Page 1: Air Conditioner
CCH mini-splits - 13 SEER Air Conditioner OWNER'S MANUAL Models: CCH009CA-410 CCH012CA-410 CCH009CD-410 CCH012CD-410 66129902934... -
Page 2: Table Of Contents
CONTENTS Operation and maintenance ■ ........1 Notices for operation ■ Notices for use ........4 ■ ......5 Names and functions of each part Operation of wireless remote control ■ .....6 ..... 11 ..■ Emergency Operation ■ ........1 Clean and care Troubleshooting ■... - Page 3 Operation and maintenance-Notices for operation Please read the following carefully before operating. WARNING When having a burning smell Don't operate the air conditioner Never cut off or damage power or smoke, please turn off the power with wet hands. cables and control wires. If the power cable and signal control wire were supply and contact with the service damaged, change them by professional...
-
Page 4: Notices For Operation
Notices for operation Earth:The ground Be sure to pull out the power Select the most appropriate tem- ¡ ï perature. be connected! plug when not using the air co- nditioner for a long time. Keep room coo- er than outside about If not, please ask the qualified person- nel to install. - Page 5 Notices for operation To adjust the airflow and direction appropriately. The power cords of this air conditioner adopt Y- type connection, please don't cut off or damage At operating the louvers of air conditioner could be the power cords and control cords. If they are adjusted by pressing the SWING button on wireless damaged, please ask the qualified personnel to remote control to change the airflow direction.
-
Page 6: Notices For Use
Notices for use Working principle and special functions for cooling Principle: Air conditioner absorbs heat in the room and transmit to outdoor and discharged, so that indoor ambient temperature decreased, its cooling capacity will increase or decrease by outdoor ambient temperature. Anti-freezing function If the unit is running in COOL mode and in low termperature, there will be frost formed on the heat exchanger, when indoor heat exchanger temperature decreased below 0¡æ,... -
Page 7: Names And Functions Of Each Part
Names and functions of each part Air in CCH009CA-410 CCH009CD-410 Indoor Unit CCH012CA-410 CCH012CD-410 ⑴ ⑷ ⑵ Air out ⑶ The pattern in displayer： ：Cool ：Dry ：Fan ：Heat Wireless remote control ： Front Panel ：Set temp. Guide louver Wall Pipe... -
Page 8: Operation Of Wireless Remote Control
Operation of wireless remote control Names and functions of wireless remote control Note: Be sure that there are no obstructions between receiver and remote controller; Don't drop or throw the remote control; Don't let any liquid in the remote control and put the remote control directly under the sunlight or any place where is very hot. -
Page 9: Light Button
Operation of wireless remote control Names and functions of wireless remote control Notice: This is a general use remote controller, it could be used for the air conditioners with multifunction; For some function, which the model dosen't have, if press the corresponding button on the remote controller that the unit will keep the original running status. -
Page 10: Timer On Button
Operation of wireless remote control Names and functions of wireless remote control Notice: This is a general use remote controller, it could be used for the air conditioners with multifunction; For some function, which the model dosen't have, if press the corresponding button on the remote controller that the unit will keep the original running status. - Page 11 Operation of wireless remote control Guide for operation- General operation 1. After powered on, press ON/OFF button, the unit will start to run.(Note: When it is powered off, the guide louver of main unit will close automatically.) 2. Press MODE button, select desired running mode, or press COOL or HEAT mode to enter into the corresponding operation directly.
- Page 12 Operation of wireless remote control ¡ï About lock Press +and - buttons simultaneously to lock or unlock the keyboard. If the remote controller is locked, the icon will be displayed on it, in which case, press any button, the mark will flicker for three times.
-
Page 14: Clean And Care
Clean and care Caution Turn power off and pull out the power plug before cleaning air conditioner, or it may cause electric shock. Never sprinkle water on the indoor unit and the outdoor unit for cleaning because it can cause an electric shock. Volatile liquid (e.g. - Page 15 Clean and care Clean and care Check before use Be sure that nothing obstructs the air outlet and intake vents. Check that whether ground wire is properly connected or not. Check that whether the batteries of air conditioner are changed or not. Check that whether the installation stand of the outdoor unit is damaged or not.
