HP Mini 210, HP Mini 110, and
Compaq Mini CQ10
Maintenance and Service Guide

Advertisement

Table of Contents
loading

Related Manuals for HP Mini 210

Summary of Contents for HP Mini 210

  • Page 1 HP Mini 210, HP Mini 110, and Compaq Mini CQ10 Maintenance and Service Guide...
  • Page 2 Corporation. SD Logo is a trademark of its proprietor. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
  • Page 3 Safety warning notice WARNING! To reduce the possibility of heat-related injuries or of overheating the device, do not place the device directly on your lap or obstruct the device air vents. Use the device only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow.
  • Page 4 Safety warning notice...

  • Page 5: Table Of Contents

    Table of contents 1 Product description ............................1 2 External component identification ........................ 7 Top ............................... 7 TouchPad ..........................7 Lights ........................... 8 Buttons ..........................9 Keys ........................... 10 Front ..............................10 Right side ............................11 Left side .............................. 12 Display ..............................
  • Page 6 Computer feet ........................43 Battery ..........................44 Service door ........................45 WLAN module ........................46 WWAN module ........................47 Memory module ......................... 48 RTC battery ........................49 Hard drive .......................... 50 Keyboard ........................... 53 Top cover ........................... 56 Speakers ..........................59 TouchPad button board .....................
  • Page 7 Windows 7 backup and recovery ....................... 83 Restore ..........................84 Creating restore media ...................... 84 Performing a system restore ....................85 Recovering using the dedicated recovery partition ........... 85 Recovering using the restore media ..............85 Changing the computer boot order ..............86 Backing up and recovering your information ..............
  • Page 8 viii...

  • Page 9: Product Description

    Product description Category Description HP Mini 210 HP Mini 110 Compaq Mini CQ10 Product Name HP Mini 210 HP Mini 110 Compaq Mini Netbook PC Netbook PC CQ10 Netbook PC Processor Intel® Atom™ N455 1.66 GHz single- √ √ √...
  • Page 10 Category Description HP Mini 210 HP Mini 110 Compaq Mini CQ10 Memory One customer accessible/upgradable SODIMM memory module slot DDR3-1333 MHz, single channel support Supports the following configurations: ● 1 GB total system memory (1024 √ √ √ MB x 1) for all supported operating systems ●...
  • Page 11 Category Description HP Mini 210 HP Mini 110 Compaq Mini CQ10 Supports the following 7.0 mm (0.28 in) × 6.35 cm (2.50 in), parallel SATA, 5400-rpm hard drives: ● 320 GB, supported for Windows 7 √ √ √ Starter ●...
  • Page 12 Category Description HP Mini 210 HP Mini 110 Compaq Mini CQ10 2 WLAN antennas built into display assembly WWAN options by way of the √ √ √ following wireless modules ● HP hs2340 HSPA+ Mobile Broadband Module ● HP lc2010 HSPA Mobile Broadband Module ●...
  • Page 13 Category Description HP Mini 210 HP Mini 110 Compaq Mini CQ10 TouchPad with multi-touch/gesture √ √ √ support: ● 2 TouchPad buttons and 2-way scrolling (pinch, zoom, and 2-finger scrolling) enabled by default ● on/off button with LED indicator (supported on Windows only)
  • Page 14 Category Description HP Mini 210 HP Mini 110 Compaq Mini CQ10 Power cord Service door WLAN module WWAN module Chapter 1 Product description...

  • Page 15: External Component Identification

    External component identification TouchPad Component Description ● TouchPad light (supported on Off: The TouchPad is on. Windows only) ● Amber: The TouchPad is off. TouchPad on/off button Quickly double-tap the TouchPad on/off button to turn the TouchPad on (supported on Windows only) or off.

  • Page 16: Lights

    Lights Component Description ● Power light White: The computer is on. ● Blinking white: The computer is in the Sleep state. ● Off: The computer is off or in Hibernation. ● Mute light Amber: Computer sound is off. ● Off: Computer sound is on. ●...

