READ THIS MANUAL CAREFULLY! It contains important safety information. OWNER’S MANUAL YFM450FAR WARNING This ATV should not be ridden by anyone under 16 years of age. LIT-11626-16-01 5ND-F8199-10...
Page 3
Yamaha experience in the production of fine sporting, touring, and pace-setting racing machines. With the purchase of this Yamaha, you can now appreciate the high degree of crafts- manship and reliability that have made Yamaha a leader in these fields.
Page 4
EBU00801 IMPORTANT MANUAL INFORMATION FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SE- RIOUS INJURY OR DEATH. Particularly important information is distinguished in this manual by the following notations: The Safety Alert Symbol means ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Failure to follow WARNING instructions could result in severe WARNING...
EBU00014 Indicator lights........4-2 WARNING Fuel gauge ........4-4 Indicates a potential hazard that could Speedometer unit ......4-4 result in serious injury or death. Handlebar switches ......4-6 Throttle lever ........4-12 Speed limiter ........4-13 CONTENTS Front brake lever......4-14 Rear brake pedal and lever ...4-14 Drive select lever ......4-15 LOCATION OF THE WARNING Recoil starter........4-15...
Page 7
PRE-OPERATION CHECKS ... 5-1 Engine break-in ....... 6-7 Front and rear brakes ..... 5-2 Parking..........6-8 Fuel ..........5-4 Parking on a slope......6-9 Engine oil ........5-6 Accessories and loading ....6-10 Final gear oil........5-7 Differential gear oil ......5-7 RIDING YOUR ATV ......
Page 8
PERIODIC MAINTENANCE AND Inspecting the brake fluid level ..8-38 ADJUSTMENT........8-1 Brake fluid replacement ....8-40 Owner’s manual and tool kit.... 8-1 Front brake adjustment....8-41 Periodic maintenance/ Rear brake lever adjustment ..8-42 lubrication ........8-3 Adjusting the rear brake light Panel removal and installation ..8-5 switch ...........8-43 Engine oil........
Page 9
CLEANING AND STORAGE.... 9-1 A. Cleaning........9-1 B. Storage ........9-3 SPECIFICATIONS......10-1 NOISE REGULATION....11-1 MAINTENANCE RECORD .... 12-1 ATV LIMITED WARRANTY.... 13-1 YAMAHA EXTENDED SERVICE (Y.E.S.) ........... 14-1...
EBU00464 LOCATION OF THE WARNING AND SPECIFICATION LABELS...
Page 11
R e f e r t o i n s t r u c t i o n s i n t h e O w n e r ' s M a n u a l . 5ND-F4877-00 Yamaha dealer.
Page 12
WARNING O v e r l o a d i n g t h i s AT V o r c a r r y i n g c a r g o i m p r o p e r l y c a n c h a n g e h a n d l i n g . s t a b i l i t y a n d b r a k i n g p e r fo r m a n c e a n d c a n l e a d t o a n a c c i d e n t .
Page 13
NEVER operate this ATV if you are under age 16. Turning the ATV in 4WD-LOCK ( “DIFF. LOCK” ) takes more effort. YAMAHA 4XE-F415A-00 Operate at a slow speed and allow extra time and distance for maneuvers to avoid loss of control.
EBU00924 SAFETY INFORMATION AN ATV IS NOT A TOY AND CAN BE HAZARDOUS TO OPERATE. An ATV handles differently from other vehicles including motorcycles and cars. A collision or rollover can occur quickly, even during routine maneuvers such as turning and riding on hills or over obstacles, if you fail to take proper precautions.
Page 15
Never operate an ATV without wearing an approved motorcycle helmet that fits properly. You should also wear eye protection (goggles or face shield), gloves, boots, long-sleeved shirt or jacket, and long pants. Never consume alcohol or drugs before or while operating this ATV. Never operate at speeds too fast for your skills or the conditions.
Page 16
Always follow proper procedures for climbing hills as described in this manual. Check the ter- rain carefully before you start up any hill. Never climb hills with excessively slippery or loose surfaces. Shift your weight forward. Never open the throttle suddenly or make sudden gear changes.
Page 17
Always be careful when skidding or sliding. Learn to safely control skidding or sliding by prac- ticing at low speeds and on level, smooth terrain. On extremely slippery surfaces, such as ice, go slowly and be very cautious in order to reduce the chance of skidding or sliding out of con- trol.
Page 18
WARNING When transporting the ATV in another vehicle, be sure it is kept upright and POTENTIAL HAZARD that the fuel cock is in the “OFF” posi- Improper handling of gasoline. tion. Otherwise, fuel may leak out of the WHAT CAN HAPPEN carburetor or fuel tank.
Page 19
WARNING POTENTIAL HAZARD Starting or running the engine in a closed area. WHAT CAN HAPPEN Exhaust fumes are poisonous and may cause loss of consciousness and death within a short time. HOW TO AVOID THE HAZARD Always operate your ATV in an area with adequate ventilation.
Record the information on this la- bel in the space provided. This information will be needed to order spare parts from your Yamaha dealer. 1. Vehicle identification number NOTE: The vehicle identification number is used to 1.
EBU00039 CONTROL FUNCTIONS WARNING Indicates a potential hazard that could result in serious injury or death. EBU01057 Main switch Functions of the respective switch positions are as follows: 1. Main switch The engine can be started only at this position and the headlights and tail/brake light come on when the light switch is on.
EBU00043 EBU01060 Indicator lights Differential gear lock indicator light “DIFF. LOCK” This indicator light and the differential gear lock indicator in the display flash when the dif- ferential gear lock switch is set to the “4WD- LOCK” position. EBU00838 Low-range indicator light “L” This indicator light comes on when the drive select lever is in the “L”...
