  • Page 1 Network IP-Camera LN-406 Wireless Network 54g IP-Camera WL-404 Full Manual...

  • Page 2: Table Of Contents

    Table of Contents 1. Introduction.....................4 Overview......................4 Features.....................4 Internet Features..................5 Security Features..................5 Wireless Features (WL-404 only)..............5 Physical Details....................6 Front - Network Camera................6 Rear - Network Camera................7 Package Contents..................8 2. Basic Setup.......................9 System Requirements..................9 Installation - Network Camera................9 Setup using the Windows Wizard...............10 Setup Procedure..................10 3.
  • Page 3 Administrator ID..................37 Upgrade File...................37 Backup Config File..................37 Restore Factory Defaults .................38 Toolbox - Status....................38 Device Name..................38 Log Screen......................39 System Log....................39 Enable Syslog Service................39 Syslog Server Address................39 Refresh Button..................39 Clear Log....................39 6. Windows Monitor/Playback/Recorder utility..........40 System Tray Icon.....................40 Main Screen....................40 Camera Setup....................40 Adding Cameras on the Internet..............42 Main Screen....................43 Recording Video....................44...

  • Page 4: Introduction

    1. Introduction Overview The Network Camera has an Integrated Microcomputer and a high quality CMOS digital- Image-Sensor, enabling it to display high quality live streaming video over your wired LAN, the Internet, and for the Network Camera, an 802.11g Wireless LAN. Using enhanced MPEG-4 technologies, the Network Camera is able to stream high quality video and audio directly to your PC.

  • Page 5: Internet Features

    Internet Features User-definable HTTP port number. This allows Internet Gateways to use "port mapping" so the Network Camera and a Web Server can share the same Internet IP address. DDNS Support. In order to view video over the Internet, users must know the Internet IP address of the gateway used by the Network Camera.

  • Page 6: Physical Details

    Physical Details Front - Network Camera Lens No physical adjustment is required or possible for the lens, but you should ensure that the lens cover remain clean. The image quality is degraded if the lens cover is dirty or smudged. Microphone The built-in microphone is mounted on the front.

  • Page 7: Rear - Network Camera

    Rear - Network Camera Antenna Attach the supplied antenna here. The antenna is adjustable; best results are usually obtained with the antenna positioned vertically. SPKR out If required, an external speaker can be plugged in here. Power Input Connect the supplied 5V power adapter here. Do not use other power adapters;...

  • Page 8: Package Contents

    Package Contents The following items should be included: If any of these items are damaged or missing, please contact your dealer immediately. Network Camera Antenna (WL-404 only) Power adapter Installation CD-ROM Quick Installation Guide...

  • Page 9: Basic Setup

    To use the Wireless interface on the Wireless IP Camera with MPEG4/MJPEG, other Wireless devices must be compliant with the IEEE802.11b or IEEE802.11g specifications. All Wireless stations must use compatible settings. The default Wireless settings are: Mode Infrastructure SSID Sitecom Security Disabled Channel Auto Installation - Network Camera 1. Assemble the Camera Screw the supplied antenna to the mounting point on the rear.

  • Page 10: Setup Using The Windows Wizard

    LAN. Subsequent administration can be performed with your Web browser, as explained in Chapter 5 - Web-based Management. Setup Procedure Insert the supplied CD-ROM into your drive. The Sitecom CDROM Menu will automatically start. Click the Install Utility button to start the installation of the Monitor/Playback/IP Recorder/Setup-wizard Utilities.
  • Page 11 Select the desired Camera from the list on the left. The current settings for the selected Camera will be displayed in the table on the right. Click Next to continue. You will be prompted to enter the Administrator Name and Administrator Password, as shown below.
  • Page 12 This screen allows you to enter a suitable Description, and set the correct Time Zone, Date, and Time. Make any desired changes, then click Next to continue. The next screen, shown below, displays all details of the Network Camera. Click Next if the settings are correct Click Back to modify any incorrect values.