  • Page 17: Buttons

    When the computer is off or in Hibernation, press the button to open on certain models only.) HP QuickWeb. ● When the computer is in Windows, press the button to open the default Web browser. ● When the computer is in HP QuickWeb, press the button to open the default Web browser.

  • Page 18: Keys

    ● When pressed in combination with the key, Beats Audio bass settings are enabled or disabled (for use with HP Mini 210 models with Windows 7 only). Operating System logo key Displays the operating system menu. Operating system applications Displays a shortcut menu for items beneath the pointer.

  • Page 19: Right Side

    Right side Component Description Digital Media Slot Supports the following digital card formats: ● MultiMediaCard (MMC) ● Secure Digital (SD) Card ● Secure Digital High Capacity Card (SDHC) ● Secure Digital Extended Capacity (SDXC) Supports mini versions by use of an adapter (purchased separately). Audio-out (headphone) jack Produces sound when connected to optional powered stereo speakers, headphones, earbuds, a headset, or television audio.

  • Page 20: Left Side

    Left side Component Description External monitor port Connects an external VGA monitor or projector. Power connector Connects an AC adapter. ● AC adapter light White: The computer is connected to external power and the battery is fully charged. ● Amber: The computer is connected to external power and the battery is charging.

  • Page 21: Display

    Display Component Description WLAN antennas (2)* Send and receive wireless signals to communicate with WLANs. WWAN antennas (2)* for select Send and receive wireless signals to communicate with WWANs. models only Internal microphone Records sound. Webcam Records video and captures still photographs. Webcam light On: The webcam is in use.

  • Page 22: Bottom

    Bottom Component Description Battery bay Holds the battery. Battery/service door latch Releases the battery from the battery bay and the service door from the computer. Service door Provides access to the hard drive bay, a memory module slot, the WLAN module, and the WWAN module.

  • Page 23: Illustrated Parts Catalog

    Illustrated parts catalog Serial number label location When ordering parts or requesting information, the serial number label, located inside the battery bay, provides important information that you may need when contacting technical support. NOTE: Serial number label location, format, and color vary on select models. (1) Product name The name affixed to the front of the computer.

  • Page 24: Computer Major Components

    Computer major components Chapter 3 Illustrated parts catalog...
  • Page 25 Item Description Spare part number Display assembly for HP Mini 210 models, 25.7 cm (10.1 in) with display panel cable, webcam/microphone module and cable, two WLAN antenna transceivers and cables, and two 3G-WWAN antenna transceivers and cables: ● HD LED AntiGlare, flush glass display assembly, Charcoal 650712-001 ●...
  • Page 26 Item Description Spare part number Display assembly for HP Mini 110 models, 25.7 cm (10.1 in) with display panel cable and webcam/microphone module and cable, 2 WLAN antenna transceivers and cables: NOTE: For more information on the display assembly internal component spare parts, Display components on page 25 ●...
  • Page 27 Item Description Spare part number ● For use in Turkey 650726-141 ● For use in the United Kingdom 650726-031 ● For use in the United States 650726-001 Crimson Red: ● For use in Belgium 656761-A41 ● For use in Bulgaria 656761-261 ●...
  • Page 28 Item Description Spare part number ● For use in Greece 656760-DJ1 ● For use in Hungary 656760-211 ● For use internationally 656760-B31 ● For use in Israel 656760-BB1 ● For use in Italy 656760-061 ● For use in Latin America 656760-161 ●...
  • Page 29 For use in Turkey 656763-141 ● For use in the United Kingdom 656763-031 ● For use in the United States 656763-001 HP Mini 110 and Compaq Mini CQ10 models: ● For use in Belgium 658517-A41 ● For use in Bulgaria 658517-261 ●...
  • Page 30 For use in Turkey 658517-141 ● For use in the United Kingdom 658517-031 ● For use in the United States 658517-001 Top cover (includes TouchPad board and bracket) HP Mini 210 models: ● Charcoal 650747-001 ● Crimson Red 650752-001 ● Luminous Rose 650751-001 ●...
  • Page 31 (10) Base enclosure ● HP Mini 210 models 650710-001 ● HP Mini 110 models and Compaq Mini CQ10 models 663675-001 (11) Hard drive: ● 500 GB, 9.5 mm (0.37 in) × 6.35 cm (2.50 in), parallel SATA, 5400-rpm (select 634932-001 models only) ●...
  • Page 32 Service door HP Mini 210 models: ● Charcoal 650727-001 ● Crimson Red 650732-001 ● Luminous Rose 650731-001 ● Ocean Drive 650728-001 ● Sweet Purple 654203-001 HP Mini 110 and Compaq CQ10 models ● Glossy Black 663676-001 Chapter 3 Illustrated parts catalog...

