CD-DP2400E

MINI COMPONENT SYSTEM

Accessories

Battery installation of remote control

Use 2 "AA" size batteries (UM/SUM-3, R6, HP-7 or similar).

Remove the

battery cover.

Remote control × 1

Insert the batteries

as shown.

This Quick Guide will help you to correctly

install and operate your system.

If you require any advice or assistance regarding

your Sharp product, please visit our web-site

www.sharp.co.uk/support.

Customers without Internet access may telephone

08705 274277 during office hours (or (01) 676 0648

if telephoning from Ireland).

AM loop aerial × 1

FM aerial × 1

Batteries are not included.

– 1 –

Replace the cover.

TINSE0479AWZZ

02H R KS 1

0101

Page 1 This Quick Guide will help you to correctly install and operate your system. If you require any advice or assistance regarding CD-DP2400E your Sharp product, please visit our web-site www.sharp.co.uk/support. Customers without Internet access may telephone MINI COMPONENT SYSTEM 08705 274277 during office hours (or (01) 676 0648 if telephoning from Ireland).
Page 2: System Connections
System connections FM aerial AM loop aerial Surround speaker Surround speaker (Right) (Left) Centre speaker Front speaker (Left) Front speaker (Right) Wall socket (AC 230 V, 50 Hz) RCA lead (not supplied) Centre speaker Surround speaker Surround speaker (Right) (Left) To the line output sockets VCR, DVD, etc.
Page 3: Listening To The Radio
Turn on your system The first time the unit is plugged Press the Press the ON/ in, the unit will enter the demon- X-BASS/DEMO button STAND-BY button to stration mode. You will see words to cancel the demon- turn the power on. scroll.
Page 4 Listening to a cassette tape (TAPE 1 or TAPE 2) Open the cassette door by pushing the area marked “ PUSH EJECT”. Load a cassette into the TAPE 1 or TAPE 2 cassette compartment with the side to be played facing toward you.