  • Page 13: Viewing Live Video

    3. Viewing Live Video Overview After finishing setup via the Windows-based Wizard, all LAN users can view live video using Internet Explorer on Windows. Many other powerful features and options are also available: To view multiple cameras simultaneously, or record video (either interactively or by schedule), you should install the Windows Viewing/Recording utility.
  • Page 14 Network Camera administrator.) 6. The first time you connect to the camera, you will be prompted to install an ActiveX component (OCX or CAB file), as in the example above. You must install this ActiveX component (OCX or CAB file) in order to view the Video stream in Internet Explorer.

  • Page 15: Viewing Live Video

    Viewing Live Video After installing the ActiveX component, you will be able to view the live video stream in its own window, as shown below. There are a number of options available on this screen, accessed by select list, button or icon.

  • Page 16: Advanced Viewing Setup

    4. Advanced Viewing Setup Introduction This chapter describes some additional settings and options for viewing live Video: Adjusting the video image Controlling user access to the live video stream Making video available from the Internet Using the Motion Detection feature Adjusting the Video Image If necessary, the Network Camera Administrator can adjust the Video image.
  • Page 17 MJPEG Settings Resolution Select the desired video resolution format. The default resolution is set to 320*240. Fixed Video Select the desired fix quality. The default fix quality is set to Normal. Quality Max. Frame Select the desired Maximum bandwidth for the video stream. Note Rate that you can specify EITHER the Bandwidth OR the Frame Rate, not both.

  • Page 18: Controlling User Access To The Video Stream

    Controlling User Access to the Video Stream By default, anyone can connect to the Network Camera and view live Video at any time.If desired, you can limit access to scheduled times, and also restrict access to known users. 1. Connect to the Web-based interface of the Network Camera. (See Chapter 5 - Web- based Management for details.) 2.

  • Page 19: Http Port Configuration

    HTTP Port Configuration Normally, HTTP (Web) connections use port 80. Since the Network Camera uses HTTP, but port 80 is likely to be used by a Web Server, you can use a different port for the Network Camera. This port is called the Secondary Port. The default Secondary Port is 1024.

  • Page 20: Viewing Live Video Via The Internet

    Viewing Live Video via the Internet Clients (viewers) will also need a broadband connection; dial-up connections are NOT recommended. Viewing Live Video Using your Web Browser If using your Web browser, you need to know the Internet IP address (or the Domain name) of the camera's Router/Gateway, and the correct port number.

  • Page 21: Motion Detection Alerts

    Motion Detection Alerts The Motion Detection feature can generate an Alert when motion is detected. The Network Camera will compare consecutive frames to detect changes caused by the movement of large objects. But the motion detector can also be triggered by: Sudden changes in the level of available light Movement of the camera itself.

  • Page 22: Web-Based Management

    5. Web-based Management Introduction The Network Camera can be configured using your Web Browser. The Network Camera must have an IP address which is compatible with your PC. The recommended method to ensure this is to use the supplied Windows-based Wizard, as described in Chapter 2 - Basic Setup.

  • Page 23: Basic Settings - System

    Basic Settings – System After clicking Basic Settings on the main menu, you will be asked for your username and password. Enter “admin” as username, and “admin” as password. After logging in, you'll see a screen like the example below. System Settings Device ID This displays the name for the Network Camera.

  • Page 24: Basic Settings - Network

    Enable this if you want to use this function. Operation Basic Settings - Network This screen is displayed when the Network menu option is clicked. Network Obtain an IP If selected, the Network Camera will obtain its IP address and Address related information from a DHCP Server.
  • Page 25 http://192.168.1.100:1024 RTP/RTSP The RTSP (Real Time Streaming Protocol), a standard for connected client(s) to control streaming data (MPEG-4) over the World Wide Web. Enter the RTSP Port number (between 1024 and 65535) in the field provided. The default RTSP Port is 554. The RTP (Real Time Transport Protocol), an Internet protocol for transmitting real-time data such as audio and video.

