- Page 1 USER’S MANUAL ice 4 Link Gateway 100/200/300 V2.01 State of the art car integration for media players, USB and Bluetooth devices...
-
Page 2: Warranty
In case of any kind of erratic behavior of your car’s electrical system, please disconnect your ice>Link first and have it checked by your installer. Dension does not assume liability for any diagnostic fees. - Page 3 Bluetooth: BTA1000 Accessory supports headset profile (HSP) and A2DP/AVRCP profiles for audio playback and handsfree profile (HFP) for handsfree telephony. PND: Portable Navigation Devices. This feature is under development. See an up to date list of supported devices at http://www.dension.com/pnd...
-
Page 4: Getting Started
Is your player up-to-date? Before you start, please check your player’s firmware, and make sure it is upgraded to the latest version. For iPod firmware visit http://www. apple.com/support/ipod. Dension only guarantees proper functionality with the latest version of firmware. Study your radio manual! Please study the owner’s manual for your radio. -
Page 5: Playback Control
Some car radios can display song information or browse music content. This feature is manually enabled during installation. Pelase visit http://support.dension.com/enabletext for a current list of radios that support this feature and instructions on how to enable it. Playback control... - Page 6 Source Selection & Operation Summary Source devices are assigned to various Track# on Disc6. When you select Disc6, the Track# indicates the current source. This may take a few seconds, depending on the radio. By changing the Track# you can select a new source device. Confirm source selection by pressing FF.
- Page 7 Bluetooth Bletooth Hands Audio Free Track Disc # Source Select: Set Track # + press FF Parking Parking & Play_All Parking Next=“Green button“ Back=“Red button“ Scan Album Enable/Disable FF=AlbumPlay Hands free operation Scan Artist Last Number Dial FF=ArtistPlay Scan Playlist or Folder Pairing Pairing...
- Page 8 Operation in Detail About Sources • In AUX mode radio displays Track99 and a dummy time counter. AUX input and iPod’s audio signals are shared. Connecting both devices to Gateway sounds will be mixed. • iPod User Interface: the iPod functionality remains normal, but additional control from the radio or steering wheel is available.
- Page 9 • Connection or disconnection of a device initiates a Magazine Eject/Load sequence, which may cause transient information on the radio display. If the radio switches to tuner (FM) mode, reselect CD changer manually. This is the normal behavior of certain radios. For example you are listening to an iPod in Gateway mode and you want to select Aux input as the source:...
- Page 10 At the end of Artist- or AlbumPlay the iPod will stop, and USB player will continue the original playback program. This feature is not available in iPod UI mode. For example you are listening to the Beatles song “Yesterday”, which is on the album “Help”: By selecting Disc2 (Artist): Next: will play e.g.
-
Page 11: About Bluetooth
Files without ID3 tags will be not added to the database, so you can’t reach them by browsing this way. Use folder based navigation to search the real file stucture. Before disconnecting the USB drive, select another source and wait until its LED goes off or stops blinking. - Page 12 Advanced pairing; disconnects the current de- vice from the selected profile and starts a new Track4 pairing for the selected profile only. This allows to connect different devices for Audio and Hands Free use. Restart connection process. Useful if BTA1000 loses the connection with a Track5 Bluetooth device for any reason.
- Page 13 Incoming calls automatically activate Bluetooth Hands Free source if any other Gateway source is selected. To Accept or Reject the call use Next or Previous Track buttons. After finishing the call, the Gateway will return to the original source. If the Radio or CD is selected, than an incoming call mutes the radio briefly allowing you to hear the phone ring.
- Page 14 Some cars enable the Gateway to display song information and browse music. Not every CD Text capable radio is browser compatible. Please refer to the knowledge base at http://support.dension. com for an up to date listing. In text capable applications Disc6 offers a menu, including Source Selection and direct Playlist, Artist, Album, etc.
- Page 15 Next/Back Track To select an item in the menu or turn Jog-Wheel To enter the selected item or start a or press Jog-Wheel song To exit the menu level Some cars equipped with dedicated Select buttons or joystick mounted on the steering wheel buttons.
-
Page 16: Troubleshooting
You may need the security code to reactivate the radio. Consult with your installer or contact your local Dension support. You cannot control the iPod from the radio: Make sure the firmware on your iPod is the most recent. - Page 17 Gateway software version in the upper right and the selected car configuration in the upper left corner of the “Warning! Don’t browse while driving” splash screen. You have to refer this information contacting Dension’s Technical Support.
- Page 18 For up to date information about available Gateway accessories visit Dension’s WEB Site at http://www.dension.com/accessories Apple, iPod, iTunes, USB and Bluetooth are registered trademarks of their respective holders.
- Page 19 DEGWX-9203-2...