  • Page 33: Display Components

    Display components NOTE: The display components are replaceable for only HP Mini 110 models and Compaq Mini CQ10 models. Item Description Spare part number Display Hinge Kit, includes: 658506-001 (1a) Left and right hinge covers (1b) Left and right hinge caps...
  • Page 34 Item Description Spare part number For use with Compaq Mini CQ10 models 658504-001 Webcam module for use with HP Mini 110 models and Compaq Mini CQ10 models 658516-001 Display panel: 10.1-in, WSVGA LED AntiGlare display panel 658511-001 Display/webcam cable 658505-001...

  • Page 35: Mass Storage Devices

    7.0 mm (0.28 in) × 6.35 cm (2.50 in), parallel SATA, 5400-rpm: 320 GB 645193-001 250 GB 645191-001 External optical drive (not illustrated): DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive for HP Mini 210 models 584383-001 DVD+-R/RW double-layer optical drive 659940-001 Mass storage devices...

  • Page 36: Miscellaneous Parts

    ● For use in Thailand 490371-201 Plastics Kit (includes left and right rear corner covers) 652308-001 Rubber Kit 650734-001 Screw Kit 650735-001 Sleeves for use with HP Mini 210 models: ● Charcoal 631188-001 ● Crimson Red 628348-001 ● Luminous Rose 628344-001 ●...