  • Page 26: Basic Settings - Wireless (Wl-404 Only)

    Basic Settings - Wireless (WL-404 only) This screen is displayed when the Wireless menu option is clicked. Wireless Network Network Type This determines the type of wireless communication used by the Network Camera. If you have an Access Point, select Infrastructure. Otherwise, select Ad-hoc.
  • Page 27 Check your wireless card's documentation to see what method to use. Note: In Infrastructure mode, either setting will normally work, since most Access Points can use both methods. Select the WEP Encryption level: Encryption 64 Bit Keys (10 Hex chars) 128 Bit Keys (26 Hex chars) 64 Bit Keys (5 ASCII chars) 128 Bit Keys (13 ASCII chars)

  • Page 28: Basic Settings - Ddns

    Basic Settings - DDNS Many internet connections use a "Dynamic IP address", where the Internet IP address is allocated whenever the Internet connection is established.This means that other Internet users don't know the IP address, so can't establish a connection. DDNS is designed to solve this problem, as follows: You must register for the DDNS service with a DDNS service provider.

  • Page 29: Video & Audio - Basic

    Video & Audio - Basic This screen is displayed when the Video & Audio option is clicked. MPEG-4 Settings Resolution Select the desired video resolution format. The default resolution is set to 320*240. Video Quality Constant Bit Rate: Select the desired bit rate. The default is set Control to 1.2 Mbps.

  • Page 30: Video & Audio - Access

    Rate Access Code Enter the code for accessing the live video from camera through cell phone connection. Video Adjustments Power Line Select the power line frequency (50Hz or 60Hz) used in your region, Frequency to improve the picture quality under florescent lighting. White Balance Select the desired option to match the current environment and lighting.

  • Page 31: Video & Audio - User

    The camera administrator must use the "User Database" menu option to create the desired users. Video Access Enable If enabled - Camera is available during the scheduled periods, Scheduled and unavailable at other times. If this option is selected, you Video Access need to define a schedule.

  • Page 32: Event - Motion Detection

    have 2 names which differ only by case. User Password The password for this user. Confirm Re-enter the password for the user, to ensure it is correct. Password Add Button Click this button to add a new user, using the data shown on screen. Clear Button Use this button to clear the input fields, ready to add a new user.

  • Page 33: Event - E-Mail

    Event - E-Mail This screen is displayed when the E-Mail option on the Event menu is clicked. Primary/Secondary SMTP Server SMTP Server Enter the address of the SMTP (Simple Mail Transport Protocol) Address Server to be used to send E-Mail. Authentication Select the desired Authentication type for the SMTP Server.

  • Page 34: Event - Ftp

    Event - FTP This screen is displayed when the FTP option on the Event menu is clicked. Primary/Secondary FTP FTP Server Enter the address of the FTP Server. Port Enter the Port of the FTP Server to be connected. Login name Enter your login name for the FTP Server.

  • Page 35: Event - Http

    Event - HTTP This screen is displayed when the HTTP option on the Event menu is clicked. HTTP Notification Enable Enable this checkbox to use the HTTP Notification. Enter the URL of your HTTP notification server. Proxy Server Specify the proxy server name in the provided field if the camera Name needs to pass through a Proxy Server to do the HTTP notification.

  • Page 36: Event - Trigger

    Event - Trigger This screen is displayed when the Event Trigger option on the Event menu is clicked. Event Schedule Schedule List The Event Schedule shows all of the event types currently configured in the Network Camera, along with various information about their configuration, as listed below: Name - the descriptive event name set by the user.

  • Page 37: Toolbox - Basic

    the JPEG image depends on this setting, and also the file size and degree of compression. Video: Video Format - Select the desired type for the video file. Pre/Post Capture - Select the desired length. The size of the file depends on this setting, and also the Video size and degree of compression.