-
Page 16: Troubleshooting
Troubleshooting CAUTION Don't attempt to repair the air conditioner by yourself, it can cause an electric shock or fire. Please check the following items before asking for repair, it can save your time and money. Phenomenon Troubleshooting Not operate immediately when the air Once the air conditioner is stopped, it will conditioner is restarted. - Page 17 Troubleshooting Phenomenon Troubleshooting The unit can not run. Has the power been shut down? Is the circuit protection device tripped off or not? Is voltage higher or lower? (Tested by professionals) Is the Timer correctly used? Break off Is Temp. setting suitable? Cooling efficiency is not good.
- Page 18 Troubleshooting Phenomenon Troubleshooting In dehumidifying mode, sometimes indoor fan Indoor unit cannot deliver air. will stop, in order to avoid condensing water be vaporized again, restrain temperature rising. If unit is running under the high humidity for a long Moisture on air outlet vent. time, the moisture will be condensed on the air outlet grill and drip off.
-
Page 19: Installation Service Notices For Installation
Installation service- Notices for installation Important Notices The unit installation work must be done by qualified personnel according to the local rules and this manual. Before installating, please contact with local authorized maintenance center, if unit is not installed by the authorized maintenance center, the malfunction may not solved, due to discommodious contacts. -
Page 20: Notices For Installation
Notices for installation Select a location where there should be sufficient ventilation. Select a location where there should be no obstructions cover the inlet and outlet vent. The location should be able to withstand the full weight and vibration of the outdoor unit and permit safe installation. -
Page 21: Installation Dimension Diagram
Installation dimension diagram Installation dimension diagram The dimensions of the space necessary for correct installation of the appliance including the minimum permissible distances to adjacent structures. Space to the ceiling 5.91in Above Space to the wall 5.91in Above 5.91in Above Space to the wall 98.43in 118.11in... -
Page 22: Wiring Diagram Indoor Unit
Wiring diagram indoor unit CCH009CA-410(I) CCH012CA-410(I) CCH009CD-410(I) CCH012CD-410(I) -
Page 23: Install Indoor Unit
Install indoor unit Install the rear panel 1. Always mount the rear panel horizontally. As the water drainage pipe at the left, when adjusting the rear panel, this side should not be too high; the right side should be slightly high. 2.F ix the rear panel on the selected Wall Mark on the middle of it... -
Page 24: Install The Indoor Unit
Install indoor unit NOTE: When connecting the electric wire if the wire length is not enough, please contact with the authorized service shop to buy a exclusive electric wire that is long enough and the joint on the wire are not allowed. The electric wiring must be correctly connected, wrong connection may cause spare parts malfunction. -
Page 25: Wiring Diagram Outdoor Unit
Wiring diagram outdoor unit CCH009CA-410(O) CCH012CA-410(O) - Page 26 Wiring diagram outdoor unit CCH009CD-410(O) CCH012CD-410(O)
-
Page 27: Install Outdoor Unit
- After the cable fixed, make sure there should be a free power ¡ñ ction wire wire space between the connection and fixing place on the lead wire. CCH009CA-410 YEGN YEGN handle handle cord cord anchorage anchorage power... - Page 28 Install outdoor unit Air purging and leakage test Take out the nut cover of the inlet for refrigerant. 2. Align the center of the piping and tighten the conical nut with hands. Fig. 3. To tighten the conical nut with spanner. Liquid pipe Liquid valve Freon charge nuzzle...
-
Page 29: Check After Installation And Test Operation
Check after installation and test operation Check after installation Items to be checked Possible malfunction Has it been fixed firmly? The unit may drop, shake or emit noise. It may cause insufficient cooling(heating) Have you done the refrigerant leakage test? capacity. -
Page 30: Installation And Maintenance Of Healthy Filter
Installation and Maintenance of Healthy Filter Installation Instructions 1. Forcibly pull the panel for a specific angle from the two ends of the front panel according to the arrow direction. Then pull the air filter downwards to remove it. (See Fig.a) Fig. - Page 31 APPENDIX Installation altitude and refrigerant charge Length (ft) 24.61 0.22 Gas additional charge(oz/ft) Outer Diameter Liquid Pipe (in) Connection Pipe Gas Pipe (in) Max Distance Height (ft) 16.4 Length (ft) 32.81 Note: The suction line pressure: 1Mpa(with indoor temperature 75F/outdoor temperature 95F in cooling mode)
