PowerLite ® 4200W
Multimedia Projector
Product Name
PowerLite 4200W
Genuine Epson Lamp
Replacement Air Filter
Specifications
Projection System
High-aperture Epson 3LCD, 3-chip technology
Projection Method
Front/rear/ceiling mount
Driving Method
Epson Poly-silicon TFT Active Matrix
Pixel Number
1,024,000 pixel x 3 LCDs (1280 x 800)
Native Resolution
1280 x 800 (WXGA)
Aspect Ratio
Supports 4:3, 16:9, 16:10
Pixel Arrangement
Cross stripe
Color Light Output
1
4500 lumens
White Light Output 1
4500 lumens (ISO 21118 standard)
Contrast Ratio (High Brightness,
Dynamic Mode)
1000:1
Brightness Uniformity (typical)
89%
Color Reproduction
16.7 million colors
Size (projected distance)
30" – 300"
Lens Shift
Vertical: ±60 degrees
Horizontal: ±10 degrees
Keystone Correction
Vertical: ±40 degrees
Horizontal: ±20 degrees
Lamp Type
330 W UHE
Lamp Life
7
2000 hours (Normal Mode)
3000 hours (ECO Mode)
Effective Scanning
Frequency Range
Pixel Clock
13.5 MHz – 162 MHz (up to UXGA 60 Hz)
Horizontal
15 kHz – 92 kHz
Vertical
50 Hz – 85 Hz
1 White and color light output will vary depending on mode selected. White light output measured using iSo 21118 standard.
2 data source: Projectorcentral.com jan 2010. average of 910 shipping models for which the manufacturers provided lumens and total power data, all resolutions
and brightness levels.
3 See our website for convenient and reasonable recycling options at www.epson.com/recycle
4 SmartWay is an innovative partnership of the u.S. environmental Protection agency that reduces greenhouse gases and other air pollutants and improves fuel efficiency.
5 this projector does not meet the dicoM standard Part 14 and should not be used as a medical diagnostic device.
6 recommended based on normal room conditions. cleaning requirements may vary depending on use, environment and other conditions.
cleaning intervals may be adjusted to accommodate the environment in which the projector is used.
7 lamp life will vary depending upon mode selected, environmental conditions and usage. lamp brightness decreases over time.
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Specifications subject to change. Epson, Easy Management, EasyMP and Quick Corner are registered trademarks, Epson Exceed Your Vision is a registered logomark and Better Products for a Better
Future and C 2 Fine are trademarks of Seiko Epson Corporation. PowerLite and PrivateLine are registered trademarks, Duet is a trademark and Epson Connection is a service mark of Epson America, Inc.
SmartWay is a service mark of the U.S. Environmental Protection Agency. All other product and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims
any and all rights in these marks. Copyright 2010 Epson America, Inc. CPD-33436 12/10
Product Code UPC
V11H348020 0 10343 88097 9
V13H010L63 0 10343 88123 5
V13H134A17 0 10343 86897 7
Video I/O
Display Performance
NTSC: 560 line
PAL: 560 line (depends on observation of the
multi-burst pattern)
Input Signal
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/
PAL60/SECAM 480i/576i/480p/576p/720p/
1080i/1080p
Pixel works: video chip
3D Y/C separation, noise reduction
motion compensated
Interlace-Progressive conversion
(2 – 2, 3 – 2 film detection)
Interfaces
Computer: D-sub 15 pin x 1
Composite video: BNC x 1
Video: 5-BNC x 1
Network: RJ-45 x 1,100 Mbps
Serial: RS-232c
Projection Lens
Type
Manual focus/zoom
F-number
1.65 – 2.55
Focal Length
21.28 mm – 37.94 mm
Zoom Ratio
Optical zoom 1.0 – 1.8
Throw Ratio Range
1.29 – 2.34
Other Features
Operating Temperature
32 ˚ to 104 ˚F (0 ˚ to 40 ˚C)
Power Supply Voltage
100 – 240 V ±10%, 50/60 Hz AC
Power Consumption
464 W (Normal Mode)
383 W (ECO Mode)
11 W Standby (Communication on)
0.47 W Standby (Communication off)
Fan Noise
38 dB (Normal Mode)
32 dB (ECO Mode)
Security
Security cable hole, lens lock,
Kensington ® lock provision
Epson Canada, Ltd.
3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
Dimensions (W x D x H)
Including Feet (with standard lens)
18.50" x 12.26" x 5.96"
Excluding Feet, Lens
18.5" x 12.26" x 5.31"
Weight 15 lb
Remote Control
Features
Power, source search selection, computer,
video, A/V mute, freeze, user ID, auto, aspect,
color mode, num, page up and down, E-zoom,
volume, help, menu, enter, esc and
pointer functions
Operating Angle
Right/left:
Front: ± 60 degrees
Rear: ± 30 degrees
Upper/lower:
Front: ± 20 degrees
Rear: +10 to +45 degrees
Operating Distance
49 ft
Support
The Epson Connection
SM
Pre-sales support
U.S. and Canada 800-463-7766
Internet website www.epson.com
Service Programs
Two-year limited warranty, Epson Road
Service program, PrivateLine
®
dedicated toll-free support (U.S. and
Canada only) and 90-day limited
lamp warranty
What's In The Box
PowerLite 4200W projector, power cable,
computer cable (VGA), projector remote control
with batteries, user manual CD, EasyMP
®
software CD, Quick Setup Sheet, PrivateLine
support card, registration card, password
protection sticker and lens lock screw
www.epson.com
www.epson.ca
Accessory Part Numbers
Genuine Epson lamp V13H010L63
Replacement air filter V13H134A17
Replacement remote control 1485872
Advanced projector ceiling mount
with precision gear ELPMBPRG
Adjustable suspended
ceiling channel kit ELPMBP01
False ceiling plate kit ELPMBP02
Structural round ceiling plate ELPMBP03
Adjustable extension column
(pipe) 8" – 11" ELPMBC01
Kensington security lock ELPSL01
50-inch portable screen
(4:3 aspect ratio) ELPSC06
60-inch portable pop-up screen
(4:3 aspect ratio) ELPSC07
80-inch portable pop-up screen
(4:3 aspect ratio) ELPSC08
Duet™ portable projector screen
(4:3/16:9 combination) ELPSC80
Component to VGA video cable ELPKC19
S-video cable ELPSV01
Distribution amplifier ELPDA01
Remote control (ELPST16) V12H007T16
Image presentation
camera (ELPDC05) V12H162020

Packaging Specifications

PowerLite 4200W
Dimensions 21.9" x 18.4" x 11.1" (W x D x H)
Weight 21.3 lb
Genuine Epson Lamp
Dimensions 6.3" x 5.6" x 5.6" (W x D x H)
Weight 0.8 lb
Master Carton
Dimensions 28.4" x 13.1" x 6.8" (W x D x H)
Weight 9 lb
Units Per Master Carton 10
Replacement Air Filter
Dimensions 11.3" x 3.7" x 1.9" (W x D x H)
Weight 0.21 lb
Master Carton
Dimensions 19.2" x 11.8" x 4.8" (W x D x H)
Weight 3.09 lb
Units Per Master Carton 10