Page 25
EBU00602 Reverse indicator light “R” CAUTION: This indicator light comes on when the trans- The engine may overheat if the ATV is mission is in reverse. overloaded. If this happens, reduce the load to specification. EBU00609 After restarting, make sure that the Park indicator light “P”...
EBU00052 Fuel gauge The fuel gauge indicates the amount of fuel in the fuel tank. When the needle reaches the red line, refill the tank at the first opportunity. 1. Speedometer 2. Odometer/Tripmeter A/Tripmeter B 3. Clock/Hour meter 4. TRIP/ODO button 5.
Page 27
two tripmeters (which show the distance Odometer and tripmeter modes traveled since they were last set to zero) Pushing the “TRIP/ODO” button switches the a clock display between the odometer mode “ODO” an hour meter (which shows the total time and the tripmeter modes “A”...
EBU00053 Clock mode Handlebar switches Pushing the “ ”/“ ” button for at least two seconds switches the display between the clock mode “CLOCK” and the hour meter mode “HOUR” in the following order. CLOCK→HOUR→CLOCK To set the clock 1. Push the “ ”/“...
Page 29
CAUTION: Do not use the headlights with the engine turned off for more than thirty minutes. The battery may discharge to the point that the starter motor will not operate properly. If this should happen, remove the battery and recharge it. EBU00849 1.
Page 30
Two-wheel drive (2WD): Power is supplied to the rear wheels only. Four-wheel drive (4WD): Power is supplied to the rear and front wheels. Four-wheel drive with the differential gear locked (4WD-LOCK): Power is supplied to the rear and front wheels when the differen- tial gear is locked (“DIFF.LOCK”).
Page 31
WARNING POTENTIAL HAZARD Changing from 2WD to 4WD or from 4WD to 4WD-LOCK (“DIFF.LOCK”), or vice-versa while the ATV is moving. WHAT CAN HAPPEN The ATV handles differently in 2WD than in 4WD and in 4WD-LOCK in some circumstances. Changing from 2WD to 1.
Page 32
WARNING POTENTIAL HAZARD Riding too fast while the ATV is in 4WD- LOCK. WHAT CAN HAPPEN All wheels turn at the same speed when the differential is locked, so it takes more effort to turn the ATV. The amount of effort is more the faster you go. You 1.
Page 33
NOTE: When the switch is set to “LOCK”, the dif- ferential gear lock indicator light will flash until the differential gear is locked. When the indicator light is flashing, turn- ing the handlebar back and forth will help the differential gear lock to engage. Riding before the differential gear lock is properly engaged (e.g., when the indica- tor light is flashing) will cause the engine...
Check the operation of the throttle lever before you start the engine. If it does not work smoothly, check for the cause. Correct the problem before riding the ATV. Consult a Yamaha dealer if you 1. Throttle lever can’t find or solve the problem yourself. 4-12...
EBU01159 Speed limiter WARNING The speed limiter keeps the throttle from fully POTENTIAL HAZARD opening, even when the throttle lever is Improper adjustment of the speed limit- pushed to the maximum. Turning in the ad- er and throttle. justing screw limits the maximum engine pow- WHAT CAN HAPPEN er available and decreases the maximum The throttle cable could be damaged.
EBU00070 Front brake lever The front brake lever is located on the right handlebar. Pull it toward the handlebar to ap- ply the front brake. 1. Rear brake pedal 1. Front brake lever EBU00073 Rear brake pedal and lever The brake pedal is located on the right side of the machine and the brake lever is located on the left handlebar.
EBU00608 EBU00855 Drive select lever Recoil starter The drive select lever is used to shift your ma- Firmly grasp the handle and pull slightly until chine into the low, high, neutral, reverse and engagement can be felt. Then pull forcefully, park positions.
EBU00092 Fuel tank cap WARNING Remove the fuel tank cap by turning it coun- POTENTIAL HAZARD terclockwise. Starting the engine without setting the drive select lever to the park position “P”. WHAT CAN HAPPEN The ATV could start to move unexpect- edly, which could cause an accident.
EBU00093 Fuel cock OFF Position The fuel cock supplies fuel from the fuel tank to the carburetor. The fuel cock has three positions. OFF: With the lever in this position fuel will not flow. Always turn the lever to this position when the engine is not running.
EBU00095 Starter (choke) “ ” RES Position Starting a cold engine requires a richer air-fuel mixture. A separate starter circuit supplies this mixture. Move in direction a to turn on the starter (choke). Move in direction b to turn off the starter (choke).
EBU00566 Seat To install the seat, insert the projection on the To remove the seat, pull the seat lock lever front of the seat into the seat holder and push upward and pull up the seat at the rear. down on the seat at the rear. NOTE: Make sure that the seat is securely fitted.
EBU01062 Storage compartment The storage compartment is located under the seat. (See page 4-19 for seat removal and installation procedures.) When storing any documents in the storage compartment, be sure to wrap them in a plas- tic bag so that they will not get wet. When washing the ATV, be careful not to let any wa- ter enter the storage compartment.
EBU00582 EBU01104 Front carrier Front shock absorber adjustment The spring preload can be adjusted to suit the Maximum load limit: 40 kg (88 lb) rider’s weight and riding conditions. Adjust the spring preload as follows. To increase the spring preload, turn the ad- EBU00583 justing ring in direction a.
Page 44
NOTE: WARNING A special wrench can be obtained at a POTENTIAL HAZARD Yamaha dealer to make this adjustment. Improper shock absorber adjustment. WHAT CAN HAPPEN Standard position: 2 Uneven adjustment can cause poor 1 - Minimum (soft) handling and loss of stability, which 5 - Maximum (hard) could lead to an accident.
Rear shock absorber adjustment A special wrench can be obtained at a The spring preload can be adjusted to suit the Yamaha dealer to make this adjustment. rider’s weight and riding conditions. Adjust the spring preload as follows: Standard position: 2 To increase the spring preload, turn the ad- justing ring in direction a.
