Please read these instructions before operating your set and retain them for future reference.
The images shown in this manual are for illustrative purposes only.
Please refer to Pan European Guarantee Card if you need to contact your local Panasonic dealer for assistance.
English
Operating Instructions
Plasma Television
TX-P46Z11E
Model No.
TX-P54Z11E
TQB0E0888U
Advertisement
Table of Contents
Related Manuals for Panasonic TX-P54Z11E
Summary of Contents for Panasonic TX-P54Z11E
-
Page 1: Operating Instructions
Please read these instructions before operating your set and retain them for future reference. The images shown in this manual are for illustrative purposes only. Please refer to Pan European Guarantee Card if you need to contact your local Panasonic dealer for assistance. English... - Page 2 Turn your own living room into a movie theatre! Experience an amazing level of multi- Notice for DVB functions ● Any functions related to DVB (Digital Video Broadcasting) will work in areas where DVB-T (MPEG2 and MPEG4-AVC ) digital terrestrial broadcasting are (H.264) received, where DVB-C (MPEG2 and MPEG4-AVC ) digital cable services...
-
Page 3: Table Of Contents
Contents media excitement Be Sure to Read ● Safety Precautions ············································ 4 (Warning / Caution) ● Notes ································································· 5 ● Maintenance ······················································ 6 ● Options ······························································ 6 Enjoy rich multi-media Quick Start Guide ● Accessories ························· 7 SD Card ● Basic Connection ··············... -
Page 4: Safety Precautions
To prevent damage which might result in electric make the Display Unit unstable, risking injury. Be shock or fire, do not expose the unit to rain or sure to ask your local Panasonic dealer to perform excessive moisture. The unit must not be exposed setup. -
Page 5: (Warning / Caution) Notes
Notes Caution ■ Do not display a still picture ■ for a long time When cleaning the unit, remove the mains plug ● Cleaning an energized unit may cause electrical shock. This causes the image to remain on the ■ When the unit is not going to be used for a plasma screen (“image retention”). -
Page 6: Maintenance
Wipe the mains plug with a dry cloth at regular intervals. (Moisture and dust may lead to fire or electrical shock.) Options Optional accessories Please contact your nearest Panasonic dealer to purchase the recommended wall-hanging bracket. For additional details, please refer to the wall-hanging Wall-hanging bracket bracket installation manual. -
Page 7: Quick Start Guide Accessories
Accessories ■ Standard accessories Check that you have the accessories and items shown □ Display Unit □ □ Remote Control Batteries for the ● N2QAYB000353 Remote Control (2) ● R6 (UM3) pqrs wxyz □ □ Cleaning cloth Clamper (2) p. 14 □... - Page 8 Do not use the pedestal if it becomes warped or physically damaged. ● If you use the pedestal while it is physically damaged, personal injury may result. Contact your nearest Panasonic dealer immediately. During set-up, make sure that all screws are securely tightened.
-
Page 9: Assembling The Pedestal
■ Assembling the pedestal Remove the Cable cover from the Frame ● Cable cover will be used again after the pedestal is attached to the Display Unit. Cable cover Use the assembly screws to fasten securely. ● Make sure that the screws are securely tightened. ●... - Page 10 Accessories Attaching the Speakers Speaker ● SP-46Z1E (TX-P46Z11E) ● SP-54Z1E (TX-P54Z11E) Speaker (2) Speaker installation kit ● TXFKR01JXUE Mounting bracket-[Top] (2) Mounting bracket-[Lower right] Mounting bracket-[Lower left] ● ● ● TXFKR04DLUJ TXFKR05DLUJ TXFKR06DLUJ Assembly screw Speaker cable (2) ● ●...
- Page 11 Use another two assembly screws to fasten the Speaker to the Mounting brackets E - - b Adjust the speaker position and make sure that the assembly screws are securely tightened. Connect the Speaker and the Display Unit with the Speaker Cable ●...