  • Page 37: Sequential Part Number Listing

    WLAN, Broadcom 4312G 802.11b/g WiFi and 2070 Bluetooth 2.1+EDR Combo Adapter (BT3.0+HS ready) 584383-001 DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive for HP Mini 210 models 593127-001 WLAN, Atheros AR9002WB-1NGB 802.11b/g/n 1x1 WiFi and Bluetooth 2.1+EDR Combo Adapter (BT3.0+HS ready)
  • Page 38 Spare part number Description 631188-001 Sleeve, Charcoal 632155-001 WWAN, HP hs2340 HSPA+ Mobile Broadband Module 634431-001 Thermal Pad Kit 634932-001 Hard drive, 500 GB, 9.5 mm (0.37 in) × 6.35 cm (2.50 in), parallel SATA, 5400-rpm (select models only) 640926-001 WLAN, Realtek 8188GN 802.11b/g/n 1x1 WiFi Adapter...
  • Page 39 Spare part number Description 650726-131 Keyboard, Charcoal, for use only in Portugal (includes cable) 650726-141 Keyboard, Charcoal, for use only in Turkey (includes cable) 650726-161 Keyboard, Charcoal, for use only in Latin America (includes cable) 650726-171 Keyboard, Charcoal, for use only in Saudi Arabia (includes cable) 650726-211 Keyboard, Charcoal, for use only in Hungary (includes cable) 650726-251...
  • Page 40 Spare part number Description 650752-001 Top cover, Crimson Red (includes TouchPad board and bracket) 651897-001 651898-001 Heat sink (includes replacement thermal material) 651899-001 Hard Drive Hardware Kit 651901-001 TouchPad button board (includes cables) 652308-001 Plastics Kit (includes left and right rear corner covers) 654201-001 25.7 cm (10.1 in) HD LED AntiGlare, flush glass display assembly, Sweet Purple (includes display panel cable, two WLAN antenna transceivers and cables, two 3-G WWAN antenna transceivers...
  • Page 41 Spare part number Description 656757-FL1 Keyboard, Ocean Drive, for use only in the Czech Republic and Slovakia (includes cable) 656760-001 Keyboard, Luminous Rose, for use only in the United States (includes cable) 656760-031 Keyboard, Luminous Rose, for use only in the United Kingdom (includes cable) 656760-041 Keyboard, Luminous Rose, for use only in Germany (includes cable) 656760-051...
  • Page 42 Spare part number Description 656761-211 Keyboard, Crimson Red, for use only in Hungary (includes cable) 656761-251 Keyboard, Crimson Red, for use only in Russia (includes cable) 656761-261 Keyboard, Crimson Red, for use only in Bulgaria (includes cable) 656761-A41 Keyboard, Crimson Red, for use only in Belgium (includes cable) 656761-B31 Keyboard, Crimson Red, for use internationally (includes cable) 656761-BA1...
  • Page 43 Display enclosure, Glossy Black 658500-001 Display enclosure, Sonoma Red 658502-001 Display enclosure, Pacific Blue 658503-001 Display bezel, HP Mini 110 models 658504-001 Display bezel, Compaq Mini CQ10 models 658505-001 Display cable 658506-001 Display Hinge Kit (includes left and right hinges) 658507-001 Display assembly, 25.7 cm (10.1 in) traditional WSVGA LED AntiGlare, Glossy Black (includes...
  • Page 44 Spare part number Description 658517-A41 Keyboard, Glossy Black, for use only in Belgium (includes cable) 658517-AB1 Keyboard, Glossy Black, for use only in Taiwan (includes cable) 658517-AD1 Keyboard, Glossy Black, for use only in South Korea (includes cable) 658517-B31 Keyboard, Glossy Black, for use internationally (includes cable) 658517-BA1 Keyboard, Glossy Black, for use only in Slovenia (includes cable) 658517-BB1...
  • Page 45 Spare part number Description 668163-001 Display assembly, 25.7 cm (10.1 in) WSVGA LED AntiGlare flush glass display assembly, Luminous Rose (includes display panel cable, webcam/microphone module and cable, and two WLAN antenna transceivers and cables) 668164-001 Display assembly, 25.7 cm (10.1 in) WSVGA LED AntiGlare, flush glass, Crimson Red (includes display panel cable, webcam/microphone module and cable, and two WLAN antenna transceivers and cables) 668165-001...

  • Page 46: Removal And Replacement Procedures

    Removal and replacement procedures Preliminary replacement requirements Tools required You will need the following tools to complete the removal and replacement procedures: ● Flat-bladed screwdriver ● Magnetic screwdriver ● Phillips P0 and P1 screwdrivers Service considerations The following sections include some of the considerations that you must keep in mind during disassembly and assembly procedures.

  • Page 47: Cables And Connectors

    Cables and connectors CAUTION: When servicing the device, be sure that cables are placed in their proper locations during the reassembly process. Improper cable placement can damage the device. Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or seat the cables during removal and insertion.

  • Page 48: Grounding Guidelines

    Grounding guidelines Electrostatic discharge damage Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure determine the degree of sensitivity. Networks built into many integrated circuits provide some protection, but in many cases, ESD contains enough power to alter device parameters or melt silicon junctions.

  • Page 49: Packaging And Transporting Guidelines

    Packaging and transporting guidelines Follow these grounding guidelines when packaging and transporting equipment: ● To avoid hand contact, transport products in static-safe tubes, bags, or boxes. ● Protect ESD-sensitive parts and assemblies with conductive or approved containers or packaging. ● Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations.

