4" Jointer Planer
Set uP and oPerating inStructionS
distributed exclusively by Harbor Freight tools
Visit our website at: http://www.harborfreight.com
read this material before using this product.
Failure to do so can result in serious injury.
SaVe tHiS manual.
©
Copyright
2008 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
3491 Mission Oaks Blvd., Camarillo, CA 93011
®
. All rights reserved. No portion of this manual or any artwork
65673
®
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 65673 and is the answer not in the manual?

Questions and answers

Tom Davis Sr.
February 23, 2025

How to adjust the moveable table

0

Related Manuals for Central Machinery 65673

Summary of Contents for Central Machinery 65673

  • Page 1 Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein. Tools required for assembly and service may not be included.

  • Page 2: Important Safety Information

    SKU 65673 For technical questions, please call 1-800-444-3353. notice is used to address practices not related to personal injury. caution, without...
  • Page 3 SKU 65673 For technical questions, please call 1-800-444-3353. Safety equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropri- ate conditions will reduce personal injuries.
  • Page 4 Use of the power tool for operations differ- ent from those intended could result in a hazardous situation. SKU 65673 For technical questions, please call 1-800-444-3353. Service Have your power tool serviced by a qualified repair person using only identical replacement parts.

  • Page 5: Vibration Safety

    Harbor Freight Tools for a replacement. Avoid unintentional starting. Prepare to begin work before turning on the tool. Do not leave the tool unattended when it is plugged into an electrical outlet. Turn off the tool, and unplug it from its electrical outlet before leav- ing.
  • Page 6 To reduce vibration, maintain the tool as explained in this manual. If any abnormal vibration occurs, stop use immediately. SaVe tHeSe inStructionS. SKU 65673 For technical questions, please call 1-800-444-3353. grounding to PreVent electric SHocK and deatH From incorrect grounding...

  • Page 7: Double Insulated Tools: Tools With Two Prong Plugs

    Inc., the Canadian Standard Association, and the National Electri- cal Code. (See outlets for 2-Prong Plug.) SKU 65673 For technical questions, please call 1-800-444-3353. Double insulated tools may be used in either of the 120 volt outlets shown in the preceding illustration. (See outlets for 2-Prong Plug.)

  • Page 8: Specifications

    When unpacking, check to make sure that the item is intact and undamaged. If any parts are missing or broken, please call Harbor Freight Tools at the number shown on the cover of this manual as soon as possible. Examine the machine work surface to make certain it is clear of grease and debris.

  • Page 9: Fence Adjustment

    Jointer Planer if Stop Block does not adequately snap into place. Loosen the tension on the Stop Block if Jointer Planer will not be used for a significant time period. Please note: Fence must be removed. installing dust collection Bag Slide Dust Collection Collar (106) over Dust Collection Bag (107).

  • Page 10: Cutting Depth Adjustment

    SaFetY inFormation section at the beginning of this manual including all text under subheadings therein before set up or use of this product. SKU 65673 For technical questions, please call 1-800-444-3353. tool Set up to PreVent SeriouS inJurY From accidental...

  • Page 11: General Operating Instructions

    Continue shifting in this fashion until all of your stock has been planed. SKU 65673 For technical questions, please call 1-800-444-3353. For Bevel Planing: Set the fence to the desired angle by using the Angle Scale (81).

  • Page 12: Maintenance And Servicing

    Warning! if the supply cord of this power tool is damaged, it must SKU 65673 For technical questions, please call 1-800-444-3353. be replaced only by a qualified service technician. PleaSe read tHe FolloWing...

  • Page 13: Parts List

    Bushing Locking washer Bolt Bolt Bushing Lock Washer Bolt Lock Washer Flat Washer Main Stand Bolt Lock Washer SKU 65673 For technical questions, please call 1-800-444-3353. PartS liSt Part description Qty. Flat Washer Foot Bolt Vent Upper Cover Bolt Adjusting Knob...

  • Page 14: Assembly Diagram

    Please note: Please see next page for rest of Assembly Diagram. SKU 65673 For technical questions, please call 1-800-444-3353. Page 14...
  • Page 15 (continued) SKU 65673 For technical questions, please call 1-800-444-3353. Page 15...

  • Page 16: Limited 90-Day Warranty

    90 daY WarrantY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this prod- uct is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
