PRESSURIZED ABRASIVE
ASSEMBLY AnD OPERATIng InSTRUcTIOnS
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE ThIS MAnUAL.
Copyright
2006 by Harbor Freight Tools
©
contained herein may be reproduced in any shape or form without the express written consent of Harbor
Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improve-
ments, actual product may differ slightly from the product described herein. Tools required for assembly
and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Revised Manual 10d
BLASTER
Model
95014
. All rights reserved. No portion of this manual or any artwork
®
Advertisement
Table of Contents
Related Manuals for Central Pneumatic 95014
Summary of Contents for Central Pneumatic 95014
-
Page 1: Assembly And Operating Instructions
Failure to do so can result in serious injury. SAVE ThIS MAnUAL. Copyright 2006 by Harbor Freight Tools © contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improve- ments, actual product may differ slightly from the product described herein. -
Page 2: Product Specifications
When unpacking, check to make sure that all the parts and accessories listed on pages 15 and 16 are included, and the product is intact and undamaged. If any parts are miss- ing or broken, please call Harbor Freight Tools at the number shown on the cover of this manual as soon as possible. - Page 3 Check for alignment and binding of moving parts, any broken parts, and any other condition that may affect proper operation. Any part that is damaged should be properly repaired or replaced by a qualified technician. For technical questions, please call 1-800-444-3353 SKU 95014 PAGE 3...
- Page 4 Use of any other parts will void the warranty. Only use accessories intended for use with this tool. Approved accessories are available from Harbor Freight Tools. Do not operate this product if under the influence of alcohol or drugs.
- Page 5 Wear washable or disposable protective clothes at the worksite. Shower, and change into clean clothes before leaving the worksite to prevent contamination of cars, homes, and other work areas. For technical questions, please call 1-800-444-3353 SKU 95014 PAGE 5...
- Page 6 It must be understood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator. For technical questions, please call 1-800-444-3353 SKU 95014 SAVE ThESE InSTRUcTIOnS PAGE 6...
-
Page 7: Assembly Instructions
Locate the two Wheels (2), three Cotter Pins (3), Wheel Axle (5), four Wheel Washers (51), and Front Foot (4). Slide the Wheel Axle (5) through the axle holes located at the bottom of the two Handle Bars (6). (See Figure B.) SKU 95014 For technical questions, please call 1-800-444-3353 PAGE 7... - Page 8 Slide one end of the Abrasive Hose (24) onto the Hose Adapter (49C) of the Blast Gun. Then, firmly tighten the Hose Clamp (23). (See Figure c.) FIgURE c For technical questions, please call 1-800-444-3353 SKU 95014 BLAST gUn PAGE 8...
-
Page 9: Operating Instructions
Tank to do the job at hand. Then, replace the Tank Filler Cap. nOTE: If this is a large job, fill the Tank only 3/4 full and reload as needed to finish the job. (See Figure D.) SKU 95014 For technical questions, please call 1-800-444-3353 OPERATIng InSTRUcTIOnS... - Page 10 Nozzle Gasket. Then screw the Nozzle Cap Nut back onto the Adapter to secure the Nozzle Gasket and Ceramic Nozzle in place. (See Figure E.) nOZZLE cAP nUT FIgURE E SKU 95014 For technical questions, please call 1-800-444-3353 FUnnEL (29)
- Page 11 Repair the leaks. Then, turn on the air compressor and resume pressurizing the Tank. (See Figure F.) Grip the Blast Gun firmly with both hands. Open the Abrasive Control Valve (18B). (See Figure F.) For technical questions, please call 1-800-444-3353 SKU 95014 OPERATIng InSTRUcTIOnS SAFETY VALVE (10) AIR SUPPLY...
-
Page 12: Inspection, Maintenance, And Cleaning
InSPEcTIOn, MAInTEnAncE, AnD cLEAnIng WARnIng! Prior to performing any inspection, maintenance, or cleaning of the Pressurized Abrasive Blaster, turn off the air compressor. Turn the Air For technical questions, please call 1-800-444-3353 SKU 95014 PAGE 12... -
Page 13: Please Read The Following Carefully
THE BUYER. THE BUYER ASSUMES ALL RISKS AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. For technical questions, please call 1-800-444-3353 SKU 95014 PAGE 13... -
Page 14: Troubleshooting
TROUBLEShOOTIng SKU 95014 For technical questions, please call 1-800-444-3353 PAGE 14... - Page 15 Hex Nut Safety Valve O-Ring Tank Filler Cap Joint Pipe Intake Manifold Pressure Gauge Maile Connector (3/8”) SKU 95014 For technical questions, please call 1-800-444-3353 Part # Description Water Trap Air Supply Valve (3/8”) Throttling Valve (3/8”) Abrasive Control Valve (3/8”)
- Page 16 Nozzle Cap Nut Screw (ST4.2x16) nOTE: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 95014 For technical questions, please call 1-800-444-3353 Part # Screw (ST4.2x12) Control Lever Spring Pin...
-
Page 17: Limited 90-Day Warranty
LIMITED 90 DAY WARRAnTY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