  • Page 50: Equipment Guidelines

    Equipment guidelines Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation. ● When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps with a minimum of one megohm ±10% resistance in the ground cords. To provide proper ground, wear a strap snugly against the skin at all times.

  • Page 51: Component Replacement Procedures

    Component replacement procedures This chapter provides removal and replacement procedures. There are as many as 33 screws, in 3 different sizes, that must be removed, replaced, or loosened when servicing the computer. Make special note of each screw size and location during removal and replacement.

  • Page 52: Battery

    Battery Description Spare part number 6-cell, Li-ion, 2.55 Ah, 55 Wh 646757-001 3-cell, Li-ion, 2.55 Ah, 28 Wh 646755-001 Before disassembling the computer, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

  • Page 53: Service Door

    Charcoal, for HP Mini 210 models 650727-001 Crimson Red, for HP Mini 210 models 650732-001 Glossy Black, for HP Mini 110 and Compaq CQ10 models 663676-001 Luminous Rose, for HP Mini 210 models 650731-001 Ocean Drive, for HP Mini 210 models...

  • Page 54: Wlan Module

    Replace the service door: Replace the service door and slide it toward the back of the computer. Insert the back edge of the battery into the battery bay and then pivot the battery downward. Press down on the battery until the latch locks. WLAN module Description Spare part number...

  • Page 55: Wwan Module

    WLAN modules are designed with a notch (5) to prevent incorrect insertion. Reverse this procedure to install a WLAN module. WWAN module Description Spare part number HP hs2340 HSPA+ Mobile Broadband Module 632155-001 HP lc2000 HSPA Mobile Broadband Module 612599-001 HP lc2010 HSPA Mobile Broadband Module...

  • Page 56: Memory Module

    Remove the battery (see Battery on page 44). Remove the service door (see Service door on page 45). Remove the WWAN module: Disconnect the red WWAN antenna cable (1) from the WWAN module “Main” terminal. Disconnect the blue WWAN antenna cable (2) from the WWAN module “Aux” terminal. Remove the Phillips M2.0×3.0 screw (3) that secures the WWAN module to the system board.

  • Page 57: Rtc Battery

    Remove the battery (see Battery on page 44). Remove the service door (see Service door on page 45). Remove the memory module: Pull away the retention clip (1) on each side of the memory module to release the module. (The memory module (2) tilts up.) CAUTION: To prevent damage to the memory module, hold it by the edges only.

  • Page 58: Hard Drive

    Remove the battery (see Battery on page 44). Remove the service door (see Service door on page 45). Remove the RTC battery: Lift the edge (1) of the battery from the system board. Remove the RTC battery (2) from the socket on the system board. Reverse this procedure to install the RTC battery.
  • Page 59 Before removing the hard drive, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
  • Page 60 Remove the hard drive bracket (3). Reverse this procedure to reassemble and install the hard drive. Chapter 4 Removal and replacement procedures...

  • Page 61: Keyboard

    Keyboard NOTE: For the complete list of available keyboards, see Computer major components on page Before removing the keyboard, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.
  • Page 62 Position the computer on its side. Using a screwdriver or a similar tool, push firmly through the bottom of the base enclosure (1) to release the keyboard (2). NOTE: Extra effort may be required to release the keyboard. Position the computer right-side up. Rotate the keyboard over onto the palm rest (1).
  • Page 63 Lift the keyboard (4) straight up to remove it from the computer. Reverse this procedure to install the keyboard. Component replacement procedures...

  • Page 64: Top Cover

    The top cover includes the TouchPad board and bracket. Description Spare part number Charcoal, for HP Mini 210 models 650747-001 Crimson Red, for HP Mini 210 models 650752-001 Glossy Black, for HP Mini 110 models 658512-001 Glossy Black, for Compaq Mini CQ10 models...
  • Page 65 Remove the five Phillips M2.0x5.0 screws (3) from the top cover . Position the computer upside down, with the front toward you. Release the TouchPad ZIF connector (1) and disconnect the TouchPad cable (2). (The ZIF cable is secured with double-sided adhesive tape.) Remove the five Phillips M2.0x5.0 screws (3) along the front edge of the base enclosure.
  • Page 66 Lift the front edge (1) of the top cover until it disengages from the base enclosure, and then remove the top cover (2) by lifting it straight up. Reverse this procedure to install the top cover. Chapter 4 Removal and replacement procedures...