  • Page 38: Restore Factory Defaults

    Click Defaults button to reloads all default settings on the Restore Factory camera. Defaults Restart Camera Click Restart button to restarts the camera. Toolbox - Status System This shows the name of the Network Camera. Device Name Description This shows the description of the Network Camera, such as location. F/W version The version of the current firmware installed.

  • Page 39: Log Screen

    Frame Rate This displays the frame rate of the video stream. Buttons Refresh Update the log and any other data on screen. Log Screen This screen displays a log of system activity. This is a log of system activity. System Log Check the box to enable the System Log Server feature.

  • Page 40: Windows Monitor/Playback/Recorder Utility

    6. Windows Monitor/Playback/Recorder utility The recommended method to view video is to use the supplied Windows Viewing/Recording utility. This utility also allows you to record the video streams, either interactively or using a schedule. System Tray Icon When started, the program will create an icon in the Windows system tray on the taskbar, as shown below.
  • Page 41 2. Select the desired Channel number in the left (No.) column. 3. There are 2 radio buttons, for LAN or Internet. The default is LAN. See the following section for details of the Internet option. The LAN panel, on the left, displays all Network Camera found on your LAN. This list can be updated by clicking the Refresh button.

  • Page 42: Adding Cameras On The Internet

    You can add the same Camera twice, once for the LAN (using the LAN IP address), and again for the Internet (using the Internet IP address). This will allow viewing the camera whether you are on the same LAN as the camera or in a remote location. Adding Cameras on the Internet If the Network Camera you wish to add is not on your LAN, but is available via the Internet, click the Internet button.

  • Page 43: Main Screen

    and password before being allowed to view the live video. If the Camera Administrator has not enabled this option, the Login fields can be left blank. Otherwise, you must enter the username and password allocated to you by the Camera Administrator. Stream Select the desired video stream type.

  • Page 44: Recording Video

    Play. Use this to re-start viewing, after using the Stop or Pause button. Pause. Use this to temporarily stop the connection to the camera Stop. This will terminate the connection to the camera, halting both the viewing and the recording (if in progress). Record.
  • Page 45 If necessary, change these settings to suit your environment. Local ID. This is the name you gave to this camera. This field must be entered. Interval. Decide which days you want the Camera to record. Select the appropriate Interval from the drop-down list. Start Date.

  • Page 46: Preferences

    Preferences This screen is displayed after clicking the Preferences tab on the Setup screen. If necessary, change these settings to suit your environment. Data - Preferences Recording Paths Recording This is the Drive and Folder on your PC where recorded files will be placed.

  • Page 47: Using Playback

    if the space is not enough for recording. Stop Recording. If the disk space limit is reached, no further recording is done. Initial Settings Launch this Check this to have this utility start when Windows starts. utility when Windows started Proxy Server Enable proxy If enabled, click the Proxy Settings button to configure the...
  • Page 48 Stop. This will terminate the connection to the camera, halting both the viewing and the recording (if in progress). Snapshot. Click this to take a single JPEG "snapshot" image of the current video. Zoom In. To zoom in on a section of the window, click this icon. Zoom Out.

  • Page 49: Appendix A: Network Camera - Specifications

    Appendix A: Network Camera - Specifications Model Network Camera Dimensions 90mm (W) * 35mm (H) * 90mm (D) Operating ° ° C to 40 Temperature Storage ° ° C to 40 Temperature Network Protocols: TCP/IP, DHCP, SMTP, NTP, HTTP, FTP, NTP, RTP, RTSP, UPnP (Discovery only) Network Interface: 1 Ethernet 10/100BaseT (RJ45) LAN connection...

  • Page 50: Ce Approvals

    CE Approvals The Network Camera and the Ethernet Network Camera meet the guidelines of the European Union and comply with the 99/5/EEC and RTTE 99/5EG directives, including the following standards: EN60950 EN300 328-2 EN301 489-1 EN301 489-17 This is a Class B product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.

