- Page 1 156999310en.qxp 11/28/2005 2:27 PM Pagina 1 User Manual Dishwasher ZDF 211...
-
Page 2: Table Of Contents
156999310en.qxp 11/28/2005 2:27 PM Pagina 2 Content Safety information - - - - - - - - - - - - - - - - - - -3 Control panel and functions - - - - - - - - - - - -4 Programme table - - - - - - - - - - - - - - - - - - -6 Before the first use - - - - - - - - - - - - - - - - - -6 Setting the water softener - - - - - - - - - - - - -7... -
Page 3: Safety Information
156999310en.qxp 11/28/2005 2:27 PM Pagina 3 Safety information In the interest of your safety and to ensure the correct use, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents. -
Page 4: Control Panel And Functions
156999310en.qxp 11/28/2005 2:27 PM Pagina 4 Never use the dishwasher if the electrical All sides of the dishwasher must never be ● ● supply cable and water hoses are damaged; drilled to prevent damage to hydraulic and or if the control panel, work top or plinth area electric components. - Page 5 156999310en.qxp 11/28/2005 2:27 PM Pagina 5 Illuminates when the washing programme has ended. Switch of the dishwasher by returning the programme selector dial to the Off position. The End of On/Off indicator light turns off. programme It also has added functions of visual signalling as: light - the setting of the water softener, - intervention of an alarm due to the malfunction of the machine.
-
Page 6: Programme Table
156999310en.qxp 11/28/2005 2:27 PM Pagina 6 Programme table Programme Cycle description Intensive 70°C Heavy soil. Prewash - Main wash Crockery, cutlery, 2 intermediate rinses - pots and pans Final rinse - Dry Normal 65°C Normal soil. Prewash - Main wash Crockery and cutlery 2 intermediate rinses - Final rinse - Dry... -
Page 7: Setting The Water Softener
156999310en.qxp 11/28/2005 2:27 PM Pagina 7 Setting the water softener The dishwasher is equipped with a water IMPORTANT! softener designed to remove minerals and salts The water softener must be set in both ways: from the water supply, which would have a manually and electronically. - Page 8 156999310en.qxp 11/28/2005 2:27 PM Pagina 8 Setting the water softener electronically (see table) The water softener is factory set at position 5. The dishwasher must Press and hold the start/cancel button and turn the Release the button. The be switched off programme selector dial clockwise till the first end of programme programme.
-
Page 9: Filling With Dishwasher Salt
156999310en.qxp 11/28/2005 2:27 PM Pagina 9 Filling with dishwasher salt CAUTION! Use only special salt suitable for dishwashers Unscrew the cap. Only before filling with Using the funnel salt for the first time, provided, pour in the fill the salt container salt until the container is with water full. -
Page 10: Adjusting The Dosage Of Rinse Aid
156999310en.qxp 11/28/2005 2:27 PM Pagina 10 CAUTION! Never fill the rinse aid dispenser with any other substances (e.g. dishwasher cleaning agent, liquid detergent). This would damage the appliance. Top up the rinse aid when the indicator (B) becomes clear. Adjusting the dosage of rinse aid Increase the dose if there are drops of water or Reduce the dose if there are whitish streaks lime spots on the dishes after washing. - Page 11 156999310en.qxp 11/28/2005 2:27 PM Pagina 11 - To avoid damage to glasses, they must not IMPORTANT! touch. Before closing the door, ensure that the spray - Lay small objects in the cutlery basket. arms can rotate freely. Plastic items and pans with teflon have a ●...
-
Page 12: Filling With Detergent
156999310en.qxp 11/28/2005 2:28 PM Pagina 12 Adjusting the height of the upper basket If washing very large Maximum height of the dishes in: plates you can load them upper basket lower basket in the lower basket after With upper basket raised 20 cm 31 cm moving the upper basket... -
Page 13: Unloading The Dishwasher
156999310en.qxp 11/28/2005 2:28 PM Pagina 13 For programmes with When using detergent Close the lid. prewash add an tablets: additional detergent place detergent tablets dose in compartment B. in compartment A. Unloading the dishwasher IMPORTANT! Empty the lower basket first and then the ●... -
Page 14: External Cleaning
156999310en.qxp 11/28/2005 2:28 PM Pagina 14 IMPORTANT! NEVER try to remove the spray arms. If residues of soil have clogged the holes in the upper spray arm, remove Remove filter A from the Put the flat filter A back Replace the filters and them with a toothpick. -
Page 15: Environmental Concerns
156999310en.qxp 11/28/2005 2:28 PM Pagina 15 Environmental concerns Packaging material Old appliance The packaging materials are environmentally The symbol on the product or on its friendly and can be recycled. The plastic packaging indicates that this product may not components are identified by markings, e.g. be treated as household waste. - Page 16 156999310en.qxp 11/28/2005 2:28 PM Pagina 16 Fault code / malfunction Possible cause Solution The dishwasher will not drain. The sink spigot is blocked. Clean out the sink spigot. - continuous flashing of the The water drain hose has not been Check the water drain hose start/cancel indicator light correctly laid or it is bent or...
-
Page 17: Technical Data
156999310en.qxp 11/28/2005 2:28 PM Pagina 17 So that you always If after all these checks, the problem persists, have these numbers contact your local Service Force Centre, at hand, we quoting the model (Mod.), product number recommend you to (PNC) and serial number (S.N.). make a note of them This information can be found on the rating here:... -
Page 18: Hints For Test Institutes
156999310en.qxp 11/28/2005 2:28 PM Pagina 18 Hints for test institutes Testing in accordance with EN 60704 must be Test in accordance with EN 50242 must be carried out with appliance fully loaded and carried out when the salt container and rinse using the test programme (see "Consumption aid dispenser have been filled with salt and values"). -
Page 19: Drain Hose
156999310en.qxp 11/28/2005 2:28 PM Pagina 19 CAUTION! If the machine is connected to new pipes or pipes which have not been used for a long time, you should run the water for a few minutes before connecting the inlet hose. Drain hose Inlet hose Connect the inlet hose to a water tap with an... -
Page 20: Fitting Under A Counter
156999310en.qxp 11/28/2005 2:28 PM Pagina 20 WARNING! Multi-way plugs, connectors and extension ● cables must not be used. This could constitute a fire hazard through overheating. If necessary, have the domestic wiring ● system socket replaced. In case that the electrical cable has to be replaced, contact your local Service Force centre. -
Page 21: European Guarantee
Ireland +353 1 40 90 753 Longmile Road Dublin 12 Italia +39 (0) 434 558500 C.so Lino Zanussi, 26 - 33080 Porcia (PN) Latvija +37 17 84 59 34 Kr. Barona iela 130/2, LV-1012, Riga Lituania +370 5 27 80 609... - Page 22 156999310en.qxp 11/28/2005 2:28 PM Pagina 22 Österreich +43 18 66 400 Herziggasse 9, 1230 Wien ul. Kolejowa 5/7, Warsaw Polska +48 22 43 47 300 Quinta da Fonte - Edificio Gonçalves Zarco Portugal +35 12 14 40 39 39 Q35 -2774-518 Paço de Arcos Romania +40 21 44 42 581 B-dul Timisoara 90, S6, Bucharest...
