING: Never put your hand into area housing the fan while the fan is operating! For optimal operation, clean range hood and all baffle/spacer/filter/grease tunnel/oil container regularly. Regular care will help preserve the appearance of the range hood. Cleaning Exterior surfaces: •... -
Page 20: Coverage & Exceptions
Warranty TO OBTAIN SERVICE UNDER WARRANTY: You must present proof of original purchase date. Please provide an original dated proof of purchase (sales receipt / invoice) in order to obtain service under warranty. One Year Parts Warranty: For one year from the date of original purchase, your local reseller will provide free of charge, non-consumable replace- ment parts or components that failed due to manufacturing defects. -
Page 21: Disclaimer & Contact Information
Disclaimer Carefully inspect all items for damages before accepting delivery. note any damages on the freight bill or express receipt. request name and signature of the carrier’s agent and keep copy to support your claim. Upon acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and file a claim immediately. - Page 22 Your Notes Page 20...
- Page 23 Your Notes Page 21...
- Page 24 Cavaliere 7372 Doig Drive Garden Grove, California 92841 Tel: 714-622-1550 Fax: 714-622-1559 http://www.cavalierehoods.com...