-
Page 12: Basic Connection
Basic Connection Connecting the Display Unit and the Tuner Box Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any leads. Tuner Box HDMI cable ● ● TU-Z100E K1HY19YY0004 ● Tuner Box K1HY19YY0006 Rear of the Display Unit HDMI cable This terminal is not used 3.0 m... - Page 13 ■ Example 2 Connecting DVD Recorder / VCR Terrestrial aerial Rear of the Tuner Box Cable AC 220-240 V 50 / 60 Hz AV 1 AUDIO AUDIO VIDEO AV 2 VIDEO Mains lead S VIDEO DIGITAL HDMI 1 HDMI 2 HDMI 3 COMPONENT AUDIO OUT...
-
Page 14: Identifying Controls
Basic Connection Using the clamper Rear of the Display Unit ● Fix cables with clampers as necessary. ● When using the optional accessory, follow the option’s assembly manual to fix cables. ■ ■ Attach the clamper Bundle the cables To remove from the TV: To loosen: hole snaps... - Page 15 Identifying Controls Remote Control VIERA IMAGE VIEWER (p. 64) Input mode selection ● Switches to SD Card viewing mode ● TV - switches DVB-S / DVB-C / DVB-T / Analogue mode (p. 18) Standby On / Off switch ● AV - switches to AV input mode from Input ●...
- Page 16 Auto Setup Search and store TV channels automatically. ● These steps are not necessary if the setup has been completed by your local dealer. ● Please complete preparations and setup of all units before starting Auto Setup. (p. 8 - 12) ●...
- Page 17 Using the On Screen Displays Many features available on this TV can be accessed via the On Screen Display menu. ■ How to use remote control Move the cursor / adjust levels / select from Move the cursor / select the menu item a range of options Access the menu / store settings after BACK/...
-
Page 18: Watching Tv
Watching TV Turn power on (Press for about 1 second) ● Mains power On / Off switch of the Display Unit should be On. (p. 14) Select the mode watch TV Selection DVB-S select INPUT DVB-C DVB-T ASPECT MENU Analogue EXIT ●... - Page 19 ■ Other useful functions Hold HOLD Freeze / unfreeze picture Display Information banner Display Information banner ● Also appears when changing a channel Category ● Channel position and name To change the category blue Channel type (if it is Radio or Data channel) Current time Example (DVB): 1 ZDF...
-
Page 20: Display / Hide Subtitles (If Available)
Watching TV ■ Other useful functions Display subtitles Display / hide subtitles (if available) STTL ● To change the language for DVB (if available) “Preferred Subtitles” (p. 34) Note ● If you press the STTL button in Analogue mode, it switches to teletext service and calls up a favourite page (p. - Page 21 ■ Other useful functions Display the selectable settings for the current programme ● To change OPTION Check or change the current programme status instantly change select Multi Video (DVB mode) Teletext Character Set Allows you to select the image (if available) Sets the teletext language Setup Menu (p.
-
Page 22: Using Tv Guide
Using TV Guide TV Guide―Electronic Programme Guide (EPG) provides an on-screen listing of the programmes currently broadcast and the forthcoming broadcasts over the next seven days (depending on the broadcasters). ● This function varies depending on the country you select (p. 16). ●... - Page 23 ■ Depending on the country you select, this TV supports the GUIDE Plus+ system in DVB-T or Analogue mode The postcode entry or update is required. Follow the message’s instructions. ● Also possible to setup manually from the Setup Menu “Update”...
-
Page 24: Viewing Teletext
Viewing Teletext Teletext services are the text information provided by the broadcasters. The features may vary depending on the broadcasters. What is FLOF (FASTEXT) mode? In FLOF mode, four differently coloured subjects are situated at the bottom of the screen. To access more information about one of these subjects, press the appropriately coloured button. - Page 25 INDEX Return to the main index page INDEX Call up a favourite page View a favourite page stored ● Call up the page stored on the blue button (List mode). STTL ● Factory setting is “P103”. View in multi window Watch TV and Teletext in two windows at once MENU (press twice)
-
Page 26: Watching External Inputs
Watching External inputs Connect the external equipment (VCRs, DVD equipment, etc.) and you can watch the input. ● To connect the equipment p. 13 and p. 76 The Remote Control is capable of operating some functions of selected external equipment. Turn the TV on ■... - Page 27 Start recording ■ How to change the code for the type of the equipment Each type of the Panasonic equipment has its own remote control code. Please change the code according to the equipment you want to operate. DVD/VCR Set the position to “DVD/VCR”...