  • Page 51: Copyright Notice

    Copyright Notice Many software components are covered by the GNU GPL (General Public License). Some are covered by other Licenses as listed in the table below. Details of each applicable license are contained in the following section. No Warranty THIS SOFTWARE IS PROVIDED BY THE AUTHOR AND CONTRIBUTORS ``AS IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.

  • Page 52: Ntp-4.1.71 License

    2. Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the following disclaimer in the documentation and/or other materials provided with the distribution. THIS SOFTWARE IS PROVIDED BY THE AUTHOR AND CONTRIBUTORS ``AS IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.

  • Page 53: Cron License

    cron license Copyright (c) 1989 The Regents of the University of California. All rights reserved. This code is derived from software contributed to Berkeley by Paul Vixie. Redistribution and use in source and binary forms are permitted provided that the above copyright notice and this paragraph are duplicated in all such forms and that any documentation, advertising materials, and other materials related to such distribution and use acknowledge that the software was developed by the University of California,...
  • Page 54 effect making the program proprietary. To prevent this, we have made it clear that any patent must be licensed for everyone's free use or not licensed at all. The precise terms and conditions for copying, distribution and modification follow. GNU GENERAL PUBLIC LICENSE Terms And Conditions For Copying, Distribution And Modification 0.
  • Page 55 3. You may copy and distribute the Program (or a work based on it, under Section 2) in object code or executable form under the terms of Sections 1 and 2 above provided that you also do one of the following: a) Accompany it with the complete corresponding machine-readable source code, which must be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange;...

  • Page 56: No Warranty

    It is not the purpose of this section to induce you to infringe any patents or other property right claims or to contest validity of any such claims; this section has the sole purpose of protecting the integrity of the free software distribution system, which is implemented by public license practices.

  • Page 57: Lesser Gnu General Public License

    Lesser GNU General Public License GNU LESSER GENERAL PUBLIC LICENSE Version 2.1, February 1999 Copyright (C) 1991, 1999 Free Software Foundation, Inc. 51 Franklin St, Fifth Floor, Boston, MA 02110-1301 USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed.
  • Page 58 Finally, software patents pose a constant threat to the existence of any free program. We wish to make sure that a company cannot effectively restrict the users of a free program by obtaining a restrictive license from a patent holder. Therefore, we insist that any patent license obtained for a version of the library must be consistent with the full freedom of use specified in this license.
  • Page 59 another language. (Hereinafter, translation is included without limitation in the term "modification".) "Source code" for a work means the preferred form of the work for making modifications to it. For a library, complete source code means all the source code for all modules it contains, plus any associated interface definition files, plus the scripts used to control compilation and installation of the library.
  • Page 60 General Public License has appeared, then you can specify that version instead if you wish.) Do not make any other change in these notices. Once this change is made in a given copy, it is irreversible for that copy, so the ordinary GNU General Public License applies to all subsequent copies and derivative works made from that copy.
  • Page 61 user who changes the contents of definitions files in the Library will not necessarily be able to recompile the application to use the modified definitions.) b) Use a suitable shared library mechanism for linking with the Library. A suitable mechanism is one that (1) uses at run time a copy of the library already present on the user's computer system, rather than copying library functions into the executable, and (2) will operate properly with a modified version of the library, if the user installs one, as long as the modified version is interface-compatible with the version that the work was made...
  • Page 62 11. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not limited to patent issues), conditions are imposed on you (whether by court order, agreement or otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this License.
  • Page 63 16. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY AND/OR REDISTRIBUTE THE LIBRARY AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE LIBRARY (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE LIBRARY TO OPERATE...

  • Page 64: Appendix B: Streaming Video/Audio Solution

    Appendix B: Streaming Video/Audio Solution Overview Streaming video is a sequence of "moving images" that are sent in compressed form over the Internet and displayed by the viewer as they arrive. With streaming, a Web user does not have to wait to download a large file before seeing the video or hearing the sound. Instead, the media is sent in a continuous stream and is played as it arrives.