EBU00748 Auxiliary DC jack Maximum rated capacity for the The auxiliary DC jack is located at the front auxiliary DC jack: right side of the ATV. The auxiliary DC jack DC 12 V, 120 W (10 A) can be used for suitable work lights, radios, etc.
PRE-OPERATION CHECKS Before using this machine, check the following points: ITEM ROUTINE PAGE • Check operation, free play, fluid level and fluid leakage. 5-2–5-3, Brakes • Fill with DOT 4 brake fluid if necessary. 8-35–8-45 • Check fuel level. 5-4–5-5 Fuel •...
Always follow the inspection and main- brakes are applied. If not, have a Yamaha tenance procedures and schedules de- dealer inspect the brake system. scribed in the Owner’s Manual.
Page 51
If a formance, inspect the brake pads for wear. problem cannot be corrected by the ad- (See pages 8-37–8-38.) justment procedures provided in this manual, have a Yamaha dealer check for the cause.
EBU01085 Fuel Your Yamaha engine has been designed to Make sure there is sufficient gasoline in the use regular unleaded gasoline with a pump tank. octane number ([R+M]/2) of 86 or higher, or research octane number of 91 or higher. If...
Page 53
Fuel can spill, which can cause a fire hol containing methanol is not recommended and severe injury. by Yamaha because it may cause fuel system Fuel expands when it heats up. If the damage or vehicle performance problems. fuel tank is overfilled, fuel could spill out due to heat from the engine or the sun.
EBU01084 Engine oil CAUTION: Make sure the engine oil is at the specified In order to prevent clutch slippage level. Add oil as necessary. (See pages 8-12– (since the engine oil also lubricates the 8-15.) clutch), do not mix any chemical addi- tives.
GL-4 is a quality and additive rating, GL-5 or correctly. It must open smoothly and spring GL-6 rated hypoid gear oils may also be used. back to the idle position when released. Have a Yamaha dealer repair as necessary for proper operation.
Always check the tightness of chassis fittings WARNING and fasteners before a ride. Take the machine POTENTIAL HAZARD to a Yamaha dealer or refer to the Service Operating this ATV with improper tires, Manual for correct tightening torque. or with improper or uneven tire pres- sure.
Page 57
2. The tires should be set to the rec- 4. Use no more than the following ommended pressure: pressures when seating the tire Recommended tire pressure beads. Front 25 kPa (0.25 kgf/cm , 3.6 psi) Front 250 kPa (2.5 kgf/cm , 36 psi) Rear 25 kPa (0.25 kgf/cm , 3.6 psi)
EBU00159 How to measure tire pressure Use the low-pressure tire gauge. NOTE: The low-pressure tire gauge is included as standard equipment. Make two measure- ments of the tire pressure and use the second reading. Dust or dirt in the gauge could cause the first reading to be incorrect.
2. Turn the fuel cock to “ON”. there is a control or function you do not 3. Turn the main switch to “ON” and the en- understand, ask your Yamaha dealer. gine stop switch to “ ”. 4. Shift the drive select lever into the neutral...
Page 61
25 °C (80 °F) and warm engine tral or park position, if either indicator light start position. does not come on, ask a Yamaha dealer to inspect its electric circuit. The engine can be started in any gear if the rear brake lever is applied. However, it is recommended to shift into neutral or park before starting the engine.
NOTE: CAUTION: If the engine fails to start, release the See the “Engine break-in” section prior to start switch, then push the start switch operating the engine for the first time. again. Pause a few seconds before the next attempt. Each cranking should be as short as possible to preserve battery en- EBU00180 ergy.
EBU00846 Drive select lever operation and reverse driving CAUTION: Before shifting, you must stop the ma- chine and return the throttle lever to the closed position. Otherwise, the transmis- sion may be damaged. Shifting: Neutral to High and High to Low 1.
Page 64
If the light does not the drive select lever along the shift come on, ask a Yamaha dealer to inspect guide. the reverse indicator light electrical cir- cuit.
Page 65
5. Open the throttle lever gradually and con- tinue to watch to the rear while backing. WARNING POTENTIAL HAZARD Improperly operating in reverse. WHAT CAN HAPPEN You could hit an obstacle or person be- hind you, resulting in serious injury. HOW TO AVOID THE HAZARD When you shift into reverse, make sure there are no obstacles or people behind...
For this reason, we ask that you carefully read build up of heat. If any abnormality is noticed the following material. Because the engine is during this period, consult a Yamaha dealer. brand new, you must not put an excessive 1. 0–10 hours: load on it for the first several hours of running.
EBU00612 2. 10–20 hours: Parking Avoid prolonged operation above 3/4 When parking, stop the engine and shift the throttle. Rev the machine freely but do drive select lever into the park position, then not use full throttle at any time. turn the fuel cock to the “OFF”...
EBU00615 Parking on a slope 1. Bring the machine to a stop by applying the brakes. WARNING 2. Stop the engine. POTENTIAL HAZARD 3. With the rear brake applied, shift the Parking on a hill or other incline. drive select lever to the park position. WHAT CAN HAPPEN The ATV could roll out of control, in- creasing the chance of an accident.
Choose only accessories designed for your dlebars which could make steering difficult, ATV. Your Yamaha dealer has a variety of an accessory that limits your ability to move genuine Yamaha accessories. Other ac-...
Page 70
EBU00960 Loading Do not exceed the maximum tongue Cargo or a trailer can change the stability and weight. You can measure tongue weight handling of an ATV. You must use common with a bathroom scale. Put the tongue of sense and good judgment when carrying car- the loaded trailer on the scale with the go or towing a trailer.
Page 71
Ride more slowly than you would without a WARNING load. The more weight you carry, the slow- POTENTIAL HAZARD er you should go. Although conditions vary, Overloading this ATV or carrying or tow- it is good practice not to exceed low range ing cargo improperly.