-
Page 28: How To Use Menu Functions
How to Use Menu Functions Various menus allow you to make settings for the picture, sound, and other functions. Display the menu ● Displays the functions that can be set INPUT MENU (varies according to the input signal) ASPECT MENU DIRECT TV REC Select the menu EXIT... - Page 29 ■ Overview ● How to operate p. 28 Main Menu Picture Menu Viewing Mode Dynamic Contrast Picture Brightness Colour Sound Sharpness Tint Colour Balance Warm Setup Colour Management x.v.Colour Auto Picture Menu Advanced Settings Eco Mode W/B High R P-NR W/B High B 3D-COMB W/B Low R...
-
Page 30: Menu List
How to Use Menu Functions ■ Menu list Menu Item Adjustments / Configurations (alternatives) Basic picture mode (Dynamic / Normal / Cinema / THX / Game) ● Set for each input signal Dynamic : Provides enhanced picture contrast and sharpness when viewing in a bright room Normal : Recommended for viewing under normal ambient room lighting conditions Cinema : For watching movies in a darkened room producing a cinema-like picture : Recommended for playback of THX disc (disc with “THX”... - Page 31 Menu Item Adjustments / Configurations (alternatives) Mode Basic sound mode (Music / Speech) Bass Increases or decreases level to enhance or minimise lower, deeper sound output Treble Increases or decreases level to enhance or minimise sharper, higher sound output Balance Adjusts volume level of right and left speakers Headphone Volume Adjusts the volume of the headphones...
- Page 32 How to Use Menu Functions ■ Menu list Menu Item Adjustments / Configurations (alternatives) Off Timer Sets the time the TV automatically turns Off (Off / 15 / 30 / 45 / 60 / 75 / 90 minutes) VIERA Link Sets to use VIERA Link functions (Off / On) (p.
- Page 33 Menu Item Adjustments / Configurations (alternatives) Favourites Edit Creates list of favourite DVB-C channels (p. 41) Channel List Skips the unwanted DVB-C channels or edits DVB-C channels (p. 41) Auto Setup Automatically sets the DVB-C channels supplied (p. 38) Manual Tuning Sets the DVB-C channels manually (p.
- Page 34 How to Use Menu Functions ■ Menu list Menu Item Adjustments / Configurations (alternatives) OSD Language Changes language for on-screen displays Selects the first and second preferred language for DVB multi audio (depending on Preferred Audio 1 / 2 the broadcaster) Selects the first and second preferred language for DVB subtitles (depending on the Preferred Subtitles broadcaster)
- Page 35 Menu Item Adjustments / Configurations (alternatives) Shipping Condition Resets all settings, for example, when moving house (p. 48) System Update Downloads new software to TV (p. 49) Software Displays the software licence information Licence Java Logo Displays the Java logo System Information Displays the system information of this TV Selects optional colour system based on video signals in AV mode...
-
Page 36: Retuning From Setup Menu
Retuning from Setup Menu Auto Setup retunes all channels automatically. DVB-S channels Automatically retune all the DVB-S channels received in the area. ● This function is available if DVB-S channel tuning is already performed. ● Only DVB-S channels are retuned. ●... - Page 37 DVB-S Tuning Menu Favourites Edit Channel List Auto Setup Manual Tuning Update Channel List Signal Condition Antenna System DiSEqC1.0 LNB Configuration Access Select “Antenna System” and set You can receive several satellites if you have DiSEqC control antenna system. ● This TV supports DiSEqC Version 1.0.
- Page 38 Retuning from Setup Menu DVB-C channels Automatically retune all the DVB-C channels supplied. ● This function is available if DVB-C channel tuning is already performed. ● Only DVB-C channels are retuned. ● All the previous tuning settings are erased. ● If a Child Lock PIN number (p.