  • Page 67: Speakers

    Speakers Description Spare part number Speakers (include cables) 650736-001 Before removing the speakers, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.

  • Page 68: Touchpad Button Board

    TouchPad button board Description Spare part number TouchPad button board 651901-001 Before removing the TouchPad button board, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.

  • Page 69: Display Assembly

    Reverse this procedure to install the TouchPad button board. Display assembly NOTE: For a complete list of display assemblies, refer to Display components on page Before removing the display assembly, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
  • Page 70 Remove the two Phillips M2.0x5.0 screws (4), one beneath each rear corner cover. Remove the WLAN antenna cables (1) from the routing channel. Disconnect the display panel cable (2) from the system board. Carefully lift the base enclosure away from the display assembly (3). Reverse this procedure to reassemble and install the display assembly.

  • Page 71: Display Assembly Components

    Display assembly components NOTE: These procedures are for replacing the display assembly internal components for HP Mini 110 and Compaq Mini CQ10 models. Description Spare part number Display assembly hinges and covers 658506-001 Display bezel for HP Mini 110 models...
  • Page 72 Remove the display assembly components: Remove the hinge covers from the hinges. Remove the two Phillips M2.0×5.0 screws (1) that secure the black plastic covers to the display assembly, and then lift the covers from the display (2). Remove the two Phillips M2.0×4.0 screws (3) that secure the hinges to the display assembly. Remove the display hinges (4).
  • Page 73 To remove the display bezel, loosen the top of the bezel (1), loosen the left and right sides of the bezel (2), loosen the bottom of the bezel (3), and then lift the bezel from the display (4). To remove the webcam module, unplug the cable from the webcam module (1), remove the silver Phillips M2.0x3.0 screw (2), and then lift the module from the display (3).
  • Page 74 To remove the display panel from the display enclosure, remove the 4 Phillips M2.0×4.0 screws (1) that secure the panel to the enclosure, lift the top of the display panel (2), and then rotate it up and out of the display enclosure. To remove the display/webcam cable assembly, disconnect the display cable (1) from the connector (2) on the back of the display panel.

  • Page 75: System Board

    (FSB) Intel Atom N455 single-core 1.66 GHz processor, 512 KB level 2 cache, 667 MHz FSB, XSLOT 650740-001 Intel Atom N475 single-core, 1.83 GHz processor, 512 KB level 2 cache, 667 MHz FSB (HP Mini 650738-001 210 models) Component replacement procedures...
  • Page 76 Spare part number Intel Atom N475 single-core, 1.83 GHz processor, 512 KB level 2 cache, 667 MHz FSB, XSLOT 650741-001 (HP Mini 210 models) Intel Atom N570 dual-core 1.66 GHz processor, 1 MB level 2 cache, 667 MHz FSB 650739-001 Intel Atom N570 dual-core 1.66 GHz processor, 1 MB level 2 cache, 667 MHz FSB, XSLOT...
  • Page 77 Tilt the system board away from the base enclosure (3). Disconnect the power cable (1) from the system board. Remove the system board (2) by sliding it up and away from the base enclosure. Reverse this procedure to install the system board. Component replacement procedures...