Page 72
EBU00956 WARNING Indicates a potential hazard that could result in serious injury or death. 6-13...
WARNING Indicates a potential hazard that could result in serious injury or death. begin to ride, be sure you have read this GETTING TO KNOW YOUR ATV Owner’s Manual completely and understand This ATV is mainly for utility use, but may also the operation of the controls.
JUDGEMENT Beginning and inexperienced operators should complete the certified training Get training if you are inexperienced. course offered by Yamaha. They should Beginners should get training from a certified then regularly practice the skills learned instructor. in the course and the operating tech- Become familiar with this ATV at slow speeds niques described in this Owner’s Manu-...
Page 77
Not recommended for children under 16 years of age. WARNING POTENTIAL HAZARD Failure to follow the age recommenda- tions for this ATV. WHAT CAN HAPPEN Use by children of ATVs that are not rec- ommended for their age can lead to se- vere injury or death of the child.
Page 78
This machine is designed to carry opera- tor and cargo only - passengers prohibit- WARNING POTENTIAL HAZARD Carrying a passenger on this ATV. WHAT CAN HAPPEN Greatly reduces your ability to balance and control this ATV. Could cause an accident, resulting in harm to you and/ or your passenger.
Page 79
Apparel Operating without protective clothing WARNING increases your chances of severe injury in the event of an accident. POTENTIAL HAZARD HOW TO AVOID THE HAZARD Operating this ATV without wearing an Always wear an approved motorcycle approved motorcycle helmet, eye pro- helmet that fits properly.
Page 80
Do not operate after consuming alcohol or WARNING drugs. POTENTIAL HAZARD Operator’s performance capability is reduced Operating this ATV after consuming al- by the influence of alcohol or drugs. cohol or drugs. WHAT CAN HAPPEN Could seriously affect your judgment. Could cause you to react more slowly.
Page 81
Pre-operation checks WARNING Always perform the pre-operation checks list- POTENTIAL HAZARD ed on page 5-1 before riding for safety and Operating this ATV with improper tires, proper care of the machine. or with improper or uneven tire pres- WARNING sure. POTENTIAL HAZARD WHAT CAN HAPPEN Failure to inspect the ATV before oper-...
Page 82
Speed limiter WARNING For riders less experienced with this model, Indicates a potential hazard that could this model is equipped with a speed limiter in result in serious injury or death. the throttle lever housing. The speed limiter keeps the throttle from fully opening, even Do not operate at speeds too fast for your when the throttle lever is pushed to the maxi- skills or the conditions.
Page 83
Loading and accessories WARNING Use extra caution when riding the machine POTENTIAL HAZARD with additional loads, such as accessories or Overloading this ATV or carrying or tow- cargo. The machine’s handling may be ad- ing cargo improperly. versely affected. Reduce your speed when WHAT CAN HAPPEN adding additional loads.
Page 84
During operation Always keep your feet on the footboards dur- WARNING ing operation. Otherwise your feet may con- POTENTIAL HAZARD tact the rear wheels. Removing hands from handlebars or feet from footboards during operation. WHAT CAN HAPPEN Removing even one hand or foot can re- duce your ability to control the ATV or could cause you to lose your balance and fall off of the ATV.
Page 85
Avoid wheelies and jumping. You may lose control of the machine or overturn. WARNING POTENTIAL HAZARD Attempting wheelies, jumps, and other stunts. WHAT CAN HAPPEN Increases the chance of an accident, in- cluding an overturn. HOW TO AVOID THE HAZARD Never attempt stunts, such as wheelies or jumps.
Page 86
Never modify this ATV through improp- er installation or use of accessories. All parts and accessories added to this ve- hicle should be genuine Yamaha or equivalent components designed for use on this ATV and should be installed and used according to instructions. If you have questions, consult an autho- rized ATV dealer.
Page 87
Exhaust system Do not touch the hot exhaust system. The exhaust system on the machine is very Do not park the machine in a place hot during and following operation. To prevent where others might be likely to touch it. burns, avoid touching the exhaust system.
BE CAREFUL WHERE YOU RIDE This machine is designed for off-road use only. Riding on paved surfaces can cause loss of control. WARNING POTENTIAL HAZARD Operating this ATV on paved surfaces. WHAT CAN HAPPEN ATVs are designed for off-road use only. Paved surfaces may seriously affect handling and control of the ATV, and may cause the vehicle to go out of con-...
Page 89
Do not ride on any public road, street, or high- way. Riding on public roads can result in collisions with other vehicles. WARNING POTENTIAL HAZARD Operating this ATV on public streets, roads or highways. WHAT CAN HAPPEN You can collide with another vehicle. HOW TO AVOID THE HAZARD Never operate this ATV on any public street, road or highway, even a dirt or...
Page 90
Know the terrain where you ride. Ride cau- tiously in unfamiliar areas. Stay alert for holes, rocks, or roots in the terrain, and oth- er hidden hazards which may cause the ma- chine to upset. WARNING POTENTIAL HAZARD Failure to use extra care when operating this ATV on unfamiliar terrain.
Page 91
WARNING POTENTIAL HAZARD Failure to use extra care when operating on excessively rough, slippery or loose terrain. WHAT CAN HAPPEN Could cause loss of traction or vehicle control, which could result in an acci- dent, including an overturn. HOW TO AVOID THE HAZARD Do not operate on excessively rough, slippery or loose terrain until you have learned and practiced the skills neces-...
Page 92
When riding in an area where you might not WHAT CAN HAPPEN easily be seen, such as desert terrain, mount You could be in a collision. You could a caution flag on the machine. DO NOT use be injured. the flag pole bracket as a trailer hitch. HOW TO AVOID THE HAZARD Always mount a caution flag on the ma- chine to make you more visible.
Page 93
Select a large, flat area off-road to become fa- With the engine idling, shift the drive select le- miliar with your ATV. Make sure that this area ver to the low position “L” or the high position is free of obstacles and other riders. You “H”.