- Page 39 DVB-T or Analogue channels Automatically retune all DVB-T or Analogue channels received in the area. ● DVB-T Auto Setup is available if DVB-T channel tuning is already performed. ● Only DVB-T channels are retuned in DVB-T mode. ● Only Analogue channels are retuned in Analogue mode. ●...
-
Page 40: Tuning And Editing Channels (Dvb)
Tuning and Editing Channels (DVB) You can retune channels or make your favourite channel lists, skip unwanted channels, etc. Select DVB-S, DVB-C or DVB-T p. 18 INPUT Display the menu MENU MENU EXIT Select “Setup” access Main Menu BACK/ RETURN Picture Sound select... -
Page 41: Favourites Edit
List favourite DVB channels Favourites Edit Create your favourite channel lists from various broadcasters (up to 4: Favourites1 to 4). The DVB Favourites lists are available from “Category” in the Information banner (p. 19) and the TV Guide (p. 22). Select a channel to list ●... -
Page 42: Tuning And Editing Channels
Tuning and Editing Channels (DVB) Set DVB channel manually Manual Tuning Normally use “Auto Setup” or “Update Channel List” to retune DVB channels. If tuning has not been done completely or for adjusting the direction of the aerial or dish, use this function. ●... -
Page 43: New Channel Message
Display a notification message New Channel Message Selects whether to give a notification message when a new DVB channel is found. (Off / On) ● Selecting OK will perform “Update Channel List”. New channels found! ● Press OK to update channel list This function is not available in DVB-S mode. -
Page 44: Tuning And Editing Channels (Analogue)
Tuning and Editing Channels (Analogue) You can retune channels or skip unwanted channels, edit channels etc. Select Analogue p. 18 INPUT Display the menu MENU MENU EXIT Select “Setup” access BACK/ Main Menu RETURN Picture Sound select Setup Select “Analogue Tuning Menu” access Setup Menu Off Timer... -
Page 45: Channel List
Skip unwanted Analogue channels, Edit Analogue channels Channel List You can hide unwanted Analogue channels. The hidden channels cannot be displayed except in this function. Use this function to skip unwanted channels. Select a channel and reveal / hide reveal / hide Analogue Channel List ●... -
Page 46: Child Lock
Child Lock You can lock specific channels / AV input terminals and control who watches them. When the locked channel / input is selected, a message appears; by entering the PIN number, you can watch it. Display the menu MENU MENU EXIT Select “Setup”... -
Page 47: Using Common Interface
Although CI module may enable you to view some services, this TV does not guarantee all services (e.g. pay-TV). Please use only the approved CI module by the broadcaster. Consult your local Panasonic dealer or broadcasters for more information and conditions of the services. CI slot Caution ●... -
Page 48: Shipping Condition
Shipping Condition Resets the TV to its original condition, i.e. no channels tuned in. All settings are reset (channels, picture, sound settings, etc.). Display the menu MENU MENU EXIT Select “Setup” access Main Menu Picture Sound select Setup Select “System Menu” access Setup Menu Off Timer... -
Page 49: Updating The Tv Software
Updating the TV Software From time to time, a new version of software may become available for download to enhance the performance or operations of the TV. If there is an update available, a notification banner is displayed when the channel has the update information. -
Page 50: Input Labels
Input Labels For easier identification and selection of the input mode, you can label each input mode or skip terminal that is not connected to any equipment. ● To select the input mode p. 26 Display the menu MENU MENU Select “Setup”... -
Page 51: Multi Window
Multi Window Enjoy viewing two images at once (multi window), such as a TV programme and a DVD. Display the menu MENU MENU Select “Picture” access Main Menu Picture Sound select Setup Select “Multi Window” access Picture Menu P-NR 3D-COMB Multi Window Access select... -
Page 52: Using Mhp Services
Using MHP Services MHP (Multimedia Home Platform) is a standard of interactive services for digital broadcasting. MHP is Java-based application, provided by broadcasters and you can load MHP services on the TV (news, information, entertaining, etc.). ● The availability of this function depends on the country you select (p. 16). ●... - Page 53 Loading MHP application manually You can load a specific MHP application directly. Display the Option menu OPTION Select “MHP App” Example: access Option menu Multi Video Video Multi Audio select Sub Channel No sub channel Subtitle Language No subtitles Teletext Character Set West Teletext Language Volume Correction...