  • Page 78: Fan And Sink

    Fan and sink Description Spare part number 651897-001 Heat sink (includes replacement thermal material) 651898-001 NOTE: To properly ventilate the computer, allow at least a 7.6-cm (3 inch) clearance on the left side of the computer. The computer uses an electric fan for ventilation. The fan is controlled by a temperature sensor and is designed to turn on automatically when high temperature conditions exist.
  • Page 79 Remove the fan (3) from the system board. NOTE: Due to the adhesive quality of the thermal material between the fan and system board components, you may need to move the fan from side to side to detach it from the system board. Remove the heat sink: Remove the two Phillips M2.0x4.0 screws (1) that secure the heat sink to the system board.
  • Page 80 Remove the heat sink (2) by lifting it straight up from the system board. NOTE: Due to the adhesive quality of the thermal material between the heat sink and system board components, you may need to move the heat sink from side to side to detach it from the system board.

  • Page 81: Power Connector

    Power connector Description Spare part number Power connector 656095-001 Before removing the power connector, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.
  • Page 82 Remove the power connector (2) by lifting it straight up from the base enclosure. Reverse this procedure to install the power connector. Chapter 4 Removal and replacement procedures...

  • Page 83: Setup Utility

    Setup Utility Starting Setup Utility Setup Utility is a ROM-based information and customization utility that can be used even when your operating system is not working. The utility reports information about the computer and provides settings for startup, security, and other preferences.

  • Page 84: Navigating And Selecting In Setup Utility

    Navigating and selecting in Setup Utility Setup Utility does not support the TouchPad. Navigation and selection are by keystroke. ● To choose a menu or a menu item, use the arrow keys. ● To choose an item in a list or to toggle a field, for example an Enable/Disable field, use either the arrow keys or or f6.

  • Page 85: Exiting Setup Utility

    Exiting Setup Utility You can exit Setup Utility with or without saving changes. ● To exit Setup Utility and save your changes from the current session: If the Setup Utility menus are not visible, press to return to the menu display. Then use the arrow keys to select Exit >...

  • Page 86: System Configuration Menu

    System Configuration Menu Select To do this Language Change the Setup Utility language. Fan Always On Enable/disable Fan Always On. When enabled, the computer fan will always be on (enabled by default). Action Keys Mode Enable/disable Action Keys Mode (enabled by default). Boot Options Set the following boot options: ●...

  • Page 87: Specifications

    Specifications Device specifications Metric U.S. Dimensions Depth 19 cm 7.5 in Width 27 cm 11 in Height 2.3-3.2 cm 0.91-0.93 in Weight 25.7-cm (10.1-in) LCD, equipped with a 3-cell battery, hard 1.26 kg 2.78lb drive, 1-GB memory, WLAN module, and 2 wireless antennas 25.7-cm (10.1-in).

  • Page 88: Cm (10.1-In) High-Definition Antiglare Display Specifications

    25.7-cm (10.1-in) high-definition AntiGlare display specifications Metric U.S. Dimensions Height 23.45 cm 9.23 in Width 14.3 cm 5.62 in Diagonal 25.7 cm 10.1 in Number of colors 262,144 Contrast ratio 400:1 (typical) Brightness 200 cd/m² (typical) Pixel resolution Pitch 0.16305 × 0.16305 mm Format High-definition: 1366 ×...

  • Page 89: Cm (10.1-In) Wsvga Led Antiglare Display Specifications

    25.7-cm (10.1-in) WSVGA LED AntiGlare display specifications Metric U.S. Dimensions Height 23.5 cm 9.3 in Width 14.3 cm 5.6 in Diagonal 25.7 cm 10.1 in Number of colors 262,144 Contrast ratio 500:1 (typical) Brightness 200 cd/m² (typical) Pixel resolution Pitch 0.2175 ×...

  • Page 90: Hard Drive Specifications

    Hard drive specifications 500 GB* 320 GB* 250 GB* Dimensions Height 9.5 mm 9.5 mm 9.5 mm Width 70 mm 70 mm 70 mm Weight 101 g 101 g 101 g Interface type SATA SATA SATA I/O data transfer rate (maximum) 100 Gb/s 100 Gb/s 100 Gb/s...