TURNING YOUR ATV HOW TO AVOID THE HAZARD To achieve maximum traction while riding off- Always follow proper procedures for road in 2WD or 4WD, the two rear wheels are turning as described in this Owner’s mounted solidly on one axle and turn together Manual.
Page 95
Once you have learned this technique you should be able to perform it at higher speeds or in tighter curves. Improper riding procedures such as abrupt throttle changes, excessive braking, incorrect body movements, or too much speed for the sharpness of the turn may cause the ATV to tip.
CLIMBING UPHILL HOW TO AVOID THE HAZARD Use proper riding techniques to avoid vehicle Never operate the ATV on hills too steep overturns on hills. Be sure that you can ma- for the ATV or for your abilities. Practice neuver your ATV well on flat ground before at- on smaller hills before attempting large tempting any incline and then practice riding hills.
Page 97
WARNING An obstacle, a sharp drop, or another vehicle or person could be on the other POTENTIAL HAZARD side of the hill. Climbing hills improperly. WHAT CAN HAPPEN Could cause loss of control or cause the ATV to overturn. HOW TO AVOID THE HAZARD Always follow proper procedures for climbing hills as described in this Own- er’s Manual.
Page 98
If you are climbing a hill and you find that you WARNING have not properly judged your ability to make POTENTIAL HAZARD it to the top, you should turn the ATV around Improperly crossing hills or turning on while you still have forward motion (provided hills.
Page 99
When crossing the side of a hill: Always follow proper procedures as de- scribed in the Owner’s Manual. Avoid hills with excessively slippery or loose surfaces. Shift your weight to the uphill side of the ATV. 7-27...
Page 100
If your ATV has stalled or stopped and you the front and rear brakes gradually, or dis- believe you can continue up the hill, restart mount the ATV immediately on the uphill side. carefully to make sure you do not lift the front WARNING wheels which could cause you to lose control.
Page 101
If you begin rolling backwards: Keep weight uphill. 2WD: Never apply the rear brake while rolling backwards. Apply the front brake. 4WD or 4WD-LOCK: Apply both front and rear brakes gradually. When fully stopped, shift to the park- ing position “P”. Dismount on uphill side or to a side if pointed straight uphill.
RIDING DOWNHILL When this ATV is in 4WD or 4WD-LOCK, all When riding your ATV downhill, shift your wheels (front and rear) are interconnected by weight as far to the rear and uphill side of the the drive train. This means that applying either ATV as possible.
Page 103
WARNING POTENTIAL HAZARD Going down a hill improperly. WHAT CAN HAPPEN Could cause loss of control or cause the ATV to overturn. Always follow proper procedures for go- ing down hills as described in this Own- er’s Manual. Note: a special technique is required when braking as you go down a hill.
CROSSING A SLOPE WARNING Traversing a sloping surface on your ATV re- POTENTIAL HAZARD quires you to properly position your weight to Improperly crossing hills or turning on maintain proper balance. Be sure that you hills. have learned the basic riding skills on flat WHAT CAN HAPPEN ground before attempting to cross a sloping Could cause loss of control or cause the...
CROSSING THROUGH SHALLOW WATER Remember that wet brakes may have re- The ATV can be used to cross slow moving, duced stopping ability. Test your brakes shallow water of up to a maximum of 35 cm after leaving water. If necessary, apply (14 inches) in depth.
Page 107
Test your brakes after leaving the water. Do CAUTION: not continue to ride your ATV without verifying After riding your ATV in water, be sure to that you have regained proper braking ability. drain the trapped water by removing the check hose at the bottom of the air filter case and the check hose on the V-belt cooling duct.
RIDING OVER ROUGH TERRAIN WARNING Riding over rough terrain should be done with POTENTIAL HAZARD caution. Look out for obstacles which could Improperly operating over obstacles. cause damage to the ATV or could lead to an WHAT CAN HAPPEN upset or accident. Be sure to keep your feet Could cause loss of control or a colli- firmly mounted on the footboards at all times.
SLIDING AND SKIDDING If the rear wheels of your ATV start to slide Care should be used when riding on loose or sideways, control can usually be regained (if slippery surfaces since the ATV may slide. If there is room to do so) by steering in the direc- unexpected and uncorrected, sliding could tion of the slide.
Page 111
With practice, over a period of time, skill at WARNING controlled sliding can be developed. The ter- POTENTIAL HAZARD rain should be chosen carefully before at- Skidding or sliding improperly. tempting such maneuvers, since both stability WHAT CAN HAPPEN and control are reduced. Bear in mind that You may lose control of this ATV.
WHAT TO DO IF ... If your ATV starts to slide sideways: This section is designed to be a reference Steer in the direction of the slide if you have guide only. Be sure to read each section on the room. Applying the brakes or accelerat- riding techniques completely.
Page 113
If your ATV is traversing a sloping surface: Be sure to ride with your weight positioned towards the uphill side of the ATV to main- tain proper balance. If the ATV starts to tip, steer down the hill (if there are no obstacles in your way) to regain balance.
EBU00515 PERIODIC MAINTENANCE AND Have a Yamaha dealer perform service if ADJUSTMENT you are not familiar with machine ser- vice. Periodic inspection, adjustment and lubrica- tion will keep your machine in the safest and EBU00535 most efficient condition possible. Safety is an Owner’s manual and tool kit...
Page 115
HOW TO AVOID THE HAZARD during a service operation requiring one, take Never modify this ATV through improp- your machine to a Yamaha dealer to check er installation or use of accessories. All the torque settings and adjust them as neces- parts and accessories added to this ve- sary.
EBU00261 PERIODIC MAINTENANCE/LUBRICATION INITIAL EVERY Whichever mile 1,500 1,500 3,000 ITEM ROUTINE comes first (km) (320) (1,200) (2,400) (2,400) (4,800) hours • Check valve clearance. Valves* • Adjust if necessary. • Check coolant leakage. Cooling system • Repair if necessary. •...