-
Page 54: Displaying Pc Screen On Tv
Displaying PC Screen on TV The screen of the PC connected to the TV can be displayed on the TV. You can also listen to PC sound with the audio cable connected. ● To connect PC p. 76 Select the external input INPUT ASPECT MENU... -
Page 55: How To Use Viera Tools
How to Use VIERA TOOLS You can access some special features easily by using the VIERA TOOLS function. Display icons of the feature EXIT Select a feature select access VIERA Link Control Follow the operations of each feature ● VIERA Link Control “VIERA Link Control”... -
Page 56: Using Network Services
60 - 62 VIERA CAST™ VIERA CAST is a gateway to the internet services unique to Panasonic. By connecting the TV to the internet environment, VIERA CAST allows you to enjoy internet content on the TV screen such as photos, movies, weather, etc. from VIERA CAST home screen. - Page 57 Network connections ● If you do not have a Broadband network services, please consult your retailer for assistance. ● Confirm the terms and conditions of the contracts with your Internet Service Provider (ISP) or telecommunications company. ● Set up and connect any equipment required for the network environment. ●...
- Page 58 Using Network Services (DLNA / VIERA CAST) Network Setup ● Ensure the connections are completed before starting Network Setup. “Network connections” (p. 57) Display the menu MENU MENU EXIT Select “Setup” access Main Menu Picture Sound select Setup BACK/ RETURN Select “Link Settings”...
- Page 59 Network Settings Set the network setting items If you make the network connection like “Example 2” (p. 57), you do ■ Acquire IP Address not have to set “Acquire DNS Address”, “Proxy” and “Proxy Port”. ■ Acquire DNS Address Sets IP Address, Subnet Mask, Gateway, Primary DNS and Secondary DNS. For most users, the recommended method of connection to your network is by using Auto feature.
- Page 60 Using Network Services (DLNA / VIERA CAST) Using DLNA features ® ● Ensure the preparation of media server, network connections and network settings are completed. “Media server” (p. 56), “Network connections” (p. 57), “Network Setup” (p. 58 and p. 59) Display the Input select menu INPUT Select “Media Server”...
-
Page 61: Audio Output Settings
Slideshow (for photo contents) ■ Start Slideshow (operate in step Select the photo for the first view Start Slideshow ● To pause ● To return to Single view green Note ● Slideshow is done for all available photo contents. ■ Slideshow settings (operate in step Display the... - Page 62 Using Network Services (DLNA / VIERA CAST) DivX® VOD ABOUT DIVX VIDEO-ON-DEMAND: This DivX® Certified device must be registered in order to play DivX Video-on-Demand (VOD) content. First generate the DivX VOD registration code for your device and submit it during the registration process. [Important: DivX VOD content is protected by a DivX DRM (Digital Rights Management) system that restricts playback to registered DivX Certified devices.
- Page 63 ● The services through VIERA CAST™ are operated by their respective service providers, and service may be discontinued either temporarily or permanently without notice. Therefore, Panasonic will make no warranty for the content or the continuity of the services. ●...
-
Page 64: Viewing From Sd Card
Viewing from SD Card (VIERA IMAGE VIEWER) Photo View : Still images recorded by digital cameras will be displayed. Movie View : Moving pictures recorded by digital video cameras will be played back. ● During the operation, sound signal is output from AV1, AV2, AUDIO OUT and DIGITAL AUDIO OUT terminals. But no video signals are output. -
Page 65: Slideshow Settings
Slideshow ■ Start Slideshow (operate in step Select the photo for the first view Start Slideshow ● To pause ● To return to Single view green Note ● Slideshow is done within the thumbnail. ● You can also start slideshow directly by using VIERA TOOLS “How to Use VIERA TOOLS”... - Page 66 Viewing from SD Card (VIERA IMAGE VIEWER) Movie View Insert the SD Card access Select “Movie View” SD Card Photo View select INPUT Movie View ● You can also access directly by using ASPECT MENU DIRECT TV REC VIERA TOOLS “How to Use VIERA TOOLS”...
