Summary of Contents for Zanussi cooker
- Page 2 Without following this procedure, the repair personnel Centre by consulting the telephone directory under will have to charge you more for the repair. the name ZANUSSI or, of course, the yellow pages under the section Electrical Domestic Appliances/ Repairs. This appliance complies with the following E.E.C. Directives: •...
-
Page 3: Warning
This warnings has been given for the safety of you and others. We therefore ask you to carefully read the procedures of installing and using this cooker. • This appliance has been designed for use by adults. -
Page 4: Table Of Contents
CONTENTS Warning Pag. 49 Instructions for the user Pag. 51 Installation Pag. 51 Pag. 51 Electric Oven Pag. 53 Advice for use of oven Pag. 55 Cooking times Pag. 56 Maintenance Pag. 57 Instructions for installation Pag. 58 Gas connection Pag. -
Page 5: Instructions For The User
Control knobs on the cooker clockwise direction to the position " ". During cooking, when using fats or oils, take The knobs for using the gas cooker are found on the particular care as they can, when over-heated, self- control panel. -
Page 6: Electric Hotplates
ELECTRIC HOTPLATES The electric plate switches can be regulated to four different positions, from position 4 (maximum heat) to position 1 (minimum heat), according to cooking requirements. For the long-life of your electric plates and to economize on electricity, we advise: use of flat-based pans having a diametre not smaller than that of the plate;... -
Page 7: Electric Oven
ELECTRIC OVEN Oven Function Control Knob (Fig. 2) The most suitable temperature for the cooking can be set by turning the oven function control knob clockwise. It is also possible to make the top or bottom hrating element operate separately. Meaning of symbols: Oven switched off Oven lamp... - Page 8 Pilot lamp When lit indicates the operation of one or more heating elements. Oven thermostat pilot lamp Switches off when the oven reaches the selected temperatue and re-lights each time the thermostat intervenes to maintain the temperature. FO 0190 Fig. 5 Mechanical timer The timer can be regulated for a maximum of one hour.
- Page 9 ADVICE FOR THE USE OF YOUR OVEN For the preparation of cakes The degree of cooking can be checked by pressing the Pre-heat the oven, unless indicated differently, for at meat with a fork; if it does not give the meat is cooked. least 10 minutes before use.
-
Page 10: Cooking Times
TABLE OF COOKING TIMES Level Cooking time Temperature Type of food in minutes Electric oven Cakes in mould with beaten egg white mixtures Marble cake 60-70 Girdle cake 60-70 Sponge cake 35-40 Shortpastry Flan base 15-20 Cheesecake 35-40 Jam tart 35-40 Cakes in moulds with raised mixtures Buns... -
Page 11: Maintenance
Before each operation, disconnect the unit. Oven lamp replacement (Fig. 7) Disconnect the appliance. Unscrew the lamp and Cleaning the cooker substitute it with another fitting for a higher tempera- Drops of sauce, fruit juice etc., should be removed as... -
Page 12: Instructions For The Installer
Lid cleaning All the cooker lids can be disassembled, to allow a better cleaning. Enamelled lids can be dissasembled as shown in fig. 9. As regards crystal lids, follow instructions included in the chapter named "Balancing the lid". After a proper cleaning, carefully reposition the lid into its hinges. -
Page 13: Gas Connection
GAS CONNECTION Gas connection must be carried out according to the rules in force. The manufacturing company release the unit, once tested, adjusted for the kind of gas stated on the rating FLEXIBLE plate located on the back of the range, next to RUBBER connection pipe. - Page 14 ADAPTATION TO DIFFERENT KINDS OF GAS To adapt the appliance to a different kind of gas from the one the appliance has been set for, follow the instructions below in their order. GAS CONNECTION (Fig. 13) LPG : use the rubber pipe holder «C». Natural gas : use the pipe fitting «A».
-
Page 15: Electrical Connection
The brown live wire (originating from the clamp of the cooker junction box) must always be connected to the phase of the mains supply. In any case, the supply cord must be positioned in such a way as it doesn't reach in any point a temperature higher by 50 C than the room temperature. - Page 16 — the pressure regulator is working; of food to be cooked. — the bottle valve is completely open. The cooker produces smoke — We advise you to clean the oven after use. Gas smell in the room Splashes of fat can occur during the cooking of...