Page 117
• Replace if damaged. • Check all chassis fittings and fasteners. Fittings and fasteners* • Correct if necessary. It is recommended that these items be serviced by a Yamaha dealer. ** Lithium-soap-based grease NOTE: Recommended brake fluid: DOT 4 Brake fluid replacement: •...
EBU00614 Panel removal and installation The panels illustrated need to be removed to perform some of the maintenance described in this chapter. Refer to this section each time a panel has to be removed or reinstalled. 1. Panel C 2. Panel D 3.
Page 119
EBU00700 Panel A, D To remove 1. Remove the seat. 2. Pull outward on the areas shown, and then pull upward.
Page 120
To install 1. Place the panel in its original position. 2. Install the seat.
Page 121
EBU01147 Panel B To remove Remove the bolt, and then take the panel off. To install Place the panel in the original position and in- stall the bolt. CAUTION: When installing the panel, be sure not to pinch the cables or wires. 1.
Page 122
EBU01141 Panel C To remove 1. Remove the front carrier by removing the stay covers at the rear, then by removing the bolts. 1. Bolt (× 2) (under fenders) 2. Remove the quick fasteners and pull the panel upward. 1. Bolt (× 4) 1.
Page 123
EBU01013 To install Panel E 1. Place the panel in the original position To remove and install the quick fasteners. Remove the bolts, and then take the panel off. 2. Install the front carrier by installing the To install bolts and tightening them to the specified Place the panel in the original position, and torques.
Page 124
EBU00638 Panel F To install To remove Place the panel in its original position. Pull outward on the areas shown. 1. Panel F 8-11...
EBU01099 Engine oil 5. Insert the dipstick in the filler hole without Engine oil level measurement screwing it in. 1. Remove panel F. (See page 8-11 for NOTE: panel removal and installation proce- Wait a few minutes until the oil level settles dures.) before checking.
Page 126
Engine oil and oil filter cartridge replace- 5. Remove the oil filter cartridge with an oil ment filter wrench. 1. Remove panels E and F. (See pages 8-10 and 8-11 for panel removal and installa- tion procedures.) 2. Warm up the engine for several minutes. 3.
Page 127
8. Install the oil filter cartridge, and then An oil filter wrench is available at a nearby tighten it to the specified torque with a Yamaha dealer. torque wrench. 6. Install the drain bolt and tighten it to the Tightening torque: specified torque.
Page 128
9. Fill the engine with sufficient oil to reach 10. Start the engine and warm it up for seve- the specified level. Install the engine oil ral minutes. While warming up, check for filler cap and tighten it. oil leakage. If oil leakage is found, stop the engine immediately and check for the Recommended engine oil: cause.
EBU01145 Final gear oil Final gear oil measurement 1. Place the machine on a level surface. 2. Remove the oil filler bolt, and then check the oil level in the final gear case. NOTE: The oil level should be at the brim of the filler hole.
Page 130
Final gear oil replacement 1. Remove the final gear case cover by re- moving the bolts. 1. Final gear case drain bolt 5. Install the drain bolt, and then tighten it to the specified torque. 1. Final gear case cover 2.
Page 131
Recommended oil: See page 10-3. Oil quantity: 0.23 L (0.2 Imp qt, 0.24 US qt) CAUTION: Be sure no foreign material enters the final gear case. 7. Install the oil filler bolt. 8. Check for oil leakage. If oil leakage is found, check for the cause.
EBU00706 Differential gear oil CAUTION: Differential gear oil measurement Be sure no foreign material enters the dif- 1. Place the machine on a level place. ferential gear case. 2. Remove the oil filler bolt and check the oil level. It should be up to the brim of the 3.
Page 133
Recommended oil: SAE 80 API “GL-4” Hypoid gear oil Oil quantity: Periodic oil change: 0.23 L (0.2 Imp qt, 0.24 US qt) Total amount: 0.28 L (0.25 Imp qt, 0.3 US qt) CAUTION: 1. Differential gear oil drain bolt Be sure no foreign material enters the dif- 4.
EBU01068 Cooling system 3. Remove the coolant reservoir cap, and 1. Check the coolant level in the coolant then add coolant or distilled water to raise reservoir when the engine is cold as the it to the specified level. coolant level will vary with engine tem- 4.
EBU00887* Changing the coolant NOTE: If water is added, have a Yamaha dealer WARNING check the antifreeze content of the cool- POTENTIAL HAZARD ant as soon as possible. Removing the radiator cap when the en- The radiator fan operation is completely gine and radiator are still hot.
Page 136
1. Place the ATV on a level surface. 2. Remove panels D, E and F. (See pages 8-6–8-7, 8-10 and 8-11 for panel removal and installation procedures.) 3. Place a container under the engine, and then remove the coolant drain bolt. (Use a trough or a similar object as shown to prevent coolant from spilling on the foot- rest.)
Page 137
1. Radiator cap 1. Coolant reservoir hose 5. Remove the radiator cap. 8. After draining the coolant, thoroughly 6. Remove the coolant reservoir cap. flush the cooling system with clean tap 7. Disconnect the hose on the coolant res- water. ervoir side, and then drain the coolant 9.
Page 138
Total amount: NOTE: 1.3 L (1.1 Imp qt, 1.4 US qt) If any leakage is found, have a Yamaha deal- Coolant reservoir capacity: er check the cooling system. 0.39 L (0.34 Imp qt, 0.41 US qt) 16.
Check the protective boots for holes or tears. If any damage is found, have them replaced 1. Remove panel A. (See pages 8-6–8-7 for by a Yamaha dealer. panel removal and installation proce- dures.) 2. Remove the spark plug cap.