- Page 67 Audio Settings You can enjoy the multi-channel sound via an amplifier connected to DIGITAL AUDIO OUT terminal. ■ To confirm or change the current sound status (during playback) Display the Option menu Change the sound (if the movie has multiple audio signals) Option Menu OPTION ●...
-
Page 68: (Viera Image Viewer) Link Functions
Connect the equipment supporting VIERA Link to the TV’s HDMI1, HDMI2, HDMI3 or HDMI4 terminal via an HDMI cable. ● About HDMI cable for connecting Panasonic HD Video Camera or LUMIX Camera, read the manual of the equipment. ■ VIERA Link (HDMI and SCART connections) - Page 69 ■ VIERA Link (HDMI and Audio out connections) Connected equipment Player theatre with Blu-ray Disc theatre with Amplifier with VIERA Link function VIERA Link function VIERA Link function Features Preset download – – – ∗ ∗ Easy playback – Power on link –...
- Page 70 Link Functions Q-Link VIERA Link Q-Link ■ Preparations ● Connect the DVD Recorder / VCR with the following logos: “Q-Link”, “NEXTVIEWLINK”, “DATA LOGIC”, “Easy Link”, “Megalogic” or “SMARTLINK” ● Q-Link connection p. 68 ● Use fully wired SCART cable. ● Set up the DVD Recorder / VCR.
- Page 71 VIERA Link “ Control™” ∗ ∗Enjoy additional HDMI Inter-Operability with Panasonic products which have “HDAVI Control” function. This TV supports “HDAVI Control 4” function. Connections to the equipment (DIGA Recorder, HD Video Camera, Player theatre, Amplifier, etc.) with HDMI and SCART cables allow you to interface them automatically (p. 68 and p. 69).
-
Page 72: Standby Power Save
Link Functions Q-Link VIERA Link ■ Features available Reduce unnecessary power consumption in standby Standby Power Save Set Standby Power Save “On” in the Setup Menu to use this function “Standby Power Save” (p. 32) The power consumption in Standby mode of the connected equipment is controlled higher or lower in synchronization with the TV On / Off state to reduce the consumption. -
Page 73: Pause Live Tv
■ Features available (Using VIERA Link Menu) Pause Live TV programme Pause Live TV You can pause the live TV programme and resume later. Live TV programme will be recorded on HDD of the connected DIGA Recorder. ● This function is available with DIGA Recorder which has HDD. ●... -
Page 74: Viera Link Control
Link Functions Q-Link VIERA Link ■ Features available (Using VIERA Link Menu) Control the menu of the connected equipment by VIERA remote control VIERA Link Control You can control some functions of the connected equipment with this TV remote control (point the remote control at the TV’s signal receiver). -
Page 75: Speaker Selection
■ Features available (Using VIERA Link Menu) Speaker control Speaker Selection You can control the theatre speaker with this TV remote control (point the remote control at the TV’s signal receiver). ● If you cannot operate, check the settings and the equipment “Summary of Q-Link and VIERA Link features”... -
Page 76: (Q-Link / Viera Link) External Equipment
External Equipment These diagrams show our recommendations for connection of your TV to various pieces of equipment. For other connections, consult the instructions for each piece of equipment, the table below, and the specifications (p. 90 and p. 91). Front of the Tuner Box Camcorder / Game equipment (AUDIO) - Page 77 Network Hub or Router Internet Rear of the Tuner Box HDMI equipment Less than 10 cm “HDMI connection” (p. 83) LAN cable Modem Ferrite core (supplied) DVD Recorder Installing the Ferrite core To watch DVDs Open Fully wired HDMI Less compliant than player...
-
Page 78: Technical Information
Technical Information Auto Aspect The optimum size and aspect can be chosen automatically, and you can enjoy finer images. (p. 20) ■ Aspect Control Signal “WIDE” will appear in the top left of the screen if a Widescreen signal (WSS) or a Control signal through SCART / HDMI terminal is found. - Page 79 Network ■ On screen messages Message Meaning / Action ● An internal error occured. Check the settings. (p. 58 and p. 59) ● The file is broken or unreadable. Cannot read file Check applicable data format. (p. 56) ● This might be a problem of the media server. Communication with the server failed.