  • Page 91: Backup And Recovery

    Performing a system restore ● Backing up and recovering your information Your computer includes tools provided by the operating system and HP to help you safeguard your information and restore it if ever needed. This section provides information on the following topics: ●...

  • Page 92: Restore

    Creating restore media HP recommends that you create either a set of recovery discs or a recovery flash drive to be sure that you can restore your computer to its original factory state if the hard drive fails, or if for any reason you cannot restore using the recovery partition tools.

  • Page 93: Performing A System Restore

    ● You can recover only files that you have previously backed up. HP recommends that you use HP Recovery Manager to create a set of recovery discs or a recovery flash drive as soon as you set up the computer.

  • Page 94: Changing The Computer Boot Order

    Select the optical drive or the flash drive. Follow the on-screen instructions. Changing the computer boot order To change the boot order for recovery flash drive: Insert the flash drive into a USB port. Restart the computer. Press while the computer is restarting, and then press for boot options.

  • Page 95: Using Windows Backup And Restore

    Using Windows Backup and Restore Windows Backup and Restore allows you to back up individual files or back up the entire computer image. Guidelines: ● Be sure that the computer is connected to AC power before you start the backup process. ●...

  • Page 96: Linux Backup And Recovery

    Recovery allows you to repair or restore the computer to its original factory state. You can create an HP factory image restore DVD, using an external DVD±RW optical drive. You can also create an HP factory restore image on a USB storage device.

  • Page 97: Backing Up Your Information

    Restart the computer. Using the arrow keys, select Recovery, and then press enter. Follow the on-screen instructions. NOTE: If you are unable to boot (start up) your computer with the primary operating system, and you did not create a system recovery disc, you must purchase a SUSE Linux Enterprise Desktop Operating System DVD to reinstall the operating system.

  • Page 98: Power Cord Set Requirements

    Power cord set requirements The wide-range input feature of the computer permits it to operate from any line voltage from 100 to 120 V ac, or from 220 to 240 V ac. The 3-conductor power cord set included with the computer meets the requirements for use in the country or region where the equipment is purchased.

  • Page 99: Requirements For Specific Countries And Regions

    Requirements for specific countries and regions Country/region Accredited agency Applicable note number Argentina IRAM Australia Austria Belgium CEBEC Brazil ABNT Canada Chile Denmark DEMKO Finland FIMKO France Germany India Israel Italy Japan The Netherlands KEMA New Zealand SANZ Norway NEMKO The People's Republic of China Saudi Arabia SASO...
  • Page 100 Country/region Accredited agency Applicable note number The United States The flexible cord must be Type HO5VV-F, 3-conductor, 0.75 mm² conductor size. Power cord set fittings (appliance coupler and wall plug) must bear the certification mark of the agency responsible for evaluation in the country or region where it will be used.

  • Page 101: Recycling

    When a battery has reached the end of its useful life, do not dispose of the battery in general household waste. Follow the local laws and regulations in your area for battery disposal. HP encourages customers to recycle used electronic hardware, HP original print cartridges, and rechargeable batteries.

  • Page 102: Index

    Index cables, service considerations 39 display enclosure AC adapter light, identifying 12 caps lock light, identifying 8 removing 67 AC adapter, spare part numbers changing the language of Setup spare part numbers 26, 35, 28, 29 Utility 75 36, 67 action keys chipset, product description 1 display hinge covers...
  • Page 103 18, 30, identifying 10 optical drive 3 31, 32, 33, 34, 35, 36, 53 operating system, product pointing device 4 keyboard for HP Mini 110 and description 5 ports 4 Compaq Mini CQ10 optical drive power requirements 5...
  • Page 104 System Configuration Menu recovering from the dedicated USB ports, identifying 11, 12 recovery partition 85 using 75 using Setup Utility 75 recovering from the recovery Setup Utility menus 77 using system restore 87 discs 85 sleeve, spare part numbers 28, recovery discs 84 29, 30 vents, identifying 12...