Page 140
Do not attempt to diagnose such problems to remove the spark plug as shown. yourself. Instead, take the ATV to a Yamaha dealer. You should periodically remove and inspect the spark plug because heat and deposits will cause the spark plug to slowly break down and erode.
Page 141
NOTE: If a torque wrench is not available when you are installing a spark plug, a good estimate of the correct torque is 1/4 to 1/2 turn past finger tight. Have the spark plug tightened to the specified torque as soon as possible. 4.
EBU01133 Air filter element cleaning NOTE: There is a check hose at the bottom of the air filter case. If dust or water collects in this hose, empty the hose and clean the air filter element and air filter case. 1.
Page 143
WARNING POTENTIAL HAZARD Using low flash point solvents or gaso- line to clean the air filter element. WHAT CAN HAPPEN Low flash point solvents or gasoline can catch fire or explode. HOW TO AVOID THE HAZARD Use parts cleaning solvent to clean the 1.
Page 144
NOTE: 7. Apply Yamaha foam air filter oil or other The air filter element should be cleaned every quality foam air filter oil to the air filter el- 20–40 hours. It should be cleaned and lubri- ement. If foam air filter oil is not available, cated more often if the machine is operated in engine oil may be used.
1. V-belt cooling duct check hose NOTE: If water drains from the V-belt case after re- moving the plug, have a Yamaha dealer in- spect the ATV as the water may affect other engine parts. 8-32...
EBU01066 Spark arrester cleaning Be sure the exhaust pipe and muffler are cool before cleaning the spark arrester. 1. Remove the bolts. 2. Remove the tailpipe by pulling it out of the muffler. 1. Tailpipe 2. Spark arrester 4. Insert the tailpipe into the muffler and align the bolt holes.
The carburetor is a vital part of the engine and POTENTIAL HAZARD requires very sophisticated adjustment. Most Improper cleaning of the spark arrester. adjusting should be left to a Yamaha dealer Hot exhaust system who has the professional knowledge and ex- WHAT CAN HAPPEN perience to do so.
EBU00657 Idle speed adjustment NOTE: A diagnostic tachometer must be used for this procedure. 1. Start the engine and warm it up for a few minutes at approximately 1,000 to 2,000 r/min. Occasionally rev the engine to 4,000 to 5,000 r/min. The engine is warm when it quickly responds to the 1.
This adjust- ment however, should be left to a professional 1. Loosen the locknut. Yamaha service technician. 2. Turn the adjusting bolt until the throttle le- ver free play is 3–5 mm (0.12–0.20 in). 3. Tighten the locknut.
Front brake pad inspection Inspect the brake pads for damage and wear. If the thickness is less than the specified val- ue, have a Yamaha dealer replace the pads. a. Free play a. Wear limit: 1 mm (0.04 in) NOTE: The wheels need to be removed to inspect the brake pads.
Inspect the grooves. If they have al- EBU00622 most disappeared, ask a Yamaha dealer to Inspecting the brake fluid level replace the pad. Insufficient brake fluid may let air enter the brake system, possibly causing the brakes to become ineffective.
Page 152
Observe these precautions: FRONT 1. When checking the fluid level, make sure the top of the master cylinder reservoir is level by turning the handlebars. 2. Use only the designated quality brake flu- id. Otherwise, the rubber seals may dete- riorate, causing leakage and poor brake performance.
Always clean up 1. Complete fluid replacement should be spilled fluid immediately. done only by trained Yamaha service 6. Have a Yamaha dealer check the cause personnel. if the brake fluid level goes down. 2. Have a Yamaha dealer replace the fol-...
The front brake lever should have a free play POTENTIAL HAZARD of zero mm (zero in) at the lever end. If not, Operating with improperly serviced or ask a Yamaha dealer to adjust it. adjusted brakes. WHAT CAN HAPPEN You could lose braking ability, which could lead to an accident.
The top of the brake pedal should be posi- tioned 75 mm (3 in ) above the top of the foot- rest. If not, ask a Yamaha dealer to adjust it. 1. Locknut 2. Adjusting bolt c. Free play 2.
Make sure the brakes do not drag. All air must be bled from the brake system. Replacement of brake components re- quires professional knowledge. These procedures should be performed by a Yamaha dealer. 1. Rear brake light switch 2. Adjusting nut 8-43...
Inspect cables frequently. Replace dam- aged cables. Lubricate the inner cables and the cable ends. If the cables do not operate smoothly, ask a Yamaha dealer to replace them. Recommended lubricant: Yamaha chain and cable lube or SAE 10W30 motor oil 8-44...
EBU01112 Wheel removal 1. Loosen the wheel nuts. 2. Elevate the ATV and place a suitable stand under the frame. 3. Remove the nuts from the wheel. 4. Remove the wheel. 1. Tapered nut (× 4) 8-45...
EBU01121 Wheel installation 2. Lower the ATV so that the wheel is on the 1. Install the wheel and the nuts. ground. NOTE: Tapered nuts are used for both the front and rear wheels. Install the nut with its ta- pered side towards the wheel.
Keep out of reach of chil- tery. If the battery seems to have discharged, dren. consult a Yamaha dealer. Antidote: EXTERNAL: Flush with water. CAUTION: INTERNAL: Drink large quantities of wa- Do not try to remove the sealing caps of ter or milk.
Then turn on the switches. If CAUTION: the fuse immediately blows again, con- A special battery charger (constant volt- sult a Yamaha dealer. age/ampere or constant voltage) is re- quired recharging sealed-type battery.
Page 162
1. Main fuse 2. Fuse box 1. Headlight fuse 2. Ignition fuse 3. Auxiliary DC jack fuse 4. Four-wheel drive fuse 5. Signaling system fuse 6. Odometer fuse (backup) 7. Spare fuse (× 3) Specified fuses: Main fuse: 30 A Headlight fuse: 15 A Ignition fuse:...