- Page 80 Technical Information DivX ABOUT DIVX VIDEO: DivX ® is a digital video format created by DivX, Inc. This is an official DivX Certified device that plays DivX video. ■ DivX video file Extension - “.divx” or “.avi” Image resolution - Up to 720 × 576 pixels ●...
- Page 81 ● Back up the recorded data at regular intervals in case of deteriorated or damaged data or erratic operation of the TV. (Panasonic is not liable for any deterioration or damage of recorded data.) ■ Data format for Card browsing ●...
- Page 82 Technical Information Characters table for numeric buttons You can enter characters by using numeric buttons for free input items. User input Press the numeric button repeatedly until you reach the desired character. Name ● A B C D E F G H J K L M N O P Q R S T The character is set automatically if you leave for one second.
- Page 83 HDMI connection HDMI (high-definition multimedia interface) is the world’s first complete digital consumer AV interface complying with a non-compression standard. HDMI allows you to enjoy high-definition digital images and high-quality sound by connecting the TV and the equipment. HDMI-compatible equipment (∗1) with an HDMI or DVI output terminal, such as a DVD player, a set top box or a game equipment, can be connected to the HDMI terminal using an HDMI compliant (fully wired) cable.
- Page 84 Technical Information Input signal that can be displayed COMPONENT (Y, P ), HDMI ∗ Mark: Applicable input signal Signal name COMPONENT HDMI ∗ ∗ 525 (480) / 60i ∗ ∗ 525 (480) / 60p ∗ ∗ 625 (576) / 50i ∗...
-
Page 85: Faqs
FAQs Before requesting service or assistance, please follow these simple guides to resolve the problem. If the problem still persists, please contact your local Panasonic dealer for assistance. White spots or shadow images (noise) ● Check the position, direction, and connection of the aerial. - Page 86 FAQs Problem Actions ● Set “P-NR” in the Picture Menu (to remove noise). (p. 30) ● Chaotic image, noisy Check nearby electrical products (car, motorcycle, fluorescent lamp). ● Is “Colour” or “Contrast” in the Picture Menu set to the minimum? No image can be displayed (p.
- Page 87 Problem Actions ● Due to the digital reception technologies involved, quality of the digital signals may be relatively low in some cases, despite good reception of analogue channels. ● Check “Signal Condition” (p. 43). If “Signal Quality” or “Signal Strength” are displayed in red, the signal is weak.
- Page 88 FAQs Problem Actions ● Check the LAN cable is connected properly. (p. 57) ● Check the connections and settings. (p. 57 - 59) ● Cannot connect to the network Check the network equipment and network environment. If the problem persists, consult your Internet Service Provider or telecommunications company.
-
Page 89: Licence
HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. ● HDAVI Control™ is a trademark of Panasonic Corporation. ● “AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation. ● x.v.Colour™ is a trademark. ● Manufactured under license from Dolby Laboratories. -
Page 90: Specifications
Specifications ■ Tuner Box Power Source AC 220-240 V, 50 / 60 Hz Power Consumption 53 W Power Consumption in 0.5 W (Without monitor out recording) Standby mode 37 W (With monitor out recording) VGA, SVGA, WVGA, XGA SXGA, WXGA ······ (compressed) PC signals Horizontal scanning frequency 31 - 69 kHz Vertical scanning frequency 59 - 86 Hz... -
Page 91: Display Unit
■ Display Unit With Speakers TX-P46Z11E TX-P54Z11E and Pedestal Power Source AC 220-240 V, 50 / 60 Hz Power Consumption 315 W 420 W Power Consumption in 0.3 W 0.5 W Standby mode Aspect Ratio 16:9 117 cm (diagonal) 137 cm (diagonal) Visible screen size 1,019 mm (W) ×... - Page 92 Warranty Service purposes. Model Number Serial Number Web Site : http://www.panasonic.net © Panasonic Corporation 2009 Printed in Czech Republic...