EBU01063 Replacing a headlight bulb WARNING If a headlight bulb burns out, replace it as fol- POTENTIAL HAZARD lows: Using an improper fuse. 1. Remove the cover at the rear of the WHAT CAN HAPPEN headlight by pulling it off. An improper fuse can cause damage to the electrical system which could lead to a fire.
Page 164
2. Remove the headlight bulb holder by WARNING turning it counterclockwise. POTENTIAL HAZARD The headlight bulb is hot when it is on and immediately after it is turned off. WHAT CAN HAPPEN You can be burned, or a fire could start if the bulb touches something flamma- ble.
Tail/brake light bulb replacement If the tail/brake light bulb burns out, have a CAUTION: Yamaha dealer replace it. It is advisable to have a Yamaha dealer make this adjustment. To raise the beam, turn the adjusting screw in direction a.
EBU00412 Troubleshooting WARNING Although Yamaha machines receive a rigid in- POTENTIAL HAZARD spection before shipment from the factory, Checking the fuel system while smok- trouble may occur during operation. Any prob- ing or near an open flame. lem in the fuel, compression, or ignition sys-...
No fuel. 2. Compression There is compression. Compression normal. Use the electric starter to see if there is compression. Ask a Yamaha dealer to No compression. inspect. 3. Ignition Wipe clean with dry cloth. Ignition system is Spark is good.
Restart the engine. If the engine overheats again, ask a Level is OK. Yamaha dealer to inspect and/or repair the cooling system. NOTE: If it is difficult to get the recommended coolant, tap water can be temporarily used, provided that it is changed to the recommended coolant as soon as possible.
EBU00419 CLEANING AND STORAGE CAUTION: Excessive water pressure may cause wa- A. CLEANING ter seepage and deterioration of wheel Frequent, thorough cleaning of your machine bearings, brakes, transmission seals and will not only enhance its appearance but will electrical devices. Many expensive repair improve its general performance and extend bills have resulted from improper high the useful life of many components.
Page 170
6. Clean the seat with a vinyl upholstery WARNING cleaner to keep the cover pliable and POTENTIAL HAZARD glossy. Operation with wet brakes after wash- 7. Automotive type wax may be applied to ing. all painted and chrome plated surfaces. WHAT CAN HAPPEN Avoid combination cleaner-waxes.
Do not apply oil to fuel) any rubber parts or the seat cover. NOTE: Use of fuel stabilizer and conditioner elimi- nates the need to drain the fuel system. Con- sult a Yamaha dealer if the fuel system needs to be drained instead.
Page 172
7. Remove the battery and charge it. Store it in a dry place and recharge it once a month. Do not store the battery in an ex- cessively warm or cold place (less than 0 °C (30 °F) or more than 30 °C (90 °F)). NOTE: Make any necessary repairs before storing the machine.
EBU00428 SPECIFICATIONS Model YFM450FA Dimensions: Overall length 1,984 mm (78.1 in) Overall width 1,085 mm (42.7 in) Overall height 1,120 mm (44.1 in) Seat height 827 mm (32.6 in) Wheelbase 1,233 mm (48.5 in) Ground clearance 245 mm (9.65 in) Minimum turning radius 3,000 mm (118.1 in) Basic weight:...
Page 174
Model YFM450FA Engine oil: Type 0˚ 90˚ 110˚ 130˚F 10˚ 30˚ 50˚ 70˚ YAMALUBE 4 (20W40) or SAE 20W40 YAMALUBE 4 (10W30) or SAE 10W30 SAE 5W30 -20˚ -10˚ 0˚ 20˚ 30˚ 40˚ 50˚C 10˚ Recommended engine oil classification API Service SE, SF, SG type or higher CAUTION: In order to prevent clutch slippage (since the en- gine oil also lubricates the clutch), do not mix any...
Page 175
Model YFM450FA Final gear case oil: Type SAE 80 API “GL-4” Hypoid gear oil Quantity: Periodic oil change 0.23 L (0.2 Imp qt, 0.24 US qt) Total amount 0.25 L (0.22 Imp qt, 0.26 US qt) Differential gear case oil: Type SAE 80 API “GL-4”...
Page 176
Model YFM450FA Spark plug: Type/manufacturer DR8EA / NGK Spark plug gap 0.6–0.7 mm (0.02–0.03 in) Clutch type Wet, centrifugal automatic Transmission: Primary reduction system V-belt Secondary reduction system Spur gear 39/24 × 24/18 × 33/9 (7.944) Secondary reduction ratio Transmission type V-belt automatic Operation Left hand operation...
Page 177
Model YFM450FA Brake: Front brake type Dual disc brake operation Right hand operation Rear brake type Single disc brake operation Left hand and right foot operation Suspension: Front suspension Double wishbone Rear suspension Swingarm (monocross) Shock absorber: Front shock absorber Coil spring / oil damper Rear shock absorber Coil spring / oil damper...
Page 178
Model YFM450FA Bulb voltage, wattage × quantity: 12 V, 30/30 W × 2 Headlight 12 V, 5/21 W × 1 Tail/brake light Indicator light: Neutral indicator light L.E.D. Reverse indicator light L.E.D. Coolant temperature warning light L.E.D. Park indicator light L.E.D.
EBU00430 NOISE REGULATION TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inop- erative by any person other than for purposes of maintenance, repair, or replacement of any de- vice or element of design incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.
EBU01126 M AINTENANCE RECORD Copies of work orders and/or receipts for parts you purchase and install will be required to docu- ment maintenance done in accordance with the warranty. The chart below is printed only as a re- minder to you that the maintenance work is required. It is not acceptable proof of maintenance work.
Page 187
LOCATE AND READ OWNER’S MANUAL. FOLLOW ALL INSTRUCTIONS AND WARNINGS. (For replacement manual, call 1-800-532-1558) YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN USA 2002.11-2.7×1 CR...
